Parkside PLBS 30 A1 User manual

IAN 71603
FINE SOLDERING IRON SET PLBS 30 A1
FINE SOLDERING IRON SET
Operation and Safety Notes
LUTOWNICA
Wskazówki dotyczące obsługi i bezpieczeństwa
FEINLÖTKOLBEN-SET
Bedienungs- und Sicherheitshinweise
KOMPLET FINEGA SPAJKALNIKA
Navodila za upravljanje in varnostna opozorila
JEMNÁ PÁJEČKA
Pokyny pro obsluhu a bezpečnostní pokyny
SÚPRAVA JEMNEJ SPÁJKOVAČKY
Pokyny pre obsluhu a bezpečnostné pokyny

GB Operation and Safety Notes Page 5
PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 21
SI Navodila za upravljanje in varnostna opozorila Stran 39
CZ Pokyny pro obsluhu a bezpečnostní pokyny Strana 57
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 73
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 89
Before reading, unfold the page containing the illustrations and familiarise yourself with all
functions of the device.
Przed przeczytaniem proszę rozłożyć stronę z ilustracjami, a następnie proszę zapoznać się z
wszystkimi funkcjami urządzenia.
Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami naprave.
Před čtením si otevřete stranu s obrázky a potom se seznamte se všemi funkcemi přístroje.
Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými funkciami prístroja.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.

1
2
3
8
7
4
5
A B
C D
10 3 119
5
4
6
12
2

5GB
Table of contents
Introduction
Proper use ...............................................................................Page 7
Features and equipment.........................................................Page 8
Included items.........................................................................Page 8
Technical information .............................................................Page 8
Safety advice
1. Workplace safety...............................................................Page 9
2. Electrical safety..................................................................Page 9
3. Personal safety ...................................................................Page 10
4. Careful handling and use of electrical power tools........Page 12
Original accessories/attachments.......................................Page 13
Before first use
Fitting the helical spring .........................................................Page 13
Inserting/replacing soldering tips........................................Page 13
Operation
Switching on and off ..............................................................Page 14
Third hand ...............................................................................Page 14
Solder sponge.........................................................................Page 14
Soldering.................................................................................Page 15
Maintenance and cleaning..................................Page 16
Service centre .................................................................Page 17
Warranty ............................................................................Page 17
Disposal................................................................................Page 18
Declaration of Conformity/Manufacturer ...Page 19

6 GB
Introduction
Introduction
The following pictograms are used in these operating
instructions/on the device:
Read instruction manual!
Observe caution and safety notes!
Caution–electric shock! Danger to life!
Risk of explosion!
Risk of fire!
Warning - Hot surfaces!
V~Volt (AC)
WWatts (Effective power)
Wear a breathing/dust mask, protective glasses,
gloves and clothing.
Keep children away from electrical devices!
Check that the device, mains lead and plug are in
good condition!
Do not smoke!
Do not eat!

7GB
Introduction
Introduction
Fine soldering iron set PLBS 30 A1
Q Introduction
Please make sure you familiarise yourself fully with the way
the device works before you use it for the first time and that
you understand how to handle it correctly. Please read the
operating instructions below. Be careful to keep these advice notes
and if necessary pass them on to a third party.
Q Proper use
The appliance is intended for electronic soldering for leisure and DIY
purposes. It is designed for uses such as soldering work, wood-engrav-
ing, welding and gluing plastics and the application of decorations.
Use the device only as described and for the indicated purposes. The
device is not intended for commercial use. Any other use or modifica-
tion to the device shall be considered as improper use and could give
rise to considerable dangers. The manufacturer will not accept
liability for loss or damage arising from improper use.
Do not drink!
Dispose packaging and appliance in an
environmentally-friendly way!

8 GB
Safety advice
Introduction
Q Features and equipment
1Soldering pencil
2Soldering tip
3Helical spring
4Clips
5Third hand
6Holder for copper attachments
7Multifunctional holder
8Soldering sponge
9Universal attachment
10 Pointed attachment
11 Conical attachment
12 Tin solder
Q Included items
1 Fine soldering iron set PLBS 30 A1
1 Multifunctional holder
2 Rolls of soldering tin (10 grams each)
2 Soldering tips (1x installed)
4 Copper attachments (engraving tips)
1 Solder sponge
1 Operating instructions
Q Technical information
Electricity supply: 230V~
Frequency: 50Hz
Power consumption: 30W

9GB
Safety advice
Safety advice
CAUTION! Failure to observe the instructions and advice given
below may result in electric shock, fire and/or serious injury.
1. Workplace safety
a) Keep your working area clean and well lit. Untidy or
poorly lit working areas can lead to accidents.
b) Do not work with the device in potentially
explosive environments in which there are
inflammable liquids, gases or dusts. Electrical
power tools create sparks, which can ignite dusts or fumes.
c) Keep children and other people away while
you are operating the electrical tool. Distrac-
tions can cause you to lose control of the device.
2. Electrical safety
To avoid danger to life from electric shock:
a)
The mains plug on the device must match the mains sock-
et. The plug must not be modified in any way. Do not
use an adapter plug with devices fitted with a protec-
tive earth. Unmodified plugs and matching sockets reduce the
risk of electric shock.
b) Keep the device away from rain or moisture. Water en-
tering an electrical device increases the risk of electric shock.
Introduction

10 GB
Safety advice
Safety advice
c) Use a residual current device (RCD) for protection if
operating the electrical power tool in a moist environ-
ment is unavoidable. The use of an RCD reduces the risk of
electric shock.
d) Do not use the mains lead for any purpose for
which it was not intended, e.g. to carry the
device, to hang up the device or to pull the
mains plug out of the mains socket. Keep the mains
lead away from heat, oil, sharp edges or moving parts
of the device. Damaged or tangled mains leads increase the
risk of electric shock.
e) Do not operate the device if the mains lead or mains plug is
damaged.
A damaged mains lead presents a serious
danger to life from electric shock.
f) Always keep the mains lead out of the operating area and run it
away from the rear of the device.
g) Always pull out the mains plug if you are about to leave the device
unattended or wish to carry out any tasks on the device.
3. Personal safety
a) Children or persons who lack the knowledge or expe-
rience to use the device or whose physical, sensory or
intellectual capacities are limited must never be al-
lowed to use the device without supervision or in-
struction by a person responsible for their safety. Chil-
dren must never be allowed to play with the device.
b) Remain alert at all times, watch what you are doing
and always proceed with caution. Do not use the
device if you are tired or under the influence of
