IMPORTANT PUMP WARNING AND SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety
precautions should always be followed, include the following:
RISK OF ELECTRICAL SHOCK. Connect only to
a branch circuit protected by a ground-fault circuit-
interrupter (GFCI). Contact a qualified electrician if you cannot verify
that the circuit is protected by a GFCI.
This unit must be connected only to a supply circuit
that is protected by a ground-fault circuit-interrupter
(GFCI). Such a GFCI should be provided by the installer and should
be tested on a routine basis. To test the GFCI, push the test button.
The GFCI should interrupt power. Push the reset button. Power should
be restored. If the GFCI fails to operate in this manner, the GFCI is
defective. If the GFCI interrupts power to the pump without the test button
being pushed, a ground current is flowing, indicating the possibility of an
electric shock. Do not use this pump. Disconnect the pump and have the
problem corrected by a qualified service representative before using.
General Warnings
• Never open the inside of the drive motor enclosure.There is a
capacitor bank that holds a 230 VAC charge even when there is no
power to the unit.
• Thepumpisnotsubmersible.
• Thepumpiscapableofhighowrates;usecautionwheninstalling
and programming to limit pumps performance potential with old or
questionable equipment.
• Code requirements for the electrical connection differ from state
tostate.InstallequipmentinaccordancewiththecurrentNational
Electrical Code and all applicable local codes and ordinances.
• Before servicing the pump; switch OFF power to the pump by
disconnecting the main circuit to the pump.
• This appliance is not intended for use by persons (including
children) of reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning the use of the appliance by a
person responsible for their safety.
FAILURETOFOLLOWALLINSTRUCTIONSAND
WARNINGS CAN RESULT IN SERIOUS BODILY
INJURYORDEATH.THIS PUMP SHOULD BE INSTALLED AND
SERVICED ONLY BY A QUALIFIED SERVICE PROFESSIONAL.
INSTALLERS, OPERATORS AND OWNERS MUST READ THESE
WARNINGS AND ALL INSTRUCTIONS IN THE OWNER’S MANUAL
BEFORE USING THIS PUMP. THESE WARNINGS AND THE OWNER’S
MANUAL MUST BE LEFT WITH THE PRODUCT OWNER.
SUCTION ENTRAPMENT HAZARD: STAY OFF
THEMAINDRAINANDAWAYFROMALLSUCTION
OUTLETS!
F
THISPUMPPRODUCESHIGHLEVELSOFSUCTIONANDCREATES
ASTRONGVACUUMATTHEMAINDRAINATTHEBOTTOMOFTHE
BODYOFWATER.THISSUCTIONISSOSTRONGTHATITCANTRAP
ADULTSORCHILDRENUNDERWATERIFTHEYCOMEINCLOSE
PROXIMITYTOADRAINORALOOSEORBROKENDRAINCOVER
ORGRATE.
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This is the safety alert symbol. When you see this
symbol on your system or in this manual, look for
one of the following signal words and be alert to
the potential for personal injury.
Warns about hazards that can cause death,
serious personal injury, or major property damage
if ignored.
Warns about hazards that may cause death,
serious personal injury, or major property damage
if ignored.
Warns about hazards that may or can cause
minor personal injury or property damage if
ignored.
NOTE indicates special instructions not related to hazards.
Carefully read and follow all safety instructions in this manual and on
equipment.Keepsafetylabelsingoodcondition;replaceifmissing
or damaged.
IMPORTANT NOTICE
This guide provides installation and operation instructions
for this product. Consult Pentair with any questions regarding this
equipment.
Attention Installer: This guide contains important information about the
installation, operation and safe use of this product. This information should
be given to the owner and/or operator of this equipment after installation or
left on or near the pump. This pump is for use for aquaculture installations
ONLY.Donotusewithanytypeofswimmingpool,hottub,orspa.
Attention User: This manual contains important information that will help
you in operating and maintaining this product. Please retain it for future
reference.ThispumpisforuseforaquacultureinstallationsONLY.Donot
use with any type of swimming pool, hot tub, or spa. Warnings and safety
instructions for Pentair Aquatic Eco-Systems pumps and other related
products are available at:
http://www.pentairaes.com or call U.S. [phone]•International
[phone] for additional free copies of these instructions.
RISK OF ELECTRICAL SHOCK OR
ELECTROCUTION: PUMPS REQUIRE HIGH
VOLTAGE WHICH CAN SHOCK, BURN, OR
CAUSE DEATH. BEFOREWORKINGONPUMP!
Always disconnect power to the pump at the circuit
breaker from the pump before servicing the pump.
Failure to do so could result in death or serious injury
to service person, system users or others due to
electric shock.

SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
iii
For Installation of Electrical Controls at Equipment Pad (ON/OFF
Switches, Timers and Automation Load Center)
Install all electrical controls at equipment pad, such as
on/off switches, timers, and control systems, etc. to
allow the operation (startup, shut-down, or servicing)
of any pump or filter so the user does not place any
portion of his/her body over or near the pump strainer
lid, filter lid or valve closures. This installation should
allow the user enough space to stand clear of the
filter and pump during system start-up, shut down or
servicing of the system filter.
Pentair Water Pool and Spa®
IMPORTANT SAFETY INSTRUCTIONS
For Installation of Electrical Controls at Equipment Pad
(ON/OFF Switches, Timers and Automation Load Center)
Install all electrical controls at equipment pad, such as on/off
switches, timers, and control systems, etc. to allow the
operation (startup, shut-down, or servicing) of any pump or
filter so the user does not place any portion of his/her body
over or near the pump strainer lid, filter lid or valve closures.
This installation should allow the user enough space to stand
clear of the filter and pump during system start-up, shut down
or servicing of the system filter.
SAVE THESE INSTRUCTIONS
IMPORTANT PUMP WARNING AND SAFETY INSTRUCTIONS
Beforeservicingequipment, makenoteofthe lterpressure.Be sure
that all controls are set to ensure the system cannot inadvertently start
during service. Turn off all power to the pump. IMPORTANT: Place filter
manual air relief valve in the open position and wait for all pressure
in the system to be relieved.
Beforestartingthesystem,fullyopenthemanualairreliefvalveandplace
all system valves in the “open” position to allow water to flow freely from the
tank and back to the tank. Stand clear of all equipment and start the pump.
IMPORTANT: Do not close filter manual air relief valve until all
pressure has been discharged from the valve and a steady stream
of water appears. Observelterpressuregaugeandbesureitisnot
higher than the pre-service condition.
HAZARDOUS PRESSURE: STAND CLEAR OF
PUMP AND FILTER DURING START UP
Circulation systems operate under high pressure.
When any part of the circulating system (i.e.
locking ring, pump, filter, valves, etc.) is serviced,
air can enter the system and become pressurized.
Pressurized air can cause the pump housing cover,
Pentair Water Pool and Spa®
IMPORTANT SAFETY INSTRUCTIONS
For Installation of Electrical Controls at Equipment Pad
(ON/OFF Switches, Timers and Automation Load Center)
Install all electrical controls at equipment pad, such as on/off
switches, timers, and control systems, etc. to allow the
operation (startup, shut-down, or servicing) of any pump or
filter so the user does not place any portion of his/her body
over or near the pump strainer lid, filter lid or valve closures.
This installation should allow the user enough space to stand
clear of the filter and pump during system start-up, shut down
or servicing of the system filter.
filter lid and valves to violently separate which can result in severe
personal injury or death. Filter tank lid and strainer cover must be properly
secured to prevent violent separation. Stand clear of all circulation system
equipment when turning on or starting up pump.
General Installation Information
• All work must be performed by a qualified service professional, and
must conform to all national, state, and local codes.
• Install to provide drainage of compartment for electrical components.
• These instructions contain information for a variety of pump models
and therefore some instructions may not apply to a specific model. All
models are intended for use in aquaculture applications. The pump will
function correctly only if it is properly sized to the specific application
and properly installed.
Pumps improperly sized or installed or used in
applications other than for which the pump was
intended can result in severe personal injury or death. These risks may
include but not be limited to electric shock, fire, flooding, suction
entrapment or severe injury or property damage caused by a structural
failure of the pump or other system component.
The pump can produce high levels of suction within
the suction side of the plumbing system. These high
levels of suction can pose a risk if a person comes within the close
proximity of the suction openings. A person can be seriously injured by
this high level of vacuum or may become trapped and drown. It is
absolutely critical that the suction plumbing be installed in accordance
with the latest national and local codes for aquaculture systems.
A clearly labeled emergency shut-off switch for the
pump must be in an easily accessible, obvious place.
Makesureusersknowwhereitisandhowtouseitincaseofemergency.
NOTE: ALL SUCTION PLUMBING MUST BE INSTALLED IN
ACCORDANCE WITH THE LATEST NATIONAL AND LOCAL CODES,
STANDARDS AND GUIDELINES.
This pump has been evaluated for use with water
only.
Beforeoperation,besuretocompletelyrinsethe
pump volute with water.
Cord Connected Models Only
RISK OF ELECTRICAL SHOCK. This pump is
supplied with a grounding conductor and grounding
type attachment plug. To reduce the risk of electric shock, be certain
that it is connected only to a properly grounded, grounding-type
receptacle.

1
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
PUMP OVERVIEW
The Sparus™Pump with Constant Flow Technology
can be programmed to run at specific speeds and time
intervals for maximum operating efficiency and energy
conservation for a variety of bodies of water.
• Thepumpcanoperatefrom1100RPMto3450RPM
withfourpresetowratesof40,50,60and70GPM
• Thepumpcanbeadjustedfromthecontrolpanelto
runatanyspeedbetween1100RPMto3450RPM
fordifferentapplications,andowfrom20-140GPM
• Upto8programmablespeeds/ows
• PumpcontrolpanelalarmLEDanderrormessages
warntheuseragainstunderandovervoltage,high
temperature,overcurrentandfreezeprotection
• Self-primingforeasystart-up
• UL/CUL
Drive Assembly and Control Panel
The pump drive assembly consists of an operator control
panel and the system electronics that drive the motor.The
drive microprocessor controls the motor by changing the
frequencyofthecurrentitreceives,aswellaschanging
the voltage to control the rotational speed.
Motor Features
• PermanentMagnetSynchronousMotor(PMSM)
• Highefciency(3450RPM92%and1100RPM
90%)
• Superiorspeedcontrol
• Operatesatlowertemperaturesduetohigh
efficiency
• Sametechnologyasdeployedinhybridelectric
vehicles
• Designedtowithstandoutdoorenvironment
• Totallyenclosedfancooledmotor
• Three-phasemotor
• 56SquareFlange
• Six-Pole
• Lownoise
PumpDriveAssembly
MotorStand
OperatorControlPanel,
ButtonsandLED
ACPowerConnection
Compartment

2
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
5 x PIPE DIAMETER
ELBOW
PumpRearClearance
REAR CLEARANCE
3 IN. (7.6 CM) MINIMUM
3 IN.
(7.6 CM)
MINIMUM
Electrical
• Install all equipment in accordance with the National
ElectricalCodeandallapplicablelocalcodesand
ordinances.
• Ameansfordisconnectionmustbeincorporatedin
the fixed wiring in accordance with the wiring rules.
• Ifthesupplycordisdamaged,itmustbereplacedto
avoidahazard.Thesupplycordcanbepurchased
separatelyfromthemanufacturer,itsserviceagent
or a qualified electrician.
Location
Be sure the pump location meets the following
requirements:
Fittings
1. Installttings(valves,elbows,tees,etc.)inthesuction
linenocloserthanve(5)timesthepipediameterto
thefrontofthepump(e.g.3”pipe=15in).
2. Donotinstall90°elbowsdirectlyintopumpinlet.
Piping
1. Be sure all plumbing connections are clean and tight
to avoid possible air leaks and entrainment of air on
the suction side of the pump.
2. Gas supersaturation conditions resulting from air
entrainment can be harmful to aquatic animal health.
3. Uselargerpipesizesforimprovedplumbing.Pipe
diameter should be the same or larger as the return
line diameter.
4. Plumbing on the suction side of the pump should be
as short as possible.
5. Install piping as close to the water level as possible.
6. Runstraight,horizontalpipingforthesuctionsideof
the pump. The length of the piping should be equal
tove(5)pipediameters.
Example: If system is plumbed with 3 in. diameter
PVC pipe, than a straight section of pipe 15 in. long
should be used for suction side of the pump.
Valves
1. Install gate valves on suction and discharge pipes for
maintenanceofoodedsuctionsystems-installno
closerthanve(5)timesthesuctionpipediameter.
2. Useacheckvalveinthedischargelinewhenusing
this pump for any application where there is significant
height to the plumbing after the pump.
3. Be sure to install check valves when plumbing in
parallel with another pump. This helps prevent reverse
rotation of the impeller and motor.
• Pump inlet as close as possible to water level.
• Short,directsuctionpipingreturns(reducesfriction
loss).
• Installpumpinasheltered,wellventilatedareato
protect from excess moisture (i.e., rain, splashing
water,etc.)andooding.
• Install and secure pump on level concrete slab or
rmsurface(reducesvibrationnoise).
• Pump location should allow access for servicing and
maintenance.
Before operation, be sure to completely rinse
the pump volute with water.
OnlyaqualiedplumbingprofessionalshouldinstalltheSparus™PumpwithConstantFlowTechnology.Referto
“Pump Warning And Safety Instructions” onpagesii-iiiforadditionalinstallationandsafetyinformation.
INSTALLATION

3
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Electrical Wiring Installation
To connect the Sparus™PumpwithConstantFlowTechnologytoanACpowersource(fornoncord
connectedpumps):
1. Besureallelectricalbreakersandswitchesareturned
off before wiring motor.
2. Be sure that the supply line voltage matches the
motor voltage listed on the motor plate. If they do
notmatch,permanentmotordamagemayoccur.
3. Use #12 AWG for wire runs up to 100 feet (30.5
meters)and#10AWGforlengthslongerthan100
feet (30.5 meters).When in doubt, use a heavier
gauge(largerdiameter)wire.
4. Usestrainreliefandbesureallelectricalconnections
are clean and tight.
5. Cutthewirestotheappropriatelengthsotheydo
not overlap or touch when connected.
6. Permanentlygroundthemotorusingthegroundwire,
asshownbelow.Usethecorrectwiresizeandtype
specied by National Electrical Code. Make sure
the ground wire is connected to an electrical service
ground.
7. Bondthemotortothestructureinaccordancewith
theNationalElectricalCode.ULrequiresuseofa
solidcopperbondingconductornotsmallerthan8
AWG.Runawirefromtheexternalbondingscrew
or lug to the bonding structure.
8. Connectthewirefromtheaccessiblewireconnector
on the motor to all metal parts of the structure and
toallelectricalequipment,metalconduit,andmetal
pipingwithin5feet(1.5m)oftheinsidewallsofthe
structure.ForCanada,a6AWGorlargersolidcopper
bonding conductor is required.
9. Thepumpshouldbepermanentlyconnectedtoeither
acircuitbreaker,2-poletimeror2-polerelay.IfAC
powerissuppliedbyaGFCIcircuitbreaker,usea
dedicated circuit breaker that has no other
electrical loads.
Note:Whenthepumpisstartedandstoppedby
removingpowerwitharelayortimer,atwo-pole
device should be used to apply and remove
powertobothPOWERLINETERMINALS.
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION. This pump must be installed by a licensed or certified electrician or
a qualified service professional in accordance with the National Electrical Code and all applicable local codes and ordinances.
Improper installation will create an electrical hazard which could result in death or serious injury to users, installers, or others
due to electrical shock, and may also cause damage to property.
Always disconnect power to the pump at the circuit breaker before servicing the pump. Failure to do so could result in
death or serious injury to service people, users or others due to electric shock.
Read all servicing instructions before working on the pump.
GroundWire
Connection
BondingLug
FieldWiringCompartment

4
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Electrical Wiring Installation (Cont.)
Note: 230voltsistheidealinputvoltagefortheSparus
pump,althoughitcanoperateonstablevoltagefrom
207Vto253V.Itisimportanttoensurethatperiodic
line voltage fluctuations do not expose the pump to
voltages outside its allowable range. The pump’s
drive electronics may have reduced length of
service life if the pump is consistently operated at
or near the extreme ends of its allowable voltage
range (+/-).
Note: Allwiringshouldbeperformedbyaqualied
electrician.Itistheresponsibilityoftheinstaller/
electrician to perform the installation in compliance
withtheNationalElectricCodeandallState,local
codes and ordinances. It is the responsibility of the
installer to perform the installation in such a manner
thatthepumpisprovidedwith230volt(+/-10%),
singlephase,ACpower,50Hzor60Hz.
Insomeeldinstallations(particularlycommercial
properties)directaccesstosingle-phasepower
may not be available. In an application where only
three-phasepowerisavailable,itispossiblefor
qualified installers to follow standard electrical wiring
procedures that will allow the pumps to be installed
and operated.
Three-phasepowermaybesourcedfromathree-
phaseelectricalpanelandconnectedtoatwo-
pole circuit breaker; thereby creating single phase
powerasrequiredbythepump.Onlysingle-phase
electrical power may be terminated into the field
wiringcompartmentjunctionboxlocatedonthe
side of the pump.
When installing a pump always safely use
a multi-meter to measure the actual voltage
across the two live conductors to verify that
it is 230 volt (+/-10%), single-phase, AC power,
50Hz or 60Hz.
ThePentairAquaticEco-Systems™Sparus™Pump with Constant Flow Technology is designed to operate on
230volt(+/-10%),single-phase,ACpower,50Hzor60Hz.

5
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
OPERATING THE PUMP
Follow the steps below to prime the pump for start up:
1. PressStart/Stop tostopthepump.Disconnectthe
pump main power supply and communication cable.
2. Closeallgatevalvesinsuctionanddischarge 
 pipes.Relieveallpressurefromthesystem.
3. Removethepumplidandlockingring.
4. Fillthepumpstrainerpotwithwater.
5. Reassemblethepumplidandlockingringontothe
strainer basket. The pump is now ready to prime.
6. Openthelterairreliefvalveandstandclearof 
 thelter.(Ifpresent.)
7. Connectpowertothepump.Besuregreenpower
light is on.
8. PressStart/Stop to start the pump. The pump will
 enterintoprimingmode(ifenabled)andspeedup
to the maximum speed set in the pump menu
settings.
9. Whenwatercomesoutofthelterairreliefvalve,
close the valve. The system should now be free of
air and recirculating water to and from the tank.
10. Do not allow your pump to run longer than 30
minutes time without developing full flow. If the
pumpdoesnotprime,checkyourprimingsettings
on the control panel or see the “Troubleshooting”
sectiononpages21-22.
Priming Features
ThedefaultprimingsettingisENABLED.
The pump also allows you to set the following from
the operator control panel:
• Maximumprimingtime
• MaximumandMinimumspeed
• Primingsensitivity(1-100%)
• Priming delay
Set up instructions on page 14.
Priming the Pump
Prime the pump before starting the pump for the first
time.Removethelidandllthebasketwithwater.The
pump basket must be filled with water before initial
start up or after servicing.
This Sparus™Pump with Constant Flow Technology is shipped with Priming mode ENABLED. Unless the Priming settings are
changed in the menu, be aware that the pump will speed up to the maximum speed when the pump is powered on for the
first time, and the start/stop button is pressed. To change the maximum speed of the pump, refer to page 10.
Before turning the pump ON, be sure the following conditions are met:
1. Open filter air relief valve (if present).
2. Open valves.
3. Return is completely open and clear of any blockages.
4. Water in the pump basket.
5. Stand clear of the filter or other pressurized vessels.
Before operation, be sure to completely fill the pump volute with water.
DO NOT run the pump dry. If the pump is run dry, the mechanical seal will be damaged and the pump will start leaking. If this
occurs, the damaged seal must be replaced. ALWAYS maintain proper water level. If the water level falls below the suction port,
the pump will draw air through the suction port, losing the prime and causing the pump to run dry, resulting in a damaged seal.
Continued operation in this manner could cause a loss of pressure, resulting in damage to the pump case, impeller and seal and
may cause property damage and personal injury.
Lid
Clamp
TopView
Volute

6
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Using the Operator Control Panel
UsetheoperatorcontrolpaneltostartandstoptheSparus™
PumpwithConstantFlowTechnology,program,set,and
change speeds (RPM), and access pump features and
settings.
ControlPanel#1-8
ControlPanel#9-15
Speed 1: PresstoselectSpeed1(40GPM).LEDon
indicatesSpeed1isactive.
Speed 2:PresstoselectSpeed2(50GPM).LEDon
indicatesSpeed2isactive.
Speed 3:PresstoselectSpeed3(60GPM).LEDon
indicatesSpeed3isactive.
Speed 4:PresstoselectSpeed4(70GPM).LEDon
indicatesSpeed4isactive.
Select: Press to select the currently displayed option
on the screen.
Escape: Goes one step back in menu; exits without
saving current setting.
Menu:Accessesthemenuitemswhenandifthepump
is stopped.
Enter: Saves current menu item setting. Press this button
to acknowledge alarms and warning alerts.
Arrow buttons:
• Up arrow:Moveonelevelupinthemenuorincrease
a digit when editing a setting.
• Down arrow:Moveoneleveldowninthemenuor
decrease a digit when editing a setting.
• Left arrow: Movecursorleftonedigitwhenediting
a setting.
• Right arrow: Move cursor right one digit when
editing a setting.
Controls and LEDs on Key Pad
12:15
1100 RPM
T 0.00 150 WATTS
Running Speed 1
Speed
1
Speed
2
Speed
3
Speed
4
Quick
Clean
Time
Out
15
Line 1
Line 2
Line 3
Line 4
9
13
12
10
11
14
Quick Clean: PumprampsuptohigherRPM.LEDlight
is on when active.
Time Out: Pump is not running on preset schedule.This
canbeusedtoallownewlygluedpipejointstimetodry
beforecirculationofwaterstarts.LEDisonwhenactive.
Start/Stop button:To start or stop the pump.When
LED is on, the pump is running or in a mode to start
automatically.
Reset button:Resetalarmoralert.
LEDs:
On:Greenlightwhenpumpispoweredon.
Warning: Onifwarningconditionispresent.
Alarm: RedLEDonifalarmconditionoccurs.
See “Alerts and Warnings” on page 20.
Control Panel LCD Screen:
• Line 1: Key icon indicates password protect mode
isactive.Ifpasswordprotectisnotenabled,nokey
iconisdisplayed.Alsoshowscurrenttimeofday.
• Line 2:Displayscurrentpumpspeed(RPM)orow
(GPM)
• Line 3: Countdown time and watts
• Line 4: Current pump status and current feature
12:15
1100 RPM
T 0.00 150 WATTS
Running Speed 1
1
5
2
6
8
4
3
7
Speed
1
Speed
2
Speed
3
Speed
4
Quick
Clean
Time
Out
5
1
2
3
4
6
7
8
9
10
11
12
13
14
15
KeyLockoutIcon
Current Speed
Countdown Time
Current Feature
Running
Current Time
CurrentPowerUsage

7
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Manual
Schedule
Egg Timer
Speed 1 (1-4) Set Speed
Set Speed
Set Start Time
Set Stop Time
Set Speed
Time
Speeds1-4MenuGuide
Speeds5-8MenuGuide
Stopping and Starting the Pump
Starting the Sparus™Pump with Constant Flow
Technology
1. Be sure thepumpis poweredon and thegreen
powerLEDison.
2. Select one ofthespeedbuttons, then pressthe
Start/Stopbutton(LEDon)tostartthepump.The
pump will go into priming mode if priming feature
is enabled.
Stopping the Pump
1. PressStart/Stop to stop the pump.
When servicing equipment, disconnect the communi-
cationcable,andswitchOFFcircuitbreakertoremove
power from the pump.
Note: The pump can automatically restart if the
communication cable is connected.
Operating the Pump at Preset Speeds
Thepumpisprogrammedwithfourdefaultspeedsof40,
50,60and70GPM.Speedbuttons1-4areforeachof
the preset speeds.
1. Be sure the pump is powered on and the green
powerLEDison.
2. PresstheSpeedbutton(1-4)correspondingtothe
desiredpresetspeedandreleasequickly.TheLED
above the button will turn on.
3. PressStart/Stop. The pump will quickly change to
the selected preset speed.
To Adjust and Save a Pump Speed
1. Whilethepumpisrunning,pressthe Up or Down
arrowtoadjusttodesiredspeedsetting.
2. Press and hold down a Speedbutton(1-4)forthree
(3)secondstosavespeedtothebuttonorpress
Enter to save the speed.
LEDlit
Speed
1
Speed
2
Speed
3
Speed
4
LED lit
Pump Operating Modes
The pump can be programmed in three different modes:
Manual, Schedule, and Egg Timer.
Speeds 1-4 can be programmed in all three modes.
Speeds 5-8 can only be programmed in Schedule mode
since there are no buttons on the control panel for Speeds
5-8.ThedefaultsettingforSpeeds5-8is“Disabled”.
Speed 5 (5-8)
Schedule Set Speed
Set Start Time
Set Stop Time
Disabled Default: Disabled
1. Manual:AssignsaspeedtooneofthefourSpeed
buttons on the control panel.This mode can only be
usedforspeeds1-4.
TooperateinManualmode,pressoneofthefour
speed buttons and then press Start/Stop. The
pump will run the assigned speed for that speed
button.
2. Egg Timer:Speeds1-4canbeprogrammedtorun
for a duration of time once a speed button is pressed.
TooperateinEggTimermode,pressaspeedbutton
and then press Start/Stop. The pump will run that
speed for the set amount of time and then turn off.
3. Schedule: Program speeds 1-8 start and stop at
a specic time during a 24 hour period. Speeds
programmed in Schedule mode will override any
manuallyselectedspeed(speedssetbymanually
pressing any of the speed buttons on the control
panel).
Control Panel Language
ThedefaultlanguageisEnglish.
1. CheckthatthegreenpowerLEDison.
2. Press MenuandpressSelecttoselect“Settings”.
3. UsetheUp or Downarrowsandscrollto“Language”.
4. Press Select. Press Select again to highlight current
language in use.
5. Press Enter to select the control panel language. To
cancelanychanges,pressEscape to exit without
saving.
6. Press Escape to exit.

8
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Set AM/PM
Pump Address
Set Time
Set Date
Alarm Log
Screen Contrast
Language
Set Min Speed
Set Max Speed
PASSWORD
Speed (1-4)
Quick Clean
Time Out
DISABLED/ENABLED
MAX PRIMING TIME
Speed 5 (5-8)
PRIMED SENSITIVITY
PRIMING DELAY
DISABLED/ENABLED
SET SPEED
PUMP TEMPERATURE
SETTINGS
SPEED 1-8
FEATURES
PRIMING
ANTI FREEZE
MENU Press MENU button to access menus
Schedule (Select Speed/Flow, Start Time, and End Time)
Egg Timer (Set Time)
Manual (Set Speed)
Set Reference (Set Speed or Flow depending on mode)
Set Start Time (hh:mm) (Schedule Mode Only)
Set End Time (hh:mm) (Schedule Mode Only)
Time (hh:mm) Pump run time (Egg Timer Mode Only)
Set from 00:01 - 10:00
Schedule (Select Speed/Flow, Start Time, and End Time)
Disabled
Set Reference (Set Speed or Flow depending on mode)
Set Start Time (hh:mm) (Schedule Mode Only)
Set End Time (hh:mm) (Schedule Mode Only)
(MM-DD-YYYY)
(1-16) Default: ADDRESS 1
(hr:mm) Default: 12:00 AM
(1100 RPM - 3450 RPM) - Default: 1100 RPM
(1100 RPM - 3450 RPM) - Default: 3450 RPM
Password Time Out (1 min. - 6 hours) Default:10 minutes
Enter Password (xxxx) Default: 1234
Flow/Speed Mode
Set Speed (1100 - 3450 RPM) Default: 3450 RPM
Time (1 min. to 10 hrs.) Default: 10 minutes
Time Out Duration (1 min. to 10 hrs.) Default: 3 hours
(1 min. to 30 min.) Default: 11 minutes
Disabled / Enabled - Default: Enabled
English - Default: English
Flow/Speed Mode
Default: Enabled
(1 - 100%) Default: 1
(1 second - 10 minutes) Default: 20 seconds
40° F - 50° F (4.4° C - 10° C) Default: 40° F (4.4° C)
Set Speed (1100 RPM - 3450 RPM) Default 1100 RPM
Default: Empty
Mode
(1-5) Default 3
AM/PM
24 hr.
Mode
Disabled/Enabled - Default: Disabled
Flow Unit GPM - Default: GPM
LPM
Temperature Unit Fahrenheit - Default: F°
C° Celsius
Operator Control Panel: Pump Menu Guide

9
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Set Temperature Unit
The default setting is Fahrenheit(°F). The pump can be
settoeitherCelsius(°C)orFahrenheit(°F).
1. Press Menu.
2. Press Select toselect“Settings”.
3. UsetheUp or Down arrows to scroll to “Temperature
Units”menuitem.PressSelect.
4. UseUp or DownarrowstochooseCelsius(°C)or
Fahrenheit(°F).
5. Press Entertosave.Tocancelanychanges,press
Escape to exit without saving.
6. Press Escape to exit.
Pump Menu: Settings
Pump Address
Thedefaultpumpaddressis#1.
Note: Sparus™Pumps with Constant Flow Technology
cannot be connected in series with other pumps.
1. BesurethegreenpowerLEDisonandthepump
is stopped.
2. Press Menu.
3. Press Selectfor“Settings”.PressSelect again to
select“PumpAddress”.
4. Tochangethepumpaddress,pressSelect.
5. Press Up or Down arrows to change the address
numberfrom1-16.
6. Press Entertosave.Tocancelanychanges,press
Escape to exit without saving.
7. Press Escape to exit.
Set Date
1. Press Menu.
2. Press Selecttoselect“Settings”.
3. UsetheUp or Downarrowstoscrollto“SetDate”
and press Select.
4. Usearrowbuttonstosetdate.
5. Press Entertosave.Tocancelanychanges,press
Escape to exit without saving.
6. Press Escape to exit.
Set Time
The time controls all scheduled times, functions, and
programmed cycles and stores the correct time for up
to96hoursafterpoweristurnedoff.Resetifthepower
isofflongerthan96hours.
1. CheckthatthegreenpowerLEDison.
2. Press Menu.
3. Press Selecttoselect“Settings”.
4. UsetheUp or Downarrowstoscrollto“SetTime”
and press Select.
5. Press Select again and use Up or Down arrows to
set the time.
Note: TochangeAM/PM,increaseordecrease
numbers until the desired time is displayed.
6. Press Entertosave.Tocancelanychanges,press
Escape to exit without saving.
7. Press Escape to exit.
Set AM/PM or 24 Clock
Changethetimefrom12hour(AM/PM)to24hourclock:
1. Press Menu.
2. Press Selecttoselect“Settings”.
3. UsetheUp or Downarrowstoscrollto“AM/PM.”
4. Press Select to change the setting.
5. Press Up or Downarrowstochoosebetween24hr.
andAM/PM.
6. Press Enter to save.Tocancelanychanges,press
Escape to exit without saving.
7. Press Escape to exit.
MENU
SETTINGS
(1-16) Default: ADDRESS 1
(hr:mm) Default: 12:00 AM
Set AM/PM AM/PM
24 hr.
Fahrenheit - Default: F°
C° Celsius
(1-5) Default 3
(450 RPM - 1700 RPM) - Default: 450 RPM
(1900 RPM - 3450 RPM) - Default: 3450 RPM
Pump Address
Set Time
Temperature Unit
Screen Contrast
Language
Set Min Speed
Set Max Speed
PASSWORD
Password Time Out (1 min. - 6 hours) Default:10 minutes
Disabled/Enabled - Default: Disabled
Enter Password (xxxx) Default: 1234
English - Default: English
Set Screen Contrast
Screencontrastlevelscanbeadjustedfrom1to5
units for low or high lighting conditions.
1. Press Menu.
2. Press Selecttoselect“Settings”.
3. UsetheUp or Down arrow to scroll to “Contrast
Level”.
4. Press Select. Screen will show current contrast
setting number.
5. Press Select to change the setting and use Up or
Down to change number.
6. Press Entertosave.Tocancelanychanges,press
Escape to exit without saving.
7. Press the Escape button to exit.
Set Flow Unit
TochangetheowunittoeitherGallonsperMinute
(GPM)orLitresperMinute(LPM).
1. Press Menu.
2. Press Select toselect“Settings”.
3. UsetheUp or Down arrows to scroll to “Set Flow
Unit”.PressSelect.
4. UseUp or DownarrowstochooseGPMorLPM.
5. Press Entertosave.Tocancelanychanges,press
Escape to exit without saving.

10
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
The Maximum Flow rate setting should be set so the
system never operates at or above 25” of Hg vacuum.
Pump Menu: Settings
MENU
SETTINGS
(1-16) Default: ADDRESS 1
(hr:mm) Default: 12:00 AM
Set AM/PM AM/PM
24 hr.
Fahrenheit - Default: F°
C° Celsius
(1-5) Default 3
(450 RPM - 1700 RPM) - Default: 450 RPM
(1900 RPM - 3450 RPM) - Default: 3450 RPM
Pump Address
Set Time
Temperature Unit
Screen Contrast
Language
Set Min Speed
Set Max Speed
PASSWORD
Password Time Out (1 min. - 6 hours) Default:10 minutes
Disabled/Enabled - Default: Disabled
Enter Password (xxxx) Default: 1234
English - Default: English
Set Minimum Speed (RPM)
Theminimumpumpspeedcanbesetfrom1100RPM
to3450RPM.Thedefaultsettingis1100RPM.
1. CheckthatthegreenpowerLEDison.
2. Press Menu.
3. Press Selecttoselect“Settings”.
4. Use the Up or Down arrows to scroll to“Set Min
Speed”.
5. Press Select to change the setting. The cursor will
appear in the first number column.
6. Press the Up or Down arrows to change the minimum
speedsettingfrom1100to3450RPM.
7. Press Entertosave.Tocancel,pressEscape to exit
edit mode without saving.
8. Press Escape to exit.
Set Maximum Speed (RPM)
The maximum speed can be set from 1100 RPM to
3450RPM(defaultis3450).Usethissettingtosetthe
maximum running speed of the pump.
WhentheSparus™Pump with Constant Flow Technology
issettoPriming“Enabled”,thepumpwillspeeduptoand
runatthisspeedtoprime.Aserviceprofessionalmust
settheMaximumSpeedofthepumptonotexceedthe
maximum flow rate of the system on which it will operate.
1. CheckthatthegreenpowerLEDison.
2. Press Menu.
3. Press Selecttoselect“Settings”.
4. UsetheUp or Downarrowstoscrollto“SetMax
Speed”.
5. Press Select to change. The cursor will appear in
therstnumbercolumn(ones).
6. Press Up or Down arrows to change the maximum
speedsettingfrom1100to3450RPM.
7. Press Enter. Press Escapetoexit.Tocancel,press
the Escape to exit without saving.
Password Protection
The default setting for password protection is disabled.
When this feature is enabled, the pump display will
prompt for the password before allowing access to the
control panel and buttons.
The entered password is any combination of four (4)
digits.
• Password protection can always be turned off by
pressing Start/Stop.
• Password protection cannot be turned back on with
Start/Stop while running in manual mode.
• Pressing Start/Stop when the pump is off will return
it back to the Running Cycles Mode and run at
the next scheduled run time. If the present time is
withinthescheduledruntime,thepumpwillrunthe
scheduled speed.
• Allfunctionsincludingprogrammingaredisabledin
PasswordProtectionMode.
• Screenwillread“EnterPassword”ifanybuttonother
than the Start/Stop button is pressed
• Key icon displayed in the upper left side of the
screen when Password Protection is on.
Entering Password
1. Press any button (besides the speed button) to
prompt the screen for a password.
2. Toenterpassword,usetheLeft and Right arrows to
move the cursor and the Up and Down arrow button
to scroll through the digit then press Enter to confirm.
Setting Password
1. Press Menu. Press Select toselect“Settings”.
2. UsetheUp or Down arrowtoscrollto“Password”.
3. Press Select. Thedefaultsettingis“Disabled”.
4. Press Up or Down arrow to change the setting to
“Enabled”andpressEnter to save.
5. Press the Down arrow. “Password Timeout” is
displayed.
6. Thefactorydefaulttimeis10minutes.Thismeans
thepumpwillgointoPasswordProtectionmode10
minutes after the last control panel key is pressed.
7. Press Selecttochangetimesettingfrom1minute
to6hoursandpressEnter to save.
8. Press Down arrow and then press Selecton“Enter
Password”tochangethesetting.
9. Press the Left or Right arrows to move cursor and
press Up or Down arrow to change password number
to desired setting.
10. Press Entertosave.Tocancelanychanges,press
Escape to exit without saving.
Alarm Log
1. Press Menu.
2. Press Select toselect“Settings”.
3. UsetheUp or Downarrowstoscrollto“AlarmLog”.
Press Select.
4. Press Select again to view alarm history.
5. UseUp or Down arrows to scroll through alarm history.

11
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Pump Menu: Speeds 1-8
SPEED 1-8
Speed 1 (1-4) Manual
Schedule
Egg Timer
Set Speed - Default: MANUAL
Set Speed
Set Start Time
Set Stop Time
Set Speed
Time
Speed 5 (5-8)
Schedule Set Speed
Set Start Time
Set Stop Time
Disabled Default: Disabled
MENU
Pump Operating Modes
The Sparus™Pump with Constant Flow Technology
can be programmed in three different modes: Manual,
Schedule, and Egg Timer.
Speeds1-4canbeprogrammedinallthreemodes.
Speeds5-8canonlybeprogrammedinSchedule
mode since there are no buttons on the control panel
forSpeeds5-8.ThedefaultsettingforSpeeds5-8is
“Disabled”.
Set Speeds in Manual or Egg Timer Mode
(Speeds 1-4 Only)
1. Press Menu.
2. Use Up or Down arrows to scroll to“Speed 1-8”,
then press Select.
3. UseUp or Downarrowstondthespeed(1-4)you
wish to program.
4. Press Select. Speeds1-4defaultsettingis
Manual.TosetaspeedinManualmode,pressthe
Downarrow(“SetSpeed”willdisplay)andpress
Select tochange.UsetheUp or Down arrow to
adjustspeed.
5. Press Enter to save the new speed setting.
Continue below to Step 6 to set a speed in Egg
Timer mode.
6. Press Select and scrollto“EggTimer”.
Press Enter.
7. Press the Downarrowtodisplay“Time”.
8. Press Select andusearrowkeystoadjusttime.
9. Press Enter to save the new time setting.
10. Press Escape to exit.
Speed 1 (1-4) Manual
Schedule
Egg Timer
Set Speed - Default: MANUAL
Set Speed
Set Start Time
Set Stop Time
Set Speed
Time
Speed 5 (5-8)
Schedule Set Speed
Set Start Time
Set Stop Time
Disabled Default: Disabled
• Manual:AssignsaspeedtooneofthefourSpeed
buttons on the control panel.This mode can only be
usedforspeeds1-4.
TooperateinManualmode,pressoneofthefour
speedbuttonsandthenpresstheStart/Stopbutton.
The pump will run the assigned speed for that
speed button.
• Egg Timer: Speeds1-4canbeprogrammedtorun
for a duration of time once a speed button is pressed.
To operate in Egg Timer mode, press a speed
buttonandthenpressStart/Stop.Thepumpwillrun
that speed for the set amount of time and then turn
off.
• Schedule: Program speeds 1-8 start and stop at
a specic time during a 24 hour period. Speeds
programmed in Schedule mode will override any
manuallyselectedspeed(speedssetbymanually
pressing any of the speed buttons on the control
panel).
12:15p
Egg Timer
Time
12:15p
Manual
Set Speed
ManualModeMenuScreen
EggTimerMenuScreen

12
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Pump Menu: Speeds 1-8
SPEED 1-8
Speed 1 (1-4) Manual
Schedule
Egg Timer
Set Speed - Default: MANUAL
Set Speed
Set Start Time
Set Stop Time
Set Speed
Time
Speed 5 (5-8)
Schedule Set Speed
Set Start Time
Set Stop Time
Disabled Default: Disabled
MENU
Set Speeds 1-8 in Schedule Mode
In Schedule mode, Speeds 1-8 can be programmed
to run a certain speed at a certain time of day. To run
ascheduledspeed,pressStart/Stop. The screen will
display “Running Schedules” when it is ready to run
a scheduled speed. If Start/Stop is pressed while a
scheduledspeedisrunning,“RunningSpeed_”willbe
displayed.
1. Press Menu.
2. Use Up or Down arrows toscrollto“Speed1-8”,
then press Select.
3. UseUp or Down arrows and press Select for the
speed you wish to set and schedule.
4. Press Select (displaywillbehighlighted)and
scrollto“Schedule”.
5. Press Enter.
6. Press Downarrow(“SetSpeed”willdisplay)and
press Select tochange.UsetheUp or Down
arrowtoadjustspeed.
7. Press Enter to save the new speed.
8. Press the Downarrowagain,“SetStartTime”will
display. Press Select -the cursor will highlight the
minute column.
9. UsetheUp or Down arrow to change the time
and the Left or Right arrow to move cursor from
minutes to hours.
10. Press Enter to save the new start time setting.
11. Press Downarrow-“SetStopTime”willdisplay.Press
Select.RepeatSteps8-9tosetstoptime.
12. Press Enter to save the new stop time setting.
13. Press Start/Stop.
The Sparus™Pump with Constant Flow Technology will
prime and begin to run the programmed schedule at the
specified start time.
When running in Schedule or Egg Timer mode, the
countdown time (T 00:01) showing the hours and
minutes remaining is displayed.
12:15p
Set Speed
Schedule
Note: The pump will not run the scheduled speeds until the
Start/Stopbuttonispressed(LEDon)toplacethepumpin
Schedule mode.
Note: Whentwospeedsarescheduledduringthe
sameruntimethepumpwillrunthehigherRPMSpeed
regardlessofSpeed#inuse.
Note: Themostrecentcommand,ManualorSchedule,
takespriorityregardlessofspeednumberRPM.
Programming Schedule for Constant Run
Aspeedcannotbeprogrammedwiththesamestart
andstoptimes.Torunaspeedwithoutstopping,set
the Start time one minute after the stop time.
Example: Asinglespeedwillrunnonstopifprogrammed
withaStartTimeof8:00AMandaStoptimeof7:59AM.
12:15p
1100 RPM
T 1:05 150 WATTS
Running Speed 1

13
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Pump Menu: Features
FEATURES
Quick Clean Set Speed (1100 -3450 RPM) Default: 3450 RPM
Time (1 min. to 10 hrs.) Default: 10 minutes
Time Out Duration (1 min. to 10 hrs.) Default: 3 hours
Time Out
MENU
Quick Clean
This feature can be used to ramp the Sparus™Pump
withConstantFlowTechnologyuptoahigherRPMfor
vacuuming,cleaning,addingchemicals,after a storm
for extra skimming capability.
Press the Quick Cleanbutton(LEDon)andthen
Start/Stoptostart.WhentheQuickCleancycleisover,
the pump will resume regular schedules and be in
“RunningSchedule”mode.
To access the Quick Clean menu:
1. CheckthatthegreenpowerLEDison.
2. PressMenu.
3. UseUp or Downarrowstoscrollto“Features”,
then press Select.
4. PresstheDown arrow and press Select for
“QuickClean”.
7. PressSelecttochoose“SetSpeed”.
8. PressSelect tohighlightthe“RPM”rst(ones)
column and change the speed.
Time Out
This feature can be used to allow newly glued pipe
joints time to dry before circulation of water resumes.
The Time Out feature keeps the pump from running its
programmed speeds.
OnceTimeOutisnished,thepumpwillbein
“RunningSchedule”mode,theStart/StopLEDwillbe
lit and ready to turn on at the next scheduled run time.
To access the Time Out menu:
1. CheckthatthegreenpowerLEDison.
2. PressMenu.
3. Use Up or Down arrows to scroll to “Features”,
then press Select.
5. PressSelect tochoose“Timeout”.
6. Then press Select again to choose “Timeout
Duration”.
7. PressSelect to change the time. The cursor will
highlight the minutes column.
8. PresstheLeft arrow to move cursor to the hours
column. Timeoutcanbesetfrom1minuteto10
hours.
9. PressEnter to save the setting.
Note:To cancel any changes,press Escape to
exit without saving.
10. PressEscape to exit the menu.
ThedefaultsettingforPrimingisENABLED.Thissetting
allows the pump to automatically detect if it is primed for
startup.
The priming feature ramps the pump to 1800 RPM and
pauses for three (3) seconds. If there is sufcient water
owinthepumpbasket,thepumpwillgooutofpriming
mode and run its commanded speed.
Ifthewaterowisnotsufcient,thepumpwillramptothe
“MaxSpeed”settingandremainfortheprimingdelaytime
(default20seconds).Ifthereissufcientwaterowinthe
pumpbasketatthistime,itwillgooutofprimingmodeand
ramp to the commanded speed.
Ifthereisstillinsufcientowinthepumpbasket,thepump
willtrytoprimeatthe“MaximumSpeed”fortheamountof
timesetupinthe“MaximumPrimingTime”menu.
PRIMING
DISABLED/ENABLED
(1 min. to 30 min. hrs.) Default: 11 minutes
MAX PRIMING TIME
Disabled / Enabled - Default: Enabled
Default: Enabled
(1 - 100%) Default: 1
PRIMED SENSITIVITY
(1 second - 10 minutes) Default: 20 seconds
PRIMING DELAY
DISABLED/ENABLED
MENU
Pump Menu: Priming
12:15p
1800 RPM
T 00:01 460 WATTS
Priming
Displayduringpriming
Continue onto the next page for Priming Features
9. UseUp or Down arrows to change the speed.
10. PressEnter to save the speed.
11. PresstheDownarrowagain,andpressSelect
for“TimeDuration”.
12. PressSelect to change the time. The cursor will
highlight the minutes column.
13. UseUp or Down arrows to change the time from
1minuteto10hours.
14. PressEnter to save the time.
15. PressEscape to exit the menu.

14
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
Setting Priming Features
1. PressMenu.
2. Use Down arrow to scroll to“Priming” and press
Select.
3. The factory default is set to priming“Enabled“.To
disable,pressSelect.
4. Press Enter if you have changed the setting - this
will save the selection.
5. Press the Down arrow - the screen will read“Max
PrimingTime”.
6. To change from factory default, press Select. The
cursor will highlight.
7. UsetheUp or Down arrows to change the time from
1minuteto30minutes.
8. PressEnter to save.
9. PresstheDownarrow-thescreenwillread“Primed
Sensitivity”.Defaultis“1”
10. PressSelect to change the priming sensitivity. The
cursor will highlight the number.
Priming Features
DISABLED/ENABLED
MAX PRIMING TIME
PRIMED SENSITIVITY
PRIMING DELAY
Default: ENABLED
AllowspumptoautomaticallydetectifSparus™Pump with Constant Flow Technology
isprimedforstartup.Thepumpwillrampupto1800RPMandpauseforthree(3)
seconds-ifthereisenoughwaterinthebasket,thepumpwillgooutofprimingmode
and run the commanded speed.
Default: 11 minutes
Themaximumprimingtimecanbesetfrom1-30minutes.Thissettingistheamountof
timethepumpwilltrytoprimebeforeitgivesaprimingerror.Ifthisoccurs,llthepump
basket with water and restart the pump.
Default: 20 seconds
Primingdelaycanbesetfrom1secondto10minutes.
Ifthepumpdoesnothaveenoughwateraftertheautomaticprimingmode,thepump
willramptotheMaximumSpeed(under“PumpSettings”onpage10)andrunfor20
seconds(orforthetimeset).
Youmayneedtoincreasetheprimingdelaytoallowthesystemtostabilizebeforethe
pumpstartsrunningspeeds.Ifpumpcontinuestoshowaprimingerror,increasingthe
priming delay time might correct this issue.
Default: 1%
Primingsensitivitycanbesetfrom1-100%.1%meansthepumpisthemostsensitive
tosensingifpumphasattainedprime.Increasing%willdecreaseamountofow
needed for pump to sense prime.
Increasethe%ifthepumpclearlyhaswaterinthebasketbutishavingtroublecoming
out of priming mode. Setting this number too high can cause the pump to think it has
attained a prime when it has not.
11. UsetheUp or Downarrowstochangefrom1%to
100%.IncreasingthenumbermakesthePrimingless
sensitive.
12. PressEnter to save.
13. PresstheDownarrow-thescreenwillread“Priming
Delay”.Defaultis20seconds.
14. PressSelect to change the priming delay time.
15. UsetheUp or Downarrowstochangefrom1second
to10minutes.
Caution: Increasing the time causes the pump to
stay in the priming mode longer.
16. PressEnter to save the setting.
17. PressEscape to exit.
PRIMING
DISABLED/ENABLED
(1 min. to 30 min. hrs.) Default: 11 minutes
MAX PRIMING TIME
Disabled / Enabled - Default: Enabled
Default: Enabled
(1 - 100%) Default: 1
PRIMED SENSITIVITY
(1 second - 10 minutes) Default: 20 seconds
PRIMING DELAY
DISABLED/ENABLED
MENU
Pump Menu: Priming

15
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
ThesensorforAntiFreezeisinthedrive,ontopofthe
motor. This feature allows you to set a speed (1100
RPM-3450RPM)thatrunswhentheSparus™Pump
with Constant FlowTechnology goes into anti freeze
mode.Thetemperaturelevelthatyouwishantifreeze
mode to start can also be set.
IMPORTANT NOTE: This feature is for protection of
thepump.Donotdependontheantifreezefeaturefor
freezeprotectionofthebodyofwater.Certainsituations
could cause the pump to sense a different temperature
than actual air temperature.
Disabled / Enabled - Default: Enabled
40°F - 50°F (4.4°C - 10°C) Default: 40°F (4.4°C)
Set Speed (1100 RPM - 3450 RPM) Default 1100 RPM
DISABLED/ENABLED
SET SPEED
PUMP TEMPERATURE
ANTI FREEZE
ANTI FREEZE
Disabled / Enabled - Default: Enabled
DISABLED/ENABLED
SET SPEED
40° F - 50° F (4.4° C - 10° C) Default: 40° F (4.4° C)
PUMP TEMPERATURE
Set Speed (750 RPM - 3450 RPM) Default 1000 RPM
PRIMING DISABLED/ENABLED
(1 min. to 30 min. hrs.) Default: 11 minutes
MAX PRIMING TIME
Disabled / Enabled - Default: Enabled
Default: Enabled
(1 - 100%) Default: 1
PRIMED SENSITIVITY
(1 second - 10 minutes) Default: 20 seconds
PRIMING DELAY
DISABLED/ENABLED
MENU
Pump Menu: Anti Freeze
12:15p
Pump Temperature
40F
°
To access the Anti Freeze menu:
1. CheckthatthegreenpowerLEDison.
2. PressMenu.
3. UsetheDownarrowtoscrollto“AntiFreeze”
and press Select.
4. ThefactorydefaultforAntiFreezeis“Enabled“.
TodisableAntiFreeze,pressSelect to highlight
“Enabled”.
5. PresstheUparrow-“Disabled”isdisplayed.
6. PressEnter to save.
To Set Anti Freeze Speed and Pump Temperature:
1. WithAntiFreezedisplayedonthescreen,press
the Downarrow-“SetSpeed”isdisplayed.The
factorydefaultis1100RPM.
2. PressSelect to change the speed. The cursor
willhighlighttherstcolumn(ones).
3. UsetheUp or Down arrows to set speed
(1100-3450RPM).
4. PressEnter to save the speed.
5. PresstheDown arrow to Pump Temperature
(the temperature the pump will activate
AntiFreeze,defaultis40°F/4.4°C).
6. PressSelect to change the setting. The cursor
will highlight the first column. Can be set 40°F
to50°F(4.4°C-10°C).
7. PressEnter to save the temperature setting.
Note:Tocancelanychanges,pressEscape to
exit without saving.
8. PressEscape to exit.
SettingtheAntiFreezePumpTemperature
AntiFreezeMenuOptions
12:15p
Set Speed
1100RPM
SettingtheAntiFreezePumpSpeed

16
SPARUS™Pump with Constant Flow Technology Installation and User’s Guide
MAINTENANCE
Cleaning the Pump Strainer Basket
1. Turnoffthepumpatthecircuitbreaker.
2. Relievepressureinthesystem.
3. Turnthelidandclampcounter-clockwiseandremove
from the pump.
4. Removedebrisand rinseoutthe basket.Replace
the basket if it is cracked.
5. Putthebasketbackintothehousing. Be sure to align
the notch in the bottom of the basket with the rib in
the bottom of the volute.
6. Fillthepumppotandvoluteuptotheinletportwith
water.
7. Cleanthelidandclamp,O-ring,andsealingsurface
of the pump pot.
Note:ItisimportanttokeepthelidO-ringcleanand
well lubricated.
8. Reinstallthelidbyplacingtheclampandlidonthe
pot.BesurethelidO-ringisproperlyplaced.
Seat the clamp and lid on the pump then turn clockwise
untilthelockingringhandlesarehorizontal.
9. Turnthepower“ON”atthecircuitbreaker.
10. Openthemanualairreliefvalveonthetopofthe
filter. Stand clear of the filter.
11. Waituntilallpressureisrelieved.Startthepump.
12. Bleedairfromthelteruntilasteadystreamof
water comes out of the filter air relief valve. Close
the manual air relief valve.
Pump Strainer Basket
Thestrainerbasket(or‘strainerpot’),islocatedinfront
of the Sparus™Pump with Constant Flow Technology
housing. The strainer basket must be kept clean and
free of debris. Inspect basket through the lid on the top
of the housing.
Besuretovisuallyinspectthestrainerbasketevery1to
4weeks.Dirtystrainerbasketsreducelterandheater
efficiency and put abnormal stress on the pump motor.
Bacterial fouling could cause the lid to not be clear.
DO NOT open the strainer pot if pump fails to prime or if pump has been operating without water in the strainer pot. Pumps operated
in these circumstances may experience a build up of vapor pressure and may contain scalding hot water. Opening the pump may
cause serious personal injury. In order to avoid the possibility of personal injury, make sure the suction and discharge valves are
open and strainer pot temperature is cool to touch, then open with extreme caution.
To prevent damage to the pump and for proper operation of the system, clean pump strainer and skimmer baskets regularly.
Winterizing
• Inmildclimateareas,whentemporaryfreezing
conditionsmayoccur,runyourlteringequipment
allnighttopreventfreezing.
• Youareresponsiblefordeterminingwhenfreezing
conditionsmayoccur.Iffreezingconditionsare
expected,takethefollowingstepstoreducethe
riskoffreezedamage.Freezedamageisnot
covered under warranty.
1. Shutoffelectricalpowerforthepumpatthecircuit
breaker.
2. Drainthewateroutofthepumphousingbyremoving
the two thumb-twist drain plugs from the housing.
Store the plugs in the pump basket.
3. Coverthemotortoprotectitfromsevererain,snow
and ice.
Note: Donotwrapmotorwithplasticorotherair
tight materials during winter storage. The motor
maybecoveredduringastorm,winterstorage,etc.,
but never when operating or expecting operation.
THIS SYSTEM OPERATES UNDER HIGH
PRESSURE. When any part of the circulating
system (e.g., Lock Ring, Pump, Filter, Valves,
etc.) is serviced, air can enter the system and
become pressurized. Pressurized air can cause
the lid to separate which can result in serious
injury, death, or property damage. To avoid this
potential hazard, follow above instructions.
Clamp,pot
O-Ring
Lid
Strainer
Basket
Pot
Drain
Plugs
Volute
StrainerPotAssembly
Topreventfreeze,damagefollowtheproceduresbelow:
