Power Supply PS1000-A6-24.20.R
Contents
2021-11
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Terminology and Abbreviations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 AC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6 DC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7 Input Inrush Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9 Hold-Up Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
10 DC-OK Relay Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
11 Efficiency and Power Losses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
12 Lifetime Expectancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
13 MTBF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
14 Functional Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
15 Terminals and Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
16 Replacing Units while the System is Running . . . . . . . . . . . . . . . . . . . . . . . . . . 25
17 Front Side and User Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
18 EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
19 Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
20 Safety and Protection Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
21 Dielectric Strength. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
22 Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
23 Other Fulfilled Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
24 Physical Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
25 Application Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Power Supply PS1000-A6-24.20.R
Contents
4
2021-11

Power Supply PS1000-A6-24.20.R
Introduction
2021-11
5
1 Introduction
The information given in this document is correct to the best of our knowledge and experience
at the time of publication. If not expressly agreed otherwise, this information does not represent
a warranty in the legal sense of the word. As the state of our knowledge and experience is
constantly changing, the information in this data sheet is subject to revision. We therefore
kindly ask you to always use the latest issue of this document.
No part of this document may be reproduced or utilized in any form without our prior
permission in writing.

2021-11
6
Power Supply PS1000-A6-24.20.R
Terminology and Abbreviations
2 Terminology and Abbreviations
Figure 2.1 N+1 Redundancy
PE and symbol PE is the abbreviation for Protective Earth and has the same meaning
as the symbol .
Earth, Ground This document uses the term earth which is the same as the U.S. term
ground.
T.b.d. To be defined, value or description will follow later.
AC 230V A figure displayed with the AC or DC before the value represents
a nominal voltage with standard tolerances (usually ±15%) included.
E.g.: DC 12V describes a 12V battery disregarding whether it is full
(13.7V) or flat (10V)
230Vac A figure with the unit (Vac) at the end is a momentary figure without
any additional tolerances included.
50Hz vs. 60Hz As long as not otherwise stated, AC 230V parameters are valid
at 50Hz mains frequency.
may A key word indicating flexibility of choice with no implied preference.
shall A key word indicating a mandatory requirement.
should A key word indicating flexibility of choice with a strongly preferred
implementation.
1+1 Redundancy Use of two identical power supplies in parallel to provide continued
operation following most failures in a single power supply.
The two power supply outputs should be isolated from each other
by utilizing diodes or other switching arrangements.
E.g. two 20A power supplies are needed to achieve a 20A redundant
system.
N+1 Redundancy Use of three or more identical power supplies in parallel to provide
continued operation following most failures in a single power supply.
All power supply outputs should be isolated from each other
by utilizing diodes or other switching arrangements.
E.g.: To achieve a 80A redundant system, five 20A power supplies
are needed in a N+1 redundant system.
PS1000-A6-
24.20.R
PS1000-A6-
24.20.R PS1000-A6-
24.20.R PS1000-A6-
24.20.R PS1000-A6- 24.20.R PS1000-A6-
24.20.R

Power Supply PS1000-A6-24.20.R
Terminology and Abbreviations
2021-11
7
Figure 2.2 1+1 Redundancy
PS1000-A6-
24.20.R
PS1000-A6-
24.20.R

2021-11
8
Power Supply PS1000-A6-24.20.R
Intended Use
3 Intended Use
This device is designed for installation in an enclosure and is intended for the general
professional use such as in industrial control, office, communication, and instrumentation
equipment.
Do not use this power supply in equipment, where malfunction may cause severe personal
injury or threaten human life.
Function
The device is used to supply field devices with 24 V DC and 20 A.
The device includes a decoupling MOSFET for building 1+1 or n+1 redundant power supply
systems.
To achieve current sharing between power supplies connected in parallel, the device
is permanently factory-set to parallel use operating mode.
The device status is indicated by an LED.
The device has a relay contact output for remote monitoring.
The device is mounted on a 35 mm DIN mounting rail according to EN 60715.
Reference Conditions
All parameters are typical values specified at 230Vac, 50Hz input voltage, 24V, 20A output
load, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.

Power Supply PS1000-A6-24.20.R
Installation Instructions
2021-11
9
4 Installation Instructions
This device may only be installed and put into operation by qualified personnel.
Install the device in an enclosure providing protection against electrical, mechanical
and fire hazards.
The device is designed for use in pollution degree 2 areas in controlled environments.
The enclosure of the device provides a degree of protection of IP20 according to IEC 60529.
Mount the unit on a DIN-rail so that the input terminals are located on the bottom of the unit.
For other mounting orientations see de-rating requirements in this document.
The device is designed for convection cooling and does not require an external fan.
Do not obstruct airflow and do not cover ventilation grid (e.g., cable conduits) by more
than 15%.
Keep the following installation clearances: 40mm on top, 20mm on the bottom, 5mm on the left
and right side are recommended when the device is loaded permanently with more than 50%
of the rated power. Increase this clearance to 15mm in case the adjacent device is a heat
source (Example: another power supply).
Make sure that the wiring is correct by following all local and national codes. Use appropriate
copper cables that are designed for a minimum operating temperature of 60°C for ambient
temperatures up to +45°C, 75°C for ambient temperatures up to +60°C and 90°C for ambient
temperatures up to +70°C. Ensure that all strands of a stranded wire enter the terminal
connection. Check also local codes and local requirements. In some countries local
regulations might apply.
Warning!
Risk of electrical shock, fire, personal injury or death.
•Do not use the power supply without proper grounding (Protective Earth).
Use the terminal on the input block for earth connection and not one of the screws
on the housing.
•Turn power off before working on the device. Protect against inadvertent re-powering.
•Make sure that the wiring is correct by following all local and national codes.
•Do not modify or repair the unit.
•Do not open the unit as high voltages are present inside.
•Use caution to prevent any foreign objects from entering the housing.
•Do not use in wet locations or in areas where moisture or condensation can be expected.
•Do not touch during power-on, and immediately after power-off. Hot surfaces may
cause burns.
Warning!
Explosion hazards
•Substitution of components may impair suitability for this environment.
•Do not disconnect the unit or operate the voltage adjustment unless power has been
switched off or the area is known to be non-hazardous.
•Wiring must be in accordance with Class I, Division 2 wiring methods of the National
Electrical Code, NFPA 70, and in accordance with other local or national codes.
•A suitable enclosure must be provided for the end product which has a minimum
protection of IP54 and fulfills the requirements of the EN 60079-0.
Note
If you use the device in hazardous areas, observe the safety information in the instruction
manual and in chapter 22.

2021-11
10
Power Supply PS1000-A6-24.20.R
Installation Instructions
This device does not contain serviceable parts. The tripping of an internal fuse is caused
by an internal defect. If damage or malfunction should occur during installation or operation,
immediately turn power off and send the device to the factory for inspection.
The device is designed, tested and approved for branch circuits up to up to 30A (UL) or 32A
(IEC) without additional protection device. If an external fuse is utilized, do not use circuit
breakers smaller than 10A B- or C-Characteristic to avoid a nuisance tripping of the circuit
breaker.
A disconnecting means shall be provided for the input of the power supply.

Power Supply PS1000-A6-24.20.R
AC Input
2021-11
11
5 AC Input
The device is suitable to be supplied from TN-, TT- or IT-mains networks with AC voltage.
For suitable DC supply voltages see chapter 6.
Figure 5.1 Input voltage range
Figure 5.2 Turn-on behavior, definitions
AC input
AC input range nom. min.
max.
AC 100-240V
85-264Vac
264-300Vac Continuous operation Occasionally for maximal 500ms
Allowed voltage L or N to
earth max. 300Vac Continuous, according to IEC 62477-1
Input frequency nom. 50-60Hz ±6%
Turn-on voltage typ. 82Vac Steady-state value, see Figure 5.1
Shut-down voltage typ. 72Vac Steady-state value, see Figure 5.1
External input protection See recommendations in chapter 4.
AC 100V AC 120V AC 230V
Input current typ. 5.17A 4.28A 2.25A At 20A, see Figure 5.3
Power factor typ. 0.996 0.996 0.980 At 20A, see Figure 5.4
Crest factor typ. 1.65 1.63 1.63 At 20A, The crest factor is the
mathematical ratio of the peak value to
RMS value of the input current waveform.
Start-up delay typ. 450ms 450ms 450ms See Figure 5.2
Rise time typ. 145ms 145ms 145ms At 20A const. current load, 0mF load
capacitance, see Figure 5.2
typ. 160ms 160ms 160ms At 20A const. current load, 20mF load
capacitance, see Figure 5.2.
Turn-on overshoot max. 1000mV 1000mV 1000mV see Figure 5.2

2021-11
12
Power Supply PS1000-A6-24.20.R
AC Input
Figure 5.3 Input current vs. output current
Figure 5.4 Power factor vs. output current

Power Supply PS1000-A6-24.20.R
DC Input
2021-11
13
6 DC Input
Figure 6.1 Wiring for DC Input
The device is suitable to be supplied from a DC input voltage.
Using DC
1. Use a battery or a similar DC source. A supply from the intermediate DC bus of a frequency
converter is not recommended and can cause a malfunction or damage the unit.
2. Connect (+) pole to L and (–) pole to N.
3. Connect the PE terminal to an earth wire or to the machine ground.
DC input Nom. DC 110-150V ±20%
DC input range Min. 88-180Vdc Continuous operation
DC input current Typ. 4.64A At 110Vdc and 20A load current
Allowed Voltage (+) or (-) input
to earth Max. 375Vdc Continuous, according to IEC 62477-1
Turn-on voltage Typ. 80Vdc Steady state value
Shut-down voltage Typ. 70Vdc Steady state value

2021-11
14
Power Supply PS1000-A6-24.20.R
Input Inrush Current
7 Input Inrush Current
An active inrush limitation circuit limits the input inrush current after turn-on of the input voltage.
The charging current into EMI suppression capacitors is disregarded in the first microseconds
after switch-on.
Figure 7.1 Typical turn-on behavior at nominal load and 25°C ambient
AC 100V AC 120V AC 230V
Inrush current Max. 15Apeak 12Apeak 5.5Apeak Temperature independent
Typ. 12Apeak 10Apeak 4.5Apeak Temperature independent
Inrush energy Max. 1A²s 1A²s 1A²s Temperature independent

Power Supply PS1000-A6-24.20.R
Output
2021-11
15
8 Output
The output provides a SELV/PELV/ES1 rated voltage, which is galvanically isolated
from the input voltage. The output of the devices includes a decoupling MOSFET for building
1+1 or N+1 redundant power supply systems.
The device is designed to supply any kind of loads, including capacitive and inductive loads.
If extreme large capacitors, such as EDLCs (electric double layer capacitors or UltraCaps)
with a capacitance >1F are connected to the output, the unit might charge the capacitor
in the Hiccup mode.
The device is featured with a soft output regulation characteristic in order to achieve
current share between multiple devices when they are connected in parallel. The soft output
regulation characteristic regulates the output voltage in such a manner that the voltage
at no load is approx. 4% higher than at nominal load.
Output voltage nom. DC 24V 23.8 - 25.2V
Adjustment range see chapter
26.2
Factory settings 24.1V ±0.2%, at 20A, cold unit (results to typ. 23.9V±0.2% at 24A
and typ. 25.1V±0.2% at no load)
Line regulation max. 10mV 85-300Vac
Load regulation typ. 1000mV Static value, 0A → 20A; see Figure 8.1
Ripple and noise voltage max. 100mVpp 20Hz to 20MHz, 50Ohm
Output current nom. 24A 1Below +45°C ambient temperature, see Figure 19.1
nom. 20A At +60°C ambient temperature, see Figure 19.1
nom. 15A At +70°C ambient temperature, see Figure 19.1
Fuse breaking current 2typ. 60A Up to 12ms once every five seconds, see Figure 8.3
Overload protection Included Electronically protected against overload, no-load and
short-circuits. In case of a protection event, audible noise
may occur.
Overload behavior Continuous current For output voltage above 13Vdc, see Figure 8.1
Intermitted current 3 For output voltage below 13Vdc, see Figure 8.1
Overload/ max. 29.8A Continuous current, see Figure 8.1
short-circuit current typ. 29A Intermitted current peak value for typ. 2s
Load impedance 10mOhm, see Figure 8.2.
Discharge current of output capacitors is not included.
max. 9.8A Intermitted current average value (R.M.S.)
Load impedance 10mOhm, see Figure 8.2.
Output capacitance typ. 8 000μF Included inside the power supply
Back-feeding loads max. 35V The unit is resistant and does not show malfunctioning
when a load feeds back voltage to the power supply.
It does not matter whether the power supply is on or off.
The absorbing energy can be calculated according
to the built-in large sized output capacitor.
1This current is also available for temperatures up to +70°C with a duty cycle of 10% and/or not longer than 1 minute every 10 minutes.
2The fuse braking current is an enhanced transient current which helps to start heavy loads or to trip fuses on faulty output branches.
The output voltage stays above 20V. See chapter 26.1 for additional measurements.
3At heavy overloads (when output voltage falls below 13V), the power supply delivers continuous output current for 2s.
After this, the output is switched off for approx. 18s before a new start attempt is automatically performed. This cycle is repeated as long
as the overload exists. If the overload has been cleared, the device will operate normally. See Figure 8.2.

2021-11
16
Power Supply PS1000-A6-24.20.R
Output
Figure 8.1 Output voltage vs. output current, typ.
Figure 8.2 Short-circuit on output, Hiccup mode, typ.
Figure 8.3 Dynamic overcurrent capability, typ.
Out put Vol t age
0
025
4
8
12
28V
16
20
24
40A15510 20 30 35
Output Current
A: cont inuous current
B: intermitted current
A
B
OOutput Voltagee
(dynamic behavior, < 12ms)
0
0
4
8
12
28V
16
20
24
70A3010 40 5020 60
Output Current

Power Supply PS1000-A6-24.20.R
Hold-Up Time
2021-11
17
9 Hold-Up Time
Figure 9.1 Hold-up time vs. input voltage
Figure 9.2 Shut-down behavior, definitions
AC 100V AC 120V AC 230V
Hold-up Time Typ. 65ms 65ms 65ms At 10A, see Figure 9.1
Min. 54ms 54ms 54ms At 10A, see Figure 9.1
Typ. 32ms 32ms 32ms At 20A, see Figure 9.1
Min. 24ms 24ms 24ms At 20A, see Figure 9.1

2021-11
18
Power Supply PS1000-A6-24.20.R
DC-OK Relay Contact
10 DC-OK Relay Contact
This feature monitors the output voltage of the power supply in front of the decoupling device
(see also chapter 14.)
Figure 10.1 DC-OK relay contact behavior
Contact closes As soon as the output voltage reaches typ. 22Vdc.
Contact opens As soon as the output voltage dips below 22Vdc.
Short dips will be extended to a signal length of 100ms. Dips shorter than 1ms will
be ignored.
Switching hysteresis 1V
Contact ratings Maximal 60Vdc 0.3A, 30Vdc 1A, 30Vac 0.5A, resistive load
Minimal permissible load: 1mA at 5Vdc
Isolation voltage See dielectric strength table in chapter 21.
100ms
22Vdc
<
1ms
open opencl osed cl osed
>
1...4ms

Power Supply PS1000-A6-24.20.R
Efficiency and Power Losses
2021-11
19
11 Efficiency and Power Losses
Figure 11.1 Efficiency vs. output current, typ.
Figure 11.2 Losses vs. output current, typ.
AC 100V AC 120V AC 230V
Efficiency Typ. 93.2% 93.8% 95.2% At 20A
Typ. 93.1% 93.7% 95.1% At 24A (Power Boost)
Average efficiency 1 Typ. 92.8% 93.4% 94.6% 25% at 5A, 25% at 10A,
25% at 15A. 25% at 20A
Power losses Typ. 3.9W 3.5W 3.3W At 0A
Typ. 17.4W 16.4W 13.8W At 10A
Typ. 35.0W 31.7W 24.2W At 20A
Typ. 42.7W 38.7W 29.7W At 24A (Power Boost)
1The average efficiency is an assumption for a typical application where the power supply is loaded with 25% of the nominal load
for 25% of the time, 50% of the nominal load for another 25% of the time, 75% of the nominal load for another 25% of the time
and with 100% of the nominal load for the rest of the time.
Ef f i ci ency
468101214 1820 24A
87
88
90
91
92
93
94
95
96%
Out put Current
16 22
(a)
(b)
(c)
(a) 100Vac
(b) 120Vac
(c) 230Vac
Pow er Losses
0 2 6 8 12 14 24A
5
0
10
20
30
40W
18 20410 16
Out p ut Cur r en t
22
(a)
(b)
(c)
(a) 100Vac
(b) 120Vac
(c) 230Vac
35
25
15

2021-11
20
Power Supply PS1000-A6-24.20.R
Efficiency and Power Losses
Figure 11.3 Efficiency vs. input voltage at 20A, typ.
Figure 11.4 Losses vs. input voltage at 20A, typ.
Efficiency
120 180 230 264Vac
90
91
92
93
Input Volt age
94
95
96%
100
Pow er Losses
120 180 230 264Vac
10
15
20
25
Input Volt age
30
35
40W
100
