PEUGEOT 306 2002 User manual

2
YOUR 306 AT A GLANCE
1
25 15
16 14
1718
19
20
24
2 3 4 57 8 9 10 12 131 2
21
22
23
611

YOUR 306 AT A GLANCE
3
1- Adjustable side vent.
2- Side window demisting vent.
3- Passenger airbag*.
4- Windscreen demisting vents.
5- Controls:
Lighter
Hazard warning lights
Rear screen and mirrors
demisting.
6- Heating/Ventilation,
Air conditioning controls*.
7- Audio equipment*.
8- Adjustable central vents.
9- Windscreen wash-wipe
control.
10 - Steering wheel with
airbag*.
11 - Audio remote control*.
12 - Lighting control, fog lamps*
and horn.
13 - Headlamp height adjustment.
- Instrument dials lighting
rheostat.
14 - Controls for:
- Electric mirrors*.
- Electric windows*.
15 - Control for locking the rear
windows.
16 - Passenger airbag disarm-
ing switch*.
17 - Bonnet opening control.
18 - Fuse box.
19 - Steering lock and ignition.
20 - Fuel filler flap control*.
21 - Handbrake.
22 - Gear lever.
23 - Storage compartment.
24 - Ashtray.
25 - Glove box.
* According to specification.

YOUR 306 AT A GLANCE
6
FRONT AIRBAGS
Disarming the passenger airbag
Insert the ignition key in switch 1
and turn it:
– to the “ON” position, the pas-
senger airbag is armed,
– to the “OFF” position, the pas-
senger airbag is not armed.
THE REMOTE CONTROL
A single press on button Alocks
the doors and boot or tailgate.
Asingle press on button Bunlocks
the vehicle.
KEYS
Using the key in the driver’s door
lock will lock or unlock the doors
and boot or tailgate.
Passenger airbag precautions
For a vehicle fitted with a disarm-
ing switch: – disarm the
airbag if you
install a
rearwards-
facing child
seat.
– arm the
airbag when
an adult is in
the seat.
For a vehicle not fitted with a dis-
arming switch:
– do not install rear-
wards-facing child
seats on the front
passenger seat.
Never place your feet or any
object on the fascia.
A
B
Operational Check
This is by means of the warning
light on the instrument panel.
If the passenger airbag is armed
or if your vehicle is not fitted with a
passenger airbag, the warning
light comes on for 6 seconds when
the ignition is switched on.
If the passenger airbag is not
armed, one of the warning lights
remains on.
Always contact your PEUGEOT
dealer if the warning light flashes.
108
**
** According to model.

YOUR 306 AT A GLANCE
5
STARTING
The 4 positions of the key in the
ignition:
“S” for STOP The ignition is off.
“A” for Accessories The ignition
is off but the accessories can be
used.
“M” for Running The ignition is
on.
“D’’ for Starting Operates the
starter.
Steering lock
Before starting, unlock the steer-
ing if necessary, by gently turning
the steering wheel at the same
time as you turn the key.
It is advisable to press the clutch
pedal while operating the starter
to make starting easier.
Starting a petrol engine
Do not press the accelerator.
Operate the starter, without
releasing the key, until the engine
turns.
Starting a diesel engine
Do not press the accel-
erator.
Turn the key to position
‘‘M’’.
If the engine is warm enough, the
pre-heat light does not come on
and you can start immediately.
If the pre-heat light comes on,
wait for it to go out before operat-
ing the starter.
HDI engine special feature
If the engine stalls, it is necessary
to return the key to position ‘‘S’’
before restarting.
Never race a cold
engine.
Never run the engine
in a confined space.
Do not make any modifications
to the steering lock.

YOUR 306 AT A GLANCE
4
Confidential card
This contains the identification
combination which is required if
any work is carried out on the
system by a PEUGEOT dealer.
This combination is concealed by
a strip which must not be removed
unless required.
Keep your card in a safe place,
never in your vehicle.
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control
system a few moments after the
ignition has been switched off and
therefore prevents starting of the
vehicle by anyone who has not
got the key.
Operation
Each key has an electronic chip
which has a special code.
When the ignition is switched on
the key code is recognised and
starting is possible.
If the key does not have a code
or has a different code from that
stored in the system memory, the
vehicle will not start.
Additional key
You can store up to 5 keys in the
memory.
If you require an additional key or
wish to change a faulty key, you
must visit a PEUGEOT dealer
with the confidential card and all
the keys in your possession.
When buying a second hand car:
Ensure that you are given the confidential card.
It is advisable to have the key codes memorised by a
PEUGEOT dealer to ensure that the keys in your possession
are the only ones which can start the vehicle.
Do not make any modifications to the PEUGEOT electronic engine
immobiliser system.

YOUR 306 AT A GLANCE
7
Automatic wipe
The system automatically adjusts the
wiper timing to the intensity of the rainfall.
After switching off the ignition or starting
in position 1, it is necessary to re-set this
function. This is possible in two ways:
– change from 1to 0then
return to 1(displayed by one
wipe),
– change from 1to 2then
return to 1(displayed by two
wipes). 91
STEERING WHEEL
STALKS
LIGHTING
Front lights (ring A) Rear
Front/rear fog lamps (ring B)
Front and rear
fog lamps on.
Front
windscreen
wipers
3Rapid wipe
2Normal wipe
1Intermittent or
automatic wipe
0Stop
4Single wipe
Wash-wipe: pull
the stalk towards
you.
Lights off.
Side lights on.
Dipped/main
beamheadlamps
on.
90
Fog lamp off.
Front fog lamps on.
3
2
1
0
4
Stop
Intermittent
wipe
Wash-wipe
AB

ADJUSTING THE FRONT
SEATS (3-door)
1Forwards-backwards adjust-
ment.
2Seat back angle adjustment.
3Drivers seat height adjust-
ment: pull the telescopic
handle and pivot it.
4Lumbar adjustment.
5Access to rear seats.
ADJUSTING THE FRONT
SEATS (4/5-door and estate)
1Forwards-backwards adjust-
ment.
2Seat back angle adjustment.
3Drivers seat height adjust-
ment: pull the telescopic
handle and pivot it.
4Lumbar adjustment.
YOUR 306 AT A GLANCE
10
HEAD RESTRAINTS
- Height adjustment: slide them.
- Adjusting the angle: tilt them.
To remove the head restraint, posi-
tion it at maximum height and
press the tab.
83 83 83
5
1
4
2323
1
4

YOUR 306 AT A GLANCE
11
FOLDING REAR SEAT
BACK
To fold the seat back:
- from inside the boot, release
control 1.
- position the seat belt under the
strap guide B.
- unlock the seat back by pres-
sing button A.
- tilt the seat back.
When repositioning the seat back,
ensure that the seat belts
are positioned correctly
and the seat back is
secured correctly.
FOLDING REAR SEATS (all models)
To fold the rear seats:
- insert the seat belt stalks in the hooks A.
- pull the strap 1.
- tilt the seat cushion 2against the front seats.
- position the seat belt under the lever 3(5-door and estate) or on the top
of the seat back (3-door).
- unlock the seat back using the controls on the side 3(5-door and estate)
or on the seat back 4 (3-door).
- tilt the seat back 4.
To tilt the rear seats, always start with the seat cushion, never
with the seat back (risk of damage).
When repositioning, take care to avoid trapping the seat belts
under the seat cushion or behind the seat back.
8586
1
4
3
A
2
AB
1

ELECTRIC WINDOWS
1. Driver's electric window
Manual mode: press or pull the switch lightly. The window stops as soon
as the switch is released.
Automatic mode: press or pull the switch firmly. One touch completely
opens or closes the window.
Automatic opening and closing only work when the engine is running.
2. Passenger’s electric window.
3. Left rear electric window.
4. Right rear electric window.
YOUR 306 AT A GLANCE
8
ADJUSTING THE HEIGHT
OF THE STEERING WHEEL
Push the handle to unlock the
steering wheel.
Adjust the steering wheel to the
desired height and pull the handle
to lock it into position.
101
2 1
ELECTRIC MIRRORS
Turn the knob Ato the right or to the left to select the corre-
sponding mirror.
Move the knob in all four directions to adjust the mirror.
3 4
A
99

YOUR 306 AT A GLANCE
99
FUEL FILLER FLAP
To open*: firmly pull the handle on the floor to the outside of the drivers seat.
To close: from outside, push the flap back and check that it is secured
correctly.
The fuel filler cap is opened and closed with the ignition key independently
of opening the doors (during model year).
Filling with fuel
Switch off the engine.
There is a holder for the fuel filler cap.
Alabel on the inside of the flap shows which fuels are permitted and which
are not allowed.
The capacity of the tank is approximately 13 gallons (60 litres).
Fuel low warning light
The fuel low warning light indicates that the quantity of
fuel remaining in the tank is approximately
1.3 gallons (6 litres). 82
Outside the vehicle
Raise the catch 1and
support the bonnet as it
rises.
*Accordingto specification.
OPENING THE BONNET
Inside the vehicle: Pull the
handle.
81
1
