Paradyne 9161 Single T1 User manual

AREA CODE CHANGE
Please note that the area code for
Paradyne Corporation in Largo, Florida
has changed from 813 to 727.
For any Paradyne telephone number that
appears in this manual with an 813 area
code, dial 727 instead.

MODEL 916x
T1 CSU/DSU ACCESS UNIT
AND T1 ACCESS MUX
USER’S GUIDE
Document No. 9161-A2-GB20-00
November 1996

Printed on recycled paper
A 9161-A2-GB20-00
November 1996
Copyright 1996 Paradyne Corporation.
All rights reserved.
Printed in U.S.A.
Notice
This publication is protected by federal copyright law. No part of this publication may be copied or distributed,
transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form
or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the
express written permission of Paradyne Corporation, 8545 126th Avenue North, P.O. Box 2826, Largo,
Florida 33779-2826.
Paradyne Corporation makes no representation or warranties with respect to the contents hereof and specifically
disclaims any implied warranties of merchantability or fitness for a particular purpose. Further, Paradyne Corporation
reserves the right to revise this publication and to make changes from time to time in the contents hereof without
obligation of Paradyne Corporation to notify any person of such revision or changes.
Changes and enhancements to the product and to the information herein will be documented and issued as a new
release to this manual.
Warranty, Sales, and Service Information
Contact your sales or service representative directly for any help needed. For additional information concerning
warranty, sales, service, repair, installation, documentation, or training, use one of the following methods:
Via the Internet: Visit the Paradyne World Wide Web site at http://www.paradyne.com
Via Telephone:
Call our automated call system to receive current information via fax or to speak with a
company representative.
— Within the U.S.A., call 1-800-870-2221
— International, call 813-530-2340
Trademarks
All products and services mentioned herein are the trademarks, service marks, registered trademarks or registered
service marks of their respective owners.

Important Regulatory Information
B
9161-A2-GB20-00 November 1996
EMI Warnings
!WARNING:
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
The authority to operate this equipment is conditioned by the requirements that no modifications will be
made to the equipment unless the changes or modifications are expressly approved by Paradyne
Corporation.
!WARNING:
To Users of Digital Apparatus in Canada:
This Class A digital apparatus meets all requirements of the Canadian interference-causing equipment
regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du règlement sur le matériel
brouilleur du Canada.

Important Regulatory Information
C 9161-A2-GB20-00
November 1996
Important Safety Instructions
1. Read and follow all warning notices and instructions marked on the product or included in the manual.
2. This product is intended to be used with a 3-wire grounding type plug – a plug which has a grounding pin. This is
a safety feature. Equipment grounding is vital to ensure safe operation. Do not defeat the purpose of the
grounding type plug by modifying the plug or using an adapter.
Prior to installation, use an outlet tester or a voltmeter to check the ac receptacle for the presence of earth
ground. If the receptacle is not properly grounded, the installation must not continue until a qualified electrician
has corrected the problem.
If a 3-wire grounding type power source is not available, consult a qualified electrician to determine another
method of grounding the equipment.
3. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to
protect it from overheating, these slots and openings must not be blocked or covered.
4. Do not allow anything to rest on the power cord and do not locate the product where persons will walk on the
power cord.
5. Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous
high voltage points or other risks. Refer all servicing to qualified service personnel.
6. General purpose cables are provided with this product. Special cables, which may be required by the regulatory
inspection authority for the installation site, are the responsibility of the customer.
7. When installed in the final configuration, the product must comply with the applicable Safety Standards and
regulatory requirements of the country in which it is installed. If necessary, consult with the appropriate regulatory
agencies and inspection authorities to ensure compliance.
8. A rare phenomenon can create a voltage potential between the earth grounds of two or more buildings. If
products installed in separate buildings are interconnected, the voltage potential may cause a hazardous
condition. Consult a qualified electrical consultant to determine whether or not this phenomenon exists and, if
necessary, implement corrective action prior to interconnecting the products.
9. In addition, if the equipment is to be used with telecommunications circuits, take the following precautions:
—Never install telephone wiring during a lightning storm.
—Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
—Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the
network interface.
—Use caution when installing or modifying telephone lines.
—Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of
electric shock from lightning.
—Do not use the telephone to report a gas leak in the vicinity of the leak.

i
9161-A2-GB20-00 November 1996
Contents
About This Guide
Document Purpose and Intended Audience iii. . . . . . . . . . . . . . . . . . . . . . . . .
Document Summary iii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product-Related Documents iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reference Documents iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1About the T1 Access Unit
What Does Your T1 Access Unit Do? 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What is Included with Your T1 Access Unit 1-1. . . . . . . . . . . . . . . . . . . . . .
What You Need to Do Before Using Your T1 Access Unit 1-2. . . . . . . . .
Observing T1 Access Unit LEDs 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2User Interface
Introduction 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
User Interface Access 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network Management 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Menu Hierarchy 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main Menu Screen 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen Field Types 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Affects Screen Displays 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen Work Areas 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Navigating the Screens 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyboard Keys 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen Function Keys 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting from a Menu 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting a Field 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Making Input Selections 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switching Between Screen Work Areas 2-7. . . . . . . . . . . . . . . . . . . . . . . .

Contents
ii 9161-A2-GB20-00
November 1996
3Start-Up
Logging In 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Logging Out 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting a Session 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ending a Session 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Entering Identity Information 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Displaying System Information
Displaying System and NAM Identity Information 4-1. . . . . . . . . . . . . . . . . . . .
Displaying APM Identity Information 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying System and Test Status 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying Voice APM Status 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying Cross Connect Status 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying Network Channels 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying DSX-1 Channels 4-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying Port Assignments 4-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying Device Name and SNMP System
Identification Information 4-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Viewing Network and Sync Data Performance Statistics 4-9. . . . . . . . . . . . . .
What Statistics Can Be Collected? 4-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Network Performance Statistics 4-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sync Data Performance Statistics 4-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displaying Performance Statistics 4-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting Performance Statistics Intervals for Display 4-11. . . . . . . . . . . .
Clearing Performance Statistics 4-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5Maintenance and Troubleshooting
ASCII Alarm Messages 5-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Error Messages 5-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Status Messages 5-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Health and Test Status Messages 5-7. . . . . . . . . . . . . . . . . . . . . . . . . .
Health and Status Messages 5-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Self-Test Results Messages 5-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Test Status Messages 5-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glossary
Index

iii
9161-A2-GB20-00 November 1996
About This Guide
Document Purpose and Intended Audience
This manual contains information needed to operate the T1 CSU/DSU Access
Unit and the T1 Access Mux. It is intended for T1 access unit operators.
Document Summary
Section Description
Chapter 1 About the T1 Access Unit. Provides information about
what your system contains.
Chapter 2
User Interface. Describes the async terminal interface.
Chapter 3
Start-Up. Tells you how to log-in/out and how to start
and end a session.
Chapter 4
Displaying System Information. Describes how to
display information about your system.
Chapter 5
Maintenance and Troubleshooting. Enables you to
troubleshoot your T1 Access Unit.
Glossary Defines acronyms and terms used in this document.
Index Lists key terms, acronyms, concepts, and sections in
alphabetical order.

About This Guide
iv 9161-A2-GB20-00
November 1996
Product-Related Documents
Document
Number Document Title Purpose/Focus
9161-A2-GH30 916x T1 CSU/DSU Access
and T1 Access MUX,
Technical Reference
Provides an overview of the unit and its
functionality, and explains basic
concepts. Describes typical
applications, setting up, operating, and
troubleshooting the unit. Provides
reference appendices: descriptions of
configuration options and the selections
that can be made, statuses and
messages, and pin assignments.
9161-A2-GN10 9161 T1 NAM Installation
Instructions Describes how to install the T1 NAM into the housing.
9000-A2-GN15 2-Slot Housing Installation
Instructions Describes how to install the 2-slot housing.
9000-A2-GN16 5-Slot Housing Installation
Instructions Describes how to install the 5-slot housing.
9109-A2-GN10 9109 Sync Data APM
Installation Instructions Describes how to install the Sync Data APM into the housing.
9109-A2-GN11 9109 E&M Analog Voice
APM Installation Instructions Describes how to install the E&M Analog Voice APM into the housing.
9109-A2-GN12 9109 FXS Analog Voice
APM Installation Instructions Describes how to install the FXS Analog Voice APM into the housing.
9000-A2-GX41 91xx Series T1 Equipment,
Safety, Regulatory, Warranty
and Service Information
Provides the information indicated by
the document’s title.
9000-A2-GX42 Affidavit Requirements for
Connection to Digital Service Provides an affidavit which must be completed and returned to the
telephone company to connect your
equipment to the network.
9000-A2-GN17 9000 Series Power Supply
Installation Instructions Describes how to install the optional redundant power supply into the
housing.
9000-A2-GN14 9000 Series Mounting
Bracket Installation
Instructions
Describes how to install the 2-slot
housing on the wall using the optional
mounting bracket kit.
9000-A2-GN20 9000 Series –48 Vdc Power
Supply Installation
Instructions
Describes how to install the optional
–48 Vdc power supply into the housing.
Call your sales representative to order additional product documentation.
Reference Documents
AT&T Technical Reference (TR) 54016 – Interfacing Digital Equipment to ESF
Services
AT&T Technical Reference (TR) 62411 – ACCUNET T1.5 Service: Description
and Interface Specifications

1-1
9161-A2-GB20-00 November 1996
About the T1 Access Unit 1
What Does Your T1 Access Unit Do?
The T1 access unit is the interface between your customer premises equipment
and a T1 network. It can be employed as an entry-level CSU/DSU and expanded
to become a multiplexer as your network needs evolve.
The 916x product line consists of the following T1 access unit configurations:
T1 CSU/DSU Access Unit
T1 Access Mux
Both configurations are referred to as the T1 access unit in this document.
What is Included with Your T1 Access Unit
The T1 access unit comprises a Network Access Module (NAM), with Application
Modules (APMs) available, installed in a two-slot or five-slot chassis.
The following components are available for your 916x T1 access unit.
Component Function
9161 T1 Network Application Module (NAM) Provides the interface between the T1 digital network and the
Customer Premise Equipment (CPE). The T1 NAM also provides
a DSX-1 drop and insert port to allow DTEs supporting the DS1
signal format to share the network T1 with other high-speed
equipment, as well as two synchronous data ports.
9109 Sync Data Application Module (APM) Provides the interface for four synchronous data ports.
9109 E&M Analog Voice Application Module
(APM) Provides the interface for eight E&M voice ports.
FXS Analog Voice Application Module (APM) Provides the interface for eight FXS ports.
2-Slot Standalone Housing (T1 CSU/DSU
Access Unit only) Accommodates one T1 NAM and one APM for T1 CSU/DSU Access Unit applications.

About the T1 Access Unit
1-2 9161-A2-GB20-00
November 1996
Component Function
5-Slot Housing (T1 Access Mux only) Accommodates one T1 NAM and up to four APMs for T1 Access
Mux applications.
Redundant AC Power Supply Provides a backup for the ac power.
–48 VDC Power Supply (T1 Access Mux only) Provides –48 Vdc power for the 5-slot housing.
Mounting Brackets (T1 CSU/DSU Access Unit
only) Enables the 2-slot housing to be mounted on a wall.
A minimum configuration consists of a T1 NAM in either of the housings.
What You Need to Do Before Using Your T1 Access Unit
Subscribe to T1 service.
Install the housing. Refer to either the
2-Slot Housing Installation Instructions
or the 5-Slot Housing Installation Instructions for more information.
If you are installing a . . . Then refer to the . . .
2-Slot housing 2-Slot Housing Installation Instructions
5-Slot housing 5-Slot Housing Installation Instructions
Install the T1 NAM and any appropriate APMs into the housing.
If you are installing a . . . Then refer to the . . .
T1 NAM 9161 T1 NAM Installation Instructions
Sync Data APM 9109 Sync Data APM Installation Instructions
E&M Analog Voice APM 9109 E&M Analog Voice APM Installation
Instructions
FXS Analog Voice APM 9109 FXS Analog Voice APM Installation
Instructions
Configure your T1 access unit for your particular application. Refer to the
916x T1 CSU/DSU Access and T1 Access Mux, Technical Reference for
configuration information.
Observing T1 Access Unit LEDs
LEDs are located on the various cards used in your T1 access unit. These LEDs
enable you to view general system status information. See the installation
instructions that accompanied your T1 NAM and APMs for more information.

2-1
9161-A2-GB20-00 November 1996
User Interface 2
Introduction
The T1 access unit uses menu-driven asynchronous (async) terminal interface
menus and screens. Along with the LED status indicators on the front panel, the
menu-driven interface provides feedback and status on the:
T1 access unit
DSX-1 and Network T1 interfaces
Synchronous data ports
Voice ports
User Interface Access
You can access the user interface:
Locally through a direct connection to the communications port via an async
terminal (or other VT100-compatible terminal) or PC emulation.
Remotely through a Telnet session, although only one user interface session
may be active at one time.
Network Management
Manage the T1 access unit via an SNMP management system connected to the
communications port or through a remote in-band connection.
Menu Hierarchy
The menu hierarchy represents the organization of the system’s menus and
screens. Refer to the enclosed
Quick Reference for a pictorial view of the menu
hierarchy.

User Interface
2-2 9161-A2-GB20-00
November 1996
Main Menu Screen
Access to all of the T1 access unit’s tasks begins at the Main Menu screen, which
has four menus or branches.
Select . . . To . . .
Status View diagnostic tests, voice interfaces, cross connections,
statistics, and T1 access unit identity information.
Test Select, monitor, and cancel test for the system’s interfaces.
Configuration Display and edit the configuration options.
Control Control the user interface for call setup, device naming, date
and time, login administration, and system alarm relay cut-off
(for the 5-slot housing). Also, initiate a power-on reset of the
system.
Screen Field Types
Three types of screen fields are available on the async terminal.
Use screen field . . . To . . .
Menu selection Display a list of available functions for user selection.
Input Add or change information on a screen.
Underlines in the field value or selection indicate an input
or edit field.
Display Display configuration information and results from
performance and system-specific tests.
No underlines in the field value or selection indicate a
display-only field.
What Affects Screen Displays
What appears on the screens depends on:
Current configuration – How your T1 access unit is currently configured.
Security access level – The security level set by the system administrator
for each user.
Data selection criteria – What you entered in previous fields or screens.

User Interface
2-3
9161-A2-GB20-00 November 1996
Screen Work Areas
There are two user work areas:
Screen area – Where you input information into fields.
Screen function key area – Where you perform specific screen functions.
Below is a sample async terminal interface screen.
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
main Access Level: 1 Company Name 9162
Device Name: Node A 01/26/96 23:32
MAIN MENU
Status
Test
Configuration
Control
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Ctrl-a to access these functions Exit
Save
Menu Path
System
Messages and
Field Values
Screen
Area
Device
Name
Model Number
Date and Time
Access Level
Screen Format Description
Menu path Menu selections made to reach the current screen.
Device name Customer-assigned identification of the system.
Access level Currently assigned security access level.
Company Name Vendor company name.
Model number xxxx The T1 access unit’s model number (9162 or 9165).
Date and Time Date and Time kept locally by the system
(24 hour clock).
Screen area Selection, display, and input fields for monitoring and
maintaining the system.

User Interface
2-4 9161-A2-GB20-00
November 1996
Screen Format Description
Screen function keys Specific functions that can be performed on the
screen.
System messages and
field values System-related information, valid values for input fields, and System Health and Status messages.
Navigating the Screens
You can navigate the screens by:
Using keyboard keys
Switching between the two screen work areas
Using screen function keys
Keyboard Keys
Use the following keyboard keys to navigate within the screens.
To . . . Press . . .
Move cursor between the screen area and
the screen function keys area Ctrl-a
Return to the previous screen Esc
Move cursor to the next field Right Arrow (on same screen row), or
Tab (on any screen row)
Move cursor to the previous field Left Arrow (on same screen row), or
Ctrl-k
Move cursor one position to the left. If the
cursor is at the beginning of a field,
Backspace has no effect.
Backspace
Move cursor to the last character of the
previous field (backtab) Ctrl-k
Display the next valid value for the field Spacebar
Delete character that the cursor is on Delete (Del)
Move cursor up one field within a column on
the same screen Up Arrow or Ctrl-u
Move cursor down one field within a column
on the same screen Down Arrow or Ctrl-d
Move cursor one character to the right if in
edit mode Right Arrow or Ctrl-f

User Interface
2-5
9161-A2-GB20-00 November 1996
To . . . Press . . .
Move cursor one character to the left if in edit
mode Left Arrow or Ctrl-b
Redraw the screen display, clearing
information typed in but not yet entered Ctrl-l
Accept entry or display valid options on the
last row of the screen when pressed before
entering data or after entering invalid data
Return (Enter)
Screen Function Keys
All screen function keys (located in the lower part of the screen) operate the
same way (upper- or lowercase) throughout the screens.
These keys use the following conventions:
Select . . . For the screen
function . . . And press Return to . . .
M or m MainMenu Return to the Main Menu screen.
E or e Exit Terminate the async terminal session.
N or n New Enter new data.
O or o Modify Modify existing data.
L or l Delete Delete data.
S or s Save Save information.
R or r Refresh Update screen with current information.
C or c ClrStats Clear network performance statistics and refresh the
screen.
U or u PgUp Display the previous page.
D or d PgDn Display the next page.

User Interface
2-6 9161-A2-GB20-00
November 1996
Selecting from a Menu
You select from a menu to get subsequent menus or screens so you can perform
desired tasks.
"Procedure
To make a menu selection:
1. Tab or press an arrow key to position the cursor on a menu selection. Each
menu selection is highlighted as you press the key to move the cursor from
position to position.
2. Press Return. The selected menu or screen appears.
3. Continue Steps 1 and 2 until you reach the screen you want.
Refer to the
Quick Reference provided with this document to guide you through
menu selections.
Selecting a Field
Once you have reached the desired menu or screen, select a field to view,
change, or issue a command. Select a field from within a menu in the same way
you select from a menu – press the Tab or right arrow key.
Example:
Selecting Control from the Main Menu, selecting Administer Logins, then entering
or changing security information.
Making Input Selections
You can enter information into a field in one of several ways. Once the field is
selected, you can:
HManually type in (enter) the field value or command.
Example:
Entering abc as a user’s Login ID on the Administer Logins screen (from the
Control menu/branch).
HType in (enter) the first letter(s) of a field value or command, using the
character matching feature.
Example:
When configuring an FXS voice port’s operating mode with the Operating
Mode configuration option/field selected (values FXS, FXSDN,
FXSDN/WINK, PLAR and DPO), entering f or F displays the first value
starting with f – FXS. In this example, entering
fxsd or FXSD would display
FXSDN as the selection.
HSwitch from the screen area to the screen function area and select or enter
the designated screen function key. See
Switching Between Screen Work
Areas
for an example.
HPress the spacebar to make the next valid choice.

User Interface
2-7
9161-A2-GB20-00 November 1996
Switching Between Screen Work Areas
Use Ctrl-a to switch between the two screen work areas to perform all screen
functions.
Procedure
1. Press Ctrl-a to switch from the screen area to the screen function key area.
2. Select either the function’s designated (underlined) character or Tab to the
desired function key.
Example:
Enter e or E to Exit.
3. Press Return. The function is performed.
4. To return to the screen area, press Ctrl-a again.

3-1
9161-A2-GB20-00 November 1996
Start-Up 3
Logging In
When there is no contention for the user interface and a login is required, you are
presented with the Login screen. Up to 10 characters can be entered in the
Login ID and Password fields. Valid characters include the following:
H0 through 9
Ha through z
HA through Z
"Procedure
To log in:
1. Enter your assigned login ID, and press Return.
2. Enter your password, and press Return.
An asterisk (*) appears in the field for each character entered.
If the Login ID/Password
combination is . . . Then the . . .
Valid Main Menu appears. Begin your session.
Invalid Message Invalid Password is displayed on line 24,
and the Login screen is redisplayed.
If an invalid Login ID/Password combination is
entered 3 consecutive times,
– The current Telnet session is closed.
– The User Interface Idle screen appears with a
directly-connected terminal.
– An external modem is disconnected.
– An SNMP trap will be generated, if so
configured.
Access is denied. See your system administrator to
verify your login (Login ID/Password combination).

Start-Up
3-2 9161-A2-GB20-00
November 1996
Logging Out
When a login is required and a timeout occurs, you are automatically logged out.
You will be prompted for your login next time you try to use the interface.
You can also end a session using the screen function area of the user interface.
"Procedure
To log out:
1. Press Ctrl-a to switch from the screen area to the screen function key area.
2. Select Exit by entering e or E and pressing Return. The session is ended.
Starting a Session
Depending on how your T1 access unit is configured, you can start a session
using one of the following methods:
HDialing in through an external modem to the COM port.
HDirect connection over the COM port.
HTelnet session over the COM port.
HTelnet session through an in-band management channel through the T1
network.
"Procedure
Upon beginning a session, the user interface is blank. To activate:
1. Press Return.
2. One of the following occurs:
If . . . Then . . . What to do now?
Security is disabled The Main Menu screen
appears. Begin your session.
Security is enabled You are prompted for a
login ID and password. Enter your ID and password. If Invalid
Password appears, see
System Error Messages in
Chapter 5.
You are attempting to
access through Telnet and
the user interface is
currently in session
The message Connection
refused: appears. (T1
access unit allows only
one connection at a time.)
See System Status
Messages in Chapter 5.
