Philco PD 1045 EA User manual

DISHWASHER

OWNER’S MANUAL

PD 1045 EA

PD 1045 EAX

Dear customer,

Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all

the instructions in this user’s manual.

EN - 1

CONTENTS

PART 1: SAFETY PRECAUTIONS......................................................................................................................2

PART 2: DISHWASHER FEATURES...................................................................................................................5

PART 3: INSTALLING THE MACHINE...............................................................................................................6

PART 4: BEFORE USING THE APPLIANCE.....................................................................................................11

PART 5: LOADING YOUR DISHWASHER .......................................................................................................15

PART 6: PROGRAMME TABLE........................................................................................................................18

PART 7: CLEANING AND MAINTENANCE.....................................................................................................22

PART 8: AUTOMATIC FAULT WARNINGS AND WHAT TO DO ......................................................................23

PART 9: TROUBLESHOOTING........................................................................................................................24

PART 10: PRACTICAL AND USEFUL INFORMATION....................................................................................26

PART 11: TECHNICAL SPECIFICATIONS .......................................................................................................27

PART 12: PRODUCT INFORMATION SHEET .................................................................................................28

EN - 2

PART 1: SAFETY PRECAUTIONS

WARNING! Please adhere to the precautions below when using

the dishwasher:

This appliance can be used by children aged from 8 years and

above and by persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have been

given supervision or instructions concerning use of the appliance

in a safe way and if they understand the hazards involved.

Children must not play with the appliance.

Cleaning and user maintenance cannot be performed by children

without supervision.

If the supply cable gets damaged, have it replaced by a specialized

service center in order to avoid dangerous situations. It is

prohibited to use an appliance with the supply cable damaged.

Do not leave the door in the open position to prevent the risk of

tripping.

When storing dishes into the dishwasher:

- WARNING: Knives and other utensils with sharp points

and edges must be placed in the basket with points facing

downwards or stored horizontally.

- Sharp items should be placed so that they cannot damage the

door gasket.

EN - 3

- Knives and other similar sharp items should always be placed

with their handles pointing upwards so that the sharp edge

would not hurt anybody.

- Do not use the dishwasher to wash plastic items that have

not been labeled as dishwasher safe by the manufacturer. The

presence of plastic dishes in the dishwasher causes worsening

of drying process results. Please adhere to the manufacturer’s

recommendations regarding plastic items that have not been

labeled as dishwasher safe.

This appliance is intended to be used in households and similar

premises, such as

– kitchenettes in shops, oces and other workplaces;

– agricultural facilities;

– hotels, motels, and other accommodation facilities where

appliances are used by guests;

– bed and breakfast facilities.

• Donotsitorstandonthedooranddishbasketsofthe

dishwasher and to not use force during operation.

• Donotplaceanyheavyitemsontheapplianceanddotostand

on the door when it is open. The appliance might tip over

towards the front.

Use only detergents and polishing agents intended to be used with

automatic dishwashers. Never use soap, detergents or washing

agents for manual dish washing.

Make sure to prevent children from accessing detergents and

polishing agents and also open door of the dishwasher that might

contain residues of the agents as they are strongly alcaline and

might be very dangerous.

EN - 4

The appliance, the power cord or the electric outlet must not lie

in, tough or be submerged in water or any other liquid to avoid

electrical hazards.

If the power cord gets damaged, it must be replaced by the

manufacturer, its service technician or another person with similar

qualication so that safety is not jeopardized.

The appliance must not stand on the power cord.

The appliance should be connected to the water supply using a

new hose, not using a hose that has already been used.

Dispose of packaging in a proper manner.

The power cord must not be excessively or dangerously bent or

compressed during installation.

The controls are not to be played with.

Make sure that the openings in the bottom part of the appliance

are not blocked by the carpet.

The dishwasher should be used only for the purpose it was

intended for - for washing dishes.

This dishwasher is for interior use only.

PLEASE READ THOSE SAFETY PRECAUTIONS CAREFULLY AND

STORE THEM FOR FUTURE REFERENCE

EN - 5

PART 2: DISHWASHER FEATURES

1. Worktop

2. Upper basket with racks

3. Upper spray arm

4. Lower basket

5. Lower spray arm

6. Filters

7. Rating plate

8. Control Panel

9. Detergent and rinse-aid dispenser

10. Cutlery basket

11. Salt dispenser

12. Upper basket track latch

1

Active Drying Unit: This system provides better drying performance for your dishes.

EN - 6

PART 3: INSTALLING THE MACHINE

Positioning the machine

When determining the place to put your machine on, take care to choose a place where you can easily load

and unload your dishes.

Do not put your machine in any location where there is the probability for the room temperature to fall below

0°C.

Before positioning, take the machine out of its packaging by following the warnings located on the package.

Position the machine close to a water tap or drain. You need to site your machine, taking into consideration

that its connections will not be altered once they are made.

Do not grip the machine by its door or panel in order to move it.

Take care to leave a certain clearance from all sides of the machine so that you can comfortably move it back

and forth during cleaning.

Make sure that the water inlet and outlet hoses do not get squeezed while positioning the machine. Also, make

sure that the machine does not stand on the electrical cable.

Adjust the machine’s adjustable feet so that it can stand level and balanced. Proper positioning of the machine

ensures problem-free opening and closing of its door.

If the door of you machine does not close properly, check if the machine is stable on the oor it stands; if not,

adjust the adjustable feet and ensure its stable position.

CAUTION!

When you set a temperature, you set an average temperature for the whole refrigerator cabinet.

Temperatures inside each compartment may vary from the temperatures displayed on the panel,

depending on how much food you store and where you place it. High or low room temperature may

also aect the actual temperature inside the appliance.

EN - 7

Water inlet hose

Do not use the water inlet hose of your old machine,if any. Use the new water

inlet hose supplied with your machine instead. If you are going to connect a

new or long - unused water inlet hose to your machine ,run water through it

for a while before making the connection. Connect the water inlet hose

directly to the water inlet tap. The pressure supplied by the tap should be at a

minimum of 0.03 Mpa and and at a maximum of 1 Mpa.If the water pressure is

above 1 Mpa,a pressure-relief valve should be tted inbetween.

After the connections are made, the tap should be turned on fully and checked for water tightness. For the

safety of your machine, make sure to always turn o the water inlet tap after each wash programme is nished.

NOTE: Aquastop water spout is used in some models. In case of using

Aquastop, a dangerous tension exists.

Do not cut Aquastop water spout. Do not let it get folded or twisted.

Note printing on the water inlet hose!

If models are marked with 25°, the water temperature may be max. 25 °C (cold water).

Forall other models:

Cold water preferred; hot water max. temperature 60 °C.

EN - 8

Water outlet hose

The water drain hose can be connected either directly to the water

drain hole or to the sink outlet spigot. Using a special bent pipe (if

available), the water can be drained directly into the sink via hooking

the bent pipe over the edge of the sink. This connection should be at

a minimum of 50 cm and at a maximum of 110 cm from the oor

plane.

WARNING!

When a drain hose longer than 4 m is used, the dishes might remain dirty. In that case, our company

will not accept responsibility.
