ParaBody 435103 User manual

I
Serious Steel
435103 LEG PRESS ADAPTER. KIT
I
ASSEMBLY INSTRUCTIONS
Part # 6747801 1 Revision: 09/25/97

]IMPORTANT NOTES]
WELCOME TO THE WORLD OF $~eiOU$ $~l~i!t
Please note:
* Thankyou for purchasing the 435103Leg Press Adapter Kit. Please read these
instructions thoroughly and keep them for future reference. This product must be assembled
ona flat, level surface to assure its properfunction.
* Werecommendcleaning your product (pads and frame) on a regular basis, using warmsoapy
water. Touch-uppaint can be purchased from your Parabody customer service representative
at [phone].
There is a risk assumedby individuals whouse this type of equipment. Tominimizerisk, please
follow these roles:
1. Inspect equipmentdaily. Tighten all loose connections and replace wornparts immediately.
Failure to do so mayresult in serious injury.
2. Donot allow minors or children to play on or around this equipment.
3. Exercise with care to avoid injury.
4. If unsure of proper use of equipment,call your local Parabodydistributor or call the
Parabody customer service department at [phone].
I Tools Required for Assemblyi
* Rubber mallet or hammer
* 3/4" wrench
*9/16" wrench
* Ratchet with 3/4" and 9/16" sockets
* 7/32" Allen wrench
* Adjustable wrench
* Tape measure
Bolt Length Ruler I "
NOTE: BOLT LENGTH IS MEASUREDFROMTHE UNDERSIDE OF Tl=l-E H~EAD OF THE BOLT.
BOLT LENGTH RULER:
[ 112 [
0I1
BOLT LENGTH
1/2 ~1/2 I1/2 I1/2 I 1/2 6
4I ’ ’
2

KEY
1
2
3
4
5
6
7
8
PART# DESCRIPTION
6747603 FRONT LEG
3116202 3-1/2" PULLEY
3108102 QUICK DISCONNECTLINK
6427101 KEYHOLECLEVIS
3117305 CLEVIS PIN
3112901 COTTERPIN
6732901 TENSION CORD
6747901 LEGPRESS CABLE
PARTSLIST
QTY KEY PART#
19 6535301
2 10 3102501
1 11 3102802
112 3102502
1 13 3102801
114 3102933
1 15 3102910
1
DESCRIP’.rlON QTY
1/4" CAPNUT 1
3/8" W, HER 4
3/8" LOCKNUT 2.
1/2" W, HER 4
1/2" LOCKNUT 4
3/8X2 BOLT 2
1/2X3 BOLT 4
NOTE:The LEGPRESSATTAClqTMENT(832101) must be assembled before connecthlg it to the
PARABODY425103 t~OME GYM
3/8" X1"
HEAD CAP SCREW
3/8" X 1" BUTTON
HEAD CAP SCREW
FIGURE1
STEP1
¯REMOVEthe four 3/8" X 1" BUTTONHEADCAPSCREWSfrom the rear SHROUD.Removethe SHROUDfrom the 425103
HOMEGYM.See FIGURE1. 3

FIGURE 2
STEP2
¯If the 445103 SECONDSTACKOPTIONis not installed, the rear SHROUDopening must be removed. AI?ply pressure to the
bottomof the SHROUDwhere the "V" groove is and carefuly removethe weight stack opening on the SHROUDas shownin
FIGURE3.
1/2 [ 1/2 [ 1/2 I 1/2 [ 1/2 6

3/8 X 2"~
BASE
FIGURE3
¯ SECURELYattach one 3-1/2" PULLEY(2) to the FRONT
LEG (1) using one 3/8 X 2" BOLT(14), two 3/8" WASH-
ERS (10), and one 3/8" LOCKNUT(11). See FIGURE
¯Attach the open end of PRESSLINKCABLE(8) to the
QUICKDISCONNECTLINK(3). See FIGURE
¯SECURELYtighten the QUICKDISCONNECT(3)
the tab on the FRONTLEG(1) as shwonin FIGURE
’,TEP3
¯SECURELYattach one 3-1/2" PULLEY(2) to the BASEusing one 3/8 X 2" BOLT(14), two 3/8" WASHERS(10), and one
LOCKNUT(11). See FIGURE
"
TIGHTEN!
FIGURE4

1/2 X 3"(~
~LEG PRESS
FIGURE 5
STEP5
¯ SECURELYattach the LEGPRESSto the FRONTLEG(1) using two 1/2" X 3" BOLTS(15), two 1/2" WASHERS(12), and
1/2" LOCKNUTS(13). See FIGURE
¯Route LEGPRESSCABLE(8) around the3-1/2" PULLEYon the LEGPRESSand UNDERthe 3-1/2" PULLEYon the FRONT
LEG(1) as shownin FIGURE
1/2 [ 1/2 [ 1/2 [ 1/2 [ 1/2 ] 1/2 ]
4 5 6
1~ I I[ I I 6

BASE
FIGURE 6
STEP6
¯ SECURELYattachthe FRONTLEG(1) to 425 BASEusingtwo 1/2 X3" BOLTS(15), two 1/2" WASHERS(12) and two 1/2"
NUTS(13). See FIGURE
¯ Route LEGPRESSCABLE(8) under the 3-1/2" PULLEYon the 425 BASEas shown in FIGURE
7

FIGURE DETAIL7
\\
I
/
/
LEG
CABLE
LEG
PRESS
CABLE
CABLE
CABLE
STEP7
¯Runthe LEGPRESSCABLE(8) through the correct hole on the d-ring and attach one KEYHOLECLEVIS(4) to the end of
LEGPRESSCABLE(8). See FIGURE7 & DETAIL
1/2 ]1/2 [ 1/2 I [ 1/2 I :1/2 [
34 5 6
8

LEG
CABLE LEG
CABLE ~
CABLE
FIGURE 8 CABLE
STEP8
¯Attach one TENSIONCORD(7) to the KEYHOLECLEVIS(4) using one CLEVISPIN (5) and one COTTERPIN (6) as
FIGURE8.
9

FIGURE 9
BOOM
LEG PRESS
CABLE
STEP 9
¯CAREFULLYattach the TENSIONCORD(7) to the corresponding small shaft on the TOPBOOMusing one 1/4" CAPNUT(9)
as shownin FIGURE9.
[ 1/2 ] 1/2 [ 1/2 I1/2 [ 1/2 [ 1,’2
5
2 I , , , I , , ,
10

3/8" X 1" BUTTON~"~
HEAD CAP SCREW
SPRING PIN ADJUSTMENT
3/8",X 1" BUTTON
HEAl3 CAP SCREW
FIGURE 10
STEP 10
¯ SECURELYattach the four previously removed 3/8 X 1" BUTTONHEADCAPSCREWSto the rear S[]?,OUD. See FIGURE
10.
¯The832 LEGPRESSis equippedwith a spring pin adjustment to accommodatedifferent sized users and allow easy entry andexit
fromthe machine.Touse, youmustslightly pushagainst the foot plates to take tension off the pin.
Thankyou for purchasingthe Parabody435103LegPress AdapterKit. If unsureof properuse of equipment,
call yourlocal Parabodydistributor or call the Parabodycustomerservice departmentat [phone].
