Petsafe Drinkwell D2KA-RE User manual

D2KA-RE
Platinum Pet Fountain - 5 Litres
플래티넘 애완동물 분수대 - 5 리터
Please read this entire guide before beginning
사용하기 전에 본 설명서 전체를 읽어보십시오
Operating Guide
사용 설명서

www.petsafe.net 32 www.petsafe.net
ENKO
IMPORTANT SAFETY INFORMATION
Explanation of Attention Words and Symbols used in this guide
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION, used without the safety alert symbol, indicates a
hazardous situation which, if not avoided, could result in harm to
your pet.
NOTICE is used to address safe use practices not related to
personal injury.
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and/or
injury to persons, including the following:
• To reduce the risk of injury, close supervision is necessary when
an appliance is used by or near children.
• To protect against electric shock, do not place Power Cord or
plug in water or other liquids.
• Only use attachments recommended or sold by the
manufacturer.
• Do not use outdoors. FOR INDOOR HOUSEHOLD USE ONLY.
• Do not unplug by pulling on Power Cord. To unplug, grasp the
plug, not the Power Cord.
• Do not operate any appliance if it has a damaged Power Cord
or plug, or if it is malfunctioning or has been damaged. Call
Customer Care Centre immediately for further instructions.
• For a portable appliance - To reduce the risk of electrical shock,
do not place or store an appliance where it can fall or be pulled
into a tub or sink.
• Always unplug any appliance when not in use, before putting
on or taking off parts and before cleaning. Never pull on the
electrical Power Cord to remove the plug from the wall outlet.
• Do not use an appliance for anything other than its intended use.
• If the plug of this device gets wet, turn off the electricity to that
outlet. Do not attempt to unplug.
• Examine this appliance after installation. Do not plug in if there
is water on the Power Cord or plug.

www.petsafe.net 3
KOEN
• Do not allow pets to chew on or swallow any parts. If you are
concerned about the Power Cord, purchase a cord conduit (a hard
plastic protector) at any hardware store.
• The Pet Fountain parts are BPA-FREE. However, some animals
have been known to be sensitive to plastic food and water
containers. If your animal shows signs of an allergic reaction to the
plastic, please discontinue use until you have consulted with your
veterinarian.
• The Pet Fountain is intended to run continuously (always plugged
into electricity), as long as the water level is maintained and the
Pet Fountain is cleaned regularly. Be sure to check the Pet Fountain
regularly to help prevent damage to the Pump, as the water may
get consumed or evaporate causing the Pump to run dry.
• Do not attempt repairs on the Pump yourself.
• To avoid the possibility of the plug or outlet getting wet, the outlet
should always be above the level of the Pet Fountain.
• If an extension cord is necessary, an extension cord with a proper
rating should be used.
• The electrical use of this appliance is 6 watts.
• Do not use appliance for anything other than intended use. The use
of attachments not recommended or sold by the manufacturer may
cause an unsafe condition. Do not modify the unit.
• Do not install or store appliance where it will be exposed to
weather or temperatures below 4.5° C.
• Read and observe all important notices listed on the appliance and
in the packaging.
SAVE THESE INSTRUCTIONS

www.petsafe.net 54 www.petsafe.net
ENKO
Thank you for choosing the PetSafe®brand. You and your pet deserve a
companionship that includes memorable moments and a shared understanding
together. Our products promote a lifestyle of protection, teaching and love; essentials
that influence memories for a lifetime. If you have any questions about our products,
please visit our website at www.petsafe.net or contact our Customer Care Centre.
Table of Contents
Components ............................................................5
Features................................................................5
Key Definitions ..........................................................6
Operating Instructions ....................................................7
Pet Fountain Disassembly & Cleaning .......................................8
Pet Fountain Reassembly .................................................10
Pump Maintenance .....................................................11
The Pet Fountain and Your Environment .....................................12
General Tips ...........................................................13
Warranty and Customer Care.............................................13
Compliance ...........................................................14
Important Recycling Advice...............................................14
Terms of Use and Limitation of Liability......................................15
Korean .............................................................16

www.petsafe.net 5
KOEN
Components
Features
Housing
Housing Lid
Bowl
Pump (Motor) with
Flow Control Knob
Reservoir
Reservoir Cap
Charcoal Filter
Inline Plug &
Power Cord
Pre-Filter
Free-Falling Stream of
Water entices pets to
drink more
Snap-On Lid Replaceable Charcoal
Filter removes bad
tastes & odours
Pre-Filter
Adjustable Flow Control
5 L Water Capacity
Dishwasher Safe
Reservoir
Receiving Ramp
reduces splash Submersible Pump
for nearly
silent operation
Low-Voltage (12V) System

www.petsafe.net 76 www.petsafe.net
ENKO
Key Definitions
Housing: The water is pumped up through the Housing to cycle through the Charcoal
Filter and out the spout to create a waterfall into the Bowl.
Housing Lid: The Housing Lid snaps in place over the Housing, keeping pets out of
the Charcoal Filter.
Charcoal Filter: is a 3-layer carbon filter with granulated carbon made from co-
conut shells. The Charcoal Filter absorbs bad tastes and odours as the water passes
through and helps keep the water tasting fresh and more appealing to pets.
Pre-Filter: The small intake grate that catches large particles such as hair and kibble
before they reach the Charcoal Filter. The Pre-Filter can be removed by pulling up on
the lip at the top. To replace, slide back into place over the Flow Control Knob and
push down until it clamps around the knob.
Bowl: The Bowl is the foundation of the Pet Fountain. It features two handles on either
side of the Pet Fountain as well as a “cord channel” to hide the cord from view.
Flow Control Knob: The black knob attaches to the Faceplate and adjusts the rate
of water flow. The Pre-Filter will snap around the neck of the Flow Control Knob which
will lock it into place.
Pump (Motor): The small submersible aquarium Pump that can be dismantled for
cleaning. Important: THE PUMP IS NOT DISHWASHER SAFE! Remove Pump from
Pet Fountain before cleaning (See section “Pump Maintenance”). The Pump also
features a removable Inline Plug for easy attachment.
Reservoir: The extra capacity Reservoir holds over 1.89 litres of water. The Reservoir
Cap will help to minimize spills when you refill the Reservoir.

www.petsafe.net 7
KOEN
Operating Instructions
Important: DO NOT RUN DRY - FOR INDOOR USE ONLY. Pet Fountain will come
fully assembled and ready for use.
1. As with any electrical device, check the electrical Power Cord for any tears or
damage before use.
2. Make sure the Inline Plug is connected. (No silver showing)
3. Remove the Housing Lid by placing your index fingers into the inset groves on
either side of the Housing Lid. Lift up. Set the Housing Lid aside.
4. Lift up the Reservoir and
check to make sure the
Intake Tube is properly
inserted into the Pump
(Fig. 1 & 2).
5. Insert the Charcoal Filter. The Charcoal Filter will fit into the two triangular slots in
the centre of the Housing. The Charcoal Filter fits narrow side down and the black
side faces the front of the Pet Fountain. The Charcoal Filter will slide easily into
place.
NOTE: Rinse the Charcoal Filter thoroughly under cool
water before placing into the Housing. This will remove
any loose charcoal dust, which is harmless. A small
amount of charcoal dust may shed for the life of the
Charcoal Filter. This is normal and not harmful to your pet
(Fig. 3).
6. Fill the Pet Fountain with water. This includes the Bowl
and the Housing. This will prime the Pump. Replace
the Housing Lid and snap into place.
Fig. 1 Fig. 2
Fig. 3

www.petsafe.net 98 www.petsafe.net
ENKO
7. Remove the Reservoir by lifting up and away from the Pet Fountain. Turn the
Reservoir upside down and remove the Reservoir Cap. Fill the Reservoir with
water and replace the Reservoir Cap. Holding the Reservoir upside down and
backwards to the Pet Fountain (Fig. 4), quickly turn the Reservoir right side up
and slide into place (Fig. 5). The water level will equalize to approximately 1.27
cm below the rim of the Bowl.
8. Place Pet Fountain in desired location. If placing on carpet, tile or wood flooring
use a protective surface such as a towel or placemat to protect your floor from
splashing or dripping from your pet.
9. Before you plug in the Pet Fountain make sure the Power Cord and your hands
are dry. Plug the Pet Fountain into a standard electrical outlet.
10. Set your desired flow rate with the Flow Control Knob,
located to the right of the Receiving Ramp. In the 10
o’clock position for a smaller stream or in the 2 o’clock
position for a stronger stream (Fig. 6).
11 . Add water as needed. Do not let the water level fall
lower than the Flow Control Knob or you may burn
out the Pump. Do not pick up a full Pet Fountain by the
Housing. Only use the handles located on the bottom of
the Bowl on either side of the Pet Fountain.
Pet Fountain Disassembly & Cleaning
Important: Pet Fountain must be cleaned to continue working normally.
CHARCOAL FILTERS: Change every 2 to 4 weeks.
1. Charcoal Filters should be changed every two to four weeks. Replace Charcoal
Filters more frequently when using the Pet Fountain for multiple pets or pets that
produce a lot of saliva.
2. Charcoal Filters are an added feature of the Pet Fountain. Their use is not required
for normal operation.
3. Charcoal Filters may be rinsed out when the Pet Fountain is cleaned. Do not wash
with soapy water since you cannot remove all the soap residue.
Fig. 4 Fig. 5
MIN MAX
Fig. 6

www.petsafe.net 9
KOEN
PET FOUNTAIN: Clean once a week.
1. Unplug the Pet Fountain, remove Housing Lid and
remove the Charcoal Filter.
2. Remove the Reservoir.
3. Empty the water out of the Pet Fountain.
4. Remove the Pre-Filter by gently pulling up on the top lip
of the Pre-Filter and wash with soap and water (Fig. 7).
5. Remove the Housing by gently pushing in on either side of the Pet Fountain where
the curve meets the seam. Gently lift up (Fig. 8-10).
NOTE: You will notice the right side of the Housing will offer some resistance as the
water Intake Tube pulls away from the Pump.
6. Next, remove the Pump by disconnecting the Inline Plug (Fig. 11 & 12), then lift
it out of the Pet Fountain. Clean away any hair, debris or kibble that may have
accumulated around the Flow Control Knob and the Faceplate of the Pump.
7. Once the Pet Fountain is completely disassembled you will have 6 plastic parts.
8. Clean the Pet Fountain parts with warm water and soap. You can also put the Pet
Fountain in the dishwasher (not the Pump). Remove the Pump before placing in the
dishwasher. It is recommended that you turn down the heat of the dishwasher
if possible.
9. If you have troubles reaching certain spots or hard-to-reach corners, try using a
cotton swab or purchase the Drinkwell®Cleaning Kit, a 3-Brush Kit.
Fig. 7
Fig. 8
Fig. 9
Fig. 10
Fig.
12
Inline Plug
Fig. 11

www.petsafe.net 1110 www.petsafe.net
ENKO
Pet Fountain Reassembly
1. Replace the Pump into its location in between the three posts on the right side of
the Pet Fountain. Gently push down to engage the suction cups. (Fig. 13 & 14)
2. Thread the Inline Plug through the opening next to the Pump. Under the arch you
can tuck the Power Cord into “cord channels” (Fig. 15), then move the Power
Cord along the back of the Pet Fountain to the Power Cord “Pass-Through”. (Fig.
16) Use this “Pass-Through” to keep the Power Cord from showing.
3. Line up the Housing unit over the Pump and then the Bowl. You will want to line
up the Intake Tube to fit directly into the Pump. Once in place, gently push down,
locking the Housing into place (Fig. 17 & 18).
Fig. 13 Fig. 14
Fig. 15
Power Cord “Pass-Through”
Fig. 16
Intake
Tube
Fig. 17 Fig. 18
