Philco PW 17 GDFB User manual

Wine cooler
OWNER’S MANUAL
PW 17 GDFB
PW 32 GD
PW 38 GDFB
PW 46 GDFB
PW 166 GD

Thank you very much for buying this product.
Before using your new refrigerator, please read this operation manual to ensure that you gain the
maximum benet from it.
Copyright © 2020, Fast ČR, a. s. Revision 01/2022

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 1
CONTENTS
SAFETY PRECAUTIONS....................................................................................................................................3
DESCRIPTION OF APPLIANCE AND INSTALLATION.....................................................................................7
ACCESSORY INSTALLATION BEFORE OPERATING......................................................................................12
OPERATING THE WINE COOLER....................................................................................................................13
CARE AND MAINTENANCE............................................................................................................................20
TROUBLESHOOTING......................................................................................................................................23
REVERSE THE DOOR SWING .........................................................................................................................24
PRODUCT INFORMATION SHEET .................................................................................................................30
This appliance has been tested in accordance with the directives in force in the European Union.
This appliance conforms to the relevant safety provisions for electrical appliances in force in the
European Union.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 2
DEAR CUSTOMER:
Thank you for buying this refrigerator. To ensure that you get the best results from your new refrigerator,
please take time to read through the simple instructions in this booklet.
Please ensure that the packing material is disposed of in accordance with the current environmental
requirements.
When disposing of any refrigerator equipment please contact your local waste disposal department for
advice on safe disposal.
This appliance must be only used for its intended purpose.
CAUTION:
The appliance is not intended for use by young children or inrm
persons without supervision.
Young children should be supervised to ensure that they do not play
with the appliance.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 3
SAFETY PRECAUTIONS
THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8
YEARS AND ABOVE AND BY PERSONS WITH REDUCED PHYSICAL,
SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE
AND KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR
INSTRUCTIONS CONCERNING USE OF THE APPLIANCE IN A SAFE
WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED.
CHILDREN MUST NOT PLAY WITH THE APPLIANCE. CLEANING
AND MAINTENANCE CANNOT BE PERFORMED BY CHILDREN
WITHOUT SUPERVISION. CHILDREN AGED FROM 3 TO 8 YEARS
OF AGE CAN INSERT AND REMOVE FOOD FROM REFRIGERATION
APPLIANCES.
IF THE SUPPLY CABLE GETS DAMAGED, HAVE IT REPLACED BY A
SPECIALIZED SERVICE CENTRE IN ORDER TO AVOID DANGEROUS
SITUATIONS. IT IS PROHIBITED TO USE AN APPLIANCE WITH THE
SUPPLY CABLE DAMAGED.
ICE MAKERS THAT ARE NOT INTENDED FOR CONNECTION
TO THE WATER SUPPLY SHOULD ONLY BE FILLED WITH
DRINKING WATER.
VENTILATION OPENINGS IN THE HOUSING OF THE
APPLIANCE OR IN ITS CONSTRUCTION MUST BE KEPT
WITHOUT OBSTACLES.
DO NOT USE ANY MECHANICAL DEVICES OR MEANS OTHER
THAN RECOMMENDED BY THE MANUFACTURER TO SPEED
UP THE DEFROSTING PROCESS.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 4
DO NOT DAMAGE THE COOLING CIRCUIT.
DO NOT USE ELECTRIC APPLIANCES IN THE FOOD
STORAGE COMPARTMENT, UNLESS IT IS A TYPE
RECOMMENDED BY THE MANUFACTURER.
DO NOTSTORE EXPLOSIVE SUBSTANCES IN THIS APPLIANCE,
SUCH AS AEROSOL CANS WITH A FLAMMABLE PROPELLANT GAS.
THIS APPLIANCE IS INTENDED TO BE USED ONLY IN
HOUSEHOLDS AND NOT IN SIMILAR PREMISES, SUCH AS:
●KITCHENETTES IN SHOPS, OFFICES AND OTHER WORKPLACES;
●APPLIANCES USED BY GUESTS IN HOTELS, MOTELS, AND
OTHER ACCOMMODATION FACILITIES;
●APPLIANCES USED IN BED AND BREAKFAST FACILITIES;
●APPLIANCES USED IN CATERING AND OTHER SIMILAR NON
VENDING ENVIRONMENTS.
ICE MAKERS THAT ARE INTENDED FOR CONNECTION TO
THE WATER SUPPLY SHOULD ONLY BE CONNECTED TO
DRINKING WATER SUPPLY.
THE APPLIANCE MUST BE FASTENED IN ACCORDANCE
WITH THE MANUAL TO PREVENT DANGER CAUSED BY ITS
INSTABILITY.
THE ISO 70001701 MARK 200401 INDICATES
MEDIUM UNDER PRESSURE.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 5

FIRE HAZARD / FLAMMABLE MATERIALS!
THE COOLING SYSTEM CONTAINS REFRIGERANT UNDER
HIGH PRESSURE. DO NOT MANIPULATE WITH THE SYSTEM.
THE SYSTEM MAY BE REPAIRED BY AUTHORISED PERSONS
ONLY.
R600A
CONTAINS COOLING GAS ISOBUTANE WHICH IS FLAMMABLE.
AVOID DAMAGING REFRIGERATION CIRCUIT COMPONENTS
DURING TRANSPORT AND INSTALLATION OF THE APPLIANCE.
WHEN PLACING THE APPLIANCE IT MUST BE ENSURED
THAT THE SUPPLY CORD DOES NOT GET CAUGHT OR
DAMAGED.
DO NOT PLACE PORTABLE MULTIPLE SOCKETOUTLETS OR
PORTABLE EXTENSION CABLES TO THE REAR SIDE OF THE
APPLIANCE.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 6
OTHER RECOMMENDATIONS / INSTALLATION
SAFETY OF THE ELECTRICAL SYSTEM:
●THE POWER CORD MUST NOT BE EXTENDED.
●PLEASE ENSURE THAT THE PLUG OF THE POWER CORD IS NOT
DAMAGED, OTHERWISE IT COULD OVERHEAT AND CAUSE A
FIRE.
●WHEN PLACING THE APPLIANCE IT MUST BE ENSURED THAT
THE CABLE CORD DOES NOT GET CAUGHT OR DAMAGED.
●DO NOT PLACE PORTABLE MULTIPLE SOCKETOUTLETS OR
PORTABLE EXTENSION CABLE TO THE REAR SIDE OF THE
APPLIANCE.
●THE APPLIANCE MUST NOT STAND ON THE POWER CORD.
●THE APPLIANCE MUST NOT BE PLACED IN A HUMID
ENVIRONMENT; THE POWER CORD MUST NOT LIE IN WATER.
●MAKE SURE THAT YOU HAVE FREE ACCESS TO THE PLUG OF
THE APPLIANCE.
●DO NOT PULL ON THE POWER CORD.
●IF AN ELECTRICAL OUTLET IS LOOSENED, DO NOT CONNECT
THE PLUG TO IT. THERE IS A RISK OF ELECTRIC SHOCK OR FIRE.
●THIS APPLIANCE MUST NOT BE USED WITHOUT THE INTERIOR
LIGHT COVER.
●THE REFRIGERATOR IS DESIGNED TO BE USED ONLY WITH
ONEPHASE ALTERNATING CURRENT POWER SUPPLY WITH
VALUES OF 220  240 V / 50 HZ. IF THE VOLTAGE FLUCTUATION
IN THE PLACE OF RESIDENCE OF THE USER IS SO GREAT THAT
IT EXCEEDS THE GIVEN LIMITS, USE AN AUTOMATIC VOLTAGE
REGULATOR WITH THE REFRIGERATOR OF MORE THAN 350 W
FOR SAFETY REASONS.
●THE PLUG MUST BE USED WITH A SOCKET WITH AN EARTH
CONTACT.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 7
DESCRIPTION OF APPLIANCE AND INSTALLATION
The following pictures only show description of appliance. The dimension and shelf quantity may dier
among the models of the same series.
PW 17 GDFB CONTROL IN CABINET
Dual Zone 17 Bottles
Control Panel
Long Shelf
Short Shelf
Front Louver
Door
Gasket
Adjustable Foot
Outside
Cabinet
• Height Adjustable:
813-845 mm

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 8
PW 32 GD CONTROL IN CABINET
Dual Zone 32 Bottles
Control Panel
Long Shelf
Short Shelf
Front Louver
Door
Gasket
Adjustable Foot
Outside
Cabinet
860
860
840
100
570
570
380
570
520
• Height Adjustable:
853-873 mm

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 9
PW 38 GDFB CONTROL IN CABINET
Dual Zone 38 Bottles
Door
Handle
Gasket
Adjustable Foot
Outside
Cabinet
Control Panel (Right)
Control Panel (Left)
Long Shelf
Short Shelf
Front Louver
863
595
863
850
150
570
600
570
520
• Height Adjustable:
813-845 mm

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 10
PW 46 GDFB CONTROL IN CABINET HEIGHT: 86.3CM
Dual Zone 46 Bottles
Long Shelf
Control Panel
Short Shelf
Front Louver
Outside
Cabinet
Door
Gasket
Adjustable Foot
870
595
850
150
570
600
520
570
870
• Height Adjustable:
813-845 mm

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 11
PW 166 GD CONTROL IN CABINET
Dual Zone 166 Bottles
Door
Gasket
Adjustable Foot
Outside
Cabinet
Control Panel
Long Shelf
Short Shelf
Front Louver
ı1770mm
(69 ¾”)
ı
635mm
(25”)
1770mm
(69 ¾”)
595mm
(23 ½”)
ı730mm
(28 ¾”)
680mm
(26 ¾”)
595
1770
635
680
1770
730

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 12
ACCESSORY INSTALLATION BEFORE OPERATING
UNPACKING AND CLEANING THE WINE COOLER
• Remove the exterior and interior packing materials.
• Let the appliance stand upright for approximately 24 hours before connecting it to the power
source, which helps to reduce the possibility of a cooling-system malfunction from handling during
transportation.
• Use a soft cloth to clean the interior surface with lukewarm water.
IMPORTANT: The front louver at the base of the appliance is for ventilation. Nothing should be placed
in front of this front louver; otherwise your Wine Cooler may not operate properly.
o A decorative plinth can be tted to the front of the base vent, a cut-out should be made in the plinth with
bigger size than the front louver. The cut out is required whether the front louver is removed or not.
ADJUSTING THE HEIGHT AND LEVELLING OFF YOUR WINE CABINET
o The appliance is equipped with adjustable feet, so that the height may be adjusted to level the cabinet on
uneven oor surfaces.
o We recommend that two people carry out this procedure.
o The height must be adjusted prior to building the appliance into the housing unit and it should be set at
such a height that the top panel of the appliance ts exactly below the kitchen worktop.
o Tilt the appliance approximately 60° to allow access to the adjustable feet.
o Take care to ensure the cabinet is supported at all times.
o Twist the foot into a suitable position to level the cabinet.
o Repeat these steps for the other adjustable feet.
IMPORTANT: If the appliance is not level, then the door and door seal may be aected.
IMPORTANT: Do not move the appliance when the feet are adjusted high.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 13
LOCK & UNLOCK THE DOOR FOR OPTION
• Lock is an optional function. If your Wine Cooler has such function, a key should be attached inside the
packing of this Manual.
• Insert the key into the lock and turn it counter-clockwise to unlock the door. To lock it, please turn
clockwise. Please save the key well.
OPERATING THE WINE COOLER
WORKING CLIMATE
• The appliance is designed for operating from SN to N climate (see below climate class chart). It is
recommended to maintain the ambient around 22-25°C which helps the appliance working with low
power consumption.
Klimaclasse Romtemperatur
SN 10 - 32 °C (50 °F - 90 °F)
N16 - 32 °C (61 °F - 90 °F)
ST 16 - 38 °C (64.4 °F - 100 °F)
T16 - 43 °C (64.4 °F - 109 °F)
• If the ambient temperature is above or below the designed climate range, the performance of the unit
may be aected. For example, the appliance operating in extreme cold or hot conditions may cause
interior temperatures to uctuate, and the temperature set 5-22°C may not be reached sometimes.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 14
THERE ARE FIVE SHELVES AND ONE DISPLAY SHELF IN TOTAL
• The standard shelves are designed perfectly for Bordeaux bottle storage. The maximum loaded bottles
may vary subject to the dierent size or dimension wine bottles you store.
• The shelves is allowed to be pulled out by about 1/3 length of it for easy access to the wine storage.
Stopper
Stopper
• To prevent damaging the door gasket, make sure to have the door opened fully all the way before pulling
the shelves out.
• Please store wine in sealed bottles.
• Do not cover the shelves with aluminum foil or any other shelf material which may prevent air circulation.
• Should the wine cooler be left empty for long periods it is suggested that the appliance is unplugged,
and after careful cleaning, leave the door ajar to allow air to circulate inside the cabinet in order to avoid
possible condensation, mold or odours forming.
• Recommended temperatures for chilling/storing your wines.
Wine Type Recommender Temp.
Red Wines 15 - 18ºC (59ºF-64ºF)
Dry/White Wines 9 - 14ºC (48ºF-57ºF)
Rose Wines 10 - 11ºC (50ºF-52ºF)
Sparkling Wines 5 - 8ºC (41ºF-46ºF)

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 15
CONTROL PANEL CONTROL IN CABINET
AB DCE
F
*+,- .
A. Power B. Lighting C. Upper Zone
Display Window
D. Temp. Plus E. Temp. Minus
F. Lock /
Unlock
G. ºC/ºF Switch H. Function
Indicator 1
I. Lower Zone
Display Window
J. Function
Indicator 2
K. Zone Select
POWER ON/OFF CONTROL
• When the appliance is plugged in to a power outlet, it powers on automatically.
• Touch the power mark and hold for 10 seconds to turn o (or turn on) the appliance.
• No matter it is under a locked or unlocked condition, you can turn o the appliance by touching the
power mark and holding for 10 seconds.
Warning: To avoid damaging the compressor, please do not turn on the appliance again
within 5 minutes after you turn it o.
UNLOCKING THE CONTROL PANEL
• To unlock the control panel, touch the power mark and lighting mark with 2 ngers at the same
time and hold for 3 seconds. When unlocked a buzz sound will be heard.
• The control panel will be automatically locked with a buzz sound heard after 10 seconds without being
touched.
• Under the locked condition, the control panel will not react to any touching order for Lighting On/O and
Temperature Setting.
INTERIOR LIGHTING ON/OFF CONTROL
• Under the unlocked condition, touch the lighting mark to turn on (or turn o) the interior cool LED
lighting.
• The lighting will stay on unstil it is manually turned o.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 16
TEMPERATURE DISPLAY WINDOW
• The temperature is displayed in digital which is the best way to be read out. The digital is shown as the set
temperature when you are setting the temperature.
• When the temperature probe is out of order, the display window will show with “HH” or “LL” instead
of a digital gure while continuous buzz sound will be heard. In case of this happens, this appliance
is considerately designed to keep periodical running of compressor and fans which helps to keep the
coldness of the inside cabinet to protect your stored wines.
Warning: To avoid destroying your stored wines, it is strongly recommended to have the
appliance repaired immediately, as the spare periodical running can not ensure the appliance
to achieve the temperature you have set.
TEMPERATURE RANGE SETTING
• The default temperature setting ranges are E: 5-12 ºC (41-54 ºF) for the upper zone and 12-22 ºC (54-72 ºF)
for the bottom zone.
• To set a temperature range as desired, pls. make sure the control panel is under locked condition.
• Press the mark for 3 seconds, the display windows will ash“E”--”F”--”H”--”L”in loop with a sound of
beep by every pressing.
• Leave the display windows ashing for 3 seconds with a sound of beep to conrm the setting.
Display Temp. Range (Dual Zone)
Upper Zone Lower Zone
E (Default) 5 - 12 °C (41ºF-54ºF) 12 - 22 °C (54ºF-72ºF)
F2 - 12 °C (36ºF-54ºF) 12 - 20 °C (54ºF-68ºF)
H5 - 12°C (41ºF-54ºF) 8 - 19 °C (46ºF-66ºF)
L2 - 10 °C (36ºF-50ºF) 2 - 10 °C (36ºF-50ºF)
TEMPERATURE SETTING
• The default temperature setting ranges are E: 5-12 ºC (41-54 ºF) for the upper zone and 12-22 ºC (54-72 ºF)
for the bottom zone.
• You need to select the set zone by touching the mark before touching the mark or to set the
desired temperature. The zone temperature will ash when it is ready to be set.
• The rst touch on mark or will recall the previous set temperature displayed in the digital window.
• Touch the mark to increase the set temperature by 1ºC (or by 1ºF). On the contrary, touch the mark
to decrease the set temperature by 1ºC (or by 1ºF).
SELECTING FAHRENHEITºF & CELSIUS ºC DISPLAY
Directly touch the mark , you can interchange the Fahrenheit and Celsius display for both zones at the
same time.
* For models of PW 38 GDFB, the Celsius and Fahrenheit of Left and Right Zone will be changed at the same time
no matter the operation above on Left or Right Zone.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 17
CONTROL PANEL PW 46 GDFB CONTROL ON DOOR
Power
Light Unlock On/O Temp.
Down
Set
°C/°F
Upper Zone Lower Zone
Display Window Temp. Up Temp.Range Set
POWER ON/OFF CONTROL
POWER
POWER
• Press to turn on the control panel back light buttons if they are o.
• To turn o your wine cellar for cleaning or extended absence, press the power button
once. After the unit beeps once, hold the power button for 10 seconds and your wine
cellar will shut itself o. Once the wine cellar has been turned o, please allow at least 5
minutes before starting up again. This will limit excessive wear on the compressor.
Warning!
Warning
To avoid damaging the compressor, please do not turn on the appliance again within 5
minutes after you turn it o.
POWER ON/OFF CONTROL
Unlock
Unlock
• Press for 3 seconds to unlock the control panel.

Copyright © 2020, Fast ČR, a. s. Revision 01/2022
EN - 18
SELECTING FAHRENHEITºF & CELSIUS ºC DISPLAY
°C/°F
• Press to alter the temperature display in Fahrenheit or Celsius.
TEMPERATURE SETTING
Set
SET
• Press to select Upper/Lower zone for setting temperature. The digital display ashes to
inform the accessibility to adjust setting.
TEMPERATURE SETTING
Temp.Up
Temp. Up
• Press to increase setting temperature by 1°.
Temp.
Down
Temp.
Down
• Press to decrease setting temperature by 1°.
