Peak Powerup Toilet Lift User manual

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
SAFETY INSTRUCTIONS
•Maximum load capacity is 200 Kg
Repair and services
1) This product provides worldwide warranty, 1 year of warranty
for a whole unit, lifetime maintenance services;
2) This equipment (excluding the battery) can be used more than
10,000 times in the case of the user uses and takes good
Maintenance according to the User Manual;
3) All equipment components are not allowed to repair by user
themselves, contact the authorized dealer for overhauling.
Level 1, 149 Princes Highway
Unanderra NSW 2526
Australia
Tel: [phone]. Fax: [phone]
www.peak-care.com.au
Peak Powerup Toilet Lift
User Manual
Distributor:
Rehab and Mobility
6-8 Imboon Street, Deception Bay QLD
1300 368 085
[email protected]
www.rehabandmobility.com.au

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
Thank you for purchasing the Peak Powerup Toilet Lift.
Kindly take time to go through this manual which gives you more
details about your Powerup Toilet Lift. Kindly keep this booklet
handy and use it as and when required.
Peak Powerup Toilet Lift is warrantied to be free of defects in
material and workmanship for twelve months from the date of
purchase. This device was built to exacting standards and carefully
inspected prior to packing and shipping. This warranty is an
expression of our confidence in the materials, our workmanship
and an assurance of the same to our customers.
In the event of a defect covered by this warranty, we will at our
option supply parts or replace the unit.
This warranty does not cover device failure due to owner’s misuse
or negligence or normal wear and tear. This warranty does not
extend to nondurable components such as clips which are subject
to normal wear and need periodic replacement.
If you have any queries, please contact the distributor.
Content
Packing and module
1. Package internal modules
Product installation
2. Installation of battery
3. Installation of handrail
4. Installation of backrest
5. Installation of the arm support
6. Adjustment of support feet
7. Fixing with the toilet
Using method
8. Switch using instruction
9. Using method of charger
Product specification
10. Product dimension
11. Technical specification
Maintenance and services
12. Equipment cleaning
Kindly attach your receipt to this booklet

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
1. Packing and module
Check all components after unpacking, if any missing or
damaged, please contact the supplier.
Package list
•Main part A：toilet lift seat base 1unit
•Handrail B (with control switch);
•Handrail C (with SOS alarming button);
•battery D (one matching cell has been inserted into
base main part A);
•Power supply E (For charging battery);
•Back bracket
•Backrest G (backrest function)
•Arm support H
•Remote control I
•Qualified Certificate and User Manual
F

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
2. Installation of Lithium battery
When using the battery for the first time or the battery has
been unused for a long time, fully charge the battery first. The
charging time is around 2-3 hours allowing more than 100
times operating circles.
1) Insert the charger interface to the charging interface of
battery and connect the power supply (Figure 1);
2) The indicator of the charger light on and shows red to
indicate that it is charging.
3) When battery is full, the indicator on the charger turns
green;
4) Insert the battery to the battery box of the equipment
(Figure 2);
5) The power display is located in the position shown in Figure
3. To save power, the battery is only displayed during the
operation of the device. The display only shows the last lamp,
and when it is red, it means that the battery is low and need to
be charged immediately.
6) Take out the battery after lifting the equipment seat ring, or
else the battery may not be taken out normally.
Proposed purchase a spare battery, the battery can be charged
to another, alternately use
Attentions: Make sure the battery surface is not covered by
anything, charging in the bathroom or any moist places is not
allowed. Dry hands during charging process. Only charger
provided by manufacturer is allowed for the battery charging.
Figure 1 battery charging diagram
Figure 2 Installation of battery
Figure 3 Power quantity display

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
3. Installation of handrail
Referring to Figure 4567689, the handrail base is fixed with
screws on the base main part A.
Figure 4 Installation of handrail
Install the handrail with the control switch circuit. Do not pull
during the process to avoid cable damage.
4. Installation of backrest
Installation of backrest Bracket is shown in Figure 5, prematch
both terminals of the Bracket tube with the connecting
blocks, then press down the Bracket until to the connecting
screw holes matched, fix them by screws. Press the backrest
onto the backrest support tube.
Figure 5 Installation of backrest support and backrest
4-8

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
5. Installation of arm support
Installation of arm support is shown in Figure 6, first to press the
arm support onto the handrails in both sides, and then fix it by
screws and nuts;
Figure 6 Installation of arm support
6.Adjustment of support feet
4 support feet (can be replaced by 4 brake wheels) are adjusted
to the minimum height already. Users measure the height
between the upper edge of the toilet ceramic base and the
ground by paper ruler which can be found in the tool bag.
Rotate support feet (Figure 8) to change the height of the
equipment adjusting the crossbeam at the back of the
Rotate support feet (Figure 7) to change the height of the
equipment adjusting the crossbeam at the back of the
equipment to around 1cm away from the upper side of the
toilet ceramic base (as shown in Figure 8). Avoid the equipment
contacting the toilet.
Figure 7 Adjustment of support feet
Figure 8 Confirm the height of seat ring

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
Attentions: Adjust 4 support feet making the equipment to be
stable, ensure the ring cover surface is in horizontal position,
and make sure the height of the back-edge of seat ring is
higher than that of the toilet upper side, or else the equipment
may not work normally.
7. Fixing with the toilet
1) Remove the cover of the toilet and the fixed screws, only
remain the toilet ceramic base
2) Lift the device (the seat to the lowest state) and move it to
the top of the toilet base and slowly lower it to ensure that the
device seat does not touch the toilet base.
3) Check the position of the equipment on the toilet, avoid the
equipment colliding with the toilet in using process.
4) for those poor body balance users, the crossbeam of the
equipment main part A must be fixed with the toilet by bolts
(as shown in Figure 9, Figure 10).
Fixing mode 1: (directly fixed by bolts)
Figure 9 Equipment is fixed with the toilet by bolts
Fixing mode 2: (For special hole position of the toilet, first to adjust the distance
by an extension part and then fix it)

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
Figure 10 Fix the equipment with the toilet after adjusted the
distance by an extension part
8. Switch using Manual
1) Power switch
Figure 11 Use of power switch
2) The control switch of the equipment is in the front of handrail
B, users can continuously press the left and right key to control
the rise and fall of the equipment (as shown in Figure 12). The
equipment stops running when releasing the switch.
Figure 12 Use of control switch
9. Using method of charger
1) charge the battery
Insert charger plug to the charging port of battery and connect
the power supply (as shown in Figure 13). The charger indicator
turns red during charging, it turns green means full battery.
Figure 13 Cell charging diagram

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
2) supply the power the equipment
Insert the charger to the power interface of the equipment and
connect the power supply (as shown in Figure 14). battery
should inserted to the Battery box.
Figure 14 supply the power of the equipment
10. Product dimensions
Product dimensions is shown in Figure 15
1. Width: 607mm
2. Length: 525mm
3. Height: 790mm
4. Distance of the handrail: 456mm
5. Distance of the machine base: 425mm
6. Minimum height of seat: 386mm
Figure 15 Product dimensions
11. Technical specifications
Maximum loading: 200kg/kg
Power voltage: 220V
battery output nominal voltage: Direct current 24V
Working voltage: 24V
Product rated power: 130w
Water-proof grade: IP44

Peak Powerup Toilet Lift
Peak Powerup Toilet Lift
12. Equipment cleaning
1) Clean the equipment by gentle, non-abrasiveness sanitary
facility, if the equipment is used by multiple persons, the
equipment must be disinfected every time;
2) The equipment is not water-proof, do not clean it by manual
cleaning device, do not spray the equipment or immerse it in
water.
