Philips DVDR3305/02 User manual

Published by KC-TE 0530 AV Systems Printed in the Netherlands Subject to modification EN 3139 785 31440
DVDR3305/02/05/19/51
DVD-Video Recorder
CLASS 1
LASER PRODUCT
Contents Page
1 Technical Specifications and Connection Facilities 2
2 Service Flow chart 4
3 Firmware Upgrading / version verification 9
4 Directions For Use 10
©Copyright 2005 Philips Consumer Electronics B.V. Eindhoven, The Netherlands.
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic,
mechanical, photocopying, or otherwise without the prior permission of Philips.
Version 1.0
Front Line Instruction
DVDR3355/02/05/19/51 & DVDR3365/02/05/19/51

EN 2 3139 785 3144x
1. Technical Specifications and Connection Facilities
1. Technical Specifications and Connection Facilities
1.1 General:
Mains voltage : 220V – 240V
Mains frequency : 50 Hz
Power consumption (typical) : 25 W
Standby Power Consumption : < 4 W
1.2 RF Tuner
Test equipment: Fluke 54200 TV Signal generator
Test streams: PAL BG Philips Standard test pattern
1.2.1 System
PAL B/G, PAL D/K, SECAM L/L’, PAL I
1.2.2 RF - Loop Through:
Frequency range : 45 MHz – 860 MHz
Gain: (ANT IN -ANT OUT) : -6dB to 0dB
1.2.3 Receiver:
PLL tuning with AFC for optimum reception
Frequency range : 45.25 MHz – 857 MHz
Sensitivity at 40dB S/N : ≥60dBμV at 75 Ω
(video unweighted)
1.2.4 Video Performance:
Channel 25 / 503,25 MHz,
Test pattern: PAL BG PHILIPS standard test pattern,
RF Level 74dBV
Measured on SCART 1
Frequency response : 0.1 – 4.00 MHz ± 3dB
Group delay (0.1 MHz - 4.4 MHz) : 0 nsec ± 150 nsec
1.2.5 Audio Performance:
Audio Performance Analogue - HiFi:
Frequency response at SCART 1
(L+R) output : 100 Hz – 12 kHz / 0 ±
3dB
S/N according to DIN 45405, 7, 1967
and PHILIPS standard test pattern
video signal : ≥50dB, unweighted
Harmonic distortion (1 kHz, ± 25
kHz deviation) : ≤1.5%
Audio Performance NICAM:
Frequency response at SCART 1
(L+R) output : 40 Hz – 15 kHz / 0 ±
3dB
S/N according to DIN 45405,7,1967
and PHILIPS standard test pattern
video signal : ≥60dB, unweighted
Harmonic distortion (1kHz) : ≤0.5%
1.2.6 Tuning
Automatic Search Tuning
Scanning time without antenna : typ. 3 min.
Stop level (vision carrier) : ≥37dBμV
Maximum tuning error of a recalled
program : ± 62.5 kHz
Maximum tuning error during
operation : ± 100 kHz
Tuning Principle
Automatic B, G, I, DK and L/L’ detection
Manual selection in “STORE” mode
1.3 Analogue Inputs / Outputs
1.3.1 SCART 1 (Connected to TV)
Pin Signals:
1 - Audio R 1.8V RMS
2 - Audio R
3 - Audio L 1.8V RMS
4 - Audio GND
5 - Blue / GND
6 - Audio L
7 - Blue out
8 - Function switch < 2V = TV
> 4.5V / < 7V = asp. Ratio 16:9 DVD
> 9.5V / < 12V = asp. Ratio 4:3 DVD
9 - Green GND
10 - NC
11 - Green 0.7Vpp ± 0.1V into 75Ω(*)
12 - NC
13 - Red GND
14 - Fast switch GND
15 - Red out 0.7Vpp ± 0.1V into 75Ω(*)
16 - Fast switch
RGB / CVBS < 0.4V into 75Ω= CVBS
>1V / < 3V into 75Ω= RGB
17 - CVBS GND OUT
18 - CVBS GND IN
19 - CVBS out 1Vpp ± 0.1V into 75Ω(*)
20 - CVBS in
21 - Shield
1.3.2 SCART 2 (Connected to AUX)
Pin Signals:
1 - Audio R 1.8V RMS
2 - Audio R
3 - Audio L 1.8V RMS
4 - Audio GND
5 - Blue GND
6 - Audio L
7 - Blue in
8 - Function switch
9 - Green GND
10 - NC
11 - Green in
12 - NC
13 - Red GND
14 - Fast switch GND
15 - Red in
16 - Fast switch
RGB / CVBS
17 - CVBS GND OUT
18 - CVBS GND IN
19 - CVBS / RGB
out sync 1Vpp ± 0.1V into 75Ω(*)
20 - CVBS in
21 - Shield
(*) for 100% white

EN 3
3139 785 3144x 1.
Technical Specifications and Connection Facilities
1.3.3 Audio/Video Front Input Connectors
Audio - Cinch
Input voltage : 2.2Vrms
Input impedance : > 10kΩ
Video - Cinch
Input voltage : 1Vpp ± 3dB
Input impedance : 75Ω
Video - YC (Hosiden)
According to IEC 933-5
Superimposed DC-level on pin 4 (load > 100kΩ)
< 2.4V is detected as 4:3 aspect ratio
> 3.5V is detected as 16:9 aspect ratio
Input voltage Y : 1Vpp ± 3dB
Input impedance Y : 75Ω
Input voltage C : burst 300mVpp ± 3dB
Input impedance C : 75Ω
1.3.4 Audio/Video Output rear Connectors
Audio - Cinch
Output voltage : 2Vrms max.
Output impedance : > 10kΩ
Video - Cinch
Output voltage : 1Vpp ± 3dB
Output impedance : 75Ω
Video - YC (Hosiden)
According to IEC 933-5
Superimposed DC-level on pin 4 (load > 100kΩ)
< 2.4V is detected as 4:3 aspect ratio
> 3.5V is detected as 16:9 aspect ratio
Output voltage Y : 1Vpp ± 10/-15%
Output voltage C : 300mVpp ± 1/-4dB
1.4 Video Performance
All outputs loaded with 75 Ω
SNR measurements over full bandwidth without weighting.
1.4.1 SCART (RGB)
SNR : > -65dB on all output
Bandwidth : 4.8MHz ± 2dB
1.5 Audio Performance CD
1.5.1 Cinch Output Rear
Output voltage 2 channel mode : 2Vrms ± 2dB
Channel unbalance (1kHz) : < 1dB
Crosstalk 1kHz : > 95dB
Crosstalk 16Hz-20kHz : > 87dB
Frequency response 20Hz-20kHz : ± 0.2dB max
Signal to noise ratio : > 85dB
Dynamic range 1kHz : > 83dB
Distortion and noise 1kHz : > 83dB
Distortion and noise 16Hz-20kHz : > 75dB
Intermodulation distortion : > 70dB
Mute : > 95dB
Outband attenuation: : > 40dB above 30kHz
1.5.2 Scart Audio
Output voltage 2 channel mode : 1.6Vrms ± 2dB
Channel unbalance (1kHz) : < 1dB
Crosstalk 1kHz : > 85dB
Crosstalk 16Hz-20kHz : > 70dB
Frequency response 20Hz-20kHz : ± 0.2dB max
Signal to noise ratio : > 80dB
Dynamic range 1kHz : > 75dB
Distortion and noise 1kHz : > 75dB
Distortion and noise 16Hz-20kHz : > 50dB
Intermodulation distortion : > 70dB
Mute : > 80dB
Outband attenuation: : > 40dB above 25kHz
1.6 Digital Output
1.6.1 Coaxial
CDDA / LPCM (incl MPEG1) : according IEC958,
IEC60958-1,-3
MPEG2, AC3 audio : according IEC1937,
IEC61937
DTS : according IEC1937,
IEC 61937
amendment 1
1.7 Digital Video Input (IEEE 1394)
1.7.1 Applicable Standards
Implementation according:
IEEE Std 1394-1995
IEC 61883 - Part 1
IEC 61883 - Part 2 SD-DVCR (02-01-1997)
Specification of consumer use digital VCR’s using 6.3 mm
magnetic tape - dec. 1994
Annex A of 61883-1
1.8 Dimensions and Weight
Height of feet : 5.5mm
Apparatus tray closed : WxDxH:435x285x65mm
Apparatus tray open : WxDxH:435x422x65mm
Weight without packaging : app. 4.0kg ± 0.5kg
Weight with packaging : app. 6kg
1.9 Laser Output Power & Wavelength
1.9.1 DVD
Output power during reading : 0.8mW
Output power during writing : 20mW
Wavelength : 660nm
1.9.2 CD
Output power : 0.3mW
Wavelength : 780nm

EN 4 3139 785 3144x
2. Service Flow Chart
2. Service Flow Chart
2.1 Start Process
Start
A
(Verification
Test)
Is it a
Hardware
problem ?
Upgrade to latest
Firmware
Is it a known
complaint ?
Is Firmware
solution
available ?
Yes
No
Yes
No
Yes
No
Is the
complaint
solved ?
Store defective sets & awaits for
collection service from Central Repair
Firmware Upgraded
Return set to
Customer
Yes
No
Send refurbished set from pool
stock to Trade / customer
Is the complaint
documented ?
Yes
No
Return set to customer with
Special Instructions:
Examples:
- Firmware solution is not
ready
- Upgrade disc will be send
to him the moment solution
is ready
Record the following information & attach
together with the defective set:
- Form containing the complaint /
symptom (including how to re-produce
the complaint)
- sale's receipt (or purchase date &
name of shop)

EN 5
3139 785 3144x 2.
Service Flow Chart
* If complaint is related to
System Menu setting
Connect up the Recorder
to TV antenna, TV set
and an External source
Yes
No
No
Check the Firmware
version on the set
Can the set
Start-up ?
Yes
No
Yes
No
A
(Verification
Test)
B
Recording
Check
C
Playback
Check
D
System Menu
*
Can the
complaint be
reproduced ?
Upgrade to latest
Firmware
Is Firmware
solution
available ?
Yes
Yes
Is the
complaint
solved ?
Store defective sets & awaits for
collection service from Central Repair
Send refurbished set from pool
stock to Trade / customer
Record the following information & attach
together with the defective set:
- Form containing the complaint /
symptom (including how to re-produce
the complaint)
- sale's receipt (or purchase date &
name of shop)
Is Firmware the
last released
version ?
No
Firmware Upgraded
Return set to
Customer
2.2 Verification Process

EN 6 3139 785 3144x
2. Service Flow Chart
Does Timer
recording
fuctions ?
Yes
No
Does manual
recording
functions ?
Yes
No
B
Recording
Check
Make a Timer recording with:
1) VPS/PDC on and off
2) Show View manually
3) Show View System
4) external Cable Box/Satellite
Receiver
Playback the recorded disc to check
A
re Timer edit &
delete feature
working ?
Yes
No
Make a manual recording using:
1) different Rec Source:
- Front CVBS
- Front S-Video
- DV
- Ext 1
- Ext 2
2) with OTR automatic turn-off
feature on and off
Playback the recorded disc to check
Does Disc
Editing
functions ?
1) Insert a recorded DVD+R/+RW disc
2) Press Top Menu button and check the
Disc editing features
Examples:
- Play
- Erase Disc (DVD+RW only)
- Record New Title
Note: The displayed option in the disc
editing menu differ depending on the
situation & disc type
1) Play a recorded DVD+R/+RW disc
2) Press Disc Menu button and check Title
editing features
Examples:
- Play Title
- Erase Title
Note: The displayed option in the disc editing
menu differ depending on the situation & disc
type
Does Title
Editing
functions ?
Continue
Continue
Yes
No
Yes
No
Store defective sets & awaits for
collection service from Central Repair
Send refurbished set from pool
stock to Trade / customer
Record the following information & attach
together with the defective set:
- Form containing the complaint /
symptom (including how to re-produce
the complaint)
- sale's receipt (or purchase date &
name of shop)
2.3 Recording Process

EN 7
3139 785 3144x 2.
Service Flow Chart
Yes
No
C
Playback
Check
Playing other type of disc:
- (Super) Video CD
- Audio CD
- DVD+R/+RW disc
- DivX (except DVDR3305)
- MP3 disc
- Picture disc (or musical slide show)
1) Playing the DVD video disc and
check the following;
- change another title/chapter /track
- pause & search functions
2) Using T/C option check:
- repeat/shuffle functions
- change audio soundtrack language
- change subtitle language
Yes
No Does the set
work ?
Does it detect /
playback JPEG /
MP3 files ?
Playing from USB flash drive/USB
memory card reader (DVDR3365 only)
Does the set
work ?
Continue
Continue
Yes
No
Store defective sets & awaits for
collection service from Central Repair
Send refurbished set from pool
stock to Trade / customer
Record the following information & attach
together with the defective set:
- Form containing the complaint /
symptom (including how to re-produce
the complaint)
- sale's receipt (or purchase date &
name of shop)
2.4 Playback Process

EN 8 3139 785 3144x
2. Service Flow Chart
D
System Menu
Check
Does the
set work ?
Continue
Yes
No
Setup System Menu - General and
check the following features:
- Screen Saver
- Country
- Video Ouput Format
- Restore Factory settings
Setup System Menu - Clock and check
the following features:
- Date and Time
- Show DivX registration code
Setup System Menu - General and
check the following features:
- TV Aspect Ratio
- Parential Rating Level
- Digital Audio Output
Setup System Menu - Channel Setup
and check the following features:
- Channel Search
- Modify Channel Information
- Sort Channel
Setup System Menu - Language and
check the following features:
- On Screen Display Language
- Default Disc Menu Language
- Default Subtitle Language
- Default Audio Language
Setup System Menu - Recording and
check the following features:
- set Auto Chapter Marker
- set Default Recording Source
- set Default Recording Mode
Store defective sets & awaits for
collection service from Central Repair
Send refurbished set from pool
stock to Trade / customer
Record the following information & attach
together with the defective set:
- Form containing the complaint /
symptom (including how to re-produce
the complaint)
- sale's receipt (or purchase date &
name of shop)
2.5 System Menu Process

EN 9
3139 785 3144x 3.
Firmware Upgrading / version verification
3. Firmware Upgrading / version verification
A. Preparation to upgrade firmware:
1. Unzip the zip-archive file
2. Start the CD Burning software and create a new CD project
(data disc) with the following settings:
File system : Joliet
Format : MODE 1: CDROM
Recording mode : SINGLE SESSION (TRACK-
AT-ONCE), FINALIZED CD
Note: Long file name is necessary for the preparation of the
upgrade disc
3. Place the content of the zip-archive into the root directory of
the new CD project.
4. Burn the data onto a blank CDR or CD-RW
B. Procedure to apply the firmware upgrade:
1. Power up the set and open tray.
2. Insert the prepared Upgrade CDROM and close the tray.
3. The TV connected to the set will display:
Software Upgrade Disc detected
Select OK to start or CANCEL to exit
4. Select OK or CANCEL with the <Right> or <Left> button and
press <OK> button to confirm.
5. The TV connected to the set will display:
Upgrading Software, Please wait
Do not switch off the power
6. When the upgrading process is successful the tray will open
and the TV connected to the set will display:
System is successfully upgraded.
Remove disc from tray & reset system
7. Remove the Upgrade Disc and press <OK> button on
Remote control to confirm
8. The TV screen goes blank and the Philips Logo screen
appear again after the tray door has closed.
C. How to Restore Factory setting (Default setting)
1. Power up the set and with no disc in the tray
2. Press <System Menu> <Right> and 4x <Down> buttons on
the Remote control to reach the Restore Factory setting
option.
3. Press <OK> button and the TV connected to the set will
display:
System will reset to the Factory settings.
Select OK to confirm or CANCEL to exit.
4. Select OK or CANCEL with the <Right> or <Left> button and
press <OK> button to confirm.
Note: All customers’ settings will be lost.
D. How to read out the firmware version to confirm
set has been upgraded.
1. Power up the set and with no disc in the tray
2. Press <0009> and <OK> buttons on the Remote control
3. The TV connected to the set will display:
DVDR3365_75_BT3_2, Drive: 43.02.11 Build:
FAE6206 Apr 21 2005, 18:49:43
where DVDR3365_75 = Type/version
BT3_2 = Application (Backend) firmware
version
43.02.11 = Drive (Basic Engine) firmware
version

EN 10 3139 785 3144x
4. Directions For Use
The following except of the Quick Use Guide serves as an introduction to the set.
The Complete Direction for the Use can be downloaded in different languages from the internet site of Philips Customer care Center:
www.p4c.philips.com
4. Directions For Use
QUICK START GUIDE 12nc: 3139 246 15861
DVDR3365
1 what’s in the box
2 connect DVD recorder
A
Main Unit
RF coaxial
cable
CD
includes 2x AA batteries
Scart cable
B
Remote
Control
2a Connect existing antenna cable/satellite signal (or from
the Cable/Satellite Box [RF OUT or TO TV]) to the
ANTENNA input socket at the back of the DVD
recorder.
2b Use the supplied RF coaxial cable to connect the DVD
recorder’s TV output socket to your TV’s antenna
input socket.
2c Use the supplied Scart cable to connect the DVD
recorder’s EXT 1 TO TV-I/O socket to the matching
SCART input socket at the back of your TV.
2d Connect the power cable from the DVD recorder’s
~ MAINS to the AC power outlet.
Helpful Hint:
For additional connection diagrams, see User
Manual pages 12~19.
3 Start initial setup
DVD recorder back panel
2a
2b
2d
System Menu - Channel Setup
Modify Channel Information
Search
Edit
System Menu - Language
Default Disc Menu Language
Default Subtitle Language
On Screen Display Language
English
Default Audio Language
English
English
English
System Menu - Clock
Time (hh:mm:ss}
Show DivX® Registration Code
Date (dd/mm/yy)
31/01/05
10 : 33 : 57
OK
Sort Channel
Sort
Channel Search
System Menu - General
Video Output Format
Screen Saver
On
Restore Factory Settingd
Germany
PAL
OK
Country
3a Press STANDBY-ON 2on
the DVD recorder to turn it on.
Note: For successful installation,
your cable/satellite box must be
turned on.
3b Turn on the TV to the correct
programme channel for the
input socket (‘EXT’,‘0’,‘AV’).
➜The blue PHILIPS DVD
background screen will appear on
the TV.
3c Press SYSTEM MENU on the
remote control.
➜Use 34keys to go through the
menu. Select an item by pressing 2,
and confirm a setting by pressing
OK.
3d Highlight and press 2.
Select the country of your
residence..
Select { Country } and press OK
on the remote control.
3e Highlight and press 2.
Setup and install TV channels.
Select { Channel Search } and
press OK on the remote control
to start automatic TV channel
search.
3f Highlight and press 2.
Select the language.
– select TV On-Screen Display
language.
– select default Disc Menu language.
– select default subtitle language.
– select default audio language.
3g Highlight and press 2.
Set the Date and Time.
Use the numeric keypad 0-9 to
input the date/time, then press OK
to confirm.
3h Press SYSTEM MENU to exit.
The DVD recorder is ready for use!
See next page for basic recording and playback.
2c

EN 11
3139 785 3144x
4 start manual recording 5 start playback
NEED HELP? Read the accompanying User Manual or visit our website www.philips.com/support
To playback a disc
5a Insert a disc with the label side
facing up.
5b Playback may start automatically.
If not, press PLAY 2.
➜If a disc menu appears,
use 1234keys to navigate
within the menu, highlight a title and
press OK to start playback.
5c To stop playback, press
STOP 9.
To watch the TV
programmes
5d Press REC SOURCE to select
{ Tuner }, then use 34keys to
select the programme number.
GET SOUND
•Use the supplied scart cable to connect the DVD recorder to
your TV, the picture and sound will output through the TV.
•Or, connect the AUDIO L/R (red/white) sockets at the back of the
DVD recorder to the corresponding AUDIO input sockets on a
TV, stereo system or receiver. Turn on the connected system and
select the appropriate channel.
GET PICTURE
•Check the AV mode on TV. It may be called FRONT,A/V IN, or
VIDEO. Choose the different modes using TV remote control.
•Or, use the TV remote control to select Channel 1 on TV, then
press Channel down button until you get the picture.
•See your TV manual for more details.
4a Insert a recordable
DVD+R/+RW with the label
facing up.
4b To record TV programme, press
REC SOURCE to select
{ Tuner }.
To record from an external
device connected to this DVD
Recorder, press REC SOURCE
repeatedly to select the
corresponding external input
channel : { Front CVBS }
{ Front S-Video }, { DV },
{ EXT 2 }.
4c Press REC MODE to select a
desired recording mode.
It defines the picture quality and
the maximum recording time
for a disc.
4d Press REC 0to start recording.
4e To pause the recording, press ;.
To resume recording,
press REC 0.
To stop the recording, press
STOP 9.
➜Wait until the message
disappears from the display panel
before you remove the disc.
SUPER VIDEO
Record
Mode
Picture Quality
Maximum Recording
Time per Disc
1 Hour Mode
2 Hour Mode
4 Hour Mode
6 Hour Mode
High quality
DVD quality-Standard Play
VHS quality-Extended Play
VHS quality-Super Long Play
1 hour
2 hours
4 hours
6 hours
4.
Directions For Use
