ParaBody 911101 User manual

SeriousSteel
911101
SPOTTER STAND ATTACHMENT
ASSEMBLY INSTRUCTIONS
ParaBody, Incorporated
14150 Sunfish Lake Boulevard
Ramsey, MN55303
1-800-328-9714
Part # 6639501 1Revision: 06/10196

911101 SPOTTER STAND ATTACHMENT ASSEMBLY PARTS ]LIST
SORT ANDCOUNTALL PARTS BEFORE BEGINNING ASSEMBLY
HARDWARE:
ITEM NAME/DESCRIPTION QTY
1/2X3-1/4INBOLT.......................................................................................................... 2
3X2INENDCAP............................................................................................................. 2
WELDMENTS/PARTS:
ITEM NAME/DESCRIPTION QTY
NOTE: BOLTLENGTHIS MEASUREDFROM~ UNDERSIDEOF THE I:I~AD OF ’rE[:E BOLT.
BOLT LENGTH
BOLTLENGTHRULER:’,
45 6
0 1 2 [ I I I
Part# 6639501 2Revision:06,/10/96

911101 SPOTTER STAND ATTACHMENTASSEMBLYINSTRLICTIONS
Loosen and remove hardware that attaches the BENCHFRAMEWELDMENTto the LOWER
CROSS SUPI[’ORT of the UPRIGHT FRAMEWELDMENT.
Insert two (2) 3 X 2 IN ENDCAPSinto the ends of the SPOTTERSTANDATTACHMENTas shown
on drawing.
SECURELYassemble the SPOTTER STANDATTACHMENTto the LOWERCROSS SUPPORT
of the UPRIGHTFRAMEWELDMENTusing the two 1/2 X 3-1/4 IN REPLACEMENTBOLTS, and
the two (2) existing 1/2 IN LOCKNUTSas shown on drawing. (THE1/2 IN WASHEI~;ARE
NEEDED FOR THIS ASSEMBLY)
Part # 6639501 3Revision: 06/10/96
