Pepperl+Fuchs HiD2024 User manual

Functional Safety
SMART Transmitter Power
Supply/Current Driver
HiD2024
PROCESS AUTOMATION
MANUAL
ISO9001
2

With regard to the supply of products, the current issue of the following document is
applicable: The General Terms of Delivery for Products and Services
of the Electrical Industry, published by the Central Association of the Electrical Industry
(Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent
version as well as the supplementary clause: "Expanded reservation of proprietorship"
Functional Safety HiD2024

Functional Safety HiD2024
Content
2016-06
3
1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3 Symbols Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4 Standards and Directives for Functional Safety. . . . . . . . . . . . 7
3 Planning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.1 System Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.2 Assumptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Safety Function and Safe State . . . . . . . . . . . . . . . . . . . . . . . . 10
3.4 Characteristic Safety Values . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.5 Useful Life Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4 Mounting and Installation . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.1 Proof Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6 Maintenance and Repair . . . . . . . . . . . . . . . . . . . . . . . . . 18
7 Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Functional Safety Manual HiD2872, HiC2873(Y1), HiD2876, HiC2877

2016-06
4
Functional Safety HiD2024
Introduction
1Introduction
1.1 Contents
This document contains information for usage of the device in functional safety-
related applications. You need this information to use your product throughout the
applicable stages of the product life cycle. These can include the following:
• Product identification
• Delivery, transport, and storage
• Mounting and installation
• Commissioning and operation
• Maintenance and repair
•Troubleshooting
•Dismounting
•Disposal
The documentation consists of the following parts:
•Presentdocument
• Instruction manual
•Manual
• Datasheet
Additionally, the following parts may belong to the documentation, if applicable:
• EC-type of examination
• EU declaration of conformity
• Attestation of conformity
• Certificates
• Control drawings
• FMEDA report
• Assessment report
• Additional documents
For more information about functional safety products from Pepperl+Fuchs see
www.pepperl-fuchs.com/sil.
Note!
This document does not substitute the instruction manual.
Note!
For full information on the product, refer to the instruction manual and further
documentation on the Internet at www.pepperl-fuchs.com.
Functional Safety KFD2-SR3-(Ex)2.2S

Functional Safety HiD2024
Introduction
2016-06
5
1.2 Safety Information
Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation, maintenance,
and dismounting lies with the plant operator.
Only appropriately trained and qualified personnel may carry out mounting,
installation, commissioning, operation, maintenance, and dismounting of the
product. The personnel must have read and understood the instruction manual
and the further documentation.
Intended Use
The device is only approved for appropriate and intended use. Ignoring these
instructions will void any warranty and absolve the manufacturer from any liability.
The device is developed, manufactured and tested according to the relevant
safety standards.
Use the device only
• for the application described
• with specified environmental conditions
• with devices that are suitable for this safety application
Improper Use
Protection of the personnel and the plant is not ensured if the device is not used
according to its intended use.
1.3 Symbols Used
This document contains symbols for the identification of warning messages and
of informative messages.
Warning Messages
You will find warning messages, whenever dangers may arise from your actions.
It is mandatory that you observe these warning messages for your personal safety
and in order to avoid property damage.

2016-06
6
Functional Safety HiD2024
Introduction
Depending on the risk level, the warning messages are displayed in descending
order as follows:
Informative Symbols
Action
This symbol indicates a paragraph with instructions. You are prompted to perform
an action or a sequence of actions.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and
plants, or result in their complete failure.
Note!
This symbol brings important information to your attention.

Functional Safety HiD2024
Product Description
2016-06
7
2 Product Description
2.1 Function
This isolated barrier is used for intrinsic safety applications.
Bi-directional communication is supported for SMART transmitters that use
current modulation to transmit data and voltage modulation to receive data.
The outputs are fully isolated from the inputs, the power supply, and each other.
An open field circuit presents a high impedance to the control side to allow alarm
conditions to be monitored by control systems.
This device mounts on a HiD Termination Board.
2.2 Interfaces
The device has the following interfaces.
• Safety relevant interfaces:input I to input IV and output I to output IV
• Non-safety relevant interfaces: power supply, collective error message output
2.3 Marking
2.4 Standards and Directives for Functional Safety
Device-specific standards and directives
System-specific standards and directives
Note!
For corresponding connections see datasheet.
Pepperl+Fuchs GmbH
Lilienthalstraße 200, 68307 Mannheim, Germany
HiD2024 Up to SIL 2
Functional safety IEC/EN 61508, part 2, edition 2010:
Functional safety of
electrical/electronic/programmable electronic
safety-related systems (manufacturer)
Functional safety IEC/EN 61511, part 1 –3, edition 2003:
Functional safety –Safety instrumented systems for
the process industry sector (user)
Functional Safety HiD2024

2016-06
8
Functional Safety HiD2024
Planning
3Planning
3.1 System Structure
3.1.1 Low Demand Mode of Operation
If there are two control loops, one for the standard operation and another one for
the functional safety, then usually the demand rate for the safety loop is assumed
to be less than once per year.
The relevant safety parameters to be verified are:
•thePFD
avg value (average Probability of dangerous Failure on Demand) and
the T1value (proof test interval that has a direct impact on the PFDavg value)
•theSFFvalue(Safe Failure Fraction)
•theHFTarchitecture(Hardware Fault Tolerance)
3.1.2 High Demand or Continuous Mode of Operation
If there is only one safety loop, which combines the standard operation and
safety-related operation, then usually the demand rate for this safety loop is
assumed to be higher than once per year.
The relevant safety parameters to be verified are:
• the PFH value (Probability of dangerous Failure per Hour)
• Fault reaction time of the safety system
•theSFFvalue(Safe Failure Fraction)
•theHFTarchitecture(Hardware Fault Tolerance)
3.1.3 Safe Failure Fraction
The safe failure fraction describes the ratio of all safe failures and dangerous
detected failures to the total failure rate.
SFF = (s+ dd) / (s+ dd + du)
A safe failure fraction as defined in IEC/EN 61508 is only relevant for elements or
(sub)systems in a complete safety loop. The device under consideration is
always part of a safety loop but is not regarded as a complete element or
subsystem.
For calculating the SIL of a safety loop it is necessary to evaluate the safe failure
fraction of elements, subsystems and the complete system, but not of a single
device.
Nevertheless the SFF of the device is given in this document for reference.
Functional Safety HiD2024

Functional Safety HiD2024
Planning
2016-06
9
3.2 Assumptions
The following assumptions have been made during the FMEDA:
• The device shall claim less than 10 % of the total failure budget for a SIL 2
safety loop.
• For a SIL 2 application operating in low demand mode the total PFDavg value
of the SIF (Safety Instrumented Function) should be smaller than 10-2, hence
the maximum allowable PFDavg value would then be 10-3.
• For a SIL 2 application operating in high demand mode the total PFH value of
the SIF should be smaller than 10-6 per hour, hence the maximum allowable
PFH value would then be 10-7 per hour.
• Failure rate based on the Siemens standard SN29500.
• Failure rates are constant, wear is not considered.
• The safety-related device is considered to be of type Adevice with a hardware
fault tolerance of 0.
• Since the safety loop has a hardware fault tolerance of 0and it is a type A
device, the SFF must be > 60 % according to table 2 of IEC/EN 61508-2 for a
SIL 2 (sub) system.
• The device will be used under average industrial ambient conditions, which
are comparable with the classification "stationary mounted" in MIL-HDBK-
217F. Alternatively, the following ambient conditions are assumed:
• IEC/EN 60654-1 Class C (sheltered location) with temperature limits in the
range of the manufacturer's specifications and an average temperature of
40 ºC over a long period. The humidity level is within manufacturer's rating.
For a higher average temperature of 60 ºC, the failure rates must be
multiplied by a factor of 2.5 based on experience. A similar factor must be
used if frequent temperature fluctuations are expected.
• The application program in the programmable logic controller (PLC) is
configured to detect underrange and overrange failures.
• The devices are not protected against power supply failures. It is within the
responsibility of the user to ensure that low supply voltages are detected and
adequate reaction on this fault is implemented.

2016-06
10
Functional Safety HiD2024
Planning
3.3 Safety Function and Safe State
Safe State
The safe state depends on the respective application.
Mostly a value within the signal range is defined, below which (low limit value) or
above which (high limit value) the safe state is initiated.
As this individual limit value and this direction are not known to Pepperl+Fuchs, a
discrepancy of more than 2 % in the signal path is as worst case rated dangerous
undetected. Furthermore, the output values below 3.6 mA or above 21.5 mA
indicate failures that are considered as dangerous detected.
Ensure that the programmable controller is programmed to react to these values
suitably.
Safety Function
The device transfers an analog signal from the input to the output with a tolerance
of 2 % of the measured range.
You have the possibility for each channel to define different functions to fit your
safety application.
DIP Switch Settings
Potentiometer Settings
You can adjust the signal transfer accuracy via the potentiometers.
Reaction Time
The reaction time for all safety functions is < 100 ms.
Function Switch settings
S1 S2 S3 S4
Analog input with source output 4 mA ... 20 mA OFF OFF OFF ON
Analog input with source output 1 V ... 5 V OFF ON OFF ON
Analog input with sink output 4 mA ... 20 mA OFF OFF ON OFF
Analog output ON OFF ON OFF
Table 3.1
Note!
For more information see the corresponding datasheets.

Functional Safety HiD2024
Planning
2016-06
11
3.4 Characteristic Safety Values
Configure the device for the required function via the DIP switches,
see chapter 3.3.
Analog Input Function
Parameters acc. to IEC 61508 Characteristic values
Assessment type and documentation FMEDA report
Device type A
Mode of operation Low Demand Mode or High Demand Mode
HFT 0
SIL (SC) 2
Safety function Signal transfer to programmable logic controller
(PLC)
s0 FIT
dd 121 FIT
du 49.9 FIT
total (safety function) 171 FIT
not part 59 FIT
SFF 1
1"Not considered" failures are considered 50 % as dangerous undetected and 50 % as "No effect". "No effect"
failures are not influencing the safety functions and are therefore not included in the calculation of the SFF.
70 %
PTC 100 %
MTBF 2
2acc. to SN29500. This value includes failures which are not part of the safety function/MTTR = 8 h. This value
is calculated for one safety function of a device.
314 years
PFH 4.99 x 10-8 1/h
PFDavg for T1= 1 year 2.18 x 10-4
PFDavg for T1= 2 years 4.37 x 10-4
PFDavg for T1= 5 years 1.03 x 10-3
Reaction time < 100 ms
Table 3.2

2016-06
12
Functional Safety HiD2024
Planning
Analog Output Function
The characteristic safety values like PFD, SFF, HFT and T1are taken from the
SIL report/FMEDA report. Observe that PFD and T1are related to each other.
The function of the devices has to be checked within the proof test interval (T1).
Parameters acc. to IEC 61508 Characteristic values
Assessment type and documentation FMEDA report
Device type A
Mode of operation Low Demand Mode or High Demand Mode
HFT 0
SIL (SC) 2
Safety function Signal transfer to field device
s0 FIT
dd 108 FIT
du 70 FIT
total (safety function) 178 FIT
not part 43 FIT
SFF 1
1"Not considered" failures are considered 50 % as dangerous undetected and 50 % as "No effect". "No effect"
failures are not influencing the safety functions and are therefore not included in the calculation of the SFF.
60.7 %
PTC 100 %
MTBF 2
2acc. to SN29500. This value includes failures which are not part of the safety function/MTTR = 8 h. This value
is calculated for one safety function of a device.
314 years
PFH 6.98 x 10-8 1/h
PFDavg for T1= 1 year 3.06 x 10-4
PFDavg for T1= 2 years 6.12 x 10-4
PFDavg for T1= 5 years 1.53 x 10-3
Reaction time < 100 ms
Table 3.3

Functional Safety HiD2024
Planning
2016-06
13
3.5 Useful Life Time
Although a constant failure rate is assumed by the probabilistic estimation this
only applies provided that the useful lifetime of components is not exceeded.
Beyond this useful lifetime, the result of the probabilistic estimation is
meaningless as the probability of failure significantly increases with time. The
useful lifetime is highly dependent on the component itself and its operating
conditions –temperature in particular. For example, the electrolytic capacitors
can be very sensitive to the operating temperature.
This assumption of a constant failure rate is based on the bathtub curve, which
shows the typical behavior for electronic components.
Therefore it is obvious that failure calculation is only valid for components that
have this constant domain and that the validity of the calculation is limited to the
useful lifetime of each component.
It is assumed that early failures are detected to a huge percentage during the
installation and therefore the assumption of a constant failure rate during the
useful lifetime is valid.
However, according to IEC/EN 61508-2, a useful lifetime, based on general
experience, should be assumed. Experience has shown that the useful lifetime
often lies within a range period of about 8 ... 12 years.
As noted in DIN EN 61508-2:2011 note N3, appropriate measures taken by the
manufacturer and plant operator can extend the useful lifetime.
Our experience has shown that the useful lifetime of a Pepperl+Fuchs product
can be higher
• if there are no components with reduced life time in the safety loop (for
example electrolytic capacitors, relays, flash memories, optocoupler) which
can produce dangerous undetected failures and
• if the ambient temperature is significantly below 60 °C.
Please note that the useful lifetime refers to the (constant) failure rate of the
device. The effective life time can be higher.

2016-06
14
Functional Safety HiD2024
Mounting and Installation
4 Mounting and Installation
Installing the device
1. Observe the safety instructions in the instruction manual.
2. Observe the information in the manual.
3. Observe the requirements for the safety loop.
4. Connect the device only to devices that are suitable for this safety application.
5. Check the safety function to ensure the expected output behavior.
4.1 Configuration
Configuring the Device Function
The function of the device is configured via DIP switches. The DIP switches are
on the side of the device.
1. De-energize the device before configuring the device.
2. Remove the device.
3. Configure the device for the required function via the DIP switches,
see chapter 3.3.
4. Secure the DIP switches to prevent unintentional adjustments.
5. Mount the device.
6. Connect the device again.
Adjusting the Signal Transfer of the Device
You can adjust the signal transfer accuracy via the potentiometers. The
potentiometers are on the front of the device.
1. Configure the device for the required function via the DIP switches,
see above and chapter 3.3.
2. Open the cover.
3. Calibrate the current transfer via the potentiometer.
4. Secure the potentiometers to prevent unintentional adjustments.
5. Close the cover.
Note!
For more information see the corresponding datasheets.
Functional Safety HiD2024

Functional Safety HiD2024
Operation
2016-06
15
5Operation
Operating the device
1. Observe the safety instructions in the instruction manual.
2. Observe the information in the manual.
3. Use the device only with devices that are suitable for this safety application.
4. Correct any occurring safe failures within 8 hours. Take measures to maintain
the safety function while the device is being repaired.
5.1 Proof Test Procedure
According to IEC/EN 61508-2 a recurring proof test shall be undertaken to reveal
potential dangerous failures that are not detected otherwise.
Check the function of the subsystem at periodic intervals depending on the
applied PFDavg in accordance with the characteristic safety values.
See chapter 3.4.
It is under the responsibility of the plant operator to define the type of proof test
and the interval time period.
Equipment required:
• Digital multimeter with an accuracy better than 0.1 %
Use for the proof test of the intrinsic safety side of the device a special digital
multimeter for intrinsically safe circuits.
If intrinsically safe circuits are operated with non-intrinsically safe circuits,
they must no longer be used as intrinsically safe circuits.
• Variable power supply 0 V DC ... 24 V DC
•Loadwith
• max. 300 for analog input function with current output
•min.1Mfor analog input function with voltage output
• max. 650 for analog output function
• Process calibrator with current source and current sink function with an
accuracy better than 20 µA
Danger!
Danger to life from missing safety function
If the safety loop is put out of service, the safety function is no longer guaranteed.
• Do not deactivate the device.
• Do not bypass the safety function.
• Do not repair, modify, or manipulate the device.
Functional Safety HiD2024

2016-06
16
Functional Safety HiD2024
Operation
Proof Test Procedure
1. Put out of service the entire safety loop. Protect the safety application by
means of other measures.
2. Prepare a test set-up, see figures below.
3. Test the devices in the mode of operation they are used in. If necessary,
change the configuration of the device. Verify the input and output values as
given in table below.
4. Set back the device to the original settings for the application after the test.
Figure 5.1 Proof test set-up for HiD2024 with analog output function
Step No. Input value (mA) Measurement point
Output value (mA) Output value (V)
120.00 20.00 ±0.4 5.00 ±0.1
212.00 12.00 ±0.4 3.00 ±0.1
34.00 4.00 ±0.4 1.00 ±0.1
423.00 23.00 ±0.4 5.75 ±0.1
5 0 < 0.3 < 0.1
Table 5.1 Steps to be performed for the proof test
Termination Board
Zone 0, 1, 2
Div. 1, 2
Zone 2
Div. 2
Multimeter (mA )
4 mA ... 20 mA
I
supply
HiD2024
SL2
5a
5b
1a
1b
3a
3b
7a
7b
SL1
8a
7a
10a
9a
9b
10b
8b
7b
4 mA ... 20 mA
4 mA ... 20 mA
4 mA ... 20 mA
4 mA ... 20 mA
Multimeter (mA )
4 mA ... 20 mA
Multimeter (mA )
4 mA ... 20 mA
Multimeter (mA )
4 mA ... 20 mA
+
-
+
-
+
-
+
-
11
14
12
15
13
16
17
18
+
-
+
-
+
-
+
-
1
5
2
4
3
8
7
6
Supply +
Supply -
Supply
Bus
24 V DC
Power
supply

Functional Safety HiD2024
Operation
2016-06
17
Figure 5.2 Proof test set-up for HiD2024 with analog input function with current source or
voltage source output
Figure 5.3 Proof test set-up for HiD2024 with analog input function with current sink
4 mA ... 20 mA
4 mA ... 20 mA
4 mA ... 20 mA
4 mA ... 20 mA
Termination Board
Zone 0, 1, 2
Div. 1, 2
Zone 2
Div. 2
I
supply
HiD2024
SL2
5a
5b
1a
1b
3a
3b
7a
7b
SL1
8a
7a
10a
9a
9b
10b
8b
7b
Multimeter
(mA)
Multimeter
(V)
R
R
R
R
+
-
+
-
+
-
+
-
11
14
12
15
13
16
17
18
+
-
+
-
+
-
+
-
1
5
2
4
3
8
7
6
Supply +
Supply -
Supply
Bus
24 V DC
Power
supply
4 mA ... 20 mA
4 mA ... 20 mA
4 mA ... 20 mA
4 mA ... 20 mA
Termination Board
Zone 0, 1, 2
Div. 1, 2
Zone 2
Div. 2
I
supply
HiD2024
SL2
5a
5b
1a
1b
3a
3b
7a
7b
SL1
8a
7a
10a
9a
9b
10b
8b
7b
Multimeter
(mA)
24 V DC
24 V DC
24 V DC
24 V DC
+
-
+
-
+
-
+
-
11
14
12
15
13
16
17
18
+
-
+
-
+
-
+
-
1
5
2
4
3
8
7
6
Supply +
Supply -
Supply
Bus
24 V DC
Power
supply
Tip
The easiest way to test HiD devices by using a stand-alone
HiDTB**-SCT-***-**-** termination board. In this test, it is not necessary to
disconnect the wiring of the existing application. Faults in a subsequent wiring
can be avoided.

2016-06
18
Functional Safety HiD2024
Maintenance and Repair
6 Maintenance and Repair
Maintaining, Repairing or Replacing the Device
In case of maintenance, repair or replacement of the device, proceed as follows:
1. Implement appropriate maintenance procedures for regular maintenance of
the safety loop.
2. Ensure the proper function of the safety loop, while the device is maintained,
repaired or replaced.
If the safety loop does not work without the device, shut down the application.
Do not restart the application without taking proper precautions.
Secure the application against accidental restart.
3. Do not repair a defective device. A defective device must only be repaired by
the manufacturer.
4. Replace a defective device only by a device of the same type.
Danger!
Danger to life from missing safety function
If the safety loop is put out of service, the safety function is no longer guaranteed.
• Do not deactivate the device.
• Do not bypass the safety function.
• Do not repair, modify, or manipulate the device.
Functional Safety HiD2024

Functional Safety HiD2024
Abbreviations
2016-06
19
7 Abbreviations
ESD Emergency Shutdown
FIT Failure In Time in 10-9 1/h
FMEDA Failure Mode, Effects, and Diagnostics Analysis
sProbability of safe failure
dd Probability of dangerous detected failure
du Probability of dangerous undetected failure
no effect Probability of failures of components in the safety loop that have
no effect on the safety function. The no effect failure is not used
for calculation of SFF.
not part Probability of failure of components that are not in the safety loop
total (safety function) Safety function
HFT Hardware Fault Tolerance
MTBF Mean Time Between Failures
MTTR Mean Time To Restoration
PCS Process Control System
PFDavg Average Probability of dangerous Failure on Demand
PFH Average frequency of dangerous failure
PTC Proof Test Coverage
SFF Safe Failure Fraction
SIF Safety Instrumented Function
SIL Safety Integrity Level
SIL (SC) Safety Integrity Level (Systematic Capability)
SIS Safety Instrumented System
T1Proof Test Interval
PLC Programmable Logic Controller
Functional Safety HiD2024

Subject to modifications
Copyright PEPPERL+FUCHS • Printed in Germany
www.pepperl-fuchs.com
PROCESS AUTOMATION –
PROTECTING YOUR PROCESS
Worldwide Headquarters
Pepperl+Fuchs GmbH
68307 Mannheim · Germany
Tel. [phone]
E-mail: [email protected]
For the Pepperl+Fuchs representative
closest to you check www.pepperl-fuchs.com/contact
DOCT-4821A
06/2016
