Philips HD9020 User manual

ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Bread Maker
HD9020
12/11
PRODUCT INFORMATION
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 220 - 240 V, 50 - 60 Hz
- Power consumption : 650 W
- Power standby : 0.5 W
- Dimensions (w x d x h) : 300 x 340 x 310 mm
- Length power cable : 1.10 Meter
- Colour setting : White / Lavender
- SAP coding : HD9020
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
-Before you start dismantling!
For your safety be sure the plug is
disconnected from the mains!
!

HD9020
2-4
REPAIR INSTRUCTIONS
- To replace the Control Panel assy, remove the lid and
remove the two screws holding the Control Panel in place.
Pull gently upwards to unhook the Control Panel , be aware
that the Contol Panel is still connected by the flat cable.
Unhook the flat cable from the PCB. Please note, the flat
cable connector will only fit in one way with respect to the
receptacle.
Electrical diagram:
Resistance
ThermostatTimer
Indicator
L
N
Upper
Heating
Element
Lower
Heating
Element
OPTIONAL (accessories)
- No specific issues
PARTS LIST
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
4222 459 45778
4222 459 45779
9965 100 55821*
4222 459 45780
4222 459 45781
4222 459 45787
4222 459 45788
4222 459 45882
4222 459 52311
4222 459 52251
4222 459 52241
4222 459 52321
4222 459 52261
4222 459 52271
4222 459 52281
4222 459 52291
9965 100 55822*
4222 459 52301
Paddle
Bread pan suitable for appliances before week 1208
Bread pan suitable for appliances after week 1208
Control panel assy
Lid assy
Spoon
Measuring cup
Hook
5 pieces of crimp housing 2 wire connection
Main PCB
Power Supply PCB
12 pieces of Screw cover
Heating element, fuses, sensor assy
Sensor
Fuses
Motor assy suitable for appliances before week 1208
Motor assy suitable for appliances after week 1208
Base incl. power cord
* When replacing a bread pan, a new motor assy must be ordered as well, since the new
bread pan is not compatible with the old motor assy. Note that the 9965 100 55821 is also
supplied when ordering the 4222 459 45779. It is to be decided locally if it is economical
feasible to execute such expensive repair.
= changed

HD9020
3-4
EXPLODED VIEW
2
11
1
5
6
7
3
4
A
A
Z

HD9020
4-4
EXPLODED VIEW
11
10
9
8
15
16
12
Z
BB
B
B
B
B
B
BBB
BB
C
4x
D
6x
14
13
