Philips AJ6000/05 User manual

Register your product and get support at
www.philips.com/welcome
Always there to help you
AJ6000/05
User manual
Question?
Contact
Philips

2
Contents
1 Important 3
2 Your clock radio 3
What's in the box 3
Overview of the main unit 4
3 Get started 5
Connect power 5
Set time 6
Turn on 6
4 Listen to FM radio 7
Tune to FM radio stations 7
Store FM radio stations manually 7
Store FM radio stations automatically 7
Select a preset radio station 7
5 Other features 8
Set alarm timer 8
Set sleep timer 9
Play audio from an external device 9
Adjust display brightness 9
6 Product information 10
Specications 10
7 Troubleshooting 10
8 Notice 11
EN

3EN
1 Important
Warning
•Never remove the casing of this clock radio.
•Never lubricate any part of this clock radio.
•Never place this clock radio on other electrical
equipment.
•Keep this clock radio away from direct sunlight, naked
amesorheat.
•Make sure that you always have easy access to the
power cord, plug or adaptor to disconnect the clock
radio from the power.
• Make sure that there is enough free space
around the product for ventilation.
• The clock radio shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
clockradio(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Only use power supplies listed in the user
manual.
• Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries when the unit is not
used for a long time.
• The batteries should not be exposed
toexcessiveheatsuchassunshinere
or the like.
2 Your clock radio
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
What's in the box
AJ6000
User Manual
www.philips.com/welcome
Always there to help you
Registeryour product and get support at
Question?
Contact
Philips

4EN
Overview of the main unit
a SOURCE
• Select a source.(FM/AUDIO IN)
• Press and hold for 3 seconds to switch
to standby mode.
b SLEEP
• Set sleep timer.
c SNOOZE/BRIGHTNESS
• Snooze alarm.
• Adjust display brightness.
d Display panel
• Show current information.
e AL1/AL2
• View alarm settings.
• Activate or deactivate alarm timer.
a
b
c
d
j
e
f
g
h
i
k
l
m
NIOIDUA
f VOLUME +/-
• Adjust volume.
g First Knob (HOUR/PRESET)
• Adjust hour.
• Select a preset radio station.
h Second Knob (MINUTE/TUNING)
• Adjust minute.
• Tune to an FM radio station.
• Skip to the previous or next track.
i Third Knob (SET TIME/SET RADIO/
CLOCK/SET AL1/SET AL2)
• Set clock.
• Scan/store FM radio stations.
• Set alarm.

5EN
j BUZZ/FM/SOUND 1/SOUND 2
• Select an alarm source for Alarm 1 and
Alarm 2.
k (5.0 V 1 A)
• Charge your iPod/iPhone through USB
cable (not included).
l AUDIO IN
• Connect an external audio device.
m FM ANT
• Improve FM reception.
3 Get started
Always follow the instructions in this chapter in
sequence.
Connect power
The unit can only be powered by supplied AC
power. Batteries are only used for alarm backup
if not connected with AC power.
Option 1:AC power
Warning
•Risk of product damage! Make sure that the power
supply voltage corresponds to the voltage printed on
the back or the underside of the unit.
•Risk of electric shock! When you disconnect the AC
power, always pull the plug from the socket. Never pull
the cord.
Connect the AC power cord to the wall socket.
Tip
•To save energy, turn the unit off after use.

6EN
Option 2: Battery power
Caution
•Batteries contain chemical substances, so they should
be disposed of properly.
Note
•Batteries are not supplied with the accessories.
•bAt shows on the display when the battery level is low.
1 Open the battery compartment.
2 Insert 2 batteries (type: 1.5V LR6/AA) with
correct polarity (+/-) as indicated.
3 Close the battery compartment.
Set time
1 Rotate the Third Knob to "SET TIME" to
activate clock setting mode.
» Hour and minute digits blinks.
2 Rotate the First Knob to adjust the hour.
3 Rotate the Second Knob to adjust the
minute.
4 Press OK on the First Knobtoconrm.
» The setting time is displayed.
5 Rotate the Third Knob to CLOCK after
setting.
» The hour and minute digits stops
blinking.
Turn on
The clock radio turns on automatically once
your plugged in.
Switch to standby mode
Press SOURCE for 3 seconds to switch to
standby mode.
» The source indicator on the display
panel turns off.

7EN
4 Listen to FM
radio
Tune to FM radio stations
Tip
•Position the antenna as far as possible from TV,VCR, or
other radiation source.
•For better reception, fully extend and adjust the
position of the antenna.
Note
•Make sure that the Third Knob switched to CLOCK
before setting.
1 Press SOURCE repeatedly to select FM
tuner source.
» FM on the display panel lights up.
2 Rotate and hold the Second Knob for two
seconds.
» The clock radio tunes to a station with
strong reception automatically.
3 Repeat step 2 to tune in to more radio
stations.
To tune to a station manually:
Rotate the Second Knob repeatedly until you
ndoptimalreception.
Store FM radio stations
manually
1 In FM mode,rotate the Third Knob to
"SET RADIO".
» FM begins to blink.
2 Rotate and hold the Second Knob for 2
seconds.
» The last selected channel show on the display.
3 Rotate the First Knob again to select the
target preset position.
4 Press OK on the First Knobtoconrm.
5 Repeat steps 2-4 to store other stations.
Note
•To remove a pre-stored station, store another station
in its place.
Store FM radio stations
automatically
Note
•You can store a maximum of 20 FM radio stations.
1 In FM mode, rotate the Third Knob to
"SET RADIO".
» FM begins to blink.
2 Press an hold OK on the First Knob for 3
seconds.
» The clock radio stores all the available
FM radio stations, and broadcasts the
rstavailablestationautomatically.
Select a preset radio station
Note
•Make sure that the Third Knob switched to CLOCK
before setting.
1 Press SOURCE repeatedly to select FM
tuner source.
» FM on the display lights up.
2 Rotate the First Knob repeatedly to select
a preset radio station.

8EN
5 Other features
Set alarm timer
In standby mode, you can set two alarms to ring
at different time.
Note
•Make sure that you have set the clock correctly.
1 Rotate the Third Knob to SET AL1 or SET
AL2 to activate alarm setting mode.
» The / and time digits blink.
2 Rotate the First Knob to adjust the hour.
3 Rotate the Second Knob to adjust the
minute.
4 Press OK on First Knobtoconrm.
5 Rotate the Third Knob to CLOCK after
setting.
Select alarm source
For alarm sound, you can select buzzer, or your
last listened radio chanel.
Tip
•If FM is selected as the alarm source and the unit is
playing under FM mode, buzzer will sound when alarm
time comes.
Activate/deactivate alarm timer
Note
•Make sure that the Third Knob switched to CLOCK
before setting.
1 Press AL1/AL2 to view alarm settings.
» The / lights up.
2 Press AL1/AL2 again to activate or
deactivate the alarm timer.
» The / appears if alarm timer is
on and disappears if it is off.
• To stop the ringing alarm, press the
corresponding AL1/AL2.
» The alarm repeats ringing for the next
day.
Snooze the alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing
nine minutes later.
ALARM
MF
BUZZ 12

9EN
Set sleep timer
Note
•Make sure that the Third Knob switched to CLOCK
before setting.
This clock radio can switch to standby mode
automatically after a preset period.
• Press SLEEP repeatedly to select the sleep
timer period (in minutes).
» When the sleep timer is activated,
appears.
To deactivate the sleep timer:
• Press SLEEP repeatedly until [OFF] (off)
appears.
Play audio from an external
device
Note
•Make sure that the Third Knob switched to CLOCK
before setting.
You can listen to audio from an external device
through this clock radio.
1 Connect an audio cable to:
• the AUDIO IN socket on the clock
radio.
• the headphone socket on an external
device.
2 Press SOURCE repeatedly to select the
Audio-in source.
» The on the display panel lights up.
3 Play the external device (refer to its user
manual).
15 30 60 90 120
OFF
Adjust display brightness
SNOOZE
BRIGHTNESS

10EN
6 Product
information
Note
•Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 1W RMS
Tuner
Tuning Range FM: 87.5 - 108
MHz
Sensitivity
- Mono, 26dB S/N Ratio
FM: <22 dBf
Search Selectivity FM: <30 dBf
Total Harmonic Distortion FM: <3%
Signal to Noise Ratio FM: >50 dBA
General information
Power supply
- AC Power
- Battery
Model:
ASSA36B-050250;
Input: 100-240 V ~,
50/60Hz, 0.6A;
Output: 5.0V 2500 mA
2 x AA batteries
Operation Power
Consumption
<15 W
Standby Power
Consumption
<1 W
Dimensions - Main
Unit (W x H x D)
195 x 99 x 123 mm
Weight - Main Unit 0.65 kg
7 Troubleshooting
Warning
•Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support).When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.
No power
•Ensure that the power cord is connected
securely.
•Ensure that there is power at the power
supply socket.
•Ensure that the batteries are installed
correctly.
No response from the clock radio
•Disconnect and reconnect the AC power
plug, then turn on the clock radio again.
Poor radio reception
•Keep the clock radio away from other
electronic devices to avoid radio
interference.
•Fully extend and adjust the position of the
FM antenna.
Alarm does not work
•Set the clock/alarm correctly.
Clock/alarm setting erased
•Power has been interrupted or the power
plug has been disconnected.
•Reset the clock/alarm.

11 EN
8 Notice
This product complies with the radio
interference requirements of the European
Community.
Anychangesormodicationsmadetothis
device that are not expressly approved by
WOOX Innovations may void the user’s
authority to operate the equipment.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment and
human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
Note
•The type plate is located on the bottom of the
apparatus.

Specifications are subject to change without notice
2014 © WOOX Innovations Limited.
All rights reserved.
Philips and the Philips’ Shield Emblem are registered
trademarks of Koninklijke Philips N.V. and are used by WOOX
Innovations Limited under license from Koninklijke Philips N.V.
AJ6000_05_UM_V2.0
