PCB Piezotronics IMI SENSORS 699A05 User manual

Model 699A05
4-20 mA Loop Calibrator
Installation and Operating Manual
For assistance with the operation of this product,
contact PCB Piezotronics, Inc.
Toll-free: 800-959-4464
24-hour SensorLine: 716-684-0001
Fax: [phone]
E-mail: [email protected]
Web: www.imi-sensors.com

Manual 21354 Rev E
ECN 50523
Repair and Maintenance
PCB guarantees Total Customer Satisfaction through its
“Lifetime Warranty Plus” on all Platinum Stock Products
sold by PCB and through its limited warranties on all other
PCB Stock, Standard and Special products. Due to the
sophisticated nature of our sensors and associated
instrumentation, field servicing and repair is not
recommended and, if attempted, will void the factory
warranty.
Beyond routine calibration and battery replacements
where applicable, our products require no user
maintenance. Clean electrical connectors, housings, and
mounting surfaces with solutions and techniques that will
not harm the material of construction. Observe caution
when using liquids near devices that are not hermetically
sealed. Such devices should only be wiped with a
dampened cloth—never saturated or submerged.
In the event that equipment becomes damaged or ceases
to operate, our Application Engineers are here to support
your troubleshooting efforts 24 hours a day, 7 days a
week. Call or email with model and serial number as well
as a brief description of the problem.
Calibration
Routine calibration of sensors and associated
instrumentation is necessary to maintain measurement
accuracy. We recommend calibrating on an annual basis,
after exposure to any extreme environmental influence,
or prior to any critical test.
PCB Piezotronics is an ISO-9001 certified company whose
calibration services are accredited by A2LA to ISO/IEC
17025, with full traceability to SI through N.I.S.T. In
addition to our standard calibration services, we also offer
specialized tests, including: sensitivity at elevated or
cryogenic temperatures, phase response, extended high
or low frequency response, extended range, leak testing,
hydrostatic pressure testing, and others. For more
information, contact your local PCB Piezotronics
distributor, sales representative, or factory customer
service representative.
Returning Equipment
If factory repair is required, our representatives will
provide you with a Return Material Authorization (RMA)
number, which we use to reference any information you
have already provided and expedite the repair process.
This number should be clearly marked on the outside of
all returned package(s) and on any packing list(s)
accompanying the shipment.
Contact Information
PCB Piezotronics, Inc.
3425 Walden Ave.
Depew, NY14043 USA
Toll-free: [phone]
24-hour SensorLine: [phone]
General inquiries: in[email protected]
Repair inquiries: [e-mail]
For a complete list of distributors, global offices and sales
representatives, visit our website, www.pcb.com.
Safety Considerations
This product is intended for use by qualified personnel
who recognize shock hazards and are familiar with the
precautions required to avoid injury. While our equipment
is designed with user safety in mind, the protection
provided by the equipment may be impaired if equipment
is used in a manner not specified by this manual.
Discontinue use and contact our 24-Hour Sensorline if:
Assistance is needed to safely operate equipment
Damage is visible or suspected
Equipment fails or malfunctions
For complete equipment ratings, refer to the enclosed
specification sheet for your product.
Definition of Terms and Symbols
The following symbols may be used in this manual:
DANGER
Indicates an immediate hazardous
situation, which, if not avoided, may
result in death or serious injury.

Manual 21354 Rev E
ECN 50523
CAUTION
Refers to hazards that could damage
the instrument.
NOTE
Indicates tips, recommendations and
important information. The notes
simplify processes and contain
additional information on particular
operating steps.
The following symbols may be found on the equipment
described in this manual:
This symbol on the unit indicates that
high voltage may be present. Use
standard safety precautions to avoid
personal contact with this voltage.
This symbol on the unit indicates that
the user should refer to the operating
instructions located in the manual.
This symbol indicates safety, earth
ground.

Manual 21354 Rev E
ECN 50523
PCB工业监视和测量设备 - 中国RoHS2公布表
PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table
部件名称
有害物质
铅(Pb)
汞
(Hg)
镉
(Cd)
六价铬(Cr(VI))
多溴联苯 (PBB)
多溴二苯醚(PBDE)
住房
O
O
O
O
O
O
PCB板
X
O
O
O
O
O
电气连接器
O
O
O
O
O
O
压电晶体
X
O
O
O
O
O
环氧
O
O
O
O
O
O
铁氟龙
O
O
O
O
O
O
电子
O
O
O
O
O
O
厚膜基板
O
O
X
O
O
O
电线
O
O
O
O
O
O
电缆
X
O
O
O
O
O
塑料
O
O
O
O
O
O
焊接
X
O
O
O
O
O
铜合金/黄铜
X
O
O
O
O
O
本表格依据 SJ/T 11364 的规定编制。
O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。
X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。
铅是欧洲RoHS指令2011/65/ EU附件三和附件四目前由于允许的豁免。
CHINA RoHS COMPLIANCE

Manual 21354 Rev E
ECN 50523
Component Name
Hazardous Substances
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Chromium VI
Compounds
(Cr(VI))
Polybrominated
Biphenyls (PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
Housing
O
O
O
O
O
O
PCB Board
X
O
O
O
O
O
Electrical Connectors
O
O
O
O
O
O
Piezoelectric Crystals
X
O
O
O
O
O
Epoxy
O
O
O
O
O
O
Teflon
O
O
O
O
O
O
Electronics
O
O
O
O
O
O
Thick Film Substrate
O
O
X
O
O
O
Wires
O
O
O
O
O
O
Cables
X
O
O
O
O
O
Plastic
O
O
O
O
O
O
Solder
X
O
O
O
O
O
Copper Alloy/Brass
X
O
O
O
O
O
This table is prepared in accordance with the provisions of SJ/T 11364.
O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement of GB/T 26572.
X: Indicates that said hazardous substance contained in at least one of the homogeneous materials for this part is above the limit
requirement of GB/T 26572.
Lead is present due to allowed exemption in Annex III or Annex IV of the European RoHS Directive 2011/65/EU.

Model 699A05
4-20 Milliamp Loop Calibrator
Operating Instructions
Basic Keypad Operations
1EZ-Check™ Switch
SOURCE mode: Slide the switch to select from Hi and low range pre-
set values and the mid ranger (Dial) is selectable. Dial the mid range
value and it will store the value with-in 5 seconds automatically.
READ mode: Slide the switch to recall minimum and maximum
readings. Press the EZ-Dial™ Knob to clear the stored values.
2SOURCE/OFF/READ Switch
Slide the SOURCE/OFF/READ Switch to SOURCE to
output a mA signal and to do 2 - wire transmitter
simulation. Use the READ position to read mA signal and
power & measure 2 – wire transmitter.
eEZ-Dial™ Knob
Turn the knob to change display in 0.01mA increments.
Push and turn for faster dialing. Push without turning to
clear EZ-Check™ switch HI/LO points in READ mode.
Press twice to select options:
In Source mode select –
% or mA
2-Wire Transmitter Simulate
% or mA
low power (15V) or High power (24V)
In Read mode select -
% or mA
Power and Measure 2-Wire Transmitter
% or mA
low power (15V) or High power (24V)
HART® Protocol
An internal jumper enables the Power & Measure 2 – wire
transmitter mode to be compatible with HART®
communicators and transmitters.
EZ-Dial™ Knob
Adjust the output up and down with the EZ-Dial™ knob. The increment is 0.01 mA (or 0.1 % if display units are % of 4-20 mA.)
Press while turning to adjust 10X faster – 0.10 mA (or 1.00 %.)
Quick Reference Bar Graph
The Quick Reference Bar Graph indicates the input and output level to the Model 699A05 in % of 4-20 mA with 1.0% resolution. If
the input or output signal is outside the normal operating range of the Model 699A05 the Quick Reference Bar Graph in source mode
will flash, in Read mode display over range when above 24.5mA.
Error Conditions
Bar Graph will flash when any error conditions exist.
HART® Protocol
Remove the back of the case and remove the jumper that is located in position J6 on the PC board. By doing so it places a 250
resister in series with the output of the model 699A05. This internal resister eliminates the need to add an external load resister
when communicating with a HART® transmitter. This reduces the typical drive capability to 950.

Model 699A05 Operating Instructions
EZ-Check™ Switch
The EZ-Check™ switch has three positions -- high, dial, and low. Its position is shown at the left edge of the display with “HI” and
“LO” indicators. Neither indicator indicates the middle position. Use of the EZ-Check™ switch depends on mode.
Source Modes:
Slide the EZ-Check™ switch to the HI and LO positions to recall the preset settings (Hi=20.00mA & Lo=4.00mA).
Hint: For faster calibrations, the position of the switch can be felt. This feature allows continuous monitoring of the device
being calibrated without looking back at the Model 699A05 display. This is also useful in poor lighting or under difficult
operating conditions.
Read Modes:
In read mode, the Model 699A05 calibrator records the maximum and minimum readings observed in each mode. Slide the
EZ-Check™ switch to the Dial position to read the loop. Then Slide the EZ-Check™ switch to the HI and LO positions to
display the max and min readings. Press the EZ-Dial™ knob to clear the readings. The display will flash “CLEARED” to
confirm.
Source Mode
Source mode uses internal power to supply current from 0.00-24.00 mA into as much as 1200until the end of battery life. The
calibrator Graph will flash if connected improperly. The three-position EZ-Check™ switch provides instant preset 4mA at zero, 12mA
at mid range and 20mA at full scale outputs. The output is adjusted in 0.01 or 0.10 mA increments (0.1 or 1.0) % display units with
the EZ-Dial™ knob.
2-Wire Transmitter Simulation Mode
The Model 699A05 can simulate a 2-wire transmitter in the 4-20 mA or % process loop. In source mode press the EZ-Dial™ knob
twice to get into the feature options. Then press the EZ-Dial™ knob to select mA 2 – wire. The EZ-Check™ switch and EZ-Dial™ knob
allow rapid and fine control of loop current.
T
r
ansmi
t
te
r
Input
(Senso
r
)
(P
r
ocess
eSignal) (Simulat d Inpu
t
)
Recei
v
e
r
Powe
r
0
Supply
0to 6VDC
+IN- REF +OUT-
T
y
pical
2-Wi
r
e
T
r
ansmi
t
t
e
r
T
r
ansmitte
r
Inpu
t
(Senso
r
)
(P
(S
r
o
imcess eSignal) ulat d Input)
Receive
r
Po
w
e
r
6Supply 0to 0VDC
Typical
2-Wi
r
e
T
r
ansmit
t
e
r
+ IN - REF+OUT-

Model 699A05 Operating Instructions
Power and Measure Transmitter Mode
T
r
ansmit
t
e
r
Input
(Senso
r
)
(
(P
r
Si ocess eSignal) mulat d Inpu
t
)
Receive
r
Powe
r
6Supply 0to 0
V
DC
Typical
2-Wi
r
e
T
r
ansmitte
r
+IN
-
REF +OUT-
The Model 699A05 supplies 15Volts or 24 Volts to the transmitter and displays the output in mA or % on the Model 699A05 display.
In read mode press the EZ-Dial™ knob twice to get into the feature options. Then press the EZ-Dial™ knob to select mA PWR - M.
Then turn EZ-Dial™ knob to select power range (15V or 24V). The EZ-Check™ switch and EZ-Dial™ knob allow rapid and fine control
of loop current.
Read Mode
The Model 699A05 can read loop currents from 0-24 mA. It limits current in read mode to 25mA to protect the devices in the loop
from over voltage or over current conditions.
ei
T
r
ansmitte
r
Input
(Senso
r
)
(P
r
ocess
eSignal) (Simulat d Input)
Rec ve
r
Powe
r
0
Supply
0to 6VDC
Typical
2-Wi
r
e
T
r
ansmitte
r
+IN -
R
EF +OUT-

Model 699A05 Operating Instructions
Specifications
General Specifications:
(Unless otherwise indicated all specifications are rated from a nominal 23 °C, 70 % RH for 1 year from calibration)
Operating Temperature Range -20 to 60 °C (-5 to 140 °F)
Storage Temperature Range -30 to 60 °C (-22 to 140 °F)
Relative Humidity Range 10 % RH 90 % (0 to 35 °C), Non-condensing
10 % RH70 % (35 to 60 °C), Non-condensing
Battery 2 AA Alkaline
Miscellaneous Low battery indication with nominal 1 hour of operation left
Over-voltage protection to 120 Vrms (rated for 30 seconds) or 240 Vrms (rated for 15
seconds)
Bar graph display with 1% resolution of 4-20 mA signal scale
High contrast graphic liquid crystal display with 0.45” (11.4 mm) high digits
Common Specifications for all current modes
Ranges 0.00 to 24.00 mA, 25.0 to 125.0% of 4-20 mA
Accuracy ± (0.05 % of Reading + 0.01 mA)
Temperature effect ± 50 ppm/°C of Range
Resolution(s) 0.01 mA and 0.1 %
Source/Power and Measure 2-Wire Transmitter Specifications:
Loop compliance voltage 15 Volts or 24 Volts
Loop drive capability 1200 at 20 mA for entire battery life @ 24 Volts
600 at 20 mA for entire battery life @ 15 Volts
Read mA Specifications:
Voltage burden 1V at 20 mA
Overload/Current limit protection nominal 24 mA
Battery life Typical 40 Hours
2-Wire Transmitter Simulation Specifications:
Voltage burden 2V at 20 mA
Overload/Current limit protection nominal 24 mA
Loop voltage limits 2-42 VDC
Miscellaneous or out of compliance conditions are indicated by appropriate error display
Battery life 40 hour typical
Manual Number: 32925
Manual Revision: A
ECR Number: 24875
*HART® is a registered trademark of the HART Communication Foundation
**EZ-Dial™ & EZ-Check™ are trademarks of Practical Instrument Electronics
