Philco Pw 12 kf User manual

Wine Cooler

OWNER’S MANUAL

PW 12 KF

PW 20 KF

PW 24 KF

Dear customer,

Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all

the instructions in this user’s manual.

EN - 1

CONTENTS

PART 1: SAFETY PRECAUTIONS......................................................................................................................3

PART 2: INSTALLATION INSTRUCTIONS ........................................................................................................7

PART 3: DESCRIPTION OF THE APPLIANCE...................................................................................................8

MODEL PW 12 KF................................................................................................................................................................................ 8

MODEL PW 20 KF................................................................................................................................................................................ 8

MODEL PW 24 KF................................................................................................................................................................................ 9

PART 4: OPERATING YOUR UNIT...................................................................................................................10

Setting the Temperature Control................................................................................................................................................10

Key Function ......................................................................................................................................................................................10

Automatic locking function .........................................................................................................................................................10

Auto light o function....................................................................................................................................................................10

Adjustable range..............................................................................................................................................................................10

Display range.....................................................................................................................................................................................10

Display stability.................................................................................................................................................................................10

Error code............................................................................................................................................................................................11

Forced defrosting function...........................................................................................................................................................11

Memory function .............................................................................................................................................................................11

Climate class.......................................................................................................................................................................................11

Tips (PW 12 KF)..................................................................................................................................................................................12

Tips (PW 20 KF)..................................................................................................................................................................................13

Tips (PW 24 KF)..................................................................................................................................................................................14

PART 5: TROUBLESHOOTING........................................................................................................................15

PART 6: DISPOSAL OF THE APPLIANCE .......................................................................................................16

Storage instructions........................................................................................................................................................................16

PART 7: PRODUCT INFORMATION SHEET ...................................................................................................17

TECHNICAL INFORMATION ...........................................................................................................................................................23

TESTING INFORMATION .................................................................................................................................................................23

CUSTOMER CARE AND SERVICE..................................................................................................................................................23

INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS...............24

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES.................................................................................24

This appliance has been tested in accordance with the directives in force in the European Union.

This appliance conforms to the relevant safety provisions for electrical appliances in force in the

European Union.

EN - 2

Dear customer:

Thank you for buying this refrigerator. To ensure that you get the best results from your new refrigerator,

please take time to read through the simple instructions in this booklet.

Please ensure that the packing material is disposed of in accordance with the current environmental

requirements.

When disposing of any refrigerator equipment please contact your local waste disposal department for

advice on safe disposal.

This appliance must be only used for its intended purpose.

CAUTION:

The appliance is not intended for use by young children or inrm

persons without supervision.

Young children should be supervised to ensure that they do not play

with the appliance.

EN - 3

PART 1: SAFETY PRECAUTIONS

THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8

YEARS AND ABOVE AND BY PERSONS WITH REDUCED PHYSICAL,

SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE

AND KNOWLEDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR

INSTRUCTIONS CONCERNING USE OF THE APPLIANCE IN A SAFE

WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED.

CHILDREN MUST NOT PLAY WITH THE APPLIANCE. CLEANING

AND MAINTENANCE CANNOT BE PERFORMED BY CHILDREN

WITHOUT SUPERVISION. CHILDREN AGED FROM 3 TO 8 YEARS

OF AGE CAN INSERT AND REMOVE FOOD FROM REFRIGERATION

APPLIANCES.

IF THE SUPPLY CABLE GETS DAMAGED, HAVE IT REPLACED BY A

SPECIALIZED SERVICE CENTRE IN ORDER TO AVOID DANGEROUS

SITUATIONS. IT IS PROHIBITED TO USE AN APPLIANCE WITH THE

SUPPLY CABLE DAMAGED.

ICE MAKERS THAT ARE NOT INTENDED FOR CONNECTION

TO THE WATER SUPPLY SHOULD ONLY BE FILLED WITH

DRINKING WATER.

VENTILATION OPENINGS IN THE HOUSING OF THE

APPLIANCE OR IN ITS CONSTRUCTION MUST BE KEPT

WITHOUT OBSTACLES.

DO NOT USE ANY MECHANICAL DEVICES OR MEANS OTHER

THAN RECOMMENDED BY THE MANUFACTURER TO SPEED

UP THE DEFROSTING PROCESS.

EN - 4

DO NOT DAMAGE THE COOLING CIRCUIT.

DO NOT USE ELECTRIC APPLIANCES IN THE FOOD

STORAGE COMPARTMENT, UNLESS IT IS A TYPE

RECOMMENDED BY THE MANUFACTURER.

DO NOT STORE EXPLOSIVE SUBSTANCES IN THIS APPLIANCE,

SUCH AS AEROSOL CANS WITH A FLAMMABLE PROPELLANT GAS.

THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLDS AND

SIMILAR PREMISES, SUCH AS

●KITCHENETTES IN SHOPS, OFFICES AND OTHER WORKPLACES;

●APPLIANCES USED BY GUESTS IN HOTELS, MOTELS, AND

OTHER ACCOMMODATION FACILITIES;

●APPLIANCES USED IN BED AND BREAKFAST FACILITIES;

●APPLIANCES USED IN CATERING AND OTHER SIMILAR NON

VENDING ENVIRONMENTS.

ICE MAKERS THAT ARE INTENDED FOR CONNECTION TO

THE WATER SUPPLY SHOULD ONLY BE CONNECTED TO

DRINKING WATER SUPPLY.

THE APPLIANCE MUST BE FASTENED IN ACCORDANCE

WITH THE MANUAL TO PREVENT DANGER CAUSED BY ITS

INSTABILITY.

THE ISO 70001701 MARK 200401 INDICATES

MEDIUM UNDER PRESSURE.

EN - 5



FIRE HAZARD / FLAMMABLE MATERIALS!

THE COOLING SYSTEM CONTAINS REFRIGERANT UNDER

HIGH PRESSURE. DO NOT MANIPULATE WITH THE SYSTEM.

THE SYSTEM MAY BE REPAIRED BY AUTHORISED PERSONS

ONLY.

R600A

CONTAINS COOLING GAS ISOBUTANE WHICH IS FLAMMABLE.

AVOID DAMAGING REFRIGERATION CIRCUIT COMPONENTS

DURING TRANSPORT AND INSTALLATION OF THE APPLIANCE.

WHEN PLACING THE APPLIANCE IT MUST BE ENSURED

THAT THE SUPPLY CORD DOES NOT GET CAUGHT OR

DAMAGED.

DO NOT PLACE PORTABLE MULTIPLE SOCKETOUTLETS OR

PORTABLE EXTENSION CABLES TO THE REAR SIDE OF THE

APPLIANCE.

EN - 6

OTHER RECOMMENDATIONS / INSTALLATION

SAFETY OF THE ELECTRICAL SYSTEM:

●THE POWER CORD MUST NOT BE EXTENDED.

●PLEASE ENSURE THAT THE PLUG OF THE POWER CORD IS NOT

DAMAGED, OTHERWISE IT COULD OVERHEAT AND CAUSE A

FIRE.

●WHEN PLACING THE APPLIANCE IT MUST BE ENSURED THAT

THE CABLE CORD DOES NOT GET CAUGHT OR DAMAGED.

●DO NOT PLACE PORTABLE MULTIPLE SOCKETOUTLETS OR

PORTABLE EXTENSION CABLE TO THE REAR SIDE OF THE

APPLIANCE.

●THE APPLIANCE MUST NOT STAND ON THE POWER CORD.

●THE APPLIANCE MUST NOT BE PLACED IN A HUMID

ENVIRONMENT; THE POWER CORD MUST NOT LIE IN WATER.

●MAKE SURE THAT YOU HAVE FREE ACCESS TO THE PLUG OF

THE APPLIANCE.

●DO NOT PULL ON THE POWER CORD.

●IF AN ELECTRICAL OUTLET IS LOOSENED, DO NOT CONNECT

THE PLUG TO IT. THERE IS A RISK OF ELECTRIC SHOCK OR FIRE.

●THIS APPLIANCE MUST NOT BE USED WITHOUT THE INTERIOR

LIGHT COVER.

●THE REFRIGERATOR IS DESIGNED TO BE USED ONLY WITH

ONEPHASE ALTERNATING CURRENT POWER SUPPLY WITH

VALUES OF 220  240 V / 50 HZ. IF THE VOLTAGE FLUCTUATION

IN THE PLACE OF RESIDENCE OF THE USER IS SO GREAT THAT

IT EXCEEDS THE GIVEN LIMITS, USE AN AUTOMATIC VOLTAGE

REGULATOR WITH THE REFRIGERATOR OF MORE THAN 350 W

FOR SAFETY REASONS.

●THE PLUG MUST BE USED WITH A SOCKET WITH AN EARTH

CONTACT.

EN - 7

PART 2: INSTALLATION INSTRUCTIONS

• Thisapplianceisdesignedtobefreestandingonly,andshouldnotberecessedorbuilt-in.

• Placeyourunitonaoorthatisstrongenoughtosupporttheunitwhenitisfullyloaded.Tolevelyour

unit, adjust the leveling legs at the bottom of the unit.

• ThisapplianceisNOTdesignedtobeinstalledinsideofacabinetwherethefrontiscoveredbyanytypeof

door.

• Allow10cmofspacebetweenthetop,backandsidesoftheunit,whichallowstheproperaircirculationto

cool the compressor and condenser.

• Locatetheunitawayfromdirectsunlightandsourcesofheat(stove,heater,radiator,etc.).Directsunlight

may aect the acrylic coating and heat sources may increase electrical consumption. Extreme cold

ambient temperatures may also cause the unit not to perform properly.

• Avoidlocatingtheunitinmoistareas.

• Plugtheunitintoanexclusive,properlyinstalled-groundedwalloutlet.Donotunderanycircumstances

cut or remove the third (ground) prong from the power cord. Any questions concerning power and/

or grounding should be directed toward a certied electrician or an authorized Avanti Products service

center.

• Afterpluggingtheapplianceintoawalloutlet,allowtheunittocooldownfor2-3hoursbeforeplacing

food in the APPLIANCE compartment.

Remark:

Please remember to keep some water in the cabinet to keep the humidity.

For disposal of the appliance:

To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it

responsibly to promote the sustainable reuse of material resources. And the disposal should only be done

through public collection points.

For installation, servicing:

Applianceshouldplacedonahorizontaloorandkeeptheventilationfreely,don‘ttrytoreplaceorrepair

any components by yourself, ask the service agency for help if necessary.

For handling:

Always handle the appliance to avoid any damage.

EN - 8

PART 3: DESCRIPTION OF THE APPLIANCE

MODEL PW 12 KF



1 Upper Hinge

2 Door Gasket

3 Shelves

4 Door Handle

5 Adjust Foot

6 Bottom Hinge

MODEL PW 20 KF



1 Upper Hinge

2 Door Gasket

3 Shelves

4 Door Handle

5 Display shelve

6 Bottom Hinge

EN - 9

MODEL PW 24 KF



1 Upper Hinge

2 Door Gasket

3 Shelves

4 Door Handle

5 Display shelve

6 Bottom Hinge

• Thisapplianceisnotintendedforuseasabuilt-inappliance.

NOTES!

• Coolingsection(fridge)-Themostecientuseofenergyisensuredbythecongurationwith

drawerscinthelowerpartoftheapplianceandshelvesevenlydistributed.Thedirectionofdoor

openingdoesnotaectenergyconsumption.

• Freezer-Themostecientuseofenergyisensuredinacongurationwherethedrawersare

properlyinserted.

EN - 10

PART 4: OPERATING YOUR UNIT

Setting the Temperature Control



KeyFunction

1Unlock key: long press for 2 seconds to unlock

2Light/CF key: short press to turn on or o; long press to switch between Fahrenheit and Celsius

3Add key: temperature setting

4Minus key: temperature setting

Automatic locking function

Automatically lock after 20 seconds without any key operation. After locking, the plus and minus keys cannot

be operated, and the unlock key and lamp/CF key operate normally.

Auto light o function

When the lamp in the box is on, the lamp will automatically turn o after 10 minutes without any key

operation.

Adjustablerange

Minimum value: 5 °C / 41 °F

Maximum value: 18 °C / 64 °F

Displayrange

Control panel temperature display range: 0 ~ 37 °C / 32 ~ 99 °F.

Displaystability

In the Celsius state: The temperature measured by the temperature probe is displayed as the set temperature

value within ±1°C of the set temperature.

In Fahrenheit: The temperature measured by the temperature probe is displayed as the set temperature value

within ±2°F of the set temperature.

EN - 11

Error code

EE:“EE”isdisplayedwhenthetemperatureprobeisshort-circuitedordisconnected,ashes,andcoolingis

stopped.

LL: When the temperature measured by the temperature probe is lower than 0 degrees Celsius,“LL” is

displayed,ashing,andthecoolingisstopped.

HH: When the temperature measured by the temperature probe is higher than 37 degrees Celsius,“HH”is

displayed,ashing,andcoolingisstopped.

Forced defrosting function

When the compressor works for 8 hours, the compressor will stop working for 45 minutes.

Memoryfunction

Thecontrolboardisre-energizedaftereachpower-o,thetemperaturesettingvalue,Fahrenheit/Celsius

statewillbethesameasbeforethepower-o,andthelengthofpower-otimeisnotlimited.

Climate class

Acronym for ambient temperature range, ie SN, N, ST or T, in determining climate classes:

1. the extended temperate zone (SN) has a temperature range of 10 °C to 32 °C;

2. the temperate zone (N) has a temperature range of 16 °C to 32 °C;

3. the subtropical zone (ST) has a temperature range from 16 °C to 38 °C,

4. The tropical zone T has a temperature range of 16 °C to 43 °C.

EN - 12

Tips(PW12KF)

• Itisintendedtobeusedexclusivelyforthestorageofwine.

• Thisrefrigeratingapplianceisnotsuitableforthefreezingfoodstus.

• Thewinecoolerisrecommendedtobedesignedat12°C.

• Theshelvesplacedinfactorymodeisthemostecientuseofenergyfortherefrigeratingappliances.

• Thefollowingcombinationofshelvesisrecommendedforenergytobeusedasecientlyaspossibleby

the refrigeration unit.

THERE ARE FIVE SHELVES AND ONE DISPLAY SHELF IN TOTAL

The rst shelf

The second shelf

The third shelf

The fourth shelf

The fth shelf

The display shelf

• Whenthesurroundingtemperatureis25°Candthewinecoolerhasnobottleloaded,itwilltakearound

30 minutes to increase the wine cooler’s temperature from 5°C to 12°C. Under the same circumstance,

it will take around one hour to decrease the wine cooler’s temperature from 12°C to 5°C. The less the

temperature span is, the less time it will take.

• Thewinecoolerisrecommendedtobedesignedat12°C.Theenergyconsumptionis0.373kWh/24h.Ifthe

setting temperature is higher than 12°C, the energy consumption will be lower. If the setting temperature

is lower than 12°C, the energy consumption will be higher.

• Whenthecompressorworksfor8hours,thecompressorwillstopanddefrostfor45minutes.

EN - 13

Tips(PW20KF)

• Itisintendedtobeusedexclusivelyforthestorageofwine.

• Thisrefrigeratingapplianceisnotsuitableforthefreezingfoodstus.

• Thewinecoolerisrecommendedtobedesignedat12°C.

• Theshelvesplacedinfactorymodeisthemostecientuseofenergyfortherefrigeratingappliances.

• Thefollowingcombinationofshelvesisrecommendedforenergytobeusedasecientlyaspossibleby

the refrigeration unit.

THERE ARE FOUR SHELVES AND ONE DISPLAY SHELF IN TOTAL

The rst shelf

The second shelf

The third shelf

The fourth shelf

The display shelf

• Whenthesurroundingtemperatureis25°Candthewinecoolerhasnobottleloaded,itwilltakearound

30 minutes to increase the wine cooler’s temperature from 5°C to 12°C. Under the same circumstance,

it will take around one hour to decrease the wine cooler’s temperature from 12°C to 5°C. The less the

temperature span is, the less time it will take.

• Thewinecoolerisrecommendedtobedesignedat12°C.Theenergyconsumptionis0.389kWh/24h.Ifthe

setting temperature is higher than 12°C, the energy consumption will be lower. If the setting temperature

is lower than 12°C, the energy consumption will be higher.

• Whenthecompressorworksfor8hours,thecompressorwillstopanddefrostfor45minutes.

EN - 14

Tips(PW24KF)

• Itisintendedtobeusedexclusivelyforthestorageofwine.

• Thisrefrigeratingapplianceisnotsuitableforthefreezingfoodstus.

• Thewinecoolerisrecommendedtobedesignedat12°C.

• Theshelvesplacedinfactorymodeisthemostecientuseofenergyfortherefrigeratingappliances.

• Thefollowingcombinationofshelvesisrecommendedforenergytobeusedasecientlyaspossibleby

the refrigeration unit.

THERE ARE FIVE SHELVES AND ONE DISPLAY SHELF IN TOTAL

The rst shelf

The second shelf

The third shelf

The fourth shelf

The fth shelf

The display shelf

• Whenthesurroundingtemperatureis25°Candthewinecoolerhasnobottleloaded,itwilltakearound

30 minutes to increase the wine cooler’s temperature from 5°C to 12°C. Under the same circumstance,

it will take around one hour to decrease the wine cooler’s temperature from 12°C to 5°C. The less the

temperature span is, the less time it will take.

• Thewinecoolerisrecommendedtobedesignedat12°C.Theenergyconsumptionis0.389kWh/24h.Ifthe

setting temperature is higher than 12°C, the energy consumption will be lower. If the setting temperature

is lower than 12°C, the energy consumption will be higher.

• Whenthecompressorworksfor8hours,thecompressorwillstopanddefrostfor45minutes.

EN - 15

PART 5: TROUBLESHOOTING

If the product is not working properly, please check and handle according to the following methods. If the

situationcannotbechanged,pleasecontactthelocalafter-salesservicecenterintime,andbesureto

provide the model name and product number in detail.

PROBLEM POSSIBLE CAUSE

Unit does not operate. Not plugged in.

The circuit breaker tripped or a blown fuse.

Turns on and o frequently. The room temperature is hotter than normal.

A large amount of food has been added to the unit.

The door is opened too often.

The door is not closed completely.

The temperature control is not set correctly.

The door gasket does not seal properly.

The unit does not have the correct clearances.

Vibrations. Check to assure that the unit is level.

The unit seems to make too much noise. Therattlingnoisemaycomefromtheowofthe

refrigerant, which is normal.

As each cycle ends, you may hear gurgling sounds

causedbytheowofrefrigerantinyourunit.

Contraction and expansion of the inside walls may

cause popping and cracking noise.

The unit is not level.

The door will not close properly. The unit is not level.

The door was reversed and not properly installed.

The gasket is dirty or bent.

The shelves, bins, or baskets are out of position.

EN - 16

PART 6: DISPOSAL OF THE APPLIANCE

It is prohibited to dispose of this appliance as household waste.

Packaging materials

Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into a suitable waste

collection container to recycle it.

Before disposal of the appliance

1. Pull out the main plug from the main socket.

2. Cut o the power cord and discard with the main plug

WARNING!

Refrigeratorscontainrefrigerantandgasesintheinsulation.Refrigerantandgasesmustbe

disposedofprofessionallyastheymaycauseeyeinjuriesorignition.Ensurethattubingofthe

refrigerant circuit is not damaged prior to proper disposal.

Storage instructions

To avoid contamination of food, please respect the following instructions

- Openingthedoorforlongperiodscancauseasignicantincreaseofthetemperatureinthe

compartments of the appliance.

- Cleanregularlysurfacesthatcancomeincontactwithfoodandaccessibledrainagesystems.

9 Wine +5~+20 Red wine,white wine,sparkling wine etc.

Note: Please store dierent foods according to the compartments or target storage temperature of your

purchased products.

-Iftherefrigeratingapplianceisleftemptyforlongperiods,switcho,defrost,clean,dry,andleavethedoor

open to prevent mould developing within the appliance.

EN - 17

PART 7: PRODUCT INFORMATION SHEET

Product Information Sheet

COMMISSION DELEGATED REGULATION (EU) 2019/2016

Supplier's name or trademark: PHILCO

Supplier's address: Černokostelecká 2111, 10000 Prague, CZ

Modelidentier: PW 12 KF

Typeofrefrigeratingappliance: Wine Cooler

Low-noiseappliance: No Design type: free-standing

Wine storage appliance: Yes Other refrigerating appliance: No

General product parameters:

Parameter Value Parameter Value

Overal dimensions

(millimetre)

Height 795

Total volume (dm³ or l) 32Width 252

Depth 450

EnergyeciencyIndex(EEI) 176 Energyeciencyclass* G

Airborne acoustical noise emissions

(dB(A) re 1 pW) 45 Airborne acoustical noise emission

class D

Annual energy consumption (kWh/a) 136 Climate class: N

Minimum ambient temperature (°C),

for which the refrigerating appliance

is suitable

Maximum ambient temperature (°C),

for which the refrigerating appliance

is suitable

Winter setting No

Compartment Parameters:

Compartment type

Compartment parameters and values

Compartment

volume

(dm³ or l)

Recommended

temperature

setting for

optimised food

storage (°C)

These settings

shall not

contradict

the storage

conditions set

out in Annex IV,

Table 3

Freezing capacity

(kg/24h)

Defrosting type

(auto-defrost=A,

manual

defrost=M)

Pantry No - - - -

Wine storage Yes 32 12 -A

Cellar No - - - -

EN - 18

Fresh food No - - - -

Chill No - - - -

0-starorice-

making No - - - -

1-star No - - - -

2-star No - - - -

3-star No - - - -

4-star No - - - -

2-starsection No - - - -

Variable

temperature

compartment

-----

Light source parameters:

Type of light source LED

Energyeciencyclass -

Minimumdurationoftheguaranteeoeredbythemanufacturer: 24 months

Additional information:

Weblinktothemanufacturer'swebsite,wheretheinformationinpoint4(a)AnnexofCommissionRegulation(EU)

2019/2019 is found: www.philco.cz

*A(highesteciency)toG(lowesteciency)

Other manuals for PW 12 KF

This manual suits for next models

Table of contents

Languages:

Popular Kitchen Appliance manuals by other brands

Tupperware

Tupperware 10141275000 user manual

TEFAL

TEFAL POCKET SANDWICH - 04-07 manual

Strata

Strata 24211 user manual

Black & Decker

Black & Decker BS500 user guide

Chicco

Chicco System Easy Meal 6M+ instructions

Livoo

Livoo DOM393 instruction manual

Arteflame

Arteflame AF30ROTIS Setup instructions

Bosch

Bosch MUZS24DSW user manual

Hamilton Beach

Hamilton Beach 11560 manual

Linea 2000

Linea 2000 DOMO DO1106C instruction manual

Philips

Philips HR1386/00 user manual

Frigidaire

Frigidaire FFWC35F4L B Specification sheet

ARESA

ARESA AR-2008 instruction manual

Siemens

Siemens HX725.20N instruction manual

Macma

Macma 80337 instructions

Groen

Groen SSB-3E Operator's manual

emerio

emerio ST-111153.4 instruction manual

Ink Bird

Ink Bird ISV-200W manual

Philco PW 12 KF User manual

Popular Kitchen Appliance manuals by other brands
