CORDLESS SCREWDRIVER PAS 4 B4
Introduction
Congratulations on the purchase of your new appliance. You have
chosen a high-quality product. The operating instructions are part of
this product. They contain important information about safety, usage
and disposal. Before using the product, please familiarise yourself
with all of the operating and safety instructions. Use the product only
as described and for the range of applications specified. Please also
pass these operating instructions on to any future owner.
Intended use
This appliance is designed for screwing into wood, plastic and metal.
Use this appliance only as described and for the areas of applications
specified. The appliance is not intended for commercial use. Any other
usage or modification of the appliance is deemed to be improper
and carries a significant risk of accidents. The manufacturer accepts
no responsibility for damage attributable to misuse.
Notes on trademarks
USB®is a registered trademark of USB Implementers Forum, Inc.
All other names and products may be trademarks or registered
trademarks of their respective owner.
Features
Rotation direction switch/safety lock-out
Motor direction indicator for clockwise rotation
Battery charge level indicator
Motor direction indicator for anticlockwise rotation
Charging socket
ON/OFF switch
LED lamps
Tool holder

PAS 4 B4 GB│IE│NI│CY│ 3 ■
Charger
9a
USB plug of the charging cable
9b
Micro-USB-C plug of the charging cable
Bits and bit extension
Package contents
1 cordless screwdriver
1 charger
1 case
1 charging cable
26 bits x 25mm
2 bits x 50mm
1 bit extension
1 set of operating instructions
Technical specifications
Cordless screwdriver: PAS 4 B4
Nominal voltage: 4 V (DC)
Battery (integrated): (1 cell)
Battery capacity: 1500 mAh
Rated idle speed: n0200rpm
Torque: max. 5.0 Nm
Tool holder: 6.35 mm (¼")

PAS 4 B4
■ 4 │ GB│IE│NI│CY
Use only the following charger to charge the cordless
tool:
PAS 4 B4-2:
INPUT:
Rated voltage: 100–240 V ∼ 50–60 Hz (AC)
Rated current: 16W
OUTPUT:
Rated voltage: 5.0 V (DC)
Rated current: 1700 mA
Charging time: approx. 1 hr
Protection class: II/ (double insulation)
Noise and vibration information:
The measured values have been determined in accordance with
EN62841. The A-rated noise level of the tool is typically:
Sound pressure level: LPA = 56.4 dB (A)
Sound power level: LWA = 67.4 dB(A)
Uncertainty K: KpA/WA = 3 dB
Vibration values (vector total of three directions) determined in
accordance with EN 62841:
Screws:
Vibration emission value: ah= 0.412 m/s2
Uncertainty: K = 1.5 m/s2

PAS 4 B4 GB│IE│NI│CY│ 5 ■
NOTE
► The vibration emission values and the noise emission values
given in these instructions have been measured in accordance
with a standardised test procedure and can be used for com-
parison of the power tool with another tool.
► The specified total vibration values and the noise emission
values can also be used to make a provisional load estimate.
WARNING!
► Depending on the manner in which the power tool is being
used, and in particular the kind of workpiece being worked,
the vibration and noise emission values can deviate from
the values given in these instructions during actual use of the
power tool.
► Try to keep the vibration loads as low as possible. Measures
to reduce the vibration load are, e.g. wearing gloves and
limiting the working time. Wherein all states of operation
must be included (e.g. times when the power tool is switched
off and times where the power tool is switched on but run-
ning without load).

PAS 4 B4
■ 6 │ GB│IE│NI│CY
General power tool
safety warnings
WARNING!
►Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to fol-
low all instructions listed below may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres, such
as in the presence of flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.

PAS 4 B4 GB│IE│NI│CY│ 7 ■
2. Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug
in any way.
Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There is
an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away from
heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When working outdoors with an electrical power tool, always
use extension cords that are also suitable for use outdoors.
Use of a cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use of
an RCD reduces the risk of electric shock.

PAS 4 B4
■ 8 │ GB│IE│NI│CY
3. Personal safety
a) Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while
you are tired or under the influence of drugs, alcohol or med-
ication. A moment of inattention while operating a power tool
may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protec-
tion. Protective equipment such as a dust mask, non-skid safety
shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-
position before connecting to power source and/or battery
pack, picking up or carrying the tool. Carrying power tools
with your finger on the switch or energising power tools that have
the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all
times. This enables better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing or jewellery.
Keep your hair and clothing away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.

PAS 4 B4 GB│IE│NI│CY│ 9 ■
h) Do not allow yourself to get lulled into a false sense of security
and do not ignore the safety rules for power tools, even if you
are familiar with the power tool after repeated use. A careless
action can cause severe injury within a fraction of a second.
4. Power tool use and care
a) Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and
off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the
battery pack, if detachable, from the power tool before making
any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach of children, and do not
allow persons unfamiliar with the power tool or these instruc-
tions to operate the power tool. Power tools are dangerous in
the hands of untrained users.

PAS 4 B4
■ 10 │ GB│IE│NI│CY
e) Maintain power tools and accessories. Check for misalign-
ment or binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s operation.
If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and tool bits, etc., in accor-
dance with these instructions, taking into account the working
conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a
hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from
oil and grease. Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in unexpected
situations.
5. Use and handling of the cordless electrical
power tool
a) Charge a rechargeable battery using only the charger recom-
mended by the manufacturer. Chargers are often designed for
a particular type of rechargeable battery unit. There is a risk of
fire if a battery charger specified for a particular type of battery
is used with other batteries.
b) Only the rechargeable battery units supplied are to be used
with an electrical power tool. The use of other rechargeable
battery units may lead to the danger of injury or fire.

PAS 4 B4 GB│IE│NI│CY│ 11 ■
c) When they are not being used, store rechargeable battery
units away from paperclips, coins, keys, nails, screws or
other small metal objects that could cause the contacts to be
bridged. Short-circuiting the contacts of a rechargeable battery
unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery units if they are
misused. If this happens, avoid contact with the fluid. If contact
occurs, flush the affected area with water. Seek additional
medical help if any of the fluid gets into your eyes. Escaping
battery fluid may cause skin irritation or burns.
e) Do not use damaged or modified batteries. Damaged or
modified batteries may behave unexpectedly and cause fires,
explosions or pose a risk of injury.
f) Do not expose a battery to fire or excessively high tempera-
tures. Fire or temperatures in excess of 130°C (265°F) can
cause an explosion.
g) Follow all instructions regarding charging and never charge
the battery or the cordless tool outside of the temperature
range given in the operating instructions. Incorrect charging
or charging outside of the permissible temperature range can
destroy the battery and increase the risk of fire.

PAS 4 B4
■ 12 │ GB│IE│NI│CY
CAUTION! RISK OF EXPLOSION! Never charge
non-rechargeable batteries.
Protect the rechargeable battery from heat; for
example, from continuous exposure to sunlight,
fire, water and moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that the
safety of the power tool is maintained.
b) Never try to repair damaged batteries. Batteries should only
be maintained by the manufacturer or an approved customer
service centre.
Safety guidelines for screw drivers
WARNING!
■Hold the power tool only by the insulated handles
when you are carrying out work in which the accesso-
ry tool may come into contact with concealed power
cables or the tool’s own power cord. If a screw comes
into contact with a live wire, this may make exposed metal
parts of the power tool live and could give the operator
an electric shock.

PAS 4 B4 GB│IE│NI│CY│ 13 ■
Extended safety guidelines
■Do not use a damaged or modified battery. Damaged or
modified batteries may behave unexpectedly and cause fires,
explosions or pose a risk of injury.
■Do not expose a battery to fire or excessively high tempera-
tures. Fire or temperatures in excess of 130°C (265°F) can
cause an explosion.
■Follow all instructions regarding charging and never charge
the battery or the cordless tool outside of the temperature
range given in the operating instructions. Incorrect charging
or charging outside of the permissible temperature range can
destroy the battery and increase the risk of fire.
Safety guidelines for battery chargers
■ This appliance may be used by children
aged 8 years and above and by persons
with limited physical, sensory or mental capa-
bilities or lack of experience and knowledge,
provided that they are under supervision or
have been told how to use the appliance
safely and are aware of the potential risks.
Do not allow children to use the appliance as
a toy. Cleaning and user maintenance tasks
may not be carried out by children unless
they are supervised.

PAS 4 B4
■ 14 │ GB│IE│NI│CY
The charger is suitable for indoor use
only.
■ If the connecting cable needs to be replaced,
this must be carried out by the manufacturer
or an authorised representative in order to
avoid safety hazards.
Before use
Charging the appliance battery (see fig. A)
NOTE
► The battery is supplied partially charged. Before first use,
charge the battery in the charger for at least 1 hours. This
guarantees full battery power. Li-ion batteries can be charged
at any time without adversely affecting their service life.
Interruption of the charging process will not damage the
battery.
► If the battery charge level indicator lights up red during
use, the battery is at less than 30% of its capacity and needs
to be charged.
► Never charge the cordless appliance when the ambient
temperature is below 10°C or above 40°C. If a lithium-ion
battery is to be stored for an extended period, the charge
level should be checked regularly. The optimum charge level
is between 50% and 80%. The storage climate should be
cool and dry and the ambient temperature should be
between 0°C and 50°C.

PAS 4 B4 GB│IE│NI│CY│ 15 ■
Starting charging:
♦ Connect the micro USB plug of the charging cable
9b
to the
charging socket .
♦ Connect the USB plug of the charging cable
9a
to the charger
.
♦ Connect the charger to a 100 - 240 V ∼ 50 - 60 Hz power
source.
The battery is fully charged when the battery level display changes
from red to green.
Stopping charging:
♦ Disconnect the charger from the mains power supply.
♦ Disconnect the micro USB plug of the charging cable
9b
from
the charging socket .
Changing bits/screw driver bits (see fig. B)
Inserting:
♦ Insert a bit into the tool holder .
Removal:
♦ Pull the bit out of the tool holder .

PAS 4 B4
■ 16 │ GB│IE│NI│CY
Use
Switching the cordless screwdriver on/off
Switching on:
♦ To start the appliance, press the ON/OFF switch and keep
it pressed in.
Switching off:
♦ Release the ON/OFF switch to switch off the appliance.
Changing the direction of rotation
Clockwise:
♦ Push the rotation direction switch to the left.
♦ Press the ON/OFF switch . The clockwise rotation indicator
lights up. You can now screw in screws.
Anticlockwise:
♦ Push the rotation direction switch to the right.
♦ Press the ON/OFF switch . The anticlockwise rotation indica-
tor lights up. You can now unscrew screws.
Safety lock-out:
♦ Push the rotation direction switch into the middle position.
The ON/OFF switch is blocked.

PAS 4 B4 GB│IE│NI│CY│ 17 ■
Tips and tricks
Screw bits are labelled according to their dimensions and their
shape. If you are unsure, always try the particular screw bit out to
see whether it sits in the screw head without any free play.
Maintenance, storage and cleaning
WARNING! RISK OF ELECTRIC SHOCK! Before
cleaning, disconnect the charger from the mains socket.
NOTE
► Before carrying out any work on the appliance, ensure that
the rotation direction switch is in the middle. This prevents
unintentional switching on.
The cordless screwdriver is maintenance-free.
■ The appliance must always be kept clean, dry and free from oil
or grease.
■ Never allow liquids to get into the appliance.
■ Use a cloth to clean the housing. Never use petrol, solvents or
cleansers which can damage plastic.
WARNING!
■ Always ensure the appliance and attachments are clean,
free of dust and dry before storing.
