PFT MULTIMIX User manual

Contents
2018-04-1710
Operating manual
FORCED ACTION MIXER PFT MULTIMIX
Overview – Operation – Spare Parts Lists
Item number of operating manual: 00 62 78 04
MULTIMIX, 400 V, 3 Ph, 50 Hz Item number of the machine: 00 25 16 36
MULTIMIX, 230 V, 1 Ph, 50 Hz, 2.2 kW Item number of the machine: 00 54 42 38
Read the operating manual prior to beginning any work!

Page 2 23.04.2018
© Knauf PFT GmbH & Co.KG
Postfach 60 97343 Iphofen
Einersheimer Straße 53 97346 Iphofen
Germany
Tel.: [phone]
Fax: [phone]
Technical hotline: [phone]
[email protected]
www.pft.eu

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Contents
23.04.2018 Page 3
23.04.2018
1 EC Declaration of Conformity ......................... 5
2 Testing............................................................... 6
2.1 Testing by machine operator............... 6
2.2 Periodic inspection .............................. 6
3 General information ......................................... 7
3.1 Information regarding the operating
manual................................................. 7
3.2 Keep the manual for later use ............. 7
3.3 Layout.................................................. 7
4 Spare part lists.................................................. 8
4.1 Accessories ......................................... 8
5 Technical data................................................... 9
5.1 General specifications ......................... 9
5.2 Connection values 400 V..................... 9
5.3 Connection values 230 V..................... 9
5.4 Operating requirements..................... 10
6 Sound power level.......................................... 10
7 Vibrations........................................................ 10
8 Type plate........................................................ 10
9 Quality control sticker.................................... 10
10 Water connection ......................................... 10
11 Overview........................................................ 11
12 Function ........................................................ 12
12.1 Description......................................... 12
12.2 Areas of application........................... 12
12.3 Advantages at a glance..................... 13
13 Accessories .................................................. 13
14 Transport, packaging and storage ............. 14
14.1 Safety instructions for transport......... 14
14.2 Transport checklist ............................ 15
15 Transport by crane....................................... 15
16 Transport in individual parts....................... 15
17 Transportation of operational machines
400 V............................................................16
18 Transportation of operational machines
230 V............................................................16
19 Packaging......................................................16
20 Operation.......................................................17
20.1 Safety.................................................17
21 Machine preparations ..................................18
21.1 Risk of injury due to rotating mixing
arms...................................................18
22 Connection to the 400 V power supply ......18
23 Connection to the 230V power supply .......19
24 Checking the direction of rotation 400 V ...20
24.1 Changing the direction of rotation
400 V..................................................20
25 Water supply connection.............................20
25.1 Water from water barrel connection ..21
26 Switching on putting into service 400 V ....21
27 Switching on putting into service 230 V ....21
27.1 Hazardous dust..................................22
27.2 Filling the MULTIMIX with bagged
material..............................................22
27.3 Opening the protective grille..............22
27.4 Danger of crushing by protective grille23
28 Emptying the machine .................................23
29 Switching off 400 V.......................................23
30 Switching off 230 V.......................................24
31 Interruption of work......................................24
32 Measures to be taken in the event of a power
failure ...........................................................24
33 Measures to be taken if there is a risk of
frost .............................................................25
34 Switching off in an emergency....................26
35 Cleaning.........................................................27

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Contents
Page 4 23.04.2018
36 Dealing with malfunctions ...........................28
36.1 Malfunctions.......................................28
36.2 Safety.................................................28
36.3 Table of malfunctions.........................29
37 Maintenance..................................................29
37.1 Safety.................................................29
37.2 Maintenancetasks..............................30
37.3 Setting the mixing arm.......................30
37.4 Motor and gearbox maintenance.......31
37.5 After performing maintenance ...........31
38 Environmental protection............................31
39 Disassembly..................................................32
39.1 Safety.................................................32
39.2 Disassembly.......................................33
40 Disposal.........................................................33
41 Spare parts drawing, spare parts list .........34
41.1 MULTIMIX material hopper................34
41.2 Spare parts list MULTIMIX material
hopper................................................35
41.3 MULTIMIX frame................................36
41.4 Spare parts list: MULTIMIX chassis...37
41.5 Mixing unit with gear motor................38
41.6 Spare parts list: Mixing unit with gear
motor..................................................39
41.7 Limit switch – On / Off switch.............40
41.8 Spare parts list: Limit switch – On /
Off switch ...........................................41
41.9 Control box MULTIMIX 230V FU Item
no. 00545071.....................................42
41.10 Spare parts list: Control box
MULTIMIX 230V FU Item no.
00545071...........................................43
41.11 Control box holder MULTIMIX ...........44
41.12 Spare parts list: Control box holder
MULTIMIX..........................................44
42 Circuit diagram..............................................45
43 Index...............................................................46

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
EC Declaration of Conformity
23.04.2018 Page 5
23.04.2018
1 EC Declaration of Conformity
Company: Knauf PFT GmbH & Co. KG
Einersheimer Straße 53
97346 Iphofen
Germany
declares, with exclusive responsibility, that the machine
Machine model: MULTIMIX
Device type: Forced action mixer
Serial number:
Guaranteed sound power level: 78 dB
conforms to the following CE regulations:
•Outdoor Noise Directive (2000/14/EC),
•Machine Directive (2006/42/EC),
•Directive on Electromagnetic Compatibility (2014/30/EU).
Applied conformity assessment procedure according to Outdoor Noise Directive 2000/14/EC:
Internal manufacturing inspection as per Article 14, Section 2 in conjunction with Appendix V.
This declaration applies only to the machine in the condition it was in when sold. Components
attached or modifications undertaken by the end customer after purchase remain unconsidered.
This declaration becomes invalid if the product is converted or altered without approval.
Agent responsible for putting together the relevant technical documentation:
Dipl.-Wirtsch.-Ing. Michael Duelli, Einersheimer Straße 53, 97346 Iphofen, Germany.
The technical documentation is held at:
Knauf PFT GmbH & Co.KG, Technische Abteilung, Einersheimer Straße 53, 97346 Iphofen, Germany.
Iphofen, Germany Dr. York Falkenberg
General Manager
Place and date of issue Name and signature Information on undersigned

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Testing
Page 6 23.04.2018
2 Testing
2.1 Testing by machine operator
Before the start of each work shift, the machine operator must test
the effectiveness of the control and safety devices as well as check
the proper attachment of all protective devices.
During operation, construction machines must be tested by the machine
operator for their operational safety.
If defects are found in the safety devices or any other area that could
impair safe operation, the supervisor must be notified immediately.
For defects posing a hazard to persons, the operation of the construction
machine must be halted until the defect is eliminated.
2.2 Periodic inspection
Construction machines must be tested for safe operation by a specialist
as the usage conditions and operating circumstances require, but at least
once a year.
Pressure vessels must undergo the prescribed inspections by
authorised experts.
The inspection results are to be documented and must be stored at least
until the next inspection.

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
General information
23.04.2018 Page 7
23.04.2018
3 General information
3.1 Information regarding the operating manual
This manual provides important information and instructions on
the correct use of the equipment. Adherence to all defined safety and
handling instructions is a prerequisite for a safe working environment.
Additionally, the on-site accident prevention regulations and general
safety guidelines for the equipment must be followed at all times.
Read the manual carefully before starting any work! It is an integral part
of the product and must be kept near the machine and accessible to
operators at all times.
Always include the operating manual when transferring the machine to
third parties.
The diagrams and illustrations shown in the manual are intended for
better understanding of tasks and descriptions. They are not necessarily
shown to the correct scale and may vary slightly from the actual
equipment used.
3.2 Keep the manual for later use
The operating manual must be available during the entire service
life of the product.
3.3 Layout
The operating manual is comprised of two booklets:
Part 1: Safety
General safety instructions for mixing pumps/conveying pumps
Item number: 00 14 63 78
Part 2: Overview, operation, servicing and spare part lists
(this booklet).
Both parts must be read and adhered to in order to ensure safe
operation of the equipment. Together, they are valid as one
operating manual.

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Spare part lists
Page 8 23.04.2018
4 Spare part lists
You can find spare part lists for the machine in the Internet under www.pft.eu.
Access for dealers with username and password.
Access
4.1 Accessories
1
2
3
4
For recommended accessories/equipment, see PFT
Machine and Equipment Catalogue or
www.pft.eu
.

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Technical data
23.04.2018 Page 9
23.04.2018
5 Technical data
5.1 General specifications
5.2 Connection values 400 V
Electrical
Specification Value Unit
Tensioning 3Ph./ 50 Hz 400 V
Energy consumption (approx.) 5.2 A
Power consumption 2.2 kW
Connection 16 A
Power unit minimum 7.5 KVA
5.3 Connection values 230 V
Electrical
Specification Value Unit
Tensioning 3Ph./ 50 Hz 230 V
Energy consumption (approx.) 9 A
Power consumption 2.2 kW
Connection 16 A
Speed range 24 - 49 rpm
Specification Value Unit
Weight 148 kg
Length 980 mm
Width 1060 mm
mixing hopper max. 140 litres
Capacity: Ready-mixed product approx. 80 litres
Maximum grain size 6 mm
Height / Feet adjustable 1120 - 1380 mm

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Sound power level
Page 10 23.04.2018
5.4 Operating requirements
Ambient conditions
Specification Value Unit
Temperature range 2 - 45 °C
Relative humidity (maximum) 80 %
6 Sound power level
Guaranteed sound power level L WA 78 dB (A)
7 Vibrations
Weighted effective acceleration value to which the upper limbs are exposed = < 2.5 m/s²
8 Type plate
Fig. 1: Type plate
The type plate is found on the chassis and contains the
following details:
Manufacturer
Type
Year built
Machine number
9 Quality control sticker
Fig. 2: Quality control sticker
The quality control sticker contains the following information:
CE confirmed in compliance with EU directives
Serial number
Controlled by / signature
Date of control
10 Water connection
Fig. 3: Water connection
Specification Value Unit
Connection 1/2 inches

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Overview
23.04.2018 Page 11
23.04.2018
11 Overview
1 2 3
10 9
Fig. 4 Overview
1. Protective grille with bag opener 2. Protective grille limit switch
3. Rotary bolt for protective grille 4. Shut-off valve for water inlet
5. Main switch ON / OFF 6. Mains connection, 16A
7. Gear motor 8. Protection and retaining bar with bracket
9. Spare wheel 10. Spring plug
11. Foot height adjustable 12. Material outlet
13. Material outlet swivel arm CLOSED / OPEN 14. Crane eyelet
14
13
12
11
4
5
6
7
8

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Function
Page 12 23.04.2018
12 Function
12.1 Description
1 2 3
Fig. 5: Description
The PFT MULTIMIX is a powerful batch mixer that is
particularly suitable for special mixtures comprising
different components.
The mixed material can be added straight into
the hopper (2) and be prepared via the water inlet (3)
using the specified quantity of liquid.
Powerful mixing arms save time while producing
homogeneous mortar mixtures.
The mixed material is quickly and cleanly drained
using a flat slide valve (1) on the hopper base.
12.2 Areas of application
Fig. 6: Use
Areas of application:
Concrete refurbishment
PCC and SPCC mortars
Fine concrete
Screeds
Furnace construction
Flue construction
Powder adhesive
Mineral plasters
Acoustic plasters*
Synthetic resin plasters
Epoxy resins
Granulates
* The TURBO mixing unit might have to be screwed
on for sensitive mortars, e.g. acoustic plasters.
The corresponding guidelines of the mortar manufacturer
have ultimate priority.

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Accessories
23.04.2018 Page 13
23.04.2018
12.3 Advantages at a glance
Fig. 7: SWING under MULTIMIX
THE MULTI-COMPONENT MIXER FOR PROFESSIONALS
What the PFT MULTIMIX transfers well mixed and capable of being
pumped to a PFT delivery pump, “transports” this to the location of use.
The sophisticated design enables diverse applications.
Exact mixing ratio of the individual components.
Adding binders.
Intensive and homogeneous material preparation.
Rapid mixing by contra-rotating mixing arms.
Height adjustable.
Can be combined with the PFT delivery pumps Swing and ZP 3.
Easy handling.
Fast and clean emptying.
Compact and stable design.
Easy to maintain.
The PFT MULTIMIX fits via the PFT Swing and PFT ZP 3.
Fig. 8: ZP 3 under MULTIMIX
13 Accessories
Fig. 9: Power cable
Item number 20 42 33 50 Power cable 5 x 2.5 50 m with
CEE plug and coupling 16 A 6 h red.
Item number 20 42 33 60 Power cable 5 x 2.5 25 m with
CEE plug and coupling 16 A 6 h red.
Fig. 10: Power cable
Power cable 3x2.5 mm², 25m safety socket CEE 16 A Item no. 20423420.
Fig. 11: Water/air hose
Item number 20212010
Water/air hose 1/2",
20 m with Geka
couplings.
Item number 00289007
Support foot with castor
MULTIMIX Mod2012
Fig. 12: Support foot
with castor
You can find further accessories on the internet under www.pft.de or at your PFT building machinery dealer’s.

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Transport, packaging and storage
Page 14 23.04.2018
14 Transport, packaging and storage
14.1 Safety instructions for transport
Improper transport
CAUTION!
Damage can be caused by improper transport!
Significant damage may occur if the equipment is
transported incorrectly.
Therefore:
Proceed with care when unloading packages
and transporting goods on-site. Always observe
the symbols and instructions on the packaging.
Only use the provided suspension points.
Only remove packaging immediately
before assembly.
Suspended loads
WARNING!
Danger of death due to suspended loads!
Falling or swinging parts can pose a fatal
hazard when heavy loads are lifted.
Therefore:
Never step underneath suspended loads.
Follow instructions regarding the provided
suspension points.
Do not attach lifting tackle to protruding machine
parts or to eyelets of add-on components.
Ensure the lifting gear is fastened securely.
Only use approved lifting gear and accessories
with a sufficient load-bearing capacity.

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Transport by crane
23.04.2018 Page 15
23.04.2018
14.2 Transport checklist
Inspect the goods for damage and missing parts immediately
after delivery.
If external transportation damage can be seen, proceed as follows:
Do not accept the delivery, or accept it only under reservations.
Note the damage on the transportation documents or the
delivery note of the carrier.
Submit the appropriate claim.
NOTE!
Always submit a claim for the defects as soon as
they are detected. Damage claims can only be
accepted within the applicable deadlines
for submission.
15 Transport by crane
Fig. 13: Attachment points
Attachment points
To transport using a crane, attach a rope to the attachment
eyelets (1)
Observe the following requirements:
The crane and lifting equipment must be suitable for
the package weight.
The operator must be authorised to operate the crane.
Fastening the lifting gear:
Attach ropes or belts as appropriate.
1. Ensure that the package is suspended so it is level.
Adjust for off-centre balancing points if necessary.
16 Transport in individual parts
Fig. 14: Individual parts
The mixing unit and the material hopper of the PFT MULTIMIX
can be removed from the frame with the motor for the transport
and maintenance:
1. Undo screws (1) of the mixing unit and lift the den material
hopper off the frame.
2. Make sure that the motor (2) points towards the sliding bar (3)
during assembly.
2
3
1

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Transportation of operational machines 400 V
Page 16 23.04.2018
17 Transportation of operational machines 400 V
Fig. 15: Removing the connections
DANGER!
Danger of injury due to escaping dry material!
Injury to the face and eyes can occur.
Carry out the following steps before transporting:
1. Remove main power cable (1).
2. Remove water supply line (2).
3. Begin transport.
18 Transportation of operational machines 230 V
Fig. 16: Removing the connections
DANGER!
Danger of injury due to escaping dry material!
Injury to the face and eyes can occur.
Carry out the following steps before transporting:
1. Remove main power cable (1).
2. Remove the water supply lines.
3. Begin transport.
19 Packaging
Packaging information Individual packages are packed according to the applicable
transportation requirements. Only environmentally-friendly
materials were used for the packaging.
The packaging is intended to protect individual components from
harm during transportation, corrosion and other damage up to the
point of assembly. Do not destroy the packaging and only remove
it shortly before assembly.
Provided no agreements for the return of the packaging have been
made, separate the materials according to type and size and reuse
or recycle them accordingly.
2
1
1

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Operation
23.04.2018 Page 17
23.04.2018
Handling the packaging materials
CAUTION!
Environmental damage can result from
improper disposal of materials!
Packaging materials are valuable resources
and can often be reused or recycled.
– Dispose of packaging materials in an
environmentally sound manner.
– Observe locally applicable waste disposal
guidelines. If necessary, contract a specialist
waste disposal company.
20 Operation
20.1 Safety
Personal protective equipment All machine operators must wear the following protective equipment:
Protective work clothing
Safety goggles
Safety gloves
Safety shoes
Ear protection
NOTE!
The warning signs illustrated in this chapter relate to
additional protective equipment that must be worn
for particular working conditions.
Basic information
WARNING!
Danger of injury due to improper operation!
Improper operation can lead to serious injuries
or equipment damage.
Therefore:
Carry out all operating steps as described this
operating manual.
Before starting any work, ensure that all covers
and protective devices are installed and
functioning properly.
Never disable protective devices during operation.
Keep the operating area clean and tidy.
Components and tools that are stacked on one
another or left lying around can cause accidents.
An increased noise level can cause permanent
hearing loss. Operation can result in noise
that exceeds 78 dB (A) in close proximity to
the machine. Close proximity is defined as
the area within 5 metres of the machine.

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Machine preparations
Page 18 23.04.2018
21 Machine preparations
21.1 Risk of injury due to rotating mixing arms
Before operating the machine, carry out the following work
steps as preparation:
DANGER!
Rotating mixing arms!
Risk of injury if reaching close to rotating
mixing arms.
The protective grille (1) and mortar outlet
(2) should not be removed while preparing
or operating the machine.
Never reach into the machine
while it is running.
1 2
Fig. 17: Protective
grille Fig. 18: Mortar outlet
Fig. 19: Setting up the machine
Install the machine on stable and even ground and secure it
against accidental movements:
Do not tilt or roll the machine away.
Place the machine where it cannot be hit by any
falling objects.
The operating element must be freely accessible.
Keep a free space of approx. 1.5 metres around
the machine.
22 Connection to the 400 V power supply
Fig. 20: Connecting the power
Only connect the machine to three-phase current with 400 V.
DANGER!
Danger of death due to electric current!
The electrical connection must be fused
correctly:
Only connect the machine to a power source
with an approved FI circuit breaker (30 mA)
RCD (residual current device) of type “A”.

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Connection to the 230V power supply
23.04.2018 Page 19
23.04.2018
Fig. 21: Power supply
WARNING!
Danger of death due to rotating parts!
Improper operation can lead to serious injuries
or equipment damage.
The relevant drive (motor) may only be
operated via the associated control box of
the machine (undervoltage release).
23 Connection to the 230V power supply
Fig. 22: 230V connection
1. 230V connection to the machine.
Fig. 23: 230V power supply
2. Only connect to power distributors that conform to regulations.
DANGER!
Danger of death due to
electric current!
The electrical connection must be
fused correctly:
For the operation of frequency
converters, only connect the machine to
a power source with an approved FI
circuit breaker (30mA RCD – residual
current device) of type “B” that is
sensitive to all currents.
WARNING!
Danger of death due to rotating parts!
Improper operation can lead to serious injuries
or equipment damage.
The motor may only be operated via the
associated control box of the machine.
1

FORCED ACTION MIXER PFT MULTIMIX Overview – Operation – Spare Parts Lists
Checking the direction of rotation 400 V
Page 20 23.04.2018
24 Checking the direction of rotation 400 V
1. Check the direction of rotation of the mixing arms.
2. The mixing unit runs anticlockwise.
Fig. 24: Checking the direction of rotation
24.1 Changing the direction of rotation 400 V
Fig. 25: Changing the direction of
rotation
1. Switch on the machine using the main reversing switch (1).
2. If the direction of rotation is incorrect, change the direction of
rotation using the main reversing switch.
NOTE!
If the direction of rotation is incorrect:
The main reversing switch is locked in the zero
position by pushing the selector switch (2) to the
left or right. This defines the direction of rotation.
If the switch is set to the left, the switch can be reset
to zero but is blocked for the right-side position.
25 Water supply connection
1. Connect the water hose to the water inlet.
Fig. 26: Water connection
2
1
