Pepperl+Fuchs ecom Ex-Handy 10 User manual

Battery
The battery of the feature phone is not fully charged.
It is recommended to charge the phone for five hours before
using it for the first time. The full capacity of the battery is
reached after 3-4 complete charge/discharge cycles.
Warranty
The warranty of this product follows the General Conditions
of Delivery and Payment of Pepperl+Fuchs GmbH, which are
available at www.pepperl-fuchs.com, or alternatively they can
be requested directly from the manufacturer.
Support
E-Mail: [email protected]
Note:
Please also observe the safety requirements in the specific
safety instructions and the information in the full user guide
for your device. The documents can be downloaded from the
relevant product page at www.ecom-ex.com
QUICK START GUIDE
THE NEXT GENERATION FEATURE PHONE FOR IIOT
ecom instruments GmbH | Industriestraße 2 | 97959 Assamstadt | Germany
Phone [phone] | Fax [phone]
[e-mail] | www.ecom-ex.com
DOCT-6426 | 01/2019
WEEE-Reg.-Nr. DE 934 99306
Subject to change without notice.
Copyright© 2018 ecom instruments GmbH.
The contents of this document, either in part or in their entirety, may not be reproduced, forwarded, distributed
or saved in any way without ecom instruments GmbH prior written consent.
The contents of this document are presented as they currently exist. ecom instruments GmbH does not provide
any express or tacit guarantee for the correctness or completeness of the contents of this document, including,
but not restricted to, the tacit guarantee of market suitability or tness for a specic purpose unless applicable
laws or court decisions make liability mandatory. ecom instruments GmbH reserves the right to make changes
to this document or to withdraw it any time without prior notice.
Intrinsically safe feature phone Ex-Handy 10
Zone 1/21, Div. 1
Zone 2/22, Div.2rugged

How to insert the nano-SIM card
Step 1
To insert the nano-SIM card
unscrew the two cover screws in
a counter clockwise direction and
remove the SIM card cover.
Please use the screwdriver Torx
T8 provided with the device.
Step 2
Insert the nano-SIM card with
the gold-colored contacts facing
downwards by pushing it upward
in the designated slot.
Step 3
Reattach the SIM card cover
and screw down the two cover
screws in a clockwise direction.
Please use the screwdriver Torx
T8 provided with the device and
ensure not to overtighten the
screws.
4
8
7
5
6
9
10
11
12
13
2
3
1
16
14 15
1Receiver
2Proximity/Light sensor
3Alarm key
4Power key
5Touchdisplay
6Home key
7Options key
8Camera key
9End Call/Reject
10 Loudspeaker
11 Magnetic USB port
12 Call/Accept
13 Back key
14 Volume keys
15 PTT key
16 Headset port
nano-
SIM
