Peak Brado User manual

1. Ergonomic Grips
2. Brake Lever
3. Seating area with drawstring
4. Hook for bag
5. Locking screw for Height Adjustment
6. Kerb Climbing Assistance
7. Brakes
8. Wheel
Brado Rollator Parts
1
2
.
3
2
.
5
2
.
6
.
7
.
4
.
8
.

The Brado –simple and user-friendly
Up / unfold 1. rollator
Place the rollator in the direction of travel and actuate the parking break.
Print with both hands the side tubes of the seat surface left and right
down to the folding mechanism locks into place.
Only then mesh pocket, bag or basket in the throw holder provided
hang.
2. Adjust handle Height
Solve urn set screw 5-6 turns (the screw must not be out completely)
and set the desired height by pushing in or pulling the push handles.
The push handles latch into increments of 25 mm.
Turn the locking screw again. The locking screw must not be
tightened between the predetermined locking positions. After
tightening, the screw can be accommodated by pulling in a
vertical position, thereby interfering less.
between the predetermined locking positions. After tightening the
3. Brake
Service Brake (when pushing): Pull the lever up.
Fasten the break (for parking): You push the lever down.
4. Brake Adjustment
The brake is correctly adjusted, even if the brake levers like those
Bowden cables a play do not exhibit themselves and the wheels without
sharpening noises to turn leave.
The braking action can be set using the adjusting screw of the
Bowden cable to the brake pads the rear wheels.
5. Climbing
Raising the steering wheels is relieved by applying pressure with the toe
the prolonged so frame.

The Brado –simple and user-friendly
6. Fold Walker
Take the mesh pocket or bag on the frame.
Pull the locking band in the center of the seating surface upward -
the rollator folds together.
Safety
Do not hang Pockets on the handles - Tipping!
Use on downhill because the service brake (Pull the lever up).
Use the rollator on firm, level ground.
If too much lean on the handles of the walker from tipping
backwards.
When folding the walker clothing and body parts can be clamped.
Please note that padded parts that are exposed to direct
sunlight, heat up and can cause skin injuries in tubing.
Therefore, cover these parts or protect the rollator from
sunlight.
Cleaning / maintenance / re-use
Maintenance
The walker brado is maintenance free. If you notice a decrease in
the brakes, the wheels binding or other functional limitations, then
bring the walker to be serviced by your local dealer.
Re-use
Please keep in mind when passing the walker to the new user,
necessary for safe handling technical documentation to upper
Enter. The rollator must by retailers - as above - checked, cleaned
and re-use for in perfect condition be added.
Cleaning
Cleaning and disinfection must in regular distances traveled by.
Use soapy water without abrasive additives.
The disinfection You can drove through with commercial
means. Use no Steam jet devices and abrasive or caustic
cleaning agents.
Technical Data
Type S / M
Type S
Type M
High:
67-82 cm
78-102 cm
High folded:
67 cm
78 cm
Seat height:
52.5 cm
62.5 cm
Height adjustment of the push
handles in 25 mm steps:
0-15 cm
0-24 cm
Frame High adjustable:
8 times
10 times
Lange:
66 cm
Width:
60 cm
Width folded:
22 cm
. Max user weight:
150 kg
Max. Load net / bag:
5 kg
Net weight:
7.1 kg
Tires (puncture proof):
20 x 3 cm
Type S / M
Type S
Type M
High:
67-82 cm
78-102 cm
High folded:
67 cm
78 cm
Seat height:
52.5 cm
62.5 cm
Height adjustment of the push
handles in 25 mm steps:
0-15 cm
0-24 cm
Frame High adjustable:
8 times
10 times
Lange:
66 cm
Width:
60 cm
Width folded:
22 cm
. Max user weight:
150 kg
Max. Load net / bag:
5 kg
Net weight:
7.1 kg
Tires (puncture proof):
20 x 3 cm

3/10
The Brado –simple and user-friendly
Scope of Delivery
- Rollatorbrado
- Mesh pocket
- Instruction Warranty
- Card
Guarantee
The warranty period is 5 years on the aluminum frame, for all
remaining portions 24 months.
Worn parts are excluded from the Guarantee.
General
For the here described Rollator is the conformity according to
the EC Directive 93/42 for medical devices explained.
This manual is part of the delivery. They must be ready for the user
and will continue to pass the product with the product.
Changes due to technical advancements against over the in this
Instructions versions described above, we reserve ourselves.
Reproduction, translation and reproduction in any Form, even in
part, require the written consent of the manufacturer.
These instructions can be no changes approximation service. For
current information, please check with us.
Indications and Usage
The hinged under the seat surface mesh pocket is provided for
transporting objects and goods. Please do not rely on the mesh
pocket.
The walker brado may only be used on firm, level ground. The use for
other purposes, especially the use as Uphill or Transporting heavy loads
is improper and dangerous!
The walker brado serves limited mobility people with max.150 kg
body weight as a walking aid and limited Seating for of transient
resting.
