PCE Instruments PCE-PH 30 User manual

© PCE Instruments
PCE-PH 30 pH Meter
User Manual
User manuals in various languages (français,
italiano, español, português, nederlands, türk, polski,
русский, 中文) can be found by using our
product search on: www.pce-instruments.com
Last change: 14 July 2020
v1.0
English

© PCE Instruments
Contents
1Safety notes........................................................................................... 1
2Features ................................................................................................. 1
3Specifications........................................................................................2
3.1 Delivery contents.............................................................................................................. 3
4Device.....................................................................................................3
5Operation ............................................................................................... 4
5.1 pH calibration................................................................................................................... 4
5.2 Calibrate conductivity....................................................................................................... 4
5.3 pH measurement.............................................................................................................. 4
5.4 Conductivity measurement............................................................................................... 5
5.5 Redox measurement........................................................................................................ 5
6Key functions ........................................................................................5
7Battery.................................................................................................... 6
8Warranty.................................................................................................6
9Disposal ................................................................................................. 6

© PCE Instruments
1
1 Safety notes
Please read this manual carefully and completely before you use the device for the first time. The
device may only be used by qualified personnel and repaired by PCE Instruments personnel.
Damage or injuries caused by non-observance of the manual are excluded from our liability and
not covered by our warranty.
•The device must only be used as described inthis instructionmanual. If used otherwise,
this can cause dangerous situations for the user and damage to the meter.
•The instrument may only be used if the environmental conditions (temperature, relative
humidity, …) are within the ranges stated in the technical specifications. Do not expose
the device to extreme temperatures, direct sunlight, extreme humidity or moisture.
•Do not expose the device to shocks or strong vibrations.
•The case should only be opened by qualified PCE Instruments personnel.
•Never use the instrument when your hands are wet.
•You must not make any technical changes to the device.
•The appliance should only be cleaned with a damp cloth. Use only pH-neutral cleaner,
no abrasives or solvents.
•The device must only be used with accessories from PCE Instruments or equivalent.
•Before each use, inspect the case for visible damage. If any damage is visible, do not
use the device.
•Do not use the instrument in explosive atmospheres.
•The measurement range as stated in the specifications must not be exceeded under
any circumstances.
•Non-observance of the safety notes can cause damage to the device and injuries to
the user.
We do not assume liability for printing errors or any other mistakes in this manual.
We expressly point to our general guarantee terms which can be found in our general terms of
business.
If you have any questions please contact PCE Instruments. The contact details can be found at
the end of this manual.
2 Features
•6 in 1 pH tester
•IP57 housing
•Automatic temperature compensation
•Battery operation
•3-point pH calibration
•Exchangeable electrodes
•Max-Min hold function
•Automatic electrode recognition

© PCE Instruments
2
3 Specifications
Measuring function
pH
Measurement range
-2 ... 16 pH
Resolution
0.01 pH
Accuracy
± 0,01pH + 1 dgt
ATC
0 ... 90°C / 32 ... 194°F
Calibration
pH 4, 7, 10
Measuring function
Redox
Measurement range
± 1000 mV
Resolution
1 mV
Accuracy
± 2 mV + 1 dgt
Measuring function
Conductivity
Measuring range
0 ... 2000 μS, 2 ... 20 mS
Resolution
1 μS, 0.01 mS
Accuracy
± 2% of measurement range
ATC
0 ... 50°C / 32 ... 122°F
Calibration
0 μS, 1413 μS, 12.88 mS
Measuring function
TDS
Measurement range
0 ... 1300 ppm, 1.3 ... 13 ppt
Resolution
1 ppm, 0.01 ppt
Accuracy
± 2% of measurement range
ATC
0 ... 50°C / 32 ... 122°F
Measuring function
Salinity
Measurement range
0 ... 1000 ppm, 1 ... 12 ppt
Resolution
1 ppm, 0.01 ppt
Accuracy
± 2% of measurement range
ATC
0 ... 50°C / 32 ... 122°F
Measuring function
Temperature
Measurement range
0 ... 90°C / 32 ... 194°F
Resolution
0.1°C / 0.18°F
Accuracy
± 0.2°C / 0.36°F + 1 dgt
Display
LCD
Power supply
4 x 1.5V AAA battery
Dimensions
195 x 40 x 36 mm / 7.7 x 1.6 x 1.4 in
Weight
About 135 g / < 1 lb

© PCE Instruments
3
3.1 Delivery contents
1 x pH meter PCE-PH 30
1 x pH electrode
1 x conductivity electrode
1 x pH 4 calibration liquid
1 x pH 7 calibration liquid
1 x 1413 μS / cm calibration liquid
1 x storage solution
1 x wrist strap
4 x 1.5 V AAA battery
1 x user manual
4 Device
Battery compartment
Display
pH electrode
Conductivity electrode
Electrode
Sensor
Measuring
mode
Hold/Max & Min
button
On/off / calibration
Electrode closure

© PCE Instruments
4
5 Operation
Remove the black protective cap from the device and optionally unscrew the electrode cap if you
want to use a different electrode. To change the electrode, you can simply remove it and attach
another one.
Note: Do not touch the sensors of the electrodes!
5.1 pH calibration
Since the electrode is subject to a time drift, it should be calibrated regularly. The interval depends
on the intended use and the required accuracy.
•Make sure that the pH electrode is mounted and the pH icon is shown on the display.
•Clean the electrode with distilled water.
•Immerse the electrode in the calibration solution pH 7, stir carefully and wait until the
value has stabilized.
•Press and hold the CAL key until "Cal" and the calibration value are displayed.
•Calibration is performed automatically and is finished when "End" is displayed. The
instrument returns to measuring mode.
•Clean the electrode with distilled water.
•Now repeat the calibration with the pH 4 calibration solution.
Notes:
•Always carry out a two-point calibration. Start at pH 7, followed by pH 4 (or 10).
•When not using the pH electrode, always keep the electrode moist with the storage
liquid.
5.2 Calibrate conductivity
1. Make sure that the conductivity electrode is mounted to the instrument. The display
shows COND, TDS or Salt.
2. Immerse the conductivity electrode in the 1413µS/cm calibration solution and wait until
the measured value has stabilized.
3. Press and hold the CAL button until "Cal" is displayed and thecalibration value flashes.
Calibration is performed automatically and is finished when "End" is displayed. The
instrument returns to measuring mode.
Notes:
•A calibration with 12.88mS/cm can also be performed optionally. It is suitable for
measurements with high conductivity.
•If the measured value is not 0µS/cm in air after calibration, calibrate the instrument in
air.
5.3 pH measurement
1. Clean the pH electrode with distilled water.
2. Dip the electrode tip into the liquid to be examined and move the tip slightly back and
forth.
3. Wait briefly until the display shows a stable pH value.

© PCE Instruments
5
5.4 Conductivity measurement
1. Clean the conductivity electrode with distilled water.
2. Dip the electrode tip into the liquid to be examined and move the tip slightly back and
forth.
3. Wait briefly until the display shows a stable value.
Notes:
•The display shows "----- " if the value exceeds the measurement range.
•The measuring unit changes automatically depending on the measurement range.
•Clean the electrode with distilled water after the measurement.
5.5 Redox measurement
1. Make sure that the conductivity electrode is mounted on the instrument. The display
automatically shows "ORP". Calibration is not necessary but can be performed to check
the ORP electrode with the appropriate calibration solution.
2. Clean the electrode with distilled water and immerse it in the liquid to be measured.
3. Wait for a short time until a stable value is displayed.
Notes:
•The display shows "----- " if the value exceeds the measurement range.
•When not using the electrode, always keep the electrode moist with the storage liquid.
•
6 Key functions
On/off / calibration key
1. Press and release the key to switch the unit on or off.
2. Press and hold the key while the instrument is switched on to enter calibration mode.
Measuring key
1. Press the key to switch between the measuring functions conductivity, TDS and
salinity. This is only possible with the conductivity electrode!
2. Press and hold the key to toggle between degrees Celsius and degrees Fahrenheit.
Hold/Max&Min key
1. Press and release the key to freeze the displayed value.
2. Press and hold the key to enter the max/min selection. Press and release the key
again to toggle between Max and Min.
3. Press and hold the key again to exit the Max/Min mode.
Note:
•The display does not switch off automatically in Max/Min mode.

© PCE Instruments
6
7 Battery
When the battery icon flashes, replace the batteries as follows:
1. Loosen the 2 screws at the top of the battery compartment.
2. Open the battery compartment and replace the 4 AAA batteries. Observe correct
polarity.
3. Close the battery compartment and tighten the screws.
8 Warranty
You can read our warranty terms in our General Business Terms which you can find here:
https://www.pce-instruments.com/english/terms.
9 Disposal
For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament
applies. Due to the contained pollutants, batteries must not be disposed of as household waste.
They must be given to collection points designed for that purpose.
In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use
them or give them to a recycling company which disposes of the devices in line with law.
For countries outside the EU, batteries and devices should be disposed of in accordance with
your local waste regulations.
If you have any questions, please contact PCE Instruments.

© PCE Instruments
7
