Peak PCAN-PC/104-Plus User manual

PCAN-PC/104Plus
User Manual
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH

Relevant Products
Product name Model Part number
PCAN-PC/104Plus SingleChannel One CAN channel IPEH-002094
PCAN-PC/104Plus DoubleChannel Two CAN channels IPEH-002095
PCAN-PC/104Plus SingleChannel
opto-decoupled
One CAN channel, galvanic isolation for
CAN connection IPEH-002096
PCAN-PC/104Plus DoubleChannel
opto-decoupled
Two CAN channels, galvanic isolation for
CAN connection IPEH-002097
The cover picture shows the product PCAN-PC/104Plus DoubleChannel opto-decoupled. Other product
versions have an identical form factor but vary in equipment.
Imprint
PCAN is a registered trademark of PEAK-System Technik GmbH. CiA® is a registered community trade mark
of CAN in Automation e.V.
All other product names in this document may be the trademarks or registered trademarks of their
respective companies. They are not explicitly marked by ™ or ®.
© 2022 PEAK-System Technik GmbH
Duplication (copying, printing, or other forms) and the electronic distribution of this document is only
allowed with explicit permission of PEAK-System Technik GmbH. PEAK-System Technik GmbH reserves the
right to change technical data without prior announcement. The general business conditions and the
regulations of the license agreement apply. All rights are reserved.
PEAK-System Technik GmbH
Otto-Röhm-Straße 69
64293 Darmstadt
Germany
Phone: [phone]
Fax: [phone]
www.peak-system.com
[email protected]
Document version 3.0.1 (2022-04-21)
Relevant Products PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
2

Contents
Imprint 2
Relevant Products 2
Contents 3
1 Introduction 4
1.1 Properties at a Glance 5
1.2 System Requirements 5
1.3 Scope of Supply 5
2 Configuration 7
2.1 Position in the PC/104-Plus Computer 7
2.2 Voltage Supply of External Devices 8
2.3 Notes for the ISA Bus Stack-through Connection 10
3 Installation 11
3.1 Install Device Driver Setup 11
3.2 Install CAN interface 12
3.3 Check Operational Readiness 13
4 Connecting the CAN Bus 14
4.1 Connection over D-Sub Connector 14
4.2 Cabling 14
4.3 Example Application under Windows 16
5 CAN Monitor PCAN-View 17
5.1 CAN interface initialize 18
5.2 Transmit CAN message 20
5.3 Additional Tabs 21
6 API PCAN-Basic 26
6.1 Features of PCAN-Basic 27
6.2 Principle Description of the API 28
7 Technical Data 29
Appendix A CE Certificate 31
Appendix B Dimension Drawings 32
Appendix C Quick Reference 33
Appendix D Linux 35
Contents PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
3

1 Introduction
The CAN interface PCAN-PC/104Plus for a PC/104-Plus computer is available as a
version with one or two channels. The CAN bus is connected via a 9-pin D-Sub
connector on the supplied slot bracket. Operation of up to four CAN interfaces
plugged into each other is possible.
Galvanic isolation up to 500 V for each CAN channel protects against the transmission
of electrical interference peaks between the CAN channels and the computer.
The monitor software PCAN-View and the programming interface PCAN-Basic for the
development of applications with CAN connection are included in the scope of
supply.
Device drivers exist for different operating systems, so programs can easily access a
connected CAN bus.
This manual describes the use of the CAN interface with Windows.
Device drivers and application information for Linux:
www.peak-system.com/quick/DL-Driver-E
At the end of this manual you can find a Quick Reference with brief
information about the installation and operation of the CAN interface.
1 Introduction PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
4

1.1 Properties at a Glance
■Form factor PC/104
■Use of the 120-pin connection for the PCI bus
■Up to four cards can be used in one system
■1 or 2 High-speed CAN channels (ISO 11898-2)
■Bit rates from 5 kbit/s up to 1 Mbit/s
■Complies with CAN specifications ISO 11898-1 for CAN
■Connection to CAN bus through D-Sub slot brackets, 9-pin
(in accordance with CiA® 303-1)
■NXP SJA1000 CAN controller, 16 MHz clock frequency
■NXP PCA82C251 CAN transceiver
■Voltage supply for external devices via CAN connection can be connected through
a solder jumper
■Galvanic isolation up to 500 V per CAN connection
(only for IPEH-002096 and IPEH-002097)
■Extended operating temperature range from -40 to +85 °C (-40 to +185 °F)
■Optional available: PC/104-ISA stack-through connector
1.2 System Requirements
PC/104-Plus computer with Operating system Windows® 11 (64 bit), 10 (32/64 bit) or
Linux(32/64-bit)
1.3 Scope of Supply
■CAN interface PCAN-PC/104Plus
■Slot bracket with D-Sub connectors for the CAN bus
1 Introduction PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
5

Downloads
■Device drivers for Windows® 11 (64 bit), 10 (32/64 bit) and Linux (32/64-bit)
■CAN monitor PCAN-View for Windows
■Programming interface PCAN-Basic for developing applications with CAN
connection
■Programming interfaces for standardized protocols from the automotive sector
1 Introduction PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
6

2 Configuration
Before installing the CAN interface into a PC/104-Plus computer, you must configure
it using jumpers on the PCB.
Attention! Electrostatic discharge (ESD) can damage or destroy
components on the card. Take precautions to avoid ESD.
2.1 Position in the PC/104-Plus Computer
The CAN interface must be adjusted to a specific position in the stack by setting the
appropriate jumpers. The position number results from the distance to the host.
2 Configuration PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
7

Position in the PC/104-Plus computer
Jumper Signal 1 2 3 4
J7 ID Select 0 1 2 3
J8 Clock Select 0 1 2 3
J9 Interrupt Select A B C D
2.2 Voltage Supply of External Devices
Attention! The voltage supply for external devices is not protected
separately. Therefore, turn off the computer before you connect and
disconnect CAN cables or peripheral systems. Consider that some
computers still supply the USB ports with power even when they are
turned off (standby operation).
Optionally, an external voltage supply can be connected separately for each CAN
channel via solder bridges at pin 1 and/or pin 9 on the D-Sub connector. This allows
external devices to be supplied with a voltage of 5 V DC, for example bus converters
(PCAN-TJA1054 for Low-Speed-CAN). Pin 1 and pin 9 are not connected at delivery.
The current output is limited to
■100 mA without galvanic isolation.
■50 mA with galvanic isolation.
The lower current output of the versions with galvanic isolation is due to an
intermediate DC/DC converter.
2 Configuration PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
8

2.2.1 Activate voltage supply
Risk of short circuit! Soldering on the CAN interface may only be
performed by qualified electrical engineering personnel.
Attention! Electrostatic discharge (ESD) can damage or destroy
components on the card. Take precautions to avoid ESD.
Set the solder bridge(s) on the card according to the desired settings.
2 Configuration PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
9

5-Volt supply
D-Sub connector Solder field Without
(Standard)
Pin 1 Pin 9 Pin 1 and
pin 9
CAN 1 JP1
CAN 2 JP2
2.3 Notes for the ISA Bus Stack-through Connection
If you want to use additional modules in the PC/104 stack being connected via the
ISA bus, the connections J1 and J2 must be equipped with stack-through connectors.
On request you get a respective version of the CAN interface.
Taking the host as point of view, PC/104 modules with ISA bus must be plugged onto
the stack behind any module with PCI bus. The signals of the ISA bus are connected
through and not used by the CAN interface PCAN-PC/104Plus.
2 Configuration PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
10

3 Installation
This chapter covers the software setup for the CAN interface PCAN-PC/104Plus under
Windows and the installation of the CAN interface into the PC/104 computer.
Note: For installation on Linux, see Appendix D Linux.
Install the driver before you install the CAN interface.
3.1 Install Device Driver Setup
1. Download the device driver setup from our website:
www.peak-system.com/quick/DL-Driver-E
2. Unpack the file PEAK-System_Driver-Setup.zip
3. Double-click the file PeakOemDrv.exe
The driver setup starts.
4. Follow the program instructions.
3 Installation PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
11

3.2 Install CAN interface
Attention! Electrostatic discharge (ESD) can damage or destroy
components on the card. Take precautions to avoid ESD.
1. Connect one cable per CAN connection from the slot bracket to a 10-pin socket
on the CAN interface.
2. Shut down the computer.
3. Disconnect the computer’s power supply.
4. Insert the CAN interface into the PC/104-Plus computer at the position configured
before (Position 1 to 4).
3 Installation PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
12

5. Install the slot bracket.
6. Reconnect the computer power supply.
7. Turn on the computer and start Windows.
Windows detects the new hardware and completes the driver installation.
3.3 Check Operational Readiness
1. Open the Windows Start menu.
2. Type Peak Settings and press |Enter|.
The window PEAK Settings appears.
3. Select CAN Hardware.
The connected CAN interface is displayed.
Under Windows the CAN interface PCAN-PC/104Plus is run as a PCI
card.
3 Installation PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
13

4 Connecting the CAN Bus
4.1 Connection over D-Sub Connector
After the slot bracket has been connected to the CAN interface a CAN bus can be
connected to the D-Sub connector. The pin assignment of the D-Sub connector
corresponds to the specification CiA® 303-1:
10-pin connector
on CAN interface
D-Sub plug on
slot bracket, 9-pin
Assignment
1 1 +5 V (optional)
2 6 GND
3 2 CAN_Low
4 7 CAN_High
5 3 GND
8 9 +5 V (optional)
6, 7, 9, 10 4, 5, 8 None
4.2 Cabling
4.2.1 Termination
The High-speed CAN bus (ISO 11898-2) must be terminated with 120 Ω on both ends.
The termination prevents interfering signal reflections and ensures the proper
operation of the transceivers of the connected CAN nodes (CAN interfaces,
controldevices).
The CAN interface PCAN-PC/104Plus does not have an internal termination. Use the
CAN interface on a terminated CAN bus.
4 Connecting the CAN Bus PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
14

4.2.2 Example of a Connection
This example shows a connection between the PCAN Interface and a control unit
(ECU). The upper example shows a connection with a cable which is terminated with
120 Ω at both ends. At the lower example the connection is made with termination
adapters.
4 Connecting the CAN Bus PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
15

4.2.3 Maximum Bus Length
The maximum bus length depends primarily on the bit rate:
Nominal bit rate Buslength
1 Mbit/s 40 m
500 kbit/s 110 m
250 kbit/s 240 m
125 kbit/s 500 m
50 kbit/s 1.3 km
20 kbit/s 3.3 km
10 kbit/s 6.6 km
5 kbit/s 13 km
The listed values have been calculated on the basis of an idealized system and can
differ from reality.
4.3 Example Application under Windows
As an example application for accessing the CAN interface, run the CAN monitor
PCAN-View from the Windows Start menu.
4 Connecting the CAN Bus PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
16

5 CAN Monitor PCAN-View
The CAN monitor PCAN-View is a Windows software for viewing, sending, and
recording CAN and CAN FD messages. The software is installed with the installation
of the device driver package under Windows.
In the following the initialization of a CAN interface is described as an example.
Detailed information about using PCAN-View can be found in the program window
under the menu item Help.
5 CAN Monitor PCAN-View PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
17

5.1 CAN interface initialize
1. Open the program PCAN-View via the Windows Start menu.
Depending on the CAN interface the Connect dialog is displayed with or without
settings for CAN FD.
CAN CAN FD
CAN interface List entry in Available Hardware
USB Interface, 1-channel see example above
USB Interface, 2-channel
PCIe Interface, 2-channel
2. If there are several CAN interfaces, select the desired interface. For multiple
channels, select the desired channel from the list.
3. Enter the bit rate(s) and other settings according to the connected CAN bus.
5 CAN Monitor PCAN-View PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
18

4. Confirm the entries with OK. The main window appears and displays the Receive /
Transmit tab.
5. For initializing another channel or CAN interface, open another instance of PCAN-
View.
5 CAN Monitor PCAN-View PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
19

5.2 Transmit CAN message
1. Select the menu command Transmit / New Message.
Depending on the CAN interface, the dialog box New Transmit Message is
displayed with or without settings for CAN FD.
CAN CAN FD
1. Enter the ID,Length and Data of the message. Other settings can be made
according to the connected CAN bus.
2. Enter a value into the Cycle Time field to choose manually or periodically message
transmission.
Enter a value greater than 0 to transmit periodically.
Enter the value 0 to transmit only manually.
3. Confirm the entries with OK.
The created transmit message appears on the Receive / Transmit tab.
4. To send the message manually, select the menu command Transmit > Send or
press the |space|bar.
The manual transmission process is performed additionally for periodically
transmitted CAN messages.
5 CAN Monitor PCAN-View PCAN-PC/104Plus
User Manual 3.0.1 © 2022 PEAK-System Technik GmbH
20
