pardo SINGLE User manual

ASSEMBLY INSTRUCTIONS
SINGLE
BI FOLD DOOR CABINET & MECHANISM
Tools Required For Assembly
Hammer
Pliers
Soc ket Set
No 2 & No 4 Phillips Head Screwdrivers
Electric Drill (Hammer Drill for Masonry)
Spirit Level
No 2 Slot Head Screwdriver
6.5mm Masonry Drill Bit
Adjustable Spanner
19.06.15
DIY WALL BED KIT

17 deg. angle to both edges
(refer to detail)
370mm
270mm
Board is to lean back
against the wall
Pillowcatch
Head Board with 4 x holes
Bolt thru back of pillowcatch so
that the nut is on the inside of the
mechanisim
Mechanisim
Piano Hinge
Cupboard
Panels (Single)
1 x Top
1
x Shelf
1 x Top Back Rail
1
x Left Hand End
1 x Right Hand End
1 x Front Skirting
1 x Bottom Back Rail
4
x Door Panels
1
x Pillow Catch
1
x Head Board
Panel #
1
2
3
4
5
6
7
8
- 11
12
13
Size (mm)
1055 x 471
1055 x 471
1055 x 250
2227
x 487
2227 x 487
1055 x 150
1055 x 570
2108 x 269
900 x 370
900 x 270
Refer to detailed Note above.
12.
13.
Piano hinge
Both edges to
be cut
at 17
degrees
Detail
Cabinet Components
Pillowcatch
1.
DIAGRAM 1
1.
4.
3.
7.
6.
2. 5.
10.
11.
9.
8.

26 x Cam Bolts
10 x Green Wall Plugs
26 x Cams
2
x Handles
6
x Butt Hinge
2.
8
x Mounting Plates
8
x Clip on Hinge
SCREWS INCLUDED
Chipboard Screws
* 65mm Screws for attaching to wall
* 5mm Varianta screws for butt hinges
4 x Nut, Bolt and
Double Washer setup
refer to detail
1
2
3
4
5
6
8
7
Mechanism Components
Cabinet Hardware
1. AUTOMATIC FOOT
2. BED FRAME
3. CONNECTING ROD
4. SPRING MECHANISMS
5. WALL MOUNTING BRACKETS
6. CRADLES
7. MATTRESS GUARD
8. EXTENSION ARM
DIAGRAM 1
1 x Magnetic Catch

Right hand end
Left hand end
Floor
Bottom
back
rail
Top
back
rail
Top
1.
2.
5.
4.
7.
Shelf
3.
Front Skirting
6.
3.
Refer to Diagram 3
Refer to Diagram 2
Step 1 - Cabinet Assembly
NOTE: STEP 1. IS ONLY REQUIRED IF PURCHASING CABINET WITH BED MECHANISM
* Using hammer, tap cams into 20mm holes in all panels where required. Important : Orientation of cam as shown in photo below.
* Screw cam bolts into 5mm holes in all panels where required.
Hammer fix cam in place.
Screw fix cam bolt into 5mm holes.
* Lay left hand end #3 on floor with cam
bolts upright.
* Join shelf #2 to left hand end #3 and
tighten cams.
* Join top #1 to left hand end #3 and
tighten cams.
* Join top back rail #2 to left hand end #3
and top #1. Tighten cams.
* Join front skirting #5 to left hand and #3
and tighten cams
* Join bottom back rail #6 to left hand end
#3 and tighten cams.
* Place right hand end #4 on top of panels
#1,
#2, #5 and #6 ensuring all cam bolts are
inserted correctly. Tighten all cams.
DIAGRAM 2
DIAGRAM
3

Skirting
Board
Wall
Cut skirting recess
before pushing cabinet
against the wall
End Panel
Front
Panel
DETAIL B
Fastening with
angle brackets
DETAIL A
Wall plugs
Refer to detail A
Refer to detail B
Step 2 - Fixing Cabinet To Wall
* Lay cabinet face down with bottom facing the wall.
* To ensure the cabinet sits neatly against the wall when upright, it may be necessary to cut a larger recess
into bottom of left and right hand end of cabinet to go over skirting. (refer to detail B)
* Lift cabinet at top, pushing towards wall, being careful to have sufficient ceiling clearance.
* Place cabinet into position against the wall and, using a spirit level against either the right or left hand end and the top,
find the correct vertical and horizontal position. Mark this position on the wall with a pencil.
PLEASE NOTE
As there is a lot of tension in the Wallbed when in the open position, it is
very important that the cabinet is securely fixed to the wall.
IMPORTANT NOTE: Before moving cabinet upright, ensure all cams are tightened securely.
FASTENING OPTIONS 1
USING ANGLE BRACKETS
(for gyprock, fibro or timber walls)
FASTENING OPTIONS 2
* Ensure cabinet is in correct vertical position.
* With a pencil or nail, mark the wall through the
predrilled holes in the top back rail and the
bottom back rail.
* Move cabinet back into place against wall.
* Fix top back rail to wall using 61mm screws.
Put on cover caps.
(for brick/masonry walls)
* Move cabinet aside. Using a 6.5mm masonry bit,
supplied.
* Fix bottom back rail to wall. Countersink screws
to avoid pillow catch scraping on them.
* Fix bottom back rail to wall. Countersink screws
to avoid pillow catch scraping on them.
* Locate wall studs and mark clearly with pencil.
* Sit angle brackets in cabinet top, flush with top and
back edge and against the wall studs. Ensure that the
twin hole side of bracket is against the wall.
* Fix angle brackets through wall into studs using
65mm screws provided.
* Ensure cabinet is in correct vertical position.
Fix bottom of brackets into cabinet top using
16mm screws.
drill 60mm deep holes into wall and insert wall plugs
4.

Split pin Extension(#8)
Cradle(#6)
Connecting rod(#3)
Spring Mechanism(#4)
Bed frame(#2)
Washer
Wall mounted bracket(#5)
Step 3 - DIY Mechanism Assembly / Instructions
* Attach spring mechanisms (#4) to front and back cradle (#6) using small nuts and bolts provided. Ensure to attach the
wall mounted brackets (#5) with the ends turned inwards together with the spring mechanism to the top rear bolt.
(See diagram 4)
* Fix the cradle assembly to the floor using the 75mm screws provided. 50mm green wall plugs are also provided if
fixing to concrete floor.
* Once the cradle is fixed to the floor, fix the wall mounted brackets (#5) to the wall using the 28mm screws provided.
50mm green wall plugs are also provided if fixing to concrete or brick walls.
* Lower the bed frame in between the mechanism arms and bolt through the predrilled holes to the cradle assembly.
You might find that the bed frame will be a tight fit in between the mechanism arms. (See diagram 4)
* Remove the split pin and washer from the extension (#8) and attach the connecting rod (#3) to the extension through
the predrilled hole on the connecting rod (#3) and replace the washer and then the spit pin. You might need to lower
the bed frame slightly to line up the extension (#8) and the connecting rod (#3). . (See diagram 4)
* Attach the red handle supplied to the Automatic foot (#1) using the screws provided. To avoid damage to the
connecting rod, be sure that the bed is lowered using the red handle.
NOTE: If fixing through a carpet floor, it is recommended that a small cut be made in the surrounding
area to be drilled so that no threads are pulled in the carpet pile. Also if fixing to a timber floor, 2mm
pilot holt is to be drilled in the floor before screwing through the cradle into the floor.
NOTE: It is very important that the cradle is fixed back to the wall and floor securely as there will be
substantial tension exerted on the cradle when the mechanism is in the lowered position.
WARNING
When operating the wall bed mechanism the bed frame must be carefully lowered all the way to
the floor and NOT left to drop freely. If the bed frame is lowered without the weight of a mattress
it may spring back causing injury. Do not try to vary the tension of the spring mechanism as it
is NOT adjustable.
DIAGRAM 4
Refer to Diagram 4
* If not using pillow catch, bolt on mattress guard(s) to the top of the bed frame through the predrilled holes and
using nuts and bolts provided.
5.

(i) Ensure Butt hinge knuckle faces
towards internal cupboard
Inside
Face
A
(ii) Attaching
Clip-on
Hinges
Door
Cabinet
(iii) Drawing showing Door adjustment
by screw on mounting plate
5b
Outside
Face
DOOR
-
hinged
to
cabinet
Step 4 - Mounting Bi-Fold Doors
* Attach butt hinges to door panel inside face to form two sets of bi-fold doors.
* Insert clip-on hinges into hinge holes on outside edges of door panels. Fix hinges to doors using screws provided.
* Attach doors to cabinet by clipping hinges onto mounting plates on cabinet end panels.
* Adjust doors if necessary by screw adjustment where hinge meets hinge plate.
* Attach handles to doors.
Note: Ensure that hinge is on inside of doors
6.
DIAGRAM 5

Plan n.t.s
Side Elevation n.t.s
2227 mm
Wall
471
117 2108
150
2
7.
Carcase Construction
DIAGRAM 11
1055mm Single
505
Min
471mm
For
250mm
thick
mattress
NOTE: ALL BASED ON 16mm
BOARD
CONSTRUCTION
16
140
