PhDsolutions HDMIDAC1 User manual

HDMI 18Gbps Audio Extractor
with HDCP 2.2
User Manual
HDMIDAC1
VER 1.0_ 23-12-2020 HDMIDAC1 User Manual

Thank you for purchasing this incredible
product
For best performance and safety, please read these
instructions carefully before connecting and operating this
product.
Surge protection device recommended
This product contains sensitive electrical components that
may be damaged by electrical spikes, power surges,
electro static discharge (ESD), lighting strikes or
transients. The use of surge protection systems is highly
recommended in order to protect and extend the life of
your equipment.
Table of Contents
Introduction
Features
Package Contents
Specifications
Operation & Functions
Front Panel
Rear Panel
Application Diagram
Product Warranty
Safety and Performance Notice
Only use the power supply supplied with the unit, or a
PhD Solutions supplied replacement.
Do not disassemble any of the equipment. This will void
the manufacturer’s warranty.
HDMIDAC1 USER MANUAL
www.phdsolutions.co
2
1
2
3
4
5
5.1
5.2
6
7

1. Introduction
The PhD HDMI audio extractor, extracts audio signals
from any HDMI compliant source and outputs digital tos-
link optical and analog stereo L/R audio. It also supports
bitstream audio to analog stereo output and retains opti-
cal and HDMI out audio pass-through. The HDMI input
and output supports video resolutions up to 4K2K@50/
60Hz 4:4:4. It supports HDR 10-bit pass through and
HDMI high resolution audio formats: LPCM 2ch, Dolby
TrueHD, Dolby Digital Plus, Dolby Atmos and DTS Master
Audio. Audio sampling rates up to 192kHz, HDCP 2.2
and CEC bypass are also supported.
2. Features
• HDMI 2.0b (18Gbps), HDCP 2.2 and DVI compliant
• Video resolutions up to 4K2K@50/60Hz (YUV444)
• Extracts HDMI audio to multi-channel optical
(SPDIF) or L/R analog audio
• HDMI Pass-through audio input to HDMI and
optical audio output
• Supports bitstream audio without downmix to L/R
analog output
• Optical audio supports LPCM 2CH, Dobly Digital
2/5.1CH, DTS 2/5.1CH
• Supports HDMI High Bit Rate(HBR) audio pass
through
• Audio sample rates up to 96kHz
• 10bits HDR (High Dynamic Range) pass through
• Supports CEC pass-through
HDMIDAC1 USER MANUAL
www.phdsolutions.co 3

3. Package Contents
• 1× HDMI 18Gbps Audio Extractor
• 1× 5V/1A power supply
• 1× User manual
HDCP Compliance
4. Specifications
HDCP 2.2 and HDCP 1.4
Video Bandwidth 18Gbps
Technical
HDMI Compliance HDMI 2.0b
Video Resolutions
Up to 4K2K@50/60Hz(YUV4:4:4),
4K2K@30Hz,1080P@120Hz,
and 1080P 3D@60Hz
Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 10-bit, 12-bit
HDMI Audio Formats
(Pass-through)
LPCM 2/5.1/7.1CH, Dolby Digital,
DTS 5.1, Dolby Digital+, Dolby
TrueHD, DTS-HD Master Audio,
Dolby Atmos, DTS:X
Optical Audio
Formats
LPCM 2CH, LPCM 5.1, Dolby
Digital 2/5.1CH, DTS 2/5.1CH
L/R Audio Formats Analog Stereo 2CH
ESD Protection
Human body model — ±8kV
(air-gap discharge) & ±4kV
(contact discharge)
HDMIDAC1 USER MANUAL
www.phdsolutions.co
4

Connections
Inputs 1x HDMI Type A [19-pin female]
Outputs
1x HDMI Type A [19-pin female]
1x L/R Audio Out [3.5mm Stereo
mini-jack]
1x Optical TOSLINK Out [S/PDIF]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 73.5mm[W] x 60.7mm[D] x
17mm[H]
Weight 130g
Power Supply
Input: AC100 - 240V 50/60Hz
Output: DC 5V/1A (US/EU
standards, CE/FCC/UL certified)
Power Consumption 1.0W (Max)
Operation
Temperature 32 - 104°F / 0 - 40°C
Storage temperature -4 - 140°F / -20 - 60°C
Relative Humidity 20 - 90% RH (no condensation)
HDMIDAC1 USER MANUAL
www.phdsolutions.co 5
NOTE: Specifications are subject to change without
notice.

DC 5V
5. Operation Controls and Functions
5.1 Front Panel
No. Function DescriptionName
1 DC 5V Connect 5V/1A adaptar to AC wall
outlet to supply power to the unit.
2 Power LED System power indicator LED
3TV/Bitstream
/2CH
Audio selection switch for Bitstream/2ch
audio or Copy TV to copy the EDID from
the display.
4 HDMI In HDMI input port.
Link LED5 The LED will illuminate when an
HDMI input signal is detected.
www.phdsolutions.co
6
HDMIDAC1 USER MANUAL
Power TV 2CH
Bitstream
HDMI In Link

5.2 Rear Panel
HDMI OUT OPTICAL OUT
No. Function DescriptionName
1HDMI 2.0
OUT
HDMI output port. Connect to the
display with an 18Gbps HDMI cable.
2
OPTICAL
OUT
Toslink digital optical audio output
(Mirrors HDMI).
3
L/R OUT Stereo 3.5 mm mini jack Analog
audio output.
HDMIDAC1 USER MANUAL
L/R Out
www.phdsolutions.co 7

6. Application Diagram
HDMIDAC1 USER MANUAL
www.phdsolutions.co
8

HDMIDAC1 USER MANUAL
7. PhD Solutions Product Warranty
