Patio Post CS63149 User manual

ASSEMBLY INSTRUCTION
ITEM CODE:CS63149
Sun Chair 3 PCS Set
For any assistance with assembly or for missing parts please Contact with us
Email: [email protected]
Web: www.lhgst.com
Adress:NO.99 South Heyang Road,Dayang Street, Linhai,zhejiang,China
Page 1

PRE-ASSEMBLY PREPARATION
Before you start:
1.Choose a clean, level, spacious assembly area. Avoid hard surfaces that
may damage the product
2.Take care when lifting. Product should be assembled as near as possible
to the point of use
3.Ensure that you have all required contents for complete assembly
4.Always read the assembly instructions carefully before beginning
assembly.
5.Keep all hardware parts and packaging out of reach of small children.
6.Do not over tighten the screws and bolts as this may damage the
threads
7.Assembly is to be carried out by a competent adult(s) ONLY
8.During assembly, children should be kept away from the product due to
possible risk to injury.
9.Do not use this item if any components are missing or damaged.
10. Please keep the instructions for future reference.
Page 2

PARTS LIST
Page 3

PARTS LIST
Page 4

You will need the following
Part A
Step 1
Page 5

You will need the following
Step 2
Page 6

Assembly is complete
Page 7

You will need the following
Part B
Step 1
Page 8
•Insert the legs in to the table back.
•Attach Leg(7) to table top(5)using the bolt(G).Cambered
washer(A) as shown in the below diagram.
•Tighten with Hexagan Key(F)

Step 2
You will need the following
Page 9
•Attach triangle base(6) to legs(7) using bolt(G)
washer(D) and nut(C) as shown below in the below
diagram
•Tighten with wrench(E)and hexagan key(F)

Step 3
You will need the following
Page 10
•Put the glass(8) onto the table base.

Assembly is complete
Page 11
