User Manual
Ellipse Lite Aluminum Outdoor Rollator
With Disc Brake and Suspension

Ellipse Lite Outdoor Ver.1.0 I Nov. 2017
2
Thank you for purchasing the Peak-Care Ellipse Lite Outdoor Rollator.
The Walking aid is suitable for a single user with limited mobility. The Ellipse Lite
Outdoor Rollator is ideal for outdoor use.
Kindly take time to go through this manual which gives you more details about
your Ellipse Lite Outdoor Rollator. Kindly keep this booklet handy and use it as and
when required.
Ellipse Lite Outdoor Rollator is warrantied to be free of defects in material and
workmanship for twelve months from the date of purchase
This device was built to exacting standards and carefully inspected prior to packing
and shipping. This warranty is an expression of our confidence in the materials, our
workmanship and an assurance of the same to our customers.
In the event of a defect covered by this warranty, we will at our option supply parts
or replace the unit.
This warranty does not cover device failure due to owner’s misuse or negligence or
normal wear and tear. This warranty does not extend to nondurable components
such as rubber accessories, castors and grips, which are subject to normal wear
and need periodic replacement.
If you have any queries, please contact the distributor
Kindly attach your receipt to this booklet

Ellipse Lite Outdoor Ver.1.0 I Nov. 2017
3
3
1
4
3
5
6
7
8
9
10
12
11
PARTS LIST
INTRODUCTION
The Walking aid is suitable for a single user with limited mobility. The Ellipse Lite Outdoor is ideal
for outdoor use.
ELLIPSE LITE OUTDOOR PACK INCLUDES
1 Ellipse Lite
Outdoor Rollator
2 Bag
3 Back Rest
4 User Manual
1. Handgrip 7. Seat
2. Adjustable tubing hand grip 8. Bag
3. Rear reflector handgrip 9. Front wheel
4. Brake lever 10. Brake adjust screw
5. Interlock button for handgrips 11. Rear wheel
6. Back Rest 12. Safety bow
2

Ellipse Lite Outdoor Ver.1.0 I Nov. 2017
4
UNFOLDING ELLIPSE LITE OUTDOOR
Position Ellipse on its safety bow and lift it up
Push downwards on the seat rails to engage the locking mechanism.
HEIGHT ADJUSTMENT
Press the red release button located below the handgrips as shown and at
the same time either push the handle down (lowering handle height) or pull
the handle up (raising handle height), releasing the push button will
automatically lock the handle at desired height.
ATTACHING THE CARRY BAG
Fold Ellipse Lite Outdoor, Remove the stopper from the tube on either side of the seat, push the
sliding block from bag into the guiding sleeve and put the stopper back in place.

Ellipse Lite Outdoor Ver.1.0 I Nov. 2017
5
BRAKING / LOCKING
Walking brake: holding the lever for stop
Parking brake: using the finger to hold the small switch and pull the lever; it can be parked at the
third position.
Free parking brake: holding the brake lever and the small switch will release automatically; in the
meantime, to release the parking brake for using rollator freely.

Ellipse Lite Outdoor Ver.1.0 I Nov. 2017
6
ADJUSTMENT OF BRAKES
To adjust the braking strength, adjust the brake by pressing the screw housing downwards and
then left or right
SITTING
Position the Ellipse Lite Outdoor on an even and solid surface.
Lock the brakes (parking position). The Ellipse Lite must stand and must
not slip.
Sit straight up and do not lean backwards
FOLDING/ TRANSPORT/ STORAGE
To fold, pull seat upwards by the handle of the seat plate
Once the Ellipse Lite Outdoor is folded, use the red safety clip to secure the seat. This will stop the
walker from opening whilst lifting in or out of a vehicle. See below:

Ellipse Lite Outdoor Ver.1.0 I Nov. 2017
7
CLEANING AND MAINTENANCE
Clean regularly by hand with a damp cloth. Do not use aggressive detergents.
SAFETY INSTRUCTIONS
Do not propel yourself or have anyone push you whilst you are seated on the Rollator. This is a
walking aid only and is not to be used as a transportation device.
Use only as walking aid
Use only on even and solid surfaces
Maximum user weight: 136 Kg
Regularly check the screws and fasteners on the Ellipse Lite Outdoor and retighten if necessary.
Use bag only for transport of objects and do not overload. Maximum load: 5 Kg
Do not expose the product to temperatures above 40 °C for an extended period of time, as this can
cause the Ellipse Lite Outdoor parts to overheat and burn the user
Please make sure the Rollator is fully opened, seat is down and the folding bar under seat is locked
in the down position.
Ensure that both knobs are fully tightened and are at equal heights. Test Rollator for stability before
applying full weight to hand grips.
Test the brake lever before operating the Rollator. When wheels are locked, lock bar on rear wheels
should prevent wheels from turning. When locks are released, the wheels should turn freely.
Always lock the brake lever before sitting and do not use seat when unit is on an incline or uneven
ground.
Replace castors when tyres are significantly worn or damaged.
SPECIFICATIONS
Outdoor
Overall length
495mm
Overall width
525mm
Handle (Highest)
1015mm
Handle (Lowest)
895mm
Seat depth
260mm
Seat width
525mm
Seat height
560mm
Product weight
10.5Kg
Weight limit
136kg
Wheel diameter Rear
280mm
Wheel diameter Front
280mm
Level 1, 149 Princes Highway
Unanderra NSW 2526
Australia
Tel: [phone]. Fax: [phone]
www.peak-care.com.au
Distributor:
