1PAX D220 Features
The sleek and elegant D220 comes with state-of-
the-art technology including:
•Cortex A9processor
•Flash 512MB+DDR 512MB
•MagStripe, EMV Chip, NFC
•PCI 4.x certified, SRED
•Optional wireless power charger
•1Micro SAM slot
•1Micro SIM slot
•1SD Card slot
•3G, 4GLTE, Bluetooth® wireless technology,Wi-Fi
2What’s in The Box

PAX D220 Quick Setup Guide
PAX Technology® 3 20180801 v1.1
[email protected]
[phone]
www.pax.us
3D220 Front Side
4D220 Back Side

PAX D220 Quick Setup Guide
20180801 v1.1 4 PAX Technology®
[email protected]
[phone]
www.pax.us
5D220 Power Button and USB
Port
6D220 Charging Instructions
Plug in the USB AC adapter.
Plug the standard USB end of the cable to the
AC adapter or a PC USB port.
Plug the micro USB end of the cable into the
micro USB port on the D220 terminal.
Allow the battery to charge until full.
NOTE
Battery must remain installed for proper operation.
7D220 Power On/Off
Power on the terminal by pressing and holding
the power button down for 3-5 seconds and
then release.
Power off the terminal by pressing and holding
the power button down for 3 to 5 seconds and
then release.

PAX D220 Quick Setup Guide
PAX Technology® 5 20180801 v1.1
[email protected]
[phone]
www.pax.us
8D220 Communication Setup
The D220 supports Wi-Fi for network and internet
access. To communicate with the host, other
devices, and/or download applications, you must
first configure communication settings.
This guide only describes setting up Wi-Fi for the
first time for following options:
•Basic Wi-Fi
•Static IP (SSID Visible)
•Static IP (SSID Not Visible)
•Proxy Server Manual Setup
8.1 D220 Basic Wi-Fi Setup
The only purpose for setting up Wi-Fi out of the box
is to allow the terminal to download its working
application. After this initial setup, the terminal
settings are changed through the application as
configured in BroadPOS.
Configure the terminal Wi-Fi settings as follows.
Power on the terminal and wait for the IDLE
screen to display.
From the IDLE screen press and hold the Cancel
and Enter buttons at the same time for 1 to 3
seconds.
Input the password and press the Enter button.
Use the Right Arrow on the screen, navigate to
and select the Communication option.
Input the password and press the Enter button.
Use the Right Arrow on the screen, navigate to
and select the Wi-Fi Parameters option.

PAX D220 Quick Setup Guide
20180801 v1.1 6 PAX Technology®
[email protected]
[phone]
www.pax.us
The terminal searches for Wi-Fi networks and
only displays local Wi-Fi networks that have the
SSID broadcast option enabled.
Use the Right and Left Arrows on the screen to
review and select the desired Wi-Fi network.
Select the Password option, input the case-
sensitive password and press the Enter button.
Use the X button on the screen to back out
of the options until you see the “Please Wait,
Wi-Fi Init…” message.
The terminal attempts to connect to the Wi-
Fi network. If the connection is successful, the
network icon at the top of the screen changes
to blue from gray and shows relative signal
strength.
If there is a connection error, the screen
displays, “Please wait Wi-Fi connecting failed”
and returns to the IDLE screen. The terminal
automatically tries to connect again every 30
seconds.
If you receive the connection error, ensure
you have the correct, case sensitive password
and that you are selecting the correct Wi-Fi
network.
Repeat Steps 1 through 6 in this section.
After selecting the Wi-Fi parameters option
(Step 6), use the Right Arrow on the screen,
navigate to and select the Switch Router
option.
The terminal searches for Wi-Fi networks.

PAX D220 Quick Setup Guide
PAX Technology® 7 20180801 v1.1
[email protected]
[phone]
www.pax.us
Use the Right and Left Arrows on the screen
to review and select the desired Wi-Fi network.
Select the Password option, input the case-
sensitive password and press the Enter button.
Wi-Fi Static IP Setup
(SSID Visible)
If you are required to setup a Wi-Fi connection with
a static IP and you know that the SSID is visible,
perform the steps in this section.
Before you begin configuration, ensure that you
have the correct network information; IP Address,
Subnet mask, Gateway ID, passwords, etc.
If you are required to setup a Wi-Fi connection with
a static IP and you know that the SSID is NOT
visible, perform the Steps in Section 8.1.2 Wi-Fi
Static IP Setup
(SSID Not Visible).
Perform Steps 1 through 6 as shown in Section
8.1 D220 Basic Wi-Fi Setup.
After selecting the Wi-Fi parameters option
(Step 6), use the Right Arrow on the screen,
navigate to and select the Switch Router
option.
The terminal searches for Wi-Fi networks.
Use the Right and Left Arrows on the screen to
review and select the desired Wi-Fi network.
Select the Password option, input the case-
sensitive password and press the Enter button.
Select the DHCP Type option and select Static.
Select the IP Address option, input the IP
Address, and press the “Enter” button.

PAX D220 Quick Setup Guide
20180801 v1.1 8 PAX Technology®
[email protected]
[phone]
www.pax.us
Select the Subnet Mask option, input the
Subnet Mask, and press the “Enter” button.
Select the Gateway IP option, input the
Gateway IP, and press the “Enter” button.
Select the DNS IP option, input the DNS IP,
and press the “Enter” button.
If the broadcast SSID is disabled on the
access point, the terminal will not display the
SSID on the available Wi-Fi network list. You
will have to manually configure the terminal
for a Static connection.
Wi-Fi Static IP Setup
(SSID Not Visible)
If you are required to setup a Wi-Fi connection with
a static IP and you know that the SSID is not visible,
perform the steps in this section.
Before you begin configuration, ensure that you
have the correct network information; IP Address,
Subnet mask, Gateway ID, passwords, etc.
Perform Steps 1 through 6 as shown in Section
8.1 D220 Basic Wi-Fi Setup.
After selecting the Wi-Fi parameters option
(Step 6), use the Right Arrow on the screen,
navigate to and select the SSID option.
Input the SSID of the desired network.
Select the Security option, select the
appropriate security type for your network and
input the case sensitive Wi-Fi network
password.
Select the DHCP Type option and select Static.
Select the IP Address option and input the IP
Address, and press the “Enter” button.

PAX D220 Quick Setup Guide
PAX Technology® 9 20180801 v1.1
[email protected]
[phone]
www.pax.us
Select the Subnet Mask option, input the
Subnet Mask, and press the “Enter” button.
Select the Gateway IP option, input the
Gateway IP, and press the “Enter” button.
Select the DNS IP option, input the DNS IP, and
press the “Enter” button.
Wi-Fi Proxy Server (Manual
Setup)
If you are required to setup a Wi-Fi connection via a
proxy server, perform the steps in this section.
Before you begin configuration, ensure that you
have the correct network information; URLs,
Address, Subnet mask, Gateway ID, passwords, etc.
Perform Steps 1 through 6 as shown in Section
8.1 D220 Basic Wi-Fi Setup.
After selecting the Wi-Fi parameters option
(Step 6), use the Right Arrow on the screen,
navigate to and Host Settings option.
Input the case-sensitive password and press
the Enter button.
Select the Host URL Params option.
Select the Auth. URLs option.
Select the Host URL 1 option.
Select the Host URL option and input the host
URL.
Press the Enter button.
Select the Host Port option and input the host
port.
If required, repeat Steps 7 through 9 for the
Host URL 2 option.

PAX D220 Quick Setup Guide
20180801 v1.1 10 PAX Technology®
[email protected]
[phone]
www.pax.us
