Philio DCH-Z110 User manual

DCH-Z110/Z120
The sensor DCH-Z110/Z120 have PIR or door/window integrated with,
temperature and i umination, which are 3 sensors function in one,
based on Z-WaveTM techno ogy.
It is the Z-WaveTM p us product, it supports the security, OTA... Those
newest features of the Z-WaveTM techno ogy. Z-WaveTM is a wire ess
communication protoco designed for home automation, specifica y to
remote y contro app ications in residentia and ight commercia
environments. The techno ogy uses a ow-power RF radio embedded or
retrofitted into home e ectronics devices and systems, such as ighting,
home access contro , entertainment systems and househo d app iances.
This product can be inc uded and operated in any Z-WaveTM network
with other Z-WaveTM certified devices from other manufacturers and/or
other app ications. A non-battery operated nodes within the network
wi act as repeaters regard ess of vendor to increase re iabi ity of the
network.
The device adopt the Z-WaveTM 500 series chip, when your Z-WaveTM
network system is a made by Z-WaveTM 500 series devices. The
network system wi have the advantages as be ow.
•Concurrent mu ti-channe support reduces externa interference.
•Better RF range, improve about 10 meters in indoor.
•Support 100 Kbps transmit speed, speed up communication.
Function Compare DCH-Z110/DCH-Z120
PIR Door/Window Temperature I umination
DCH-Z110 V V V
DCH-Z120 V V V
Add to/Remove from Z-WaveTM Net ork
There are two tamper keys in the device, one is in the back side,
another is in the front side. Both of them can add, remove, reset or
association from Z-WaveTM network.
In the first time, add the device into the Z-WaveTM network. First,
make sure the primary contro er is in the add mode. And then power
on the device, just take out the insu ation My ar in the back side of the
device. The device wi auto start the NWI (Network Wide Inc usion)
mode. And it shou d be inc uded in 5 seconds. You wi see the LED
ight ON one second.
1

Notice: Inc uding a node ID a ocated by Z-WaveTM Contro er means
“Add” or “Inclusion”. Exc uding a node ID a ocated by Z-WaveTM
Contro er means “Remove” or “Exclusion”.
Function Description
Add
1.Have Z-WaveTM Contro er entered inc usion mode.
2.Pressing tamper key three times within 1.5 seconds
to enter the inc usion mode.
3.After add successfu , the device wi wake to receive
the setting command from Z-WaveTM Contro er about
20 seconds.
Remove
1.Have Z-WaveTM Contro er entered exc usion mode.
2.Pressing tamper key three times within 1.5 seconds
to enter the exc usion mode.
Node ID has been exc uded.
Reset
Notice: Use this procedure only in the event
that the primary controller is lost or other ise
inoperable.
1.Pressing tamper key four times within 1.5 seconds
and do not re ease the tamper key in the 4th pressed,
and the LED wi ight ON.
2.After 3 seconds the LED wi turn OFF, after that
within 2 seconds, re ease the tamper key. If successfu ,
the LED wi ight ON one second. Otherwise, the LED
wi f ash once.
3.IDs are exc uded and a settings wi reset to factory
defau t.
Association 1.Have Z-WaveTM Contro er entered association mode.
2.Pressing tamper key three times within 1.5 seconds
to enter the association mode.
Note: The device support 2 groups. The group 1 is for
receiving the report message, ike triggered event,
temperature, i umination etc. The group 2 is for ight
contro , the device wi send the “Basic Set” command
to this group. And each group support 8 nodes
maximum.
•Fai ed or success in add/remove the node ID can be viewed from Z-
WaveTM Contro er.
Notice 1: A ways RESET a Z-WaveTM device before trying to add it to a
Z-WaveTM network
Notice 2: When the device into NWI mode, the sensor functiona ity
wi use ess. The NWI mode wi timeout after 30 seconds. You can
press the tamper key 3 times to abort the NWI mode.
Z-WaveTM Notification
After the device adding to the network, it wi wake-up once per day in
defau t. When it wake-up it wi broadcast the “Wake Up Notification”
message to the network, and wake-up 10 seconds for receive the
setting commands.
The wake-up interva minimum setting is 30 minutes, and maximum
setting is 120 hours. And the interva step is 30 minutes.
If the user want to wake-up the device immediate y, p ease remove the
front cover, and press the tamper key once. The device wi wake-up 10
seconds.
Z-WaveTM Message Report
When the PIR motion triggered or the door/windows triggered, the
device wi report the trigger event and a so report the battery status,
temperature and i umination eve .
In defau t the device wi using Notification Report to represent the
trigger event, it can be changed to Sensor Binary Report by setting the
configuration NO. 7 Bit4 to 1.
2

* Motion Report:
When the PIR motion detected, the device wi unso icited to send the
report to the nodes in the group 1.
Notification Report (V4)
Notification Type: Home Security (0x07)
Event: Motion Detection, Unknown Location (0x08)
Sensor Binary Report (V2)
Sensor Type: Motion (0x0C)
Sensor Va ue: 0xFF
* Door/Windo Report:
When the door/window state changed, the device wi unso icited to
send the report to the nodes in the group 1.
Notification Report (V4)
Notification Type: Access Contro (0x06)
Event: Door/Window is open (0x16)
Door/Window is c osed (0x17)
Sensor Binary Report (V2)
Sensor Type: Door/Window (0x0A)
Sensor Va ue: 0x00 is c osed, 0xFF is opened.
* Tamper Report:
Both the 2 tamper keys are pressed over 5 seconds. The device wi
into the a arm state. In that state, if any one of the tamper keys be
re eased, the device wi unso icited to send the report to the nodes in
the group 1.
Notification Report (V4)
Notification Type: Home Security (0x07)
Event: Tampering. Product covering removed (0x03)
Sensor Binary Report (V2)
Sensor Type: Tamper (0x08)
Sensor Va ue: 0xFF
* Temperature Report:
When the PIR motion detected or the door/window state changed, the
device wi unso icited to send the “Sensor Mu ti eve Report” to the
nodes in the group 1.
Sensor Type: Temperature (0x01)
Note: To disab e this functiona ity by setting the configuration N0.5 bit5
to 1.
*** Temperature differentia report ***
This function defau t is enab ed, to disab e this function by setting the
configuration NO.21 to 0.
In the defau t, when the temperature is changed to p us or minus one
degree Fahrenheit (0.56 degree Ce sius), the device wi report
temperature information to the nodes in the group 1.
The device wi measure the temperature in every one minute. And if
the temperature is over 140 degree Fahrenheit (60 degree Ce sius), the
device wi a ways report in each measurement.
Caution 1: Enab e this functiona ity, it wi cause the PIR Motion to
disab e detection when the temperature measurement. In other words,
The PIR motion wi b ind one second in every one minute.
* Illumination Report:
When the PIR motion detected or the door/window state changed, the
device wi unso icited to send the “Sensor Mu ti eve Report” to the
nodes in the group 1.
Sensor Type: Luminance (0x03)
Note: To disab e this functiona ity by setting the configuration N0.5
bit4 to 1.
*** I umination differentia report ***
3

This function defau t is disab ed, to enab e this function by setting the
configuration NO.22 not to zero.
Enab e this functiona ity, the device wi measure the i umination in
every one minute. And if the i umination is changed to p us or minus
the va ue (setting by the configuration NO.22), the device wi report
i umination information to the nodes in the group 1.
Caution 1: Enab e this function wi reduce the battery ife about 15%
~ 20%. And another issue is setting the differentia va ue too sma , it
wi cause report too frequency, shorter the battery ife more.
Propose the setting differentia va ue shou d not sma than 10.
Caution 2: If the configuration No.4 is setting to 0 or 100, this
functiona ity is use ess.
Caution 3: Enab e this functiona ity, it wi cause the PIR Motion to
disab e detection when the i umination measurement. In other words,
The PIR motion wi b ind one second in every one minute.
* Timing Report:
Beside the event triggered cou d report message, the device a so
support the timing unso icited report of the status.
•Battery eve report: Every 6 hours report once in defau t.
It cou d be changed by setting the configuration NO. 10.
•Low battery report: When the battery eve is too ow, every 30
minutes wi report once.
•Door/window state report: Every 6 hours report once in defau t.
It cou d be changed by setting the configuration NO. 11.
•I umination eve report: Every 6 hours report once in defau t.
It cou d be changed by setting the configuration NO. 12.
•Temperature report: Every 6 hours report once in defau t.
It cou d be changed by setting the configuration NO. 13.
Notice: The configuration NO. 10, 11, 12 and 13 cou d be setting to
zero to disab e the auto report. And the configuration NO. 20 cou d
change the tick interva , the defau t va ue is 30, if setting to 1, that
means the minimum auto report interva wi be one minute. And p ease
notice if setting this va ue to zero, that means disab e a of the timing
report except the ow battery detection.
Po er Up Procedure
* Battery Po er Check
When the device power up, the device wi detect the power eve of the
battery immediate y. If the power eve is too ow, the LED wi continue
f ash about 5 seconds. P ease change another new battery.
* PIR Warm Up
When the device power on, the PIR need to warm up before the
operation. The warm up time about 1 minute, the LED wi f ash in
every 2 seconds. After finish the procedure the LED wi ight ON three
times.
* NWI
When the device power on, the device wi check is it a ready adding to
the network? If doesn't, it wi auto start the NWI mode. The LED wi
f ash in every second and continue 30 seconds. Unti timeout or the
device successfu to inc usion by contro er. The use can presses the
tamper key 3 times to abort the NWI mode.
* Wake
When the device power on, the device wi wake about 20 seconds. In
this duration, the contro er can communicate with the device. Norma y
the device is a ways s eeping to save the battery energy.
Over The Air (OTA) Firm are Update
The device supports the Z-Wave firmware update via OTA.
Before starting the procedure, p ease remove the front cover of the
device. Otherwise the hardware check wi be fai ed.
Let the contro er into the firmware update mode, and then press the
front tamper key once to start the update.
4

After finish the firmware down oad, the LED wi start f ash in every 0.5
second. At that time, please don't remove the battery , otherwise it
wi cause the firmware broken, and the device wi no function.
After the LED stop f ash, it is recommended that the user power up the
device. Caution: After remove the battery, p ease wait about 30
seconds, and then re-insta the battery.
Security Net ork
The device supports the security function. When the device inc uded
with a security contro er, the device wi auto switch to the security
mode. In the security mode, the fo ow commands need using Security
CC wrapped to communicate, otherwise it wi not response.
COMMAND_CLASS_BATTERY
COMMAND_CLASS_NOTIFICATION_V4
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_CONFIGURATION
COMMAND_CLASS_SENSOR_BINARY_V2
COMMAND_CLASS_SENSOR_MULTILEVEL_V5
COMMAND_CLASS_WAKE_UP_V2
Operation Mode
There are two modes “Test” and “Norma ”.
“Test Mode” is for the user test the sensor function when insta ation.
“Norma Mode” for the norma operation.
When the event triggered, norma y the LED won't indicated, un ess the
battery is in the ow eve , the LED wi f ash once. But in the “Test
Mode” the LED a so wi ight ON one second.
When the event triggered, the device wi report the messages to the
nodes in the group 1. The messages a so inc ude the battery eve , the
temperature and the i umination eve . The user can switch the report
by setting the configuration NO. 5 bit4 (i umination) and bit5
(temperature), and the configuration NO. 7 bit6 (battery).
When the event triggered, if the environment uminance is ess than
the setting of the va ue of the configuration NO. 4, the device wi emit
the signa to turn ON the ighting equipment, those nodes are in the
group 2. And de ay a whi e to turn OFF the ighting equipment. The
de ay time is setting by the configuration NO. 9.
The PIR motion re-detected interva , in the “Test Mode” fixed to 6
seconds. In the “Norma Mode”, it according to the setting of the
configuration NO. 8.
Notice: When the tamper key of the back side is re eased, the device
a ways in the “Test Mode”.
5

6

Battery Installation
When the device report the ow battery message. The user shou d
rep ace the battery to new one. The battery type is CR123A, 3.0V.
The way to open the front cover p ease fo ow be ow steps.
1.Using a too to press the 1-1 position, to re ease the cover.
2.Ho d the front cover and pu back
3.Ho d the front cover and pu up
Rep ace the new battery and insta the cover back.
1.Put the front cover bottom to 1-1, and press down.
2.Push the front cover top to 2-1.
Choosing a Suitable Location
1.The recommended mounting height is 160cm for DCH-Z120.
2.Don't et the device facing the window or the sun ight.
3.Don't et the device facing the source of heat. For instance the heater
or the air-condition.
7

Installation
1. In the first time, add the device into the Z-WaveTM network. First,
make sure the primary contro er is in the inc usion mode. And then
power on the device, just take out the insu ation My ar in the back side
of the device. The device wi auto start the NWI (Network Wide
Inc usion) mode. And it shou d be inc uded in 5 seconds. You wi see
the LED ight ON one second.
2. Let the contro er associate with the device into the first group, any
ight switch that intend to be turned on when the device trig p ease
associate with the device into the second group.
3. In the accessory pack. There are two types of doub e coated tape,
one is thicker (hereinafter referred to as A tape) and another is thinner
(hereinafter referred to as B tape), you can use A tape for the test at
the beginning. The right way for A tape insta ation is stick it to the
position be ow tamper key. The thicker tape won't et the tamper key
pressed, so the sensor wi enter the test mode, You may test if
insta ed position is good or not by this way.
After finish the test and decide to fix, then you can remove tape A, and
mounting the sensor by using tape B. The tamper key wi pressed and
et the sensor enter norma mode.
Z-Wave Configuration Settings
Notice:
* A of the configuration, the data size is 1.
* The configuration mark with star(*), means after the remove the setting sti
keep, don't reset to factory defau t. Un ess the user execute the “RESET”
procedure.
* The reserve bit or not supported bit is a owed any va ue, but no effect.
8

NO. Name Def. Va id A B Description
2Basic Set
Leve 0xFF A  
Setting the BASIC command va ue to
turn on the ight. The 0xFF(-1) means
turn on the ight. For dimmer
equipment 1 to 100 means the ight
strength.
0 means turn off the ight.
3
(*)
PIR
Sensitivity 80 0 ~ 99  
PIR sensitivity settings.
0 means disab e the PIR motion.
1 means the owest sensitivity,
99 means the highest sensitivity.
High sensitivity means can detected
ong distance, but if there is more
noise signa in the environment, it wi
re-trigger too frequency.
4Light
Thresho d 99 0 ~ 100  
Setting the i umination thresho d to
turn on the ight. When the event
triggered and the environment
i umination ower then the thresho d,
the device wi turn on the ight.
0 means turn off i umination detected
function. And never turn on the ight.
1 means darkest.
99 means brightest.
100 means turn off i umination
detected function. And a ways turn on
the ight.
Notice: In none test mode, on y the
va ue in 1 to 99 wi enab e the
i umination detected function and
update the i umination va ue.
NO. Name Def. Va id A B Description
NO. Name Def. Va id A B Description
5
(*)
Operation
Mode
0A Operation mode. Using bit to contro .
0  Bit0: Reserve.
0 
Bit1: 1 means test mode,
0 means norma mode.
Notice:
This bit on y effect by the DIP Switch
setting to “customer mode”, otherwise
it decides by DIP Switch setting to Test
or Norma Mode.
0  Bit2: Disab e the door/window
function. (1:Disab e, 0:Enab e)
0  Bit3: Setting the temperature sca e.
0: Fahrenheit, 1:Ce sius
0  Bit4: Disab e the i umination report after event triggered. (1:Disab e,
0:Enab e)
0  Bit5: Disab e the temperature report after event triggered. (1:Disab e,
0:Enab e)
0  Bit6: Reserve.
0  Bit7: Disab e the back key re ease into test mode. (1:Disab e,
0:Enab e)
NO. Name Def. Va id A B Description
9

NO. Name Def. Va id A B Description
6
(*)
Mu t-
Sensor
Function
Switch
4A Mu tisensor function switch. Using bit
to contro .
0 
Bit0: Disab e magnetic integrate
i umination to turn ON the ighting
nodes in the association group 2.
(1:Disab e, 0:Enab e)
0 
Bit1: Disab e PIR integrate
I umination to turn ON the ighting
nodes in the association group 2.
(1:Disab e, 0:Enab e)
1 
Bit2: Disab e magnetic integrate PIR
to turn ON the ighting nodes in the
association group 2. (1:Disab e,
0:Enab e) (Defau t is Disab e)
0 
Bit3: When Bit2 is 0 (Enab e), Are the
device and the ighting in the same
room?
0: In the same room(Defau t),
1: In the different room.
Notice: If this bit is 1, it is
recommended a so set the Bit1 to 1,
cause the PIR triggered, doesn't
mean the peop e in that room.
0  Bit4: Disab e de ay 5 seconds to turn off the ight, when door/window
c osed. (1:Disab e, 0:Enab e)
0  Bit5: Disab e auto turn off the ight,
after door/window opened to turn on
the ight. (1:Disab e, 0:Enab e)
Notice: If bit2 is zero, this setting is
use ess.
Notice: If the configuration No.9 is
zero, this setting is use ess.
0  Bit6: Reserve.
0  Bit7: Reserve.
NO. Name Def. Va id A B Description
NO. Name Def. Va id A B Description
7
(*)
Customer
Function 4A Customer function switch, using bit contro .
0  Bit0: Reserve.
0 
Bit1: Enab e sending motion OFF
report. (0:Disab e, 1:Enab e)
Note: Depends on the Bit4,
0: Report Notification CC,
Type: 0x07, Event: 0xFE
1: Sensor Binary Report,
Type: 0x0C, Va ue: 0x00
1  Bit2: Enab e PIR super sensitivity
mode. (0:Disab e, 1:Enab e)
0  Bit3: Disab e send out BASIC OFF after door c osed. (1:Disab e,
0:Enab e)
0  Bit4: Notification Type, 0: Using Notification Report.
1: Using Sensor Binary Report.
0  Bit5: Disab e Mu ti CC in auto report.
(1:Disab e, 0:Enab e)
0  Bit6: Disab e to report battery state
when the device triggered. (1:Disab e,
10

0:Enab e)
0  Bit7: Reserve.
NO. Name Def. Va id A B Description
8
PIR Re-
Detect
Interva
Time
31 ~
127  
In the norma mode, after the PIR
motion detected, setting the re-detect
time. 8 seconds per tick, defau t tick is
3 (24 seconds).
Setting the suitab e va ue to prevent
received the trigger signa too
frequent y. A so can save the battery
energy.
Notice: If this va ue bigger than the
configuration setting NO. 9. There is a
period after the ight turned off and
the PIR not start detecting.
9
Turn Off
Light
Time
40 ~
127  
After turn on the ighting, setting the
de ay time to turn off the ighting
when the PIR motion is not detected.
8 seconds per tick, defau t tick is 4 (32
seconds).
0 means never send turn off ight
command.
10
Auto
Report
Battery
Time
12 0 ~
127  
The interva time for auto report the
battery eve .
0 means turn off auto report battery.
The defau t va ue is 12. The tick time
can setting by the configuration No.20.
11 Auto Report
Door/Windo
w State
Time
12 0 ~
127
  The interva time for auto report the
door/window state.
0 means turn off auto report
door/window state.
The defau t va ue is 12. The tick time
can setting by the configuration No.20.
NO. Name Def. Va id A B Description
NO. Name Def. Va id A B Description
12
Auto Report
I umination
Time
12 0 ~
127  
The interva time for auto report the
i umination.
0 means turn off auto report
i umination.
The defau t va ue is 12. The tick time
can setting by the configuration No.20.
13
Auto Report
Temperatur
e Time
12 0 ~
127  
The interva time for auto report the
temperature.
0 means turn off auto report
temperature.
The defau t va ue is 12. The tick time
can setting by the configuration No.20.
20
Auto Report
Tick
Interva
30 0 ~
0xFF  
The interva time for auto report each
tick. Setting this configuration wi
effect configuration No.10, No.11,
No.12 and No.13.
Caution: Setting to 0 means turn off
a auto report function.
21
Temperature
Differentia
Report
10 ~
0x7F  
The temperature differentia to report.
0 means turn off this function.
The unit is Fahrenheit.
Enab e this function the device wi
detect every minutes.
And when the temperature is over 140
degree Fahrenheit, it wi continue
report.
Enab e this functiona ity wi cause
some issue p ease see the detai in the
“Temperature Report” section.
11

NO. Name Def. Va id A B Description
NO. Name Def. Va id A B Description
22
I umination
Differentia
Report
00 ~
0x63  
The i umination differentia to report.
0 means turn off this function.
The unit is percentage.
Enab e this function the device wi
detect every minutes.
Enab e this functiona ity wi cause
some issue p ease see the detai in the
“I umination Report” section.
NO. Name Def. Va id A B Description
Note: Refer A as DCH-Z110, B as DCH-Z120
Z-Wave Supported Command Class
COMMAND_CLASS_ZWAVEPLUS_INFO_V2
COMMAND_CLASS_BATTERY
COMMAND_CLASS_NOTIFICATION_V4
COMMAND_CLASS_ASSOCIATION_V2
COMMAND_CLASS_CONFIGURATION
COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
COMMAND_CLASS_VERSION_V2
COMMAND_CLASS_SENSOR_BINARY_V2
COMMAND_CLASS_SENSOR_MULTILEVEL_V5
COMMAND_CLASS_WAKE_UP_V2
COMMAND_CLASS_ASSOCIATION_GRP_INFO
COMMAND_CLASS_POWERLEVEL
COMMAND_CLASS_DEVICE_RESET_LOCALLY
COMMAND_CLASS_MULTI_CMD
COMMAND_CLASS_SECURITY
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
COMMAND_CLASS_MARK
COMMAND_CLASS_BASIC
Specifications
Power by CR123A ithium battery.
Signa (Frequency):
868.40 MHz, 869.85 MHz(EU),
908.42 MHz - 916.00 MHz(US),
922~927 MHz(JP/TW),
921.40 MHz, 919.80 MHz(ANZ),
869.00 MHz(RU),
865.20 MHz(IN),
916.00 MHz(IL),
Range:
Minimum 30 meters indoor,
70 meters outdoor ine of sight.
Operating Temperature: -10oC ~ 40oC
For indoor use on y.
Specifications subject to change without notice due to continuing
product improvement.
FCC ID for DCH-Z110: KA2CHZ110A1
FCC ID for DCH-z120: KA2CHZ120A1
12

FCC Interference Statement
This equipment has been tested and found to comp y with the imits for
a C ass B digita device, pursuant to Part 15 of the FCC Ru es. These
imits are designed to provide reasonab e protection against harmfu
interference in a residentia insta ation. This equipment generates, uses
and can radiate radio frequency energy and, if not insta ed and used in
accordance with the instructions, may cause harmfu interference to
radio communications. However, there is no guarantee that
interference wi not occur in a particu ar insta ation. If this equipment
does cause harmfu interference to radio or te evision reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the fo owing
measures:
•Reorient or re ocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an out et on a circuit different from that to
which the receiver is connected.
•Consu t the dea er or an experienced radio/TV technician for he p.
This device comp ies with Part 15 of the FCC Ru es. Operation is subject
to the fo owing two conditions:
(1) This device may not cause harmfu interference, and
(2) This device must accept any interference received, inc uding
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not express y approved by
the party responsib e for comp iance cou d void the user's authority to
operate this equipment.
This transmitter must not be co- ocated or operating in conjunction
with any other antenna or transmitter.
Warning
Do not dispose of e ectrica app iances as unsorted municipa waste,
use separate co ection faci ities. Contact your oca government for
information regarding the co ection systems avai ab e. If e ectrica
app iances are disposed of in andfi s or dumps, hazardous substances
can eak into the groundwater and get into the food chain, damaging
your hea th and we -being.
When rep acing o d app iances with new once, the retai er is ega y
ob igated to take back your o d app iance for disposa at east for free
of charge.
13
