PhatNoise PhatBox User manual

Section I : Installing the PhatBox
Mounting the PhatBox
Connecting the PhatBox to a Car Stereo Head Unit
8. Approximately 5 seconds later, both lights should be off and stay off.
9. Turn on your stereo (usually by turning the key to ACC).
10. Switch to CD changer mode on your stereo by pressing the CD changer button. CD should appear on the display.
11. Wait up to 15 seconds for a welcome message to play.
12. Congratulations! The PhatNoise PhatBox is installed and ready to be used. Turn off the stereo and remove the cartridge.
7. The red and green lights should turn on.
1302-QSG-HADD
When choosing a mounting location remember:
Leave at least 3 inches of clearance for the cable.
The PhatBox should be mounted parallel or
perpendicular to the floor of the car.
Don't mount near wiring or fuel lines.
Leave the front of the PhatBox unobstructed for easy
insertion of and removal of the cartridge.
The unit should be mounted to a hard stable surface,
such as particle board or sheet metal.
Important note: If you do not have experience installing car audio equipment, we recommend you seek the
assistance of a professional car audio installer.
Red (Power)
Green (Activity)
3"
1. Turn off the car.
2. Gain access to the rear portion of your car stereo.
3. Plug the PhatNoise connector cable into the port on the rear
of the car stereo. Depending on your stereo you should have
either a round connector A or a rectangular connector B .
4. Secure the PhatBox to a flat mounting location
parallel or
perpendicular to the floor of the car
with the four included self-
tapping screws.
5. Fully insert the cartridge into the front. 6. Plug the PhatNoise cable into the back of the
PhatBox
Section II : Setting up at home
Installing the PhatNoise PhatBox of the PhatNoise Music Manager Software
The PhatNoise Music Manager software is included on the CD found in your package.
1. Launch the PhatNoise Music Manager software.
2. After the Music Manager splash screen appears, the Load Songs screen will appear.
Choose a location on your computer that contains songs you wish to load into the PhatNoise Music Manager
database. This may be a music folder you already have (i.e. " C:\My Music ").
Launching the PhatNoise Music Manager
Please make sure that the cradle is disconnected before installing the PhatNoise Music Manager.
1. Close all Windows programs that may be running.
2. Insert the PhatNoise Music Manager software CD into your PC's CD-ROM
drive. The PhatNoise Music Manager software installation program will
launch automatically.
3. Follow the instructions to install the PhatNoise Music Manager software.
4. When the installation is finished, the program setup will ask you to reboot
the computer.
5. Once your computer has restarted, plug the power connector into the
USB cradle. Make sure the cradle is plugged into a power supply.
6. Connect the USB cradle to a USB port on your PC.
7. Insert the DMS cartridge firmly into the USB cradle. Avoid 'slapping' the
cartridge into place. The green and red indicator lights should illuminate.
The DMS cartridge will then be detected by the computer's
operating system.
To PhatBox
To PhatBox
A
B
PhatBox Digital Media Player - Honda / Acura Quick-Start Guide

Section III : Creating and Managing Playlists
To search, create and manage your music playlists, click on the Library button.
1. Creating a new playlist
Click the Create Playlist button. Change the
name of the playlist to a name of your choice.
2. Adding songs to a static playlist
1. Click on the All Songs playlist.
2. Type a keyword or phrase in the Search box.
3. Highlight the desired songs.
Transferring MP3s and playlists to the DMS cartridge
1. Make sure the DMS cartridge is inserted into the USB cradle.
The LED lights on the cradle will flicker when the cartridge has
been properly inserted.
2. Click on the Device Manager button to access the Device View.
3. The Devices view is organized in two parts:
·The PhatNoise Music Manager Playlist and Windows explorer panels.
·The All Supported Devices panels.
4. Activate the cartridge by clicking PhatNoise DMS in All Supported Devices
If the DMS cartridge is connected properly, a summary screen appears
with a red Go button. If the DMS cartridge has not been configured properly, a
configuration wizard will launch. For more information, refer to Appendix A:
Updating the Firmware in your PhatBox in the user manual.
5. Click the red Go button.
4. Drag the desired songs into your playlist.
Your PhatNoise Music Manager Software is used to create and manage playlists. If you do not have any digital
music files on your computer please go to "Section III : Creating and Managing Playlists" of the user manual to
learn how to convert audio CDs into MP3s.
PhatBox Digital Media Player - Honda / Acura Quick-Start Guide
There are many ways to search, organize, customize and add to your music collection. To learn how to create
dynamic playlists please refer to "Section III : Creating and Managing Playlists" of the user manual.
Section IV: Operating the PhatNoise Car Audio System
1. Setting the audio mode.
Put the head unit into CD changer mode by pressing the CD button
2. Using the SSA/Voice Interface for stereos with 6 DISC buttons.
A. The PhatBox uses the 6 DISC buttons as "mode" buttons.
- Button 1 activates track browsing
- Buttons 2 through 5 are Browse Modes
- Button 6 lists features
B. Use the TRACK FORWARD or TRACK BACKWARD buttons to find the next Selection in a Mode.
C. Push the Track button (the DISC 1 button) and then use the TRACK FORWARD or
TRACK BACKWARD buttons to advance through the Tracks within your Selection.
D. After 5 seconds of song play the PhatBox will automatically
toggle into track browsing mode. You can then use
the SEEK toggle button to advance through the Tracks within your Selection.
Honda Accord stereo pictured may not be identical to your
stereo and is shown only as an example
Start Digital Media Player
Random
Current ModeCurrent Track/Item
Track Mode Playlist Mode
Artist Mode
Album Mode
Genre Mode Feature Menu
Backward Track
(Press once)
Backward Seek
(Hold)
Forward Track
(Press once)
Forward Seek
(Hold)
