Pepperl+Fuchs PS3500 N+1 User manual

REDUNDANT POWER SUPPLY
INSTALLATION & OPERATION MANUAL
PROCESS AUTOMATION
PS3500 N+1

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
1
Contents
1 Introduction .................................................................................................................. 2
2 Instructions................................................................................................................... 3
2.1 Intended use.......................................................................................................... 4
2.2 Product label.......................................................................................................... 4
2.3 Mounting................................................................................................................ 5
3 Specications............................................................................................................... 5
3.1 Power supply module specications...................................................................... 5
3.2 System specications............................................................................................ 6
3.3 Dimensions............................................................................................................ 8
4 Temperature considerations....................................................................................... 9
4.1 Convection cooling ................................................................................................ 9
4.2 Forced cooling..................................................................................................... 10
4.3 Clearances .......................................................................................................... 10
5 Technical concept.......................................................................................................11
5.1 N+1 redundancy...................................................................................................11
5.2 Hot swapping........................................................................................................11
5.3 Automatic load-sharing.........................................................................................11
5.4 Variable output voltage.........................................................................................11
5.5 Alarm output.........................................................................................................11
5.6 Internal diagnostics, recovery, and LEDs ............................................................ 12
6 Wiring .......................................................................................................................... 13
6.1 Special conditions of use..................................................................................... 13
6.2 Input supply line .................................................................................................. 13
6.3 Input congurations............................................................................................. 14
6.4 Output conguration............................................................................................ 16
6.5 Alarm conguration ............................................................................................. 17
7. Output congurations................................................................................................ 18
8. Operations .................................................................................................................. 19
8.1 Supply line checks............................................................................................... 19
8.2 Output line checks............................................................................................... 19
8.3 Alarm lines checks .............................................................................................. 19
8.4 Commissioning.................................................................................................... 19
9 Maintenance & Repair................................................................................................ 20
10 Troubleshooting ......................................................................................................... 21
11 Special warnings!....................................................................................................... 22
12 Notes ........................................................................................................................... 23

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
2
1 Introduction
This manual applies to the Pepperl+Fuchs PS3500 system that consists of the products
shown in Table 1:
Model number Description
PS3500-PM-1.24.15 N+1 power supply module, 24 V DC @ 15 A
PS3500-TB-3 Backplane for three power modules and one diagnostic module
PS3500-TB-6 Backplane for six power modules and one diagnostic module
Table 1. PS3500 series product range
The manual assumes that the user has technical knowledge of and experience with power
supply systems, explosion protection, as well as planning and installing power systems. It
does not provide an introduction to power systems or explosion protection for inexperienced
users. The content of this manual applies in conjunction with the respective data sheets,
Declaration of Conformity and Certicate of Compliance. For further information please
refer to the Pepperl+Fuchs "Wiring and Installation Guide."
Substantial amounts of voltage, current and power are provided by the supply. Read this
manual carefully before installation and operation to avoid risk of damage, failures, or
personal injury. Take great care on input and output supply lines to protect from the effects
of short circuits and provide the required ground connections.

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
3
2 Instructions
2.1 Intended use
The PS3500 product range may be installed in Zone 2 or Class I/Division 2
hazardous areas. Type of protection is Ex nA nC (non-arcing, sealed device)
for Zone 2 Gas Groups IIC, and non-incendive for use in Class I Division 2
Gas Groups A, B, C, and D. Please consult local electrical codes for hazardous
location installation guidelines.
NOTE: This equipment is suitable for use in Class I, Division 2; Groups A, B, C, D and
Class I, Zone 2; Group IIC or nonhazardous locations only.
The Declaration of Conformity, Certicate of Compliance and data sheets are considered
as an integral part of this user manual. The data sheets contain the electrical data of the
Declaration of Conformity and the Certicate of Compliance. Laws and/or regulations
governing the use or intended use must be observed.
The PS3500 products are only approved for proper professional use in accordance with
the intended purposes. Improper handling will void any claim made under the warranty as
well as any manufacturer’s liability. The PS3500 system can only be operated by trained
professionals in accordance with this manual.
2.2 Product label
For proper identication and operation, examine the system model number nameplate to
identify the appropriate approvals, area classication, and type as noted in Figure 1:
Figure 1. Power Supply Module
Figure 2. Backplane
Warning
-25°C T 45
°C Type 1 (70°C derated)
amb
90...250VAC
44...66Hz
90...300VDC
6.5Amax
22.5...30VDC
15A
Output:Input:
Class l, Division 2,
Groups A, B, C, D, T4
Class l, Zone 2,
Groups IIC, T4
WARNING- DO NOT SEPARATE WHEN ENERGIZED
UNLESS AREA IS KNOWN TO BE NONHAZARDOUS
PS3500-P M-1.24.15
Twinsburg, OH 44087 USA / www.pepperl-fuchs.com
II 3 G Ex nA nC IIC T4 Gc
12ATEX1103387X
IECEx UL 13.0082X
Certified to UL STD 508
Certified to ANSI/ISA STD 12.12.01
Certified to CSA STD C22.2 No. 107.1
Certified to CSA STD C22.2 No. 213
AVERTISSEME NT - RISQUE D’EXPLOSION.
NEPAS DEBRANCHER TANT QUE LE CIRCUIT EST
SOUS TENSION, A MOINS QU’IL NE S’AGISSE D’UN
EMPLACEMENT NON DANGEREUX
Part No. 913919
WARNING - HOT SURFA CE - RISK OF BURN
A
vertissement - surface chaude - risk de brûlures
See Manual for operating instructions
4KM0
Industrial Control Equipment for use in Hazardous Locations
II 3 G Ex nA IIC T4 Gc
12ATEX1103387X
IECEx UL 13.0082X
Certified to UL STD 508
Certified to ANSI/ISASTD 12.12.01
Certified to CSA STD C22.2 No. 107.1
Certified to CSA STD C22.2 No. 213
CET EQUIPEMENT RENFERME PLUSIEURS CIRCUITS
SOUS TENSION. VOIR LE SCHEMA.
RISK OF ELECTRIC SHOCK - MORE THAN ONE
DISCONNECT SWITCH MAY BE REQUIRED TO
DE-ENERGIZE THE EQUIPMENT BEFORE SERVICING
CAUTION
AVERTISSEMENT
AVERTISSEMENT
See Manual for operating instructions
EXPL OSION HAZARD - DO NOT SEPARATE WHEN ENERGIZED
UNLESS AREA IS KNOWN TO BE NONHAZARDOUS
HOT SURFACE - RISK OF BURN
WARNING
RISQUE D’EXPLOSION - NEPAS DEBRANCHER TANT QUE LE CIRCUIT EST SOUS
TENSION, A MOINS QU’IL NE S’AGISSE D’UN EMPLACEMENT NON DANGEREUX
SURFACE CHAUDE - RISK DE BRÛLURES
90...250VAC
44...66Hz
90...300VDC
6.5A
per slot
max
Input: -25°C T 70
°C Type 1
amb
Industrial Control Equipment
for use in Hazardous Locations
Class l, Division 2,
Groups A,B,C,D, T4
Class l, Zone 2,
Groups IIC, T4
4KM0

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
4
2.3 Mounting
2.3.1 Mounting PS3500 backplanes (termination boards) PS3500-TB-*
The PS3500 backplanes are designed for protection class IP20 in accordance with EN 60529 and
must be protected against adverse ambient conditions such as water or dirt ingress.
The backplane chassis is mounted on a at metal sheet plate or on two properly spaced rails. Drill
four 5 mm (0.2") DIA holes and tap them 6 MA (or 1/4"NC). Insert the top and bottom screws but
leave a gap of approximately 5 mm (0.2") between the screw heads and mounting surface. Slide
the chassis through the keyed holes and hang it rmly on the screw heads. Proceed to tighten all
the screws.
2.3.2 Mounting PS3500-PM-1.24.15 power modules
The housing of PS3500-PM-1.24.15 meets the degree of protection class IP 20. It is intended for
mounting on the PS3500 backplane PS3500-TB-*.
To install a new module on the backplane proceed as follows:
1. Carefully center and mate the plug and connector on the back of the power module to the
backplane; then press rmly on the module.
2. With a screwdriver, screw in the top and bottom mounting screw on the power module to
secure the module in the slot.
3. The modules are hot swappable; they can be replaced without shutting down the system. See
Section 5.2, Hot swapping.

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
5
3 Specications
PS3500 has a wall-mount, multi-slot backplane accepting hot swappable plug-in power
converter modules that provides an isolated output at 24 V DC nominal.
Each power module has an individually isolated input port accepting either AC or DC that
provides inrush current limiting and power factor control. The output port is completely
isolated from the input and provides up to 15 A per module at a nominal 24 V DC
(adjustable 22.5 to 30 V from chassis mounted trimmer) with a load sharing conguration
for paralleled output operation. Input and output lines can be wired independently or in
parallel providing N+1 redundant structures.
System conguration is obtained by wiring and conguration DIP switches on the various
backplane slots leaving power modules interchangeable and easily swappable under load.
All relevant failures in the modules are detected and signaled by individual LEDs and alarm
relays providing a exible combination of redundancy, fault tolerance, and automatic fault
detection ideally suited to critical applications.
Full compliance to the EU directives for EMC and low-voltage equipment ensure minimum
emissions and high immunity in harsh environments. High conversion efficiency normally permits
natural convection cooling operation eliminating cooling fans for most application requirements.
3.1 Power supply module specications
Mechanical specications
Dimensions (134 mm x 62 mm x 268 mm) 5.3” x 2.5” x 10.6”
Input
Voltage 90…250 V AC ±10%; 90...300 V DC, overvoltage category II
Input current Max. 6.5 A
Efficiency Up to 91%
Inrush current < 50 A peak for 50 µs
Power factor > 0.97, 50...100% load
Output
Voltage 24 V DC +/-1%, adjustable between 22.5...30 V
Current
Fault signal Relay 50 V/0.6 A or 30 V/1 A DC
Short-circuit current ≤ 20 A
Temperature coefficient ±0.01% per °C max
Input regulation < 100 mV ( 90 ... 250 V AC ; 90 ... 300 V DC )
Load regulation <100 mV (0...15 A output load)
Turn-on/turn-off voltage transient 200 ms to nal value (no over/under shoot)
Ripple 35 mV rms (< 100 mV pp)
Response time Min. hold-up time: ≥ 25 ms at nominal input voltage & output load
Indicators/settings
Display elements LED Power, green: power on
LED Fault, red: fault indication
LED Alarm, red: module shut-down
Table 2. Power supply module specications
15 A (See Output Derating Curves)

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
6
3.2 System specications
Electrical isolation
Input/output 4.25 kV DC
3.0 kV AC
Input/ground 2.12 kV DC
1.5 kV AC
Output/ground 2.12 kV DC
1.5 kV AC
Ambient conditions
Ambient temperature -25…+45 °C derated: 0.4 A/°C , (from 45...70 °C)
Altitude Installation is 2000 m or less
Polution degree Polution degree 2 or 1
Storage temperature -40…+85 °C
Shock resistance 15 g, 11 ms
Vibration resistance 1 g, 58...150 Hz
Relative humidity < 95 % non condensing
Mechanical specication
Protection degree IP20
Weight Approximately 1.8 kg (4.125 lbs)
Directive conformity
Electromagnetic compatibility
Directive 2004/108/EC EN 61326-1:2006
EN 61000 sections 4-2, 4-4, and 4-6
EN 55011
Conformity
Electrical isolation IEC 61131-2
Electromagnetic compatibility NE 21
Protection degree EN 60529
Shock resistance EN 60068-2-27
Vibration resistance EN 60068-2-6

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
7
Data for application in conjunction
with hazardous areas
Type Examination Certicate 12ATEX1103387X Rev.1
Group, category, type of protection II3 G Ex nA nC IIC T4 (PS3500-PM)
II3 G Ex nA IIC T4 (PS3500-TB)
Directive conformity
Directive 94/9 EC EN 60079-0, EN 60079-15, EN 61010-1
International approvals
IECEx approvals Ex nA nC IIC T4 (PS3500-PM)
Ex nA IIC T4 (PS3500-TB)
IECEx UL 13.0082X
UL Listed ANSI/ISA 12.12.01-2011
UL 508
CSA C22.2 No. 213-M1987,
CSA C22.2 No. 107.1
Approved for Class I, Zone 2, Group IIC T4
Class I, Division 2, Groups A, B, C, D, T4
General information
Supplementary information Statement of Conformity, Declaration of Conformity and
instructions have to be observed where applicable.
For information see www.pepperl-fuchs.com.
Table 3. System specications
3.2 System specications (continued)

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
8
3.3 Dimensions
mm (in)
134
(5.3)
62
(2.5)
193
(7.6)
78
(3.1)
238
(9.4)
267
(10.5)
134
(5.3)
306
(12.0)
35
(1.4)
272
(10.7)
249
(9.8)
Ø 10
(Ø 0.4)
193
(7.6)
112
(4.4)
Ø 10
(Ø 0.4)
486
(19.1)
465
(18.3)
193
(7.6)
112
(4.4)

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
9
4 Temperature considerations
Temperature accelerates the failure mechanism of every electronic component (Arrhenius
criteria). If the operating temperature is increased by 10 °C from its normal operating range,
-25…+45 °C (-11...+113 °F), its expected life is almost cut in half.
Temperature rise depends on dissipated power density. For the same enclosure volume
more power dissipated produces higher temperature rise. For example, a cabinet 600 x
600 x 2000 mm dissipating 300 W with natural convection cooling produces an internal
temperature rise of 10 °C. This should be regarded as an ideal case.
Identify the worst load/temperature environment that the power supply will encounter and
determine the recommended cooling method.
• Use convection cooling when the supply load/operating temperature is typically in the
lower part of the diagram and free air circulation is ensured.
•Use forced cooling when the supply load/operating temperature is in the upper part
of the diagram for extended periods of time or when a very high system reliability is
required.
Figure 3. Recommended load current per module vs. operating temperature
4.1 Convection cooling
Hot components exchange heat with the surrounding air producing a vertically rising hot
air ow. This determines new cool air intake to cool the component in a natural convection
cooling mode, which is controlled by the intake air temperature and ow.
For good convection cooling, install the equipment with an unobstructed vertical ow
of relatively cool (ambient temperature) air entering from the bottom and ow out at
a higher temperature from the top. To avoid excessive temperature build up, do not
stack power dissipating devices vertically in close proximity.

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
10
4.2 Forced cooling
Forced cooling is obtained by using suitable fans. Fans generate a strong air ow that
removes heat from the power generating equipment. Use two (PS3500-TB-3) or four
(PS3500-TB-6) 120 mm, 100 m3/h, brushless, long-life fans operated from the output bus
at 24 V DC (e.g., PAPST type) installed immediately below the backplanes and blowing air
up against the bottom of the power modules. Make sure to allow relatively free airow below
the fans and above the supply rack.
4.3 Clearances
For clearances, we would recommend 1.25” from the sides of the power supplies, and 5”
from the top and bottom when oriented in the standard horizontal position, for convection
cooling. If using forced air convection cooling, this may be reduced some. This assumes
that below the backplane is not another source of heat.

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
11
5 Technical concept
The power supply system consists of two different backplanes (3 and 6 slots) and the
power supply module. The key features of the system are:
•Nominal output 24 V/15 A per module (See Output Derating Curves)
• Nominalinputof90to250VAC/90to300VDCpermodule
• N+1redundancy
• Automaticload-sharing
• Highefficiency(upto91%)
• Fanless
• Moduleoutputvoltageisadjustableatthebackplanefrom22.5Vto30V
• Basicmodulefailurealarmingviarelaycontact(normallyopen/closeconfigurable)
• Redundancyonsupplyline
5.1 N+1 redundancy
N+1 redundancy is based on the fact, that the maximum drawn current is lower than the
maximum current provided by the overall number of modules minus one. Based on the
backplane size, N can be any number between 1 and 5.
5.2 Hot swapping
Hot swapping allows replacement of a module under power without any visible functional
impact on the output side. Hot swapping is allowed only in an environment where no
hazardous materials are present. The hot swapping feature is not permitted in a Class I/
Div2 area or Zone 2 area unless under a hot permit.
5.3 Automatic load-sharing
The power supply modules implement a real load-sharing function; all modules supply the
same amount of current. The tolerance for the current difference between the modules
should be within a range of ±1.5 A.
5.4 Variable output voltage
The factory default output voltage is 24 V. The output voltage is adjustable in a range from
22.5 V to 30 V for each module by using a potentiometer. Inserted modules can be easily
adjusted with a screwdriver during setup. Potentiometers are accessible on the adjacent
backplane slot making the voltage setting tamper proof during operation.
5.5 Alarm output
Each power module has its own alarm monitoring circuit that controls a relay for a common
failure output signal. It can be congured normally open or normally closed using the
terminal blocks on the backplane.

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
12
5.6 Internal diagnostics, recovery, and LEDs
Overvoltage (OV), overcurrent (OC) and overheat (OHT) conditions lead to an output
shutdown of the unit. Also, they create an alarm signal at the internal relay. Undervoltage
(UV) creates an alarm, but does not shutdown the unit.
During shutdown mode, the unit continuously checks for the actual failure condition to go
away. If that is the case, the unit would go back to normal operation. However, this behavior
must not impact the remaining running units in an N+1 redundant system.
There are three LEDs:
• Powergood(green)
• Fault(red)
• Alarm(red)

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
13
6 Wiring
The PS3500 system has separate input/output terminal blocks for simple conguration.
Connect ground terminals to the mains ground, otherwise lethal voltages
may occur.
Permanent power module damage will result in case of input voltage
overload.
6.1 Special conditions of use
1. To be installed in an end-use ATEX approved system, providing re, impact, grounding,
and accessibility protection. The power supply must be installed in an ATEX Certied,
IP54 enclosure. Alternatively, the power can be installed in an IP4X enclosure, having
adequate protection against the entry of solid foreign objects or water capable of
impairing safety.
2. GND connection on backplane at Mains supply connections is a protective ground
connection. The wire guage should be at least the same as what is used for the mains
power feed.
3. For any hazardous locations (Class I/Div 2, Zone 2) the PS3500 system must be
installed in a locked enclosure.
4. Power supply must be secured to system using screws requiring tools for removal.
5. For indoor use only; not to be subjected to UV exposure from luminaires.
6. Ambient ratings for operation are -25…+45 °C, derated 0.4 A/°C (from 45...70 °C).
See Figure 3, temperature curve.
7. The PS3500 system is designed for use in pollution degree 2 environments.
8. For use with Class 1 conductors or equivalent.
9. For use with CU conductors or equivalent.
10. Use 14 AWG conductors or equivalent.
11. Use conductors rated 75 °C minimum or equivalent.
12. Alarm relay contacts are rated for 50 VDC or less and are intended to be powered by
DC sources with proper isolation from MAINS.
6.2 Input supply line
Power line voltage is 90...250 V AC ±10% (90...300 V DC). Check supply line voltage to
meet power module supply requirements. Plan for disconnecting capability and over-current
protection by adequately sized fuses or circuit breakers on the lines.
Circuit breakers or fusing shold be 20A or less. connections to 6 poition backplane will
require 2 breakers or fused sources feeding the backplane. Group of 3 slots needs 20A
breaker or less. A single 40A breaker is not allowed.
Ground connection should be made rst.
Input Terminals
strip length = 8mm
wire guage max = 4mm sq (10AWG)
tightening torque 0.6 - 0.8Nm
Warning

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
14
Output Terminals
strip length = 12mm
wire guage max = 10mm sq (6AWG)
tightening torque 1.2 - 1.5N
Other Terminals
strip length = 7mm
wire guage max = 2.5mm sq (12AWG)
tightening torque 0.5 - 0.6Nm
6.3 Input congurations
6.3.1 Single line input
Use with uninterruptible power systems (UPS) supply or when input line integrity is not
critical, wire per sketch in Figure 4. For DC input, polarity does not matter
N L
Note!
Each spur to the individual group
of 3 power supplies needs its own 20 A breaker.
Figure 4. Single line input connection

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
15
6.3.2 Dual Line Input
Wire per sketch in Figure 5. For redundant input line conguration, load should not exceed
45 Amps per every 6-position backplane used.
N
Line 1
Primary
Line 2
Backup
N L L
Figure 5. Dual line input connection
6.3.3 Independent line connection
Wire per sketch in Figure 6. For independent input line conguration, load should remain
separated.
N
Line 1
Primary
L N
Line 2
Backup
L N
Line 3
Optional
L
Figure 6. Independent multi input line connections

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
16
6.4 Output conguration
Each power module slot has a 6-position DIP switch that enables the various alarm
congurations as well as the load sharing ability of each PS3500 power module. See Table
4 for proper conguration. These congurations are on a per slot basis.
Sx.1 Sx.2 Sx.3 Sx.4 Sx.5 Sx.6
Parallel alarm Off On Off Off x x
Serial alarm+On Off On On/ Off* x x
Load share OFF x x x x Off Off
Load share ON x x x x On On
*Any slot not having a module should have DIP switch #4 turned on
+Slot #1, S1.1 and S1.2 are in parallel therefore either one can be on.
Table 4. Alarm/load sharing conguration
6.4.1 Independent outputs
Use for separate output applications; wire per Figure 7.
+
Out 1
- +
Out 2
- +
Out 3
- +
Out 4
- +
Out 5
- +
Out 6
-
Figure 7. Independent output lines
6.4.2 Common outputs
Use for bus connected output or redundant congurations; wire per Figure 8. Refer to Table
4 for load share DIP switch conguration. For multi backplane parallel operation, extend
load sharing connections at terminals 5 and 6 to the next backplane.
NOTE: A separate bus is required for loads > 45 A.
+
Load Sharing
-
Figure 8. Bus connected output or redundant congurations

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
17
6.5 Alarm conguration
6.5.1 Parallel alarm
Connect in parallel, as per Figure 9, the normally closed (N.C.) alarm contacts on all power
modules, and refer to Table 4 for parallel alarm DIP switch conguration. When any specic
relay on a module deenergizes under alarm condition, including power off, the circuit will
close and actuate an alarm (at terminals 1-2 of the alarm terminal block). Pulling a power
module out of the backplane will not actuate an alarm.
Figure 9. Parallel alarm
6.5.2 Serial alarm
Connect in series, as per Figure 10, the normally open (N.O.) alarm contacts on all power
modules and refer to Table 4 for serial alarm DIP switch conguration. When any specic
relay on a module de-energizes under alarm condition, the circuit will open and cause an
alarm. Removing a module will set off the alarm. Any slot without a module will need to
have DIP switch Sx.4 turned on.
Figure 10. Serial alarm connection
2
NO
3
1 2 3
NOTE: Alarm relay # 3 shown in alarm position.
NOTE:If serial alarm is used an alarm will occur when
pulling out a module.
1
1 2 3
NC
NOTE: Alarm relay # 3 shown in alarm position
2

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
18
7. Output congurations
Alarm conguration Module No module
(empty slot)
Parallel with
Load Share
Sx
OFF OFF = Open
Parallel without
Load Share
Sx
Serial with
Load Share
Sx
Sx
Serial without
Load Share
Sx
Sx
Note: Diagnostic Module DIP Switches
When the Diagnostic Module is not in use, all Diagnostic Module port DIP
switches must be set to the "OFF"position.

Subject to modifications www.pepperl-fuchs.com
USA: [phone] Singapore: [phone]
Copyright Pepperl+Fuchs
Germany: [phone]
PS3500 N+1 Redundant Power Supply
19
8. Operations
Warning!
Do not plug and power modules on the backplane before checking all the
systems as recommended.
8.1 Supply line checks
1. Grounding conductor to be connected and rmly secured to the GND terminals.
2. Input lines to be protected by appropriately sized fuses or sectioning circuit breakers
(turning them off).
3. Line conductors to be of adequate size and rmly secured with no exposed conductors
risking contacts with the backplane or short circuits.
4. Supply line voltage to meet power module rating. (Check side label.)
8.2 Output line checks
1. Output polarity to be correct. (Severe damage to the powered equipment might result in
case of reverse polarity powering.)
2. Output voltage value 24 V. Check on side label of power modules.
3. Output conductors to be of adequate size and rmly secured with no exposed risking
contacts with the backplane or short circuits.
4. Load sharing DIP switches conguration are set. (See section 6.4.)
8.3 Alarm lines checks
1. Alarm circuit to be correctly wired and conductors rmly secured with no exposed
conductors risking contacts with the backplane or short circuits.
2. Alarm DIP switches conguration set. (See section 6.4.)
8.4 Commissioning
1. Pull out all modules from the backplane
2. Disconnect load on the 24 V output bus and switch the input mains ON.
3. Plug one of the PS3500 modules in slot 1 of the backplane and validate the output to
be within the limits (for a 24 V nominal output, 23.6 V to 24.24 V).
Factory default for the modules is 24 V +/-1%. If a different output voltage is required (within
the 22.5 V to 28 V range), adjust the potentiometer on the backplane to obtain the desired
output.
4. Repeat step 3, using the same module plugged in the backplane slot 2, 3, etc., and
check the output voltage to be within the limits
5. Turn power off, reconnect the load plug in and tighten all modules on the backplane
with the xing screws.
6. Turn power ON. Only the green LED should appear (no alarms). If any alarm is
displayed, check mains voltage, module conguration and adjustment. If problem
remains refer to the troubleshooting section.
Warning
