Philio PAT12 User manual

CO2 Sensor PAT12
The PAT 12 CO2 sensor is a device that allows you to check the air quality in your
home by detecting and measuring CO2 concentrations. The PAT12 sensor is easy to
use and very convenient for your home. ust set the sensor on the wall of the rooms
you would like to control, and you are ready to go. Moreover, the PAT12 can be
integrated to other Z-Wave certified devices, and controlled with Philio app “Home
Mate 2.” You can now protect your family and your business and make sure that air
you are breathing is safe. Set up your PAT12 to send regular notifications and take
control even when not at home.
This product can be included and operated in any Z-WaveTM network with other Z-
WaveTM certified devices from other manufacturers and/or other applications. All non-
battery operated devices within the network will act as repeaters regardless of vendor
to increase reliability of the network.
The device adopts the Z-WaveTM 500 series chip when your Z-WaveTM network
system is made by Z-WaveTM 500 series devices. This network system has the
following advantages:
The product supports Over The Air (OTA) feature for the products firmware upgrade.
Adding to Z-WaveTM Network
This product can be operated in any Z-Wave network with other Z-Wave certified
devices from other manufacturers. All non-battery operated nodes within the network
will act as repeaters regardless of vendor to increase reliability of the network.
The table below lists an operation summary of basic Z-Wave functions. Please refer
to the instructions for your Z-WaveTM Certificated Primary Controller to access the
Setup function, and to Add/Remove/associate devices
Function Descri tion Annotation
No node ID The Z-Wave Controller does not allocate
a node ID to the Switch.
flash for 30 seconds.
Add (Inclusion) 1. Put your Z-Wave controller into
inclusion mode by following the
instructions provided by the
controller manufacturer.
LED will flash slowly.
2. Pressing Include button of PAT12
three times within 3 seconds will
enter inclusion mode.
If the learning code is successful, the
LED will flash slowly.
Remove
(Exclusion)
1. Put your Z-Wave controller into
exclusion mode by following the
instructions provided by the
controller manufacturer.
2. Pressing Include button of PAT12
three times within 3 seconds will
enter exclusion mode.
3. Node ID has been excluded. flash for 30 seconds.
Reset 1. Pressing Include button of PAT12
three times within 3 seconds will
enter inclusion mode.
Use this procedure only in
the event that the primary
controller is lost or
otherwise inoperable.
2. Within 1 second, press Include
button of PAT12 again for 5 seconds.
1

3. IDs are excluded.
SmartStart 1. Product has a DSK string, you can key
in first five digit to increment smart
start process, or you can scan QR
code.
Ex: mydsk
10209-46687-52248-13629-04783-
07465-15776-56519
2. SmartStart enabled products can be
added into a Z-Wave network by
scanning the Z-Wave QR Code
present on the product providing
SmartStart inclusion. No further
action is required and the SmartStart
product will be added automatically
within 10 minutes of minutes On in
the network vicinity.
Association
This machine provides a group of groups.
Each group can set 5 Nodes.
Group 1: Used for event return.
Report type:
1.Notification report
2.Sensor multilevel report
3.Reset report
Adding a node ID allocated by Z-Wave Controller means inclusion. Removing a node
ID allocated by Z-Wave Controller means exclusion.
Failed or success in including/excluding the node ID can be viewed from the Z-Wave
Controller.
LED Indication
To distinguish what mode the switch is in, view from the LED for identification.
State Ty e LED Indication
No node ID Under normal operation, when the Switch has not been allocated a node ID,
the LED flashes on and off alternately at 30 second intervals. By pressing
On/Off button, it will stop flashing temporarily.
Learning When PAT12 is in learning mode, If the learning code is successful, the LED
will flash slowly.
Programming
2. Z-Wave’s Configuration
Configuration
Parameter
Function Size
(Byte)
Value Unit Default Description
1Fixed timer for
report Co2
concentration
1 0-127 1 Units of 1 minutes.
2Concentration
change report
1 0-100 10 Units of 1 %.
3Baseline level 1 1 0-50 6 Units of 100 ppm.
4Baseline level 2 1 0-50 8 Units of 100 ppm.
5Baseline level 3 1 0-50 10 Units of 100 ppm.
6Baseline level 4 1 0-50 12 Units of 100 ppm.
7Baseline level 5 1 0-50 16 Units of 100 ppm.
2. Firmware update over the air (OTA)
PAT12 is based on 500 series SoC and supports Firmware Update Command
Class, it can receives the updated firmware image sent by controller via the Z-
wave RF media. It is a helpful and convenient way to improve some function if
needed.
Command Classes
2

The Sensor supports Command Classes including…
COMMAND_CLASS_ZWAVEPLUS_INFO,
COMMAND_CLASS_ASSOCIATION,
COMMAND_CLASS_ASSOCIATION_GRP_INFO,
COMMAND_CLASS_TRANSPORT_SERVICE_V2,
COMMAND_CLASS_VERSION,
COMMAND_CLASS_MANUFACTURER_SPECIFIC,
COMMAND_CLASS_DEVICE_RESET_LOCALLY,
COMMAND_CLASS_POWERLEVEL,
COMMAND_CLASS_SECURITY_2,
COMMAND_CLASS_CONFIGURATION,
COMMAND_CLASS_NOTIFICATION_V3,
COMMAND_CLASS_SECURITY,
COMMAND_CLASS_SENSOR_MULTILEVEL_V11,
COMMAND_CLASS_SUPERVISION
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
Over The Air (OTA) Firmware U date
The device supports Z-Wave firmware update via OTA.
Before starting the update, please remove the front case of the device otherwise the
hardware check will fail.
Let the controller into firmware update mode, and press the front tamper key once to
start the update.
After firmware download is completed, the LED light will flash intermittently.
Overview
S ecification
Rated Voltage DC5V from USB
Range Minimum 40M in door and 100M in outdoor line of
sight
Operating Temperature -10°C ~ 40°C (85% humidity)
Storage Temperature -20 C ~ 60°C
Location Indoor use only
Dimension 65(L) x 44.1 (W) x 56.3 (H) mm
CO2 0-5000ppm
Frequency Range 868.40MHz; 869.85MHz (EU)
908.40MHz; 916.00MHz (USA/Canada)
916MHz (Israel)
922.5MHz, 923.9MHz, 926.3MHz ( P)
RF Maximum Power (peak) +5dBm (peak)
RF Maximum Power
(Average) -10dBm (Average)
RF Modulation Type FSK (Frequency-Shift Keying)
FCC ID RHHPAT12
3
