2-D Laser Scanner
Contents
1 Introduction ..............................................................................5
1.1 Introduction.......................................................................... 5
1.2 Validity .................................................................................. 5
2 Declaration of Conformity .......................................................6
3 Safety ........................................................................................7
3.1 Symbols relevant to safety ................................................. 7
3.2 Safety Information ............................................................... 7
3.3 Laser Class 1 ....................................................................... 8
3.4 Intended Use........................................................................ 8
4 Product Description.................................................................9
4.1 R2000 Laser Scanner .......................................................... 9
4.2 Functional Principle .......................................................... 10
4.3 Indicators and Operating Controls .................................. 11
4.4 Interfaces and Connections ............................................. 11
4.5 Included in Delivery .......................................................... 13
4.6 Accessories ....................................................................... 13
5 Installation ..............................................................................15
5.1 Storage and Transport ...................................................... 15
5.2 Unpacking .......................................................................... 15
5.3 Mounting ............................................................................ 15
5.4 Device Connection ............................................................ 16
5.5 Grounding / Shielding ....................................................... 17
6 Commissioning ......................................................................18
6.1 Ethernet Configuration ..................................................... 18
7 Operation ................................................................................21
7.1 Menu Structure .................................................................. 21

2022-12
4
2-D Laser Scanner
Contents
7.2 Operation............................................................................ 23
7.3 Description of Menu Items ............................................... 26
7.3.1 "Ethernet Info" Menu Item ........................................................ 26
7.3.2 "Ethernet Setup" Menu Item..................................................... 26
7.3.3 Sensor Setup Menu Item ......................................................... 27
7.3.4 "Tools" Menu Item .................................................................... 29
7.3.5 "End" Menu Item ...................................................................... 29
8 Maintenance and Repair .......................................................30
8.1 Maintenance....................................................................... 30
8.2 Repairs ............................................................................... 30
9 Troubleshooting .....................................................................31
9.1 Troubleshooting................................................................. 31
10 Appendix.................................................................................33
10.1 Technical Data.................................................................... 33
10.2 Pulse Ranging Technology (PRT) Glossary.................... 36
10.3 Using Open Source Programs ......................................... 38

2022-12
5
2-D Laser Scanner
Introduction
1Introduction
1.1 Introduction
Congratulations
You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs
develops, produces and distributes electronic sensors and interface modules for
the market of automation technology on a worldwide scale.
Read these instructions carefully before you install this device and put it into oper-
ation. Instructions and hints included in this manual lead you step by step through
the installation and commissioning and provide a trouble-free use of this product.
This is for your benefit, since this helps you to:
•ensures the safe operation of the device
•exploit the full functionality of the device
•avoid operating errors and related disturbances
•avoid costs due to disruptions and repair work
•increase the effectiveness and efficiency of your system.
Keep these instructions for reference for later work on the equipment.
Please check after opening the package, that the device isn't damaged and the
completeness of the delivered goods.
Symbols used
The following symbols are used in this manual:
Handling instructions
1. You will find handling instructions beside this symbol
Contact
If you have any questions about the device, its functions, or accessories, please
contact us at:
Pepperl+Fuchs Group
Lilienthalstraße 200
68307 Mannheim, Germany
Telephone: [phone]
Fax: [phone]
Email: [email protected]
1.2 Validity
This manual applies to devices from firmware 1.20 and hardware 1.00 onward.
The versions can be found in the device menu; .
For devices with older versions, documentation is available on request.
Note
This symbol draws your attention to important information.

2022-12
6
2-D Laser Scanner
Declaration of Conformity
2 Declaration of Conformity
All products were developed and manufactured under observance of the
applicable European standards and guidelines.
The product manufacturer, Pepperl+Fuchs Group, has a certified quality assur-
ance system that conforms to ISO 9001.
Note
A declaration of conformity can be requested from the manufacturer.
ISO9001

2022-12
7
2-D Laser Scanner
Safety
3Safety
3.1 Symbols relevant to safety
3.2 Safety Information
Read the following information carefully and follow this information when working
with the device. Failure to observe the safety notices and warning messages in
this documentation can lead to malfunctions and hazardous operating scenarios
during operation.
This can result in serious personal injury or death.
Ta r g e t G r o u p, Pe r s o n ne l
The personnel must be appropriately trained and qualified in order to carry out
mounting, installation, commissioning, operation, maintenance, and dismounting
of the device. The trained and qualified personnel must have read and under-
stood the instruction manual.
Prior to using the product make yourself familiar with it. Read the instruction man-
ual carefully.
Reference to Further Documentation
Observe laws, standards, and directives applicable to the intended use and the
operating location.
Intended Use
The R2000 2-D LiDAR sensor is a 360°measuring instrument with an all-round
display. It is used on automated transport systems or other movable machinery in
intralogistics. It is also used on stationary equipment in the area of factory and
building automation.
The device is only approved for appropriate and intended use. Ignoring these
instructions will void any warranty and absolve the manufacturer from any liability.
Danger!
This symbol indicates an imminent danger.
Non-observance will result in personal injury or death.
Warning!
This symbol indicates a possible fault or danger.
Non-observance may cause personal injury or serious property damage.
Caution!
This symbol indicates a possible fault.
Non-observance could interrupt the device and any connected systems and
plants, or result in their complete failure.

2022-12
8
2-D Laser Scanner
Safety
Operation, Maintenance, Repair
Do not remove the nameplate.
Do not remove the warning markings.
Do not repair, modify, or manipulate the device.
If there is a defect, always replace the device with an original device.
Only use accessories specified by the manufacturer.
When using the device with rack feeders and moving carriages, observe the
applicable safety guidelines for these applications.
Supply the device with a power supply that meets the requirements for safety
extra-low voltage (SELV) or protective extra-low voltage (PELV).
Do not point the device directly at the sun. Do not use the device to conduct mea-
surements into the sun.
Delivery, Transport, Disposal
Keep the original packaging. Always store and transport the device in the original
packaging.
The device, built-in components, packaging, and any batteries contained within
must be disposed in compliance with the applicable laws and guidelines of the
respective country.
3.3 Laser Class 1
Class 1 Laser Product
This sensor is certified according to laser protection class 1.
3.4 Intended Use
The R2000 laser scanners are measuring devices that are used on automated
transport systems or other movable machinery in intralogistics. They are also
used on stationary equipment in the area of factory and building automation.
Make sure that the devices are used only for their intended purpose.
Warning!
Class 1 laser light
The laser light can be an irritant, especially in a dark environment. Do not point
lasers at people!
Maintenance and repairs should only be carried out by authorized service person-
nel!
Install the device so that the warning is clearly visible and readable.
Caution: Use of controls, adjustments, or performance of procedures other than
those specified herein may result in harmful laser beam exposure.

2022-12
9
2-D Laser Scanner
Product Description
4ProductDescription
4.1 R2000 Laser Scanner
The two-dimensional R2000 laser scanner is made up of a static body, on which a
continuously turning measurement module with an emitter laser and receiver ele-
ment is located. The laser scanner uses pulse ranging technology (PRT). The
implementation of this innovative functional principle permits continuous scanning
of the surroundings through a full 360°.
The measurement data is evaluated in an integrated control interface for monitor-
ing tasks and the results made available at up to four switching outputs. The
binary switching signals can be further processed by external controllers or other
decentralized intelligent automation components. The monitoring fields are
defined using a device type manager (DTM).This DTM can be used in an FDT
frame application such as PACTware, so that graphically supported parameteriza-
tion of monitoring fields takes place on the PC screen. The monitoring fields can
handle virtually any geometric shape. A monitoring field can extend over a full
360°, but likewise may include only a portion. Up to four fields can be configured.
Typical applications for the 2-D laser scanner include object detection, area moni-
toring, and collision prevention. One particular strength of the device is the detec-
tion of small objects. In going about this task, the sensor combines its above-
average detection performance with maximum ease of use.
One particular highlight of the laser scanner is the row of LEDs arranged on the
back of the measurement module. Rotating the scanner produces a cylinder-
shaped projection surface, which is suitable for displaying text-based as well as
graphical information. In this way, commissioning and operations can be carried
out without aids such as a PC or Notebook. Operating and diagnostic information
can be seen directly during ongoing operation.
The laser scanner from the R2000 series fulfills the safety requirements of laser
class 1 in measurement mode.The low amount of laser light emitted guarantees
that operating personnel are neither injured nor harmed.

2022-12
10
2-D Laser Scanner
Product Description
4.2 Functional Principle
The laser scanner works according to the principle of pulse ranging technology
(PRT). As part of this principle, the time between sending a visible light pulse and
receiving the reflected pulse from the object is measured in the device. Due to the
constancy of the speed of light, this time is a distance measurement.
In comparison with other distance measurement processes, time-of-flight mea-
surement is affected very little by any disturbances in the measuring environment.
As a result, this measurement process can be used with a high level of accuracy
even under tough everyday industrial conditions.The light source and light
receiver are located in the rotating sensor head.
In the integrated measurement data evaluation, the measurements are compared
with up to four configured monitoring fields. The results can be logically linked in
two levels and read out at up to four outputs. Up to four inputs can be integrated
into the logical linking of the monitoring fields.The laser scanner has four I/Q con-
nections so that an appropriate combination of inputs and outputs is possible.

2022-12
11
2-D Laser Scanner
Product Description
4.3 Indicators and Operating Controls
Figure 4.1 Indicators and Controls
4.4 Interfaces and Connections
The following connections are found on all devices:
Power Supply
There is a 4-pin M12 connector on the rear of the housing to connect the power
supply. The following diagram shows the pinning:
Note
Influence of Ambient Conditions
The speed of light depends on the air temperature and barometric pressure.
The influence of the air temperature amounts to 1 ppm/K.
The influence of the barometric pressure amounts to -0.3 ppm/hPa.
These faults must be taken into consideration by the user in the case of longer
distances.
In the operating range (-10 °C ... +50 °C) this fault amounts to 0.6 mm at a
distance of 10 m.
No. Designation Color
1Operating status indicator Green
2Error indicator Red
3"Next" menu button
4"Return" menu button
5Q2—input/output 2 Ye l l o w
6Q1—input/output 1 Ye l l o w
7Laser face
8Ethernet activity indicator Ye l l o w
9Ethernet link indicator Green
Table 4.1 Indicators and Operating Controls
2
6
1
4
3
5
7
9
8

2022-12
12
2-D Laser Scanner
Product Description
Figure 4.2 Power supply connection layout
MultiPort
An 8-pin M12 connector is located on the rear of the housing. Inputs/outputs 3
and 4 are located here
All pins with "DNC (Do not connect)" must not be connected!
Interface:
There is a 4-pin M12 socket on the back of the housing to connect the Ethernet
interface. The following diagram shows the pinning:
124 V power supply
2I/Q2
3Ground (GND)
4I/Q1
1DNC (Do not connect)
2DNC (Do not connect)
3DNC (Do not connect)
4I/Q3
5I/Q4
6I/Q2
7I/Q1
8DNC (Do not connect)
1
3
4
2
1
4
6
7
8
53
2

2022-12
13
2-D Laser Scanner
Product Description
Figure 4.3 Ethernet connection layout
The connector housing is located on the shield.
4.5 Included in Delivery
The delivery package contains:
•R2000 2D laser scanner
•Quick start guide
•Protective cover for MultiPort and Ethernet
•3 x socket cap screws, M5 x 10
•3 x washers, size 5
4.6 Accessories
The following products are available as accessories.
1TD+
2RD+
3TD-
4RD-
1
3
42
Designation Description
V1SD-G-2M-PUR-
ABG-V45-G
Patch cable M12 to RJ45, length 2 m
V1SD-G-5M-PUR-
ABG-V45-G
Patch cable M12 to RJ45, length 5 m
V1SD-G-ABG-PG9 Single-ended male cordset, M12 D-coded, 4-pin for bus
cable
V1-G-2M-PUR Single-ended female cordset, straight, M12, 4-pin, PUR
cable, length 2 m
V1-G-5M-PUR Single-ended female cordset, straight, M12, 4-pin, PUR
cable, length 5 m
V1-W-2M-PUR Single-ended female cordset, angled, M12, 4-pin, PUR
cable, length 2 m
V17-G-2M-PUR Single-ended female cordset, straight, M12, 8-pin,
shielded, PUR cable, length 2 m

2022-12
14
2-D Laser Scanner
Product Description
V17-G-5M-PUR Single-ended female cordset, straight, M12, 8-pin,
shielded, PUR cable, length 5 m
V1S-B Blind plugs
Designation Description
Note
Installation Information for North America
If a connection is made with the M12 multi-pin connector, then in the final
installation of the power supply, the product must be used with a UL-listed
cable/connector assembly (CYJV) that is designed for at least 30 VDC and at least
1.0 A.
Designation Description
V1-G-BK-2M-PUR-U Single-ended female cordset, straight,
M12, 4-pin, PUR cable, length 2 m, "UL
recognized"
V1-G-BK-5M-PUR-U Single-ended female cordset, straight,
M12, 4-pin, PUR cable, length 5 m, "UL
recognized"
V1-G-BK-10M-PUR-U Single-ended female cordset, straight,
M12, 4-pin, PUR cable, length 10 m,
"UL recognized"

2022-12
15
2-D Laser Scanner
Installation
5Installation
5.1 Storage and Transport
Package the device for storage and transport such that it is protected from impact
and moisture.The original packaging provides optimum protection. Also take note
of the permitted ambient conditions.
5.2 Unpacking
Check the product for damage while unpacking. If the product should be dam-
aged, inform the post office or parcel service and notify the supplier.
Retain the original packaging in case the device must be stored or shipped again
at a later date.
Should you have any questions, please contact Pepperl+Fuchs.
5.3 Mounting
The device can be fitted with the supplied socket head screws with washers on
the underside of the device.
Note
If the temperature is subject to major fluctuations during transport, the device
must be allowed to acclimatize for around two hours prior to installation and use.
During this acclimatization period, avoid subjecting the device to condensation at
all costs, as this could have an effect on internal parts and cause damage.
Caution!
Safety information
Do not point the sensor into the sun.
Protect the sensor against direct and prolonged sunlight.
Prevent condensation from forming by ensuring that the sensor is not subjected to
any major temperature fluctuations.
Do not subject the sensor to aggressive chemicals.
Keep the glass on the device clean.
For cleaning, use only water (if necessary with a little detergent) and a soft micro-
fiber cloth! The use of other detergents is not permitted! The glass must never be
cleaned when dry!
Caution!
Screw-in depth
The maximum screw-in depth in the base must not exceed 8 mm, otherwise the
device will be mechanically destroyed! The minimum screw-in depth is 5 mm.

2022-12
16
2-D Laser Scanner
Installation
Figure 5.1 Dimensional drawing R2000
5.4 Device Connection
Electrical connection in line with IP65
1. Put protective covers on unused M12 connectors.
The IP65 protection class is achieved. The protective covers can be ordered
as accessories .
The device conforms to protection class III. This means that the power has to be
supplied as a low protective voltage (PELV).
The power supply of the device is 10 VDC ... 30 VDC. On account of the inte-
grated motor, an increased level of startup current is required compared with nor-
mal operation. It is recommended that power supplies with 1 A (at 24 V) or with
2 A (at 12 V) are used.
The maximum cable length is 30 m.
The pin assignment is as follows:
70
(40)20
60
20
53
106
117.5
4658
116.5
106
16
97.1
3 x M5
20
45
Emitter range and receiver range
Complieswith 21CFR
1040.10and1040.11 except
for deviations pursuant to
Laser Notice No. 50,
dated June 24 , 2007
CLASS 1
LASER PRODUCT
IEC60825-1:2007 certified.
Note
Keep the emitting/receiving area clear
During assembly, make sure that the emitting/receiving area is kept clear. If the
emitting/receiving area is covered, this reduces the performance of the 2D laser
scanner.

2022-12
17
2-D Laser Scanner
Installation
Figure 5.2 R2000 pin assignment
5.5 Grounding / Shielding
The grounding of the cable shields on the metallic flush-type connectors is not
protective grounding in the sense of personnel protection, but is a functional
grounding.
The functional grounding of the cable shields is recommended, if the housing
does not have its own grounding. In environments with severe interference, it is
also sensible to shield and to position the shield on both sides.
For shield grounding, use the preassembled insertion prong, which is fixed to the
Ethernet socket.
PowerMultiportEthernet
4
1
2
3
TD+
TD-
RD-
Shield
4
1
2
3
24 V DC
0 V DC
RD+ I/Q2
I/Q1
4
1
2
3
DNC
DNC
DNC
I/Q3
7
5
6I/Q2
I/Q4
I/Q1
8DNC
DNC = Do not connect
1
3
4
2
1
3
42
1
4
6
7
8
53
2

2022-12
18
2-D Laser Scanner
Commissioning
6 Commissioning
1. Connect the device to the power supply.
The initialization phase lasts approx. 10 seconds. This phase is indicated by
an illuminated Power LED. The display is still disabled in this phase.
2. There is another initialization phase that lasts approx. 10 seconds.
The display turns on and shows circles moving downward.
3. After the initialization phase, the Pepperl+Fuchs logo will appear.
The device is ready for operation.
To achieve the best measurement accuracy, allow the device to warm up for 30
minutes.
The sensor has been tested and calibrated before delivery. It can be put into oper-
ation immediately.
It is generally recommended to use a dedicated network card for the connection
to the device.
For parameterization, connect the device to an Ethernet interface on a computer.
Install the PACTware software and the appropriate DTM.
6.1 Ethernet Configuration
The device has three different address modes. Select your preferred mode from
the modes described below. The setting is configured directly on the device using
the menu interface.
Auto IP
In this mode, the device independently selects a "Link-Local" IP address in the
169.254.0.0/16 range. During this process, measures are taken to ensure that the
selected address is not already being used by another device.
The device is configured to Auto IP by default.The Auto IP setting is the ideal way
to establish a direct connection to a PC. Set the DHCP mode (Dynamic Host Con-
figuration Protocol) on the PC. To do this, select the TCP/IP protocol in the net-
work card properties and select the "Obtain an IP address automatically" setting
there. After approx. 30 seconds, Windows assigns an Auto IP for the PC.

2022-12
19
2-D Laser Scanner
Commissioning
DHCP
Set the device to DHCP under the "Address mode" menu item.The DHCP config-
uration requires a DHCP server in the local network, e.g., a router. See the "Auto
IP" item for information on this.
Manual IP
Set the device to manual under the "Address mode" menu item.The IP address is
set to 10.0.10.9 and the subnet mask to 255.0.0.0 by default. To connect the
device to the PC, the network card must be configured as follows.
Set the required IP address in the network card menu. Select the TCP/IP protocol
in the network card properties and select the "Use the following IP address" set-
ting there. Enter the required IP address and subnet mask.

2022-12
20
2-D Laser Scanner
Commissioning
Note
Device restart
You must restart the device after changing the Ethernet configuration.
