BASIC OPTICS
DIODE LASER
Instruction Sheet
for the PASCO
Model OS-8525A
Basic Optics Diode Laser
012-07892A
6/01
$1.00
© 1995 PASCO scientific
This instruction sheet written/edited by:
Mary Ellen Niedzielski
➂Turn the Laser Diode power on.
If necessary, the beam location can be adjusted by
turning the Horizontal and Vertical Adjust screws on
the back of the Laser.
Aligning laser using the OS-8517 Light
Source and OS-8515 Optics Bench.
➀Mount the Light Source and the Laser at opposite ends
of the Optics Bench.
➁Turn the Light Source so the crosshair image is facing
the Laser.
➂Turn the Laser on and turn the Horizontal and Vertical
Adjust screws until the Laser spot is centered on the
crosshair image.
Equipment
Basic Optics
Laser Diode
9VDC
Adapter
Introduction
The PASCO Model OS-8525A Basic Optics Diode Laser
includes a laser diode and mount, and a 9 VDC AC
adapter. The Basic Optics Diode Laser was designed as
an accessory to the Model
OS-8515 Basic Optics System. The laser is permanently
mounted in a freestanding holder which allows it to be
used with other optics systems.
Specifications
Class: II Laser
Wavelength: 650 nm
Max. Output: < 1mW
Setup Procedure
➀Attach the Basic Optics Diode Laser to the OS-8515
Optics Bench by gently squeezing the base and insert-
ing it into the bench. The base will snap into place.
➁Plug the AC Adapter phone plug connector into recep-
tacle on the back of the Laser.
Vertical
Adjustment
Horizontal
Adjustment
Beam Adjustments
better
teach science
ways to
