Pentagram Eon Cineo User manual

2008-10-01
INDEX
INTRODUCTION .....................................................................................................................................EN - 2
GETTING STARTED ...............................................................................................................................EN - 3
USAGE ....................................................................................................................................................EN - 5
NAVIGATION...........................................................................................................................................EN - 7
FIRMWARE UPGRADE.........................................................................................................................EN - 15
TROUBLESHOOTING...........................................................................................................................EN - 16
SPECIFICATION ...................................................................................................................................EN - 17
WPROWADZENIE................................................................................................................................... PL - 2
PRZYGOTOWANIE DO PRACY.............................................................................................................. PL - 3
OBSŁUGA ............................................................................................................................................... PL - 5
NAWIGACJA ........................................................................................................................................... PL - 7
AKTUALIZACJA FIRMWARE ................................................................................................................ PL - 16
ROZWIĄZYWANIE PROBLEMÓW ........................................................................................................ PL - 17
SPECYFIKACJA.................................................................................................................................... PL - 18

NOTE! Any information and technical data are subject to change without prior notification and/or
indication in this manual.
Copyright © 2008 PENTAGRAM
All rights reserved; copying and reproduction is strictly forbidden.
UWAGA! Wszystkie informacje i dane techniczne mogąulec zmianie bez wcześniejszego
powiadomienia i/lub zaznaczenia tego w niniejszej instrukcji.
Copyright © 2008 PENTAGRAM
Wszelkie prawa zastrzeżone, powielanie i kopiowanie zabronione.

EN
Instruction Manual
The latest versions of the manual, software and applications are available at www.pentagram.eu

Eon Cineo (P 5116)
EN - 2
Introduction
Thank you for purchasing PENTAGRAM Eon Cineo. This player is an advanced type of a portable digital multimedia
player. It perfectly combines high quality digital audio (MP3, WMA, APE, FLAC, AAC, WAV) and video playback (AVI,
RM, RMVB, FLV), voice recording, FM tuner, FM recording, photo album (JPG, BMP, GIF), eBook browsing and
PlayFX™ sound enhancement. Player also supports multitasking (you can read eBook while listening to music) and
has built-in microSD (aka TF or TransFlash) card reader.
System Requirements
•IBM PC, notebook or Mac with available USB port;
•Operating system: Windows 2000 / XP / Vista, Linux 2.4.4 or newer.
Box Content
•PENTAGRAM Eon Cineo (P 5116)
•In-Ear Earphones
•3 pairs of soft, silicon earbuds (S, M, L)
•USB cable
•Instruction Manual
•Power adapter
•Car USB charger
•Velvet carrying pouch
•Soft wipe cloth

Eon Cineo (P 5116)
EN - 3
Getting started
Safety precautions
•Please avoid placing the player directly in the sunshine or dusty, humid places or in extremely low or high
temperatures (i.e. car with closed windows in summer);
•Please avoid dropping or impact upon player;
•Don't let liquid or objects into player;
•Don't use chemicals, such as gasoline or other diluents, upon player's surface;
•Clean player only with soft cloth;
•Before cleaning, disconnect player from computer or other power source;
•When start using the unit, please fully charge and discharge the battery for about 2 - 3 times to ensure
maximum battery life and power capacity;
•Please do not disassemble any part of the unit, any unauthorized disassembling will cause termination of
PENTAGRAM official warranty;
•Please don't use wet hands to plug/unplug or contact player to prevent electric shock or damage;
•Please don't unplug player while data is being transferred to/from the computer, otherwise the data may be
lost;
•Please don't judder, otherwise player may be damaged;
•Files or data stored in player cannot completely avoid being destroyed or lost due to improper use or other
reasons. Please backup files and data when necessary;

Eon Cineo (P 5116)
EN - 4
Battery charging
When you start using the unit, please fully charge and discharge the battery about 2 - 3 times to ensure maximum
battery life and power capacity.
In the top right corner of the display (in most modes), a battery charge indicator is visible. If the indicator is filled – the
battery is fully charged, if it’s empty – battery is almost discharged and must be charged as soon as possible. During
the charging process the indicator changes its color or full screen animation is displayed (to exit this animation
press ESC button).
To charge the battery:
•connect the player to computer’s USB port, or
•connect the player to a power outlet via attached power adapter, or
•connect the player to a car lighter socket via car USB charger
Connecting to computer
The player has a USB 2.0 High Speed interface, and is recognized by operating system as a standard USB mass
storage device (second device recognized by system corresponds to microSD card reader). Player supports following
operating systems: Windows 2000 / XP Vista, Linux 2.4.4 or newer. After connecting to the PC (several seconds
later), the player will display icon of USB connection (file management available) or battery charge.

Eon Cineo (P 5116)
EN - 5
Usage
Player’s appearance
3 5
1
4
2
1. ESC button
2. VOL button
3. ◄button 6
4. M button
5. ►button
7
6. Earphone socket
7. microSD card slot
8. USB port 8
9. ON/OFF switch
a. HOLD position
b. PLAY position
9 b
a

Eon Cineo (P 5116)
EN - 6
Buttons
General
ON/OFF switch – power on/off, button lock and play/pause. This switch has three positions:
•HOLD – button lock enabled.
•ON/OFF – button lock disabled.
•PLAY – hold ON/OFF switch in this position for 2-3 seconds to power on/off the player. In this manual pressing
PLAY button refers to moving the ON/OFF switch to PLAY position and releasing it.
ESC – previous menu, return to main menu.
Main Menu:
◄and ►– select main menu option.
Mor PLAY – confirm selection.
Submenu / file list
◄and ►– select submenu/list option.
Mor PLAY – confirm selection.
ESC – return to previous menu / parent folder.
Turning the player on
To turn on/off the player, move the ON/OFF switch to PLAY position and hold it in this position for 2-3 seconds.

Eon Cineo (P 5116)
EN - 7
Buttons lock
To lock player’s buttons, please move the ON/OFF switch to HOLD position. When the key lock is active, a padlock
icon appears in the upper left corner of the display.
To unlock player’s buttons, move the ON/OFF switch back to ON/OFF position.
Emergency power off
Under specific conditions the player’s buttons may stop responding. In such cases, please move the ON/OFF switch
to PLAY position and hold it in this position for about 8 seconds. Player will be turned off.
Navigation
Main Menu
Use ◄and ►buttons to navigate through the main menu and press Mor PLAY to confirm selection.
Music Menu
After selecting Music in main menu you will see Media Library screen in which you can choose playback criteria:
Now Playing – opens main Music screen without changing current play list.
All Music – plays all audio files starting with the selected file. Files on this play list are sorted by filename.
Artist – plays all audio files of a selected Artist starting with the selected file. Files on this play list are sorted by
filename.
Album – plays all audio files of selected Album beginning with the selected file. Files on this play list are sorted by
filename.

Eon Cineo (P 5116)
EN - 8
Title – plays all audio files starting with selected file. Files on this play list are sorted by song title.
My Favorite – My Favorite is custom play list. To add file or folder to this list, select it on one of the other lists,
hold VOL button for 2-3 seconds and select Add to Favorite option. Files added to Favorites are put on the end of
this list – this allows you to create custom order in which files will be played. If you want to delete a single file from My
Favorite play list, select this file, hold VOL for 2-3 seconds and choose Delete File option. If you want to delete all
files from My Favorite play list, hold VOL for 2-3 seconds and choose Clear Up option.
Recorded – play all recorded audio files starting with selected file. Files on this play list are sorted by filename.
Directory List – play all audio files in selected folder starting with selected file. Files on this play list are sorted by
filename.
MediaLibrary Update – in some cases, after uploading or deleting files and also after inserting microSD card you
should use this function to see all available audio files.
Buttons function in main Music screen are:
PLAY – pause / resume playback.
◄/ ►– previous / next audio file. Hold to rewind / fast forward current file.
VOL – enter / exit volume control mode (use ◄/ ►, to turn up or down the volume). If enabled, volume icon in the
bottom left corner will change its color.
M– Music sub menu.
M(hold) – A-B repeat:
•press and hold for 2-3 seconds Mbutton, to select the start point (A), Aicon will appear on the display.
•press and hold for 2-3 seconds Mbutton, to select the end point (B). Aicon will change to A-B and the
player will repeat continuously the selected fragment. To disable A-B repeat press and hold for 2-3 seconds M
button again.
ESC – return to file selection screen.

Eon Cineo (P 5116)
EN - 9
Music submenu
Repeat Mode
•Once – play one file one time.
•Repeat – play one file repeating it indefinitely.
•All – play all files on the play list one time.
•All Repeat – play all files on the play list repeating them indefinitely.
•Intro – play only few first seconds of each file on the play list.
Play Mode
•In Order – play files in order.
•Shuffle – play files in random order.
MS PlayFX – select one of MS PlayFX™ functions: 3D Headphones, True Bass or Auto Volume
EQ – select equalizer mode: Normal, MS PlayFX, Rock, Pop, Classic, Bass, Jazz, User EQ.
User EQ Setup – follow these steps to configure User EQ settings:
•use ◄/ ►, to select frequency and confirm your choice by pressing VOL.
•use ◄/ ►, to choose desired value and approve it by pressing VOL.
•use ◄/ ►, to select YES and press Mto save settings, or select NO and press Mto discard changes.
Display – select what will be displayed in main part of display:
•Lyrics – if lyrics file (LRC) file is available, lyrics will be displayed.
•Frequency Chart – real time spectrum analyzer.
•Closed – disables display of lyrics and spectrum analyzer.
Lyrics Display
The player supports lyrics files In LRC format. Copy lyrics file to the folder with the corresponding music file and
ensure that both filenames are identical (i.e. “vanquish.mp3” and “vanquish.lrc”). To enable lyrics display open Music

Eon Cineo (P 5116)
EN - 10
mode submenu, select Display and then Lyrics – lyrics will be displayed automatically when music file is being
played.
Video Menu
After selecting Video in main menu you will see Video screen in which you can choose file you want to play.
This mode is used for playing video files. Supported file formats are AVI (max. resolution 624x352), RM / RMVB
(max. resolution 624x352) and FLV. Note that large files will take longer to load than small ones. Buttons function in
video file playback screen are:
PLAY – pause / resume playback.
◄/ ►– previous / next video file.
VOL – enter / exit volume control mode (use ◄/ ►, to turn up or down the volume). If enabled, volume icon in the
bottom left corner will change color.
ESC – return to file selection screen.
Photo Menu
After selecting Photo in main menu you will see Photo screen in which you can choose file you want to view.
This mode is a photo (JPG, BMP, GIF) browser. Buttons function in photo view screen are:
Mor PLAY – Photo submenu.
◄/ ►– previous / next file. If rotate and/or zoom mode is enabled you must press ESC to return to normal view
before you can change displayed file.
ESC – return to file selection screen.
ESC (when file is rotated or zoomed) – return to normal view.
Photo submenu
Rotate Right – rotate current file clockwise.
Rotate Left – rotate current file counter-clockwise.

Eon Cineo (P 5116)
EN - 11
Zoom In – in Zoom mode you can scroll the photo using ◄/ ►. Press VOL to switch between scrolling left and
right/up and down.
Zoom Out – in Zoom mode you can scroll the photo using ◄/ ►. Press VOL to switch between scrolling left and
right/up and down.
Slide Show – select time after which next image will be displayed or Off to disable slide show.
eBook Menu
After selecting eBook in main menu you will see eBook screen in which you can choose file you want to view.
This menu is eBook (TXT) browser. Buttons function in file view screen are:
M– eBook submenu.
◄/ ►– scroll up / down one page.
ESC – return to file selection screen.
eBook submenu
Jump To Page – select page you want to see.
Save Bookmark – save bookmark for current page in selected position.
Load Bookmark – load one of the saved bookmarks.
Del Bookmark – delete one of the saved bookmarks.
Set Font Size – select font size.
Set Font Color – select font color.
Display Time – select time after which next page will be displayed or Off to disable auto page flipping.
Radio Menu
This mode is FM tuner. In this mode the earphones are used as antenna and they should be connected before the
station tuning. Buttons function in this mode are:
M– Radio submenu:

Eon Cineo (P 5116)
EN - 12
◄/ ►(Manual mode) – change the frequency by 0,1MHz, hold to scan for nearest the station.
◄/ ►(Preset mode) – previous / next saved station.
VOL – enter / exit volume control mode (use ◄/ ►, to turn up or down the volume). If enabled, volume icon in the
bottom left corner will change color.
ESC – return to file selection screen.
Radio submenu
Search Manually – manual tuning mode, which allows changing frequency by 0,1MHz or searching for nearest
station with strong signal.
Auto search – player will scan whole band and save stations with strong signal. This will overwrite saved stations.
Preset stations – use this mode for easy changing between saved stations.
Save preset – save currently selected frequency on selected position.
Delete preset – delete saved station from selected position.
Stereo switch – select Yes for stereo or No for mono.
FM Range – select region where you will use player.
FM recording – start recording from FM tuner (see Recorder Menu section for details).
Recorder Menu
This mode can be used to record voice via a built-in microphone (select Recorder from main menu) or from FM
(select FM Recording option from Radio submenu). Recorded files are named VRECxxx.WAV for voice record and
FMRCxxx.WAV for FM record. Buttons functions in this mode are:
PLAY – start / pause / resume recording
M– Record submenu, allows change of recording quality (Low quality or High quality). This is only available when
Preparing… message is displayed.
ESC (voice) – when Recording… or Paused… message is displayed save file, when Preparing… message is
displayed return to main menu.
ESC (FM) – save file and return to Radio mode.

Eon Cineo (P 5116)
EN - 13
Other Functions Menu
Stopwatch
This function can be used as a stopwatch. Use ◄to start/stop time and ►to reset counter.
Calendar
This calendar is preview only. If you want to change system date, see Settings Menu section for details.
M– select if you want to change year, month or day.
VOL – when day is selected, changes mode between previous/next day or same weekday in previous/next week.
◄/ ►– change selected value.
ESC – return to main menu.
Explorer
This mode is a file browser. Select a file to play/view it in appropriate mode (i.e. MP3 file will be played in Music
mode). Buttons functions in this mode are:
◄/ ►– file / folder selection.
Mor PLAY – confirm selection.
VOL – hold for 2-3 seconds to delete selected file.
ESC – return to main menu.

Eon Cineo (P 5116)
EN - 14
Settings Menu
Settings Menu is used to configure various player functions.
Display Settings
•Lighting time – change idle time, after which the display will be turned off.
•Brightness – select display brightness.
System Settings
•Update – firmware upgrade. See Firmware upgrade chapter for more details.
•Default settings – restore player’s settings to factory defaults.
Desktop – select one of the background images.
Language – select player interface language.
System Information – displays information about player (Chip ID), firmware version (Soft version ID) and memory
status (Local Memory Size and Card Memory Size).
Time Settings – system time and date configuration. On time screen Press VOL to switch between Hour and
Minutes fields and use ◄/ ►to change selected field value. When time is set press Mto save changes and go to
date screen. On date screen Press VOL to switch between Year, Month and Day fields and use ◄/ ►to change
selected field value. When date is set press Mto save changes and return to Settings menu.
Auto turn-off Time – change idle time, after which player will be turned off.

Eon Cineo (P 5116)
EN - 15
Firmware upgrade
NOTE:
•The firmware upgrade is meant to improve and optimize the performance of the player. The normal work of the
player will not be affected even if the firmware isn’t upgraded. The wrong operation of upgrading firmware
would cause the device not to work normally! The firmware upgrade software of this player does not apply to
other series of players.
•Before firmware upgrade we recommend you to backup the files stored inside the player’s memory. Files may
be erased during the upgrade procedure. PENTAGRAM Europe cannot be held responsible for any data loss.
•Make sure that you use only the genuine PENTAGRAM firmware for upgrading Eon Cineo. You can download
the latest firmware from www.pentargam.eu
•Do not detach the player from your computer while the firmware upgrade procedure is in progress. This may
cause a critical malfunction.
•Make sure that battery is charged before upgrade process.
Follow this steps to upgrade player’s firmware:
1. Connect the player to PC.
2. Go to the disk of the player.
3. Copy downloaded firmware file (*.RKW) to root directory of the player.
4. Disconnect the player from PC.
5. Enter Settings > System Settings > Update menu and answer YES to question regarding upgrade.
6. Player’s firmware will be upgraded and player will be restarted after the process.

Eon Cineo (P 5116)
EN - 16
Troubleshooting
If you experience any of the following difficulties in using player, use the following guide for help. Should any problem
persist, please visit www.pentagram.eu web site and eventually contact PENTAGRAM Customer Service.
Symptoms Possible cause Solution
Fail to power on
Power off shortly after
power on
Low battery Charge the battery
The volume is set to 0 Turn up the volume
No sound output Earphones not connected properly Connect earphone correctly
Player is stuck
Move the ON/OFF switch to PLAY
position and hold it in this position for
about 8 seconds to perform emergency
shutdown.
Buttons doesn’t work
Button lock enabled Disable button lock
Fail to connect with the
computer
USB cable isn’t connected
correctly Connect USB cable correctly
Fail to copy files Your system doesn’t meet player’s
requirements
Upgrade your system to meet the
requirements
Low battery Charge battery
Can’t recording Space insufficient Delete some files
Can’t play video Format error Convert video file

Eon Cineo (P 5116)
EN - 17
Specification
Function Description
Chipset Rockchip 2706
Dimensions 86 × 49 × 10,5 mm (W x H x D)
Weight ~ 54g
Display TFT LCD 3” 400x240 (WQVGA)
Power supply built-in Li-Poly 750mAh
Working time Music: ~10h (power saving) Video: ~4h (power saving)
Frequency:
China, Europe, U.S.A
Japan
87MHz – 108MHz
76MHz – 90MHz
Radio FM
Preset stations 30
Music MP3, WMA, APE, FLAC, AAC, WAV
Video AVI, RM, RMVB, FLV
Text TXT
Supported files
Photo JPG, BMP, GIF
Sound enhancemens MS PlayFX™, Equalizer (6 predefined modes + 1 custom)
Max. output power 12mW in left and right
SNR 95dB
Frequency 20Hz ~ 20kHz
Distortion < 0,1%
Working temperature 5°C~40°C
Data transfer PC or notebook with USB port
Operating system Windows 2000 / XP / Vista, Linux 2.4.4 or newer.
* specification may be changed without prior notice

Eon Cineo (P 5116)
EN - 18
