Pepperl+Fuchs IDM-Z2-160-D-1D-J2-SU-N-N0 User manual

IDM-Z2-160-D-1D-J2-SU-N-N0
IDM-Z2-160-D-1D-J2-SU-P-N0
IDM-Z2-260-D-2D-J2-S1-N-N0
Wired handheld scanner for
use in explosion-hazardous
areas Zone 2/22
Manual

With regard to the supply of products, the current issue of the following document is applicable:
The General Terms of Delivery for Products and Services of the Electrical Industry, published
by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elek-
troindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause:
"Expanded reservation of proprietorship"
Worldwide
Pepperl+Fuchs Group
Lilienthalstr. 200
68307 Mannheim
Germany
Phone: [phone] - 0
E-mail: [e-mail]
North American Headquarters
Pepperl+Fuchs Inc.
1600 Enterprise Parkway
Twinsburg, Ohio 44087
USA
Phone: [phone]
E-mail: [email protected].com
Asia Headquarters
Pepperl+Fuchs Pte. Ltd.
P+F Building
18 Ayer Rajah Crescent
Singapore 139942
Phone: [phone]
E-mail: [email protected]
https://www.pepperl-fuchs.com

IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1-
N-N0
2022-01
3
1 History of the Manual ................................................................................................ 4
2 Introduction................................................................................................................ 5
2.1 Content of this Document............................................................................. 5
2.2 Manufacturer .................................................................................................. 5
2.3 Target Group, Personnel ............................................................................... 5
2.4 Symbols Used ................................................................................................ 5
3 Technical Specifications ........................................................................................... 7
3.1 Explosion Protection..................................................................................... 7
3.2 Technical Data for Corded Reader ............................................................... 8
3.3 Use .................................................................................................................. 9
4 System Structure ..................................................................................................... 10
4.1 Overview....................................................................................................... 10
4.2 IDM-Z2-x60-D-* System Structure 1 ........................................................... 12
4.3 IDM-Z2-x60-D-* System Structure 2 ........................................................... 13
4.4 IDM-Z2-x60-D-* System Structure 3 ........................................................... 14
4.5 IDM-Z2-160-D-J2-SU-* System Structure 4................................................ 16
4.6 IDM-Z2-160-D-J2-SU-* System Structure 5................................................ 17
5 Commissioning........................................................................................................ 19
5.1 Connection of the Wired Handheld Readers............................................. 19
5.2 Pin allocation of supply cable SK-IDM-Z2-J2-5M-S-N RS-232 interface. 20
5.3 Pin allocation of supply cable SK-IDM-Z2-J2-1M-U-N USB interface ..... 22
6 Accessories.............................................................................................................. 24

2022-01
4
IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1-
N-N0
1 History of the Manual
The following editions of the manual have been released:
Version Comments
01/2022 First edition

IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1-
N-N0
2022-01
5
2 Introduction
2.1 Content of this Document
This document contains information required to use the product in the relevant phases of the
product life cycle. This may include information on the following:
•Product identification
•Delivery, transport, and storage
•Mounting and installation
•Commissioning and operation
•Maintenance and repair
•Troubleshooting
•Dismounting
•Disposal
The documentation comprises the following parts:
•This document
•Datasheet
In addition, the documentation may comprise the following parts, if applicable:
•Type examination certificate
•EU declaration of conformity
•Attestation of conformity
•Certificates
•Control drawings
•Instruction manual
•Other documents
2.2 Manufacturer
2.3 Target Group, Personnel
Responsibility for planning, assembly, commissioning, operation, maintenance, and dismount-
ing lies with the plant operator.
Only appropriately trained and qualified personnel may carry out mounting, installation, com-
missioning, operation, maintenance, and dismounting of the product. The personnel must have
read and understood the instruction manual and the further documentation.
Prior to using the product make yourself familiar with it. Read the document carefully.
2.4 Symbols Used
This document contains symbols for the identification of warning messages and of informative
messages.
Note
For full information on the product, refer to the further documentation on the Internet at
www.pepperl-fuchs.com.
Pepperl+Fuchs Group
Lilienthalstraße 200, 68307 Mannheim, Germany
Internet: www.pepperl-fuchs.com

2022-01
6
IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1-
N-N0
Warning Messages
You will find warning messages, whenever dangers may arise from your actions. It is mandatory
that you observe these warning messages for your personal safety and in order to avoid prop-
erty damage.
Depending on the risk level, the warning messages are displayed in descending order as fol-
lows:
Informative Symbols
Action
This symbol indicates a paragraph with instructions. You are prompted to perform an action or
a sequence of actions.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and plants, or result in
their complete failure.
Note
This symbol brings important information to your attention.

IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1-
N-N0
2022-01
7
3 Technical Specifications
3.1 Explosion Protection
IDM-Z2-160-D-1D-J2-*
II 3G Ex ic IIC T4 Gc
II 3D Ex ic IIIC T135°C Dc
IDM-Z2-260-D-2D-J2-*
II 3G Ex ic IIB T4 Gc
II 3D Ex ic IIIC T135 °C DC
Test certificate
IBExU19ATEXB016X
IECEx IBE 19.0026X
Manufacturer
Pepperl+Fuchs SE
Lilienthalstraße 200

2022-01
8
IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1-
N-N0
68307 Mannheim
Germany
[e-mail]
3.2 Technical Data for Corded Reader
IDM-Z2-160-D-1D-
J2-SU-N-N0
IDM-Z2-160-D-1D-
J2-SU-P-N0
IDM-Z2-260-D-2D-
J2-S1-N-N0
Description Linear imager 2-D imager
Barcode One-dimensional 1-D
(barcode)
One-dimensional 1-D
(Barcode and stack
code incl. PDF417)
One-dimensional 1-D
& 2-D
(Barcode and stack
code incl. PDF417)
Barcode types Code 39, Code 39 Trioptic, Code 32, Code 93, Code 11, Codabar,
Code 128, GS1-128 / EAN 128, UPC / EAN / JAN (with addition),
MSI/Plessey, UK/Plessey, IATA, Interleaved 2 of 5, standard and
Industrial 2 of 5, Matrix 2 of 5, Telepen, GS1 DataBar, Australian Post,
China Post, German Post, US Planet, US Postnet, British Post, Intelli-
gent Mail, Japan Post, Korean Post, Dutch KIX Post
Stack codes - PDF417, MicroPDF417, Code 49, Code 16K,
Composite, Codablock F
2-D code types - Data Matrix, QR code,
MicroQR-Code,
Aztec, MaxiCode
Light source LED, visible red light, 630 nm
Scan frequency 500 Hz 60 Hz
Reading distance 50 mm to 800 mm 35 mm to 90 mm
Code resolution
(code-dependent)
Approx.  0.076 mm Approx.  0.13 mm
Immunity to extrane-
ous light
100.000 lx
Electrical data
Interfaces RS-232 / RS-422 / USB RS-232 / USB
Feedback
Visual 2x LED (operating state/read confirmation)
Acoustic Beeper / buzzer (can be switched off)
Ambient conditions
Shock resistance 50 drop tests on concrete from a height of 2 m
Operating tempera-
ture
-20°C to +50°C
Storage temperature -30°C to +70°C
Relative humidity 95% non-condensing
Mechanical data
Degree of protection IP65
Dimensions [W x H x
D]
104 mm x 185 mm x 76 mm
Weight Approx. 220 g without connection cable

IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1-
N-N0
2022-01
9
3.3 Use
The handheld reader is a piece of handheld device.
It enables portable recording and direct data transfer in explosion-hazardous areas. The device
is modified for use in explosion-hazardous areas of Zone 2 and Zone 22.

2022-01
10
IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1-
N-N0
4 System Structure
4.1 Overview
The wired handheld readers and their accessories are presented in the following overview. The
handheld readers can be used in stand-alone applications or can be connected to a Pep-
perl+Fuchs VisuNet operator workstation. Connections to the VisuNet FLX are realized with an
additional barrier (SK-IDM-Z2-J2-1M-U-N) or via an integrated barrier when connecting the
barcode reader to the VisuNet GXP. The data can be transferred via the network interface of the
VisuNet operator workstation to a host PC in the non-explosion-hazardous area.
Alternatively, the handheld readers can be connected to a PC or a programmable logic control-
ler (PLC) with the associated power module and operated as "standalone" units.
