Assembly instruction
art.nr.mont-sidoskydd-carbon-eng-
Rev.2012-02
Sideguard Carbon
Carbon with large cover Carbon with small cover
The sideguard Carbon is made of carbon bre and are designed to be used on wheelchair Panthera X and U2 light.
The sideguards prevents clothes or similar to get into the wheels and protect the clothes from dirt. The Carbon side-
guard comes in two versions, one with small cover and one with large cover. The sidegurads with large cover covers
more of the tyre, as shown in the picture.
To mount the sideguards on the wheelchair there are a number of different attachments, to make it t properly. What de-
termines which attachment to use is the model of the wheelchair. the size of the rearwheels and on U2 light, the height
of the backrest.
Wheelchair model Rearwheel size Sideguard Attach. front Attach. rear Plate
X24" Carbon large Fig.1 Fig 2 Fig 8
X24" Carbon small Fig 1 Fig 2 Fig 8
X25" Carbon large Fig 1 Fig 3 Fig 10
X25" Carbon small Fig 1 Fig 3 Fig 10
X26" Carbon large Fig 1 Fig 3 Fig 10
X26" Carbon small Fig 1 Fig 3 Fig 10
U2 light 24" Carbon large Fig 4 Fig 5 Fig 9
U2 light 24" Carbon small Fig 4 Fig 5 Fig 9
U2 light backrest 30, 35, 40 25" Carbon large Fig 4 Fig 6 Fig 10
U2 light backrest 25 25" Carbon large Fig 4 Fig 7 Fig 10
U2 light backrest 30, 35, 40 25" Carbon small Fig 4 Fig 6 Fig 10
U2 light backrest 25 25" Carbon small Fig 4 Fig 7 Fig 10
U2 light backrest 30, 35, 40 26" Carbon large Fig 4 Fig 6 Fig 10
U2 light backrest 25 26" Carbon large Fig 4 Fig 7 Fig 10
U2 light backrest 30, 35, 40 26" Carbon small Fig 4 Fig 7 Fig 10
U2 light backrest 25 26" Carbon small Fig 4 Fig 7 Fig 10
Fig.1
Attach. X front
Fig. 2
Attach X rear
Fig. 3
Attach X 25-26” rear
Fig. 4
Attach U2 light front
Fig. 5
Attach U2 light rear
Fig, 6
Attach U2 light 25”-26” rear
Backrest 30, 35, 40 cm
Fig. 8
Plate X
Fig. 9
Plate U2 light
Fig. 10
Plate 25”-26” Fig. 11
At different backrest positions the mounting plate can be adjusted into alternative
positions on the sideguard.
Fig. 7
Attach U2 light 25”-26” rear
Backrest 25 cm

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, [phone], www.panthera.se
Mounting on Panthera X
Rearwheel 24”
Fig. 13 Rear attachment, right Fig. 14 Front attachment, right
The rear attachment is mounted around the backrest tube. Loosen screw (8) and clamp the bracket (10) around the
tube and reassemble the parts as in g. 13. The front attachment is mounted with on the chassis tube with two screws
(3) in the predrilled holes. Use plate X (Fig 8) to the sideguard for rearwheel 24” on Panthera X. Adjust the plate to the
right position regarding the depth of the backrest position. See g 11.
Fig. 12
Fig. 15
Fig. 17 Rear attachment 25”,
right
Fig. 18 Rear attachment 26”,
right
Mounted as for 24” rearwheels, except for the raising kit for 25” and 26” rearwheels on the rear attachment. Note the
difference in position of the screw and pin for 25 or 26” rearwheels, see g 17-18. Use plate 25”-26”, g 10, for the
front attachment on the sideguard. Adjust the plate to the right position regarding the depth of the backrest position.
See g 11.
Fig. 16 Rear attachment, right
Mounting on Panthera X
Rearwheel 25”and 26”
Mounting on U2 light
Rearwheel 24”
Fig. 20 Rear attachment, right Fig. 21 Front attachment, right
The rear attachment is screwed on to the threaded hole on the backrest. The rear attachment is mounted on the chassis
tube in the pre drilled holes. Use plate U2 light, g 9, for the front attachment on the sideguard. Adjust the plate to the
right position regarding the depth of the backrest position. See g 11.
Fig. 19

Panthera AB, Gunnebogatan 26, SE-163 53 Spånga, Sweden, [phone], www.panthera.se
Mounting on U2 light
Rearwheel 25”and 26” for backrest height 30, 35 and 40 cm
At 25” and 26” rearwheels a raising kit is used on the rear attachment. Fot backrest height 25 cm, see below. The lower
attachment is screwded in the threaded hole on the backrest and the upper is clamped around the backrest tube. Adjust
the position of the ”wheel” for either 25 or 26” rearwheel. see g 19 and 20. The front attachment is the same as for 24”
rearwheels. Use plate 25”- 26”, g 10, for the front attachment on the sideguard. Adjust the plate to the right position
regarding the depth of the backrest position. See g 11.
Fig. 17 Rear attachment, right Fig. 18 Rear attachment, right Fig. 19 For 25” rearwheel Fig. 20 For 26” rearwheel
Mounting on U2 light
Rearwheel 25”and 26” for backrest height 25 cm
At 25” and 26” rearwheels and backrest height 25 cm a raising kit is used on the rear attachment. The lower attachment
is screwded in the threaded hole on the backrest and the upper is clamped around the backrest tube. Adjust the position
of the ”wheel” for either 25 or 26” rearwheel. see g 23 and 24. The front attachment is the same as for 24” rearwheels.
Use plate 25”- 26”, g 10, for the front attachment on the sideguard. Adjust the plate to the right position regarding the
depth of the backrest position. See g 11.
Fig. 21 Rear attachment, right Fig. 22 Rear attachment, right Fig. 23 For 25” rearwheel Fig. 24 For 26” rearwheel
art.no. Decsription
4420730 Sideguard carbon small cover U2L 24” wheel Cpl pair
4420733 Sideguard carbon small cover U2L 25-26” wheel Cpl pair for backrest 30-35
4420736 Sideguard carbon small cover U2L 25-26” wheel Cpl pair for backrest 25
4420740 Sideguard carbon small cover X 24” wheel Cpl pair
4420743 Sideguard carbon small cover X 25-26” wheel Cpl pair
4420630 Sideguard carbon large cover U2L 24” wheel. Cpl .pair
4420633 Sideguard carbon large cover U2L 25-26” wheel Cpl pair for backrest 30-35
4420636 Sideguard carbon large cover U2L 25-26” wheel Cpl pair for backrest 25
4420640 Sideguard carbon large cover X 24” wheel Cpl pair
4420643 Sideguard carbon large cover X 25-26” wheel - Cpl pair
Article numbers for complete sideguards in pair
