Philips CEM220/55 User manual

Register your product and get support at CEM220
EN Quick Start Guide
34
2
A1 A2 A3 A4 A5 A6 A7 A8
B1 B2 B3 B4 B5 B6 B7 B8
A
AB
abcd
B
b
a
c
d
aa
bcd
ab
ef
cd
ghi
b
c
d
1ab
efg
c
h
d

5
5mm
5mm

Overview of parts 1
These are the supplied parts needed to
connect and install this unit.
1 In-car audio system
2 Sleeve
3 Front panel
4 Standard connector
5 Trim plate (2 pieces)
6 Rubber cushion
7 Disassembly tools
8 Screws 4 pieces
Connect wires
Caution
Ensure that all loose leads are insulated with
electrical tape.
•
For cars with ISO connectors 2 3
1Pull out the ISO connectors from car
dashboard and connect them to the bigger
end of the supplied standard connector.
2Connect the other end of the supplied
standard connector to the unit.
3Connect the antenna and amplifier as
illustrated, if applicable.
Connector Connect to
1 REAR LINE OUT R Rear right
speaker
2 REAR LINE OUT L Rear left speaker
3 SUB OUT Subwoofer
4 ANTENNA Antenna
For cars with ISO connectors 3 4
Caution
Be sure to connect the black ground (earth)
lead first.
•
1Connect the antenna and amplifier as
illustrated, if applicable.
2Cut off the bigger end of the supplied stan-
dard connector.
3Check the car’s wiring carefully and connect
them to the supplied standard connector.
4Connect the supplied standard connector to
the unit.
1Green/black
strip
Left speaker
(Rear)
2 White/black
strip
Left speaker
(Front)
3 Gray/black
strip
Right speaker
(Front)
4 Purple/black
strip
Right speaker
(Rear)
eRED Ignition key +12V DC
when ON/ACC
fBLUE Motor/electric antenna
relay control lead/
Amplifier relay control
lead
gBLACK Ground
h Orange/
white
Illumination switch
i YELLOW To the +12V car battery
which is energized at all
times
Note
Check wire connection before you mount
the unit into a car.
If preset radio stations are lost when the
ignition key is turned OFF and then back
ON, reconnect the red leads crosswise to
the yellow ones.
•
•
Attach the front panel 5
1Insert the right side of the panel in the
chassis until it is correctly engaged.
2Press the left side of the panel and point
the left hole at the left pillar.
3Release the panel to engage the left side.
4Attach the trim plate.
Mount in the dashboard 5
1If the car does not have an on-board drive
or navigation computer, disconnect the
negative terminal of the car battery.
If you disconnect the car battery in a car
that has an on-board drive or navigation
computer, the computer may lose its
memory.
If the car battery is not disconnected,
to avoid short-circuit, ensure that bare
•
•
wires do not touch each other.
2Remove the two screws on the top of the
unit.
3Remove the mounting sleeve with the
supplied disassembly tools.
4Ensure that car dashboard opening is
within these measurements:
5Install the sleeve into the dashboard and
bend the tabs outward to fix the sleeve.
6Place the rubber cushion over the end of
the bolt.
7Slide the unit into the dashboard until you
hear a click sound.
8Reconnect the negative terminal of the car
battery.
Turn on
1Press
zto turn on the unit.
To turn off the unit, press zfor 3
seconds.
Set clock
1Press MENU/DISP for 3 seconds.
2Press
3 or 4repeatedly to until the cur-
rently time is displayed.
3Tu r n
zclockwise to set hour.
4Press
zto confirm.
5Tu r n
zanti-clockwise to set minute.
6Press
zto confirm.
View clock
1Press MENU/DISP repeatedly until the clock
is displayed.
•

Listen to radio
1Press SOURCE repeatedly to select Radio.
2Press or to select band: [FM1], [FM2],
[FM3], [AM1], or [AM2] .
3Press ∞or §to tune to a radio station
manually.
To search for a radio station
automatically, press SEARCH.
Play audio files
1Press on the front panel to release the
panel.
2Insert a CD with the printed side facing up.
3Close the panel.
4Press
2; , to start play.
To pause CD play, press 2; .
To resume CD play, press 2; again.
Insert the USB device
1Open the cover marked on the front
panel.
2Insert the USB device into the USB socket.
»ToThe unit starts playing from the USB
device automatically.
Insert SD/MMC card
1Press to release the panel.
2Insert the SD or MMC card into the card
slot.
»The unit starts playing from the SD/
MMC card automatically.
•
•
•
© 2008 Koninklijke Philips Electronics N.V.
All rights reserved.
