Path medical SENTIERO ADVANCED User manual

QUICK START GUIDE
SENTIERO ADVANCED ASSR
(GOLD LABEL)
Page 1of 7
100800-18_Sentiero Advanced ASSR Quick Start Guide_Rev 1
TURNING ON/OFF, CHARGING THE DEVICE
START MENU
Note: this screen (test options) can vary depending on your set up
Current time
Battery status
Turn off device
Customize settings
On/off
button on
right side
Power
supply
connector
Select patient
Additional
information on
options for current
screen

QUICK START GUIDE
SENTIERO ADVANCED ASSR
(GOLD LABEL)
Page 2of 7
100800-18_Sentiero Advanced ASSR Quick Start Guide_Rev 1
TESTING
AUDITORY STEADY STATE RESPONSE (ASSR)
Connect the electrode cable to the white connector.
Connect the transducer to the appropriate connector:
Headphones or insert earphones: blue connector
Probe: red connector
Second probe for binaural testing: blue connector
Clean the patient’s skin and place the electrode pads. Connect the clips to the corresponding sites.
Recommended montage is:
White: high forehead
Black: cheek
Red: mastoid
For binaural testing, place red electrode on
the nape.

QUICK START GUIDE
SENTIERO ADVANCED ASSR
(GOLD LABEL)
Page 3of 7
100800-18_Sentiero Advanced ASSR Quick Start Guide_Rev 1
If you are using an ear probe or insert earphones, select the appropriate ear tip size and place it on
the probe tip. Insert the probe in the ear making sure that the ear tip fits tightly into the ear canal.
If you are using headphones, place them over the ears.
Select ASSR
Select the protocol you would like to use. To change the parameters, select one of the presets and then
the tools button at the bottom of the page:
Select
frequencies to
test
CONFIGURABLE TEST PARAMETERS
Fixed: will test
all selected
levels
Adaptive: used
for threshold
search
Select start, minimum and maximum
lever for adaptive mode
Select masking noise (monaural testing
only)
40 Hz: awake and adult patients
80 Hz: babies and higher frequencies
Auto: mixed rate, optimized for performance
Half octave
stimuli provide
better
frequency
specificity but
longer test time

QUICK START GUIDE
SENTIERO ADVANCED ASSR
(GOLD LABEL)
Page 4of 7
100800-18_Sentiero Advanced ASSR Quick Start Guide_Rev 1
Select the test ear by pressing either the Right or Left button, or Right + Left for binaural testing. Binaural
testing is available when headphones, insert phones or two ear probes are connected.
Make sure the patient is sitting or lying down comfortably.
An impedance check will be performed prior to measurement. If impedance is below 6 k ohm, the start
button will become available. You can configure the settings for the test to autostart if the impedance is
lower than 4 k ohm. If impedance is higher than 6 k ohm but below 12 k ohm, a skip button will become
available. An impedance below 6 k ohm is recommended for best test results.

QUICK START GUIDE
SENTIERO ADVANCED ASSR
(GOLD LABEL)
Page 5of 7
100800-18_Sentiero Advanced ASSR Quick Start Guide_Rev 1
If you are using an ear probe, a calibration will be performed together with the impedance check. You
can select the simple calibration or the expert calibration mode in the device set up.
ASSR TEST SCREEN
Progress for each tested
frequency
Overall EEG, –value
should remain in the lower
third. Press to enable raw
EEG view
Progress
Impedance monitor
Stop test
Pause
ongoing test
Skip this
single test
Frequency being tested
Intensity level being tested
Simple calibration mode
Expert calibration mode

QUICK START GUIDE
SENTIERO ADVANCED ASSR
(GOLD LABEL)
Page 6of 7
100800-18_Sentiero Advanced ASSR Quick Start Guide_Rev 1
ASSR TEST RESULTS
Please note that the estimated audiogram is only available in the adaptive test mode.
Note: These circles
indicate that other screens
are available to view.
Swipe your finger right or
left to get other views.
Print results to a label or to a pdf file
Test conditions
Press on a check
mark or circle to
view details

QUICK START GUIDE
SENTIERO ADVANCED ASSR
(GOLD LABEL)
Page 7of 7
100800-18_Sentiero Advanced ASSR Quick Start Guide_Rev 1
Quick Guide Information
Release date: 2017-01-11
Revision: 01
Valid from: Firmware Rev. 2.1, Mira PC Software Rev. 1.6.4
Applies to: Model: SOH100360, web description SOH09
All mentioned items, products, brands and trademarks are registered or owned by the mentioned companies.
All information, illustrations, and specifications provided within this manual are based on the latest product
information available at the time of publication. PATH MEDICAL reserves the right to make changes at any time
without notice.
Please note that not all products displayed on our webpage or advertising materials are available in all territories.
Please contact your local distributor or PATH MEDICAL for further information.
The latest revision of the Quick Start Guide is available online at www.pathme.de/download.
Errors and omissions excepted.
Copyright Notice
No part of this manual may be reproduced, translated, stored, or transmitted, in any form or by any means,
electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of PATH
MEDICAL GmbH.
Copyright © 2016 PATH MEDICAL GmbH
PATH MEDICAL GmbH
Landsberger Straße 65
82110 Germering
Germany
Tel.: [phone] Fax: [phone] Internet: www.pathme.de
