Philips VR6670 User manual

otitis
STOP__ VPS START
cassette RUcKtaur @ERMEDEaReC sToP VORLAUF PAUSE —_STARTZEIT STOPZEIT
Le]
|
PHILIPS
[cs]
‘STANDSILD
‘OTR
VIDEO-RECORDER
VR
6670
\NDAIE
HUAUUUUHT
4
VR6670
VIDEO RECORDER
VIDEO-RECORDER

PSESLLLISLE
cassette RUcKLaur QI STOP VORLAUF PAUSE — STARTZEIT STOPZEIT MEMO «UHR PROG SUCHEN
PHILIPS

CONTENTS
Section 1. INTRODUCTION page
On Screen Display (OSD) page.
Explanation of buttons & controls page
Section 2 INSTALLATION page
Safety precautions page
Playback of a cassette page
Section 3. SHORT DESCRIPTION OF BUTTONS AND
CONTROLS page 7
Section 4 MANUAL RECORDING OF TV ;
PROGRAMMES page 10
One Touch Recording (OTR) page 11
Section 5 TIMED (UNATTENDED) RECORDING ~
OF TV PROGRAMMES page 13
Video Program System page 16
Section 6 OTHER RECORDING POSSIBILITIES page 17
Section 7 REMOTE.CONTROL OF THE
VIDEO RECORDER page 17
Section 8 CASSETTES. page 18
Section 9 BEFORE YOU CALL THE REPAIRMAN — page 20
Section 10. . TECHNICAL DATA “page 22
Using this book
All numbers in bold type 1, 2, 3, etc. refer to the main
illustrations on the inside front cover.
This video recorder incorporates a display which shows
various information. Examples of display readings are used
throughout this text. However, the actual readings will vary
according to the situation at any particular time. ‘
Remember: Only use cassettes of a well-known brand which
carry the VHS-logo.
VHS
PAL SECAM -
Packed with this video recorder are:
- Antenna cable
- Remote control unit AV5623
OwWw N+
English
@ Your VHS video recorder is one of the most sophisticated yet
simple-to-use home video recorders you can buy.
Features
e@ Video Programm System (VPS)
This video recorder has been equipped with a VPS decoder. VPS
(Video Program System) is the system of the future. It controls.
the video recorder so that timed recordings will be made at the
exact moment the TV programme starts, even if the start time
(and therefore also the stop time) has been delayed or changed.
(See Section 5 for detailed information.)
@ On Screen Display (OSD) *
This video recorder has also been equipped with the so called |
‘On Screen Display’ system. By displaying on the TV screen all
kinds of useful information, this interactive system eases the
installation and operation of your video recorder.
The system informs you about the tape transport modes of the
video recorder, or it tells you what has to:be done to programa -
timed recording.
The On Screen Display system shows: 5 ots
The current time; Black and white test pattelh: Searching for and
storing TV stations; Tuner only mode; Tape transport modes;
Eject and go-to-zero; Tape counter position; Programming a
timed recording.
Each time the video recorder is switched on, the OSD system is
operative. If OSD is not required, it can be switched off by ©
pressing the OSD © button on remote control unit AV5623.
Important
- The OSD information is only visible on the TV screen when the -
TV set has been tuned to the video recorder and when the .-
pre-selector for the video recorder has been ealacied on the TV
set (see Section 2).
- Some OSD information, e.g. for tape transport modes, is only |
displayed for a few seconds after the mode has-been selected.’
Press button @ once more if:you want to have the OSD
information again.
- Other OSD information, e.g. during programming a timed
recording, is displayed until the whole step is completed.
@ General
- Many buttons (for example Play, Wind, Rewind, Up + or
Down —) will automatically switch on the video recorder; it is not
necessary to press On/Standby | () button 24 first.
- It is possible to use your video recorder as a TV tuner if you | ‘
leave your TV tuned to the video recorder channel. Up to 48 TV
stations can be selected using the Up.+ /Down — buttons 2 and
3 or using the digit buttons (0-9) on the remote control unit.
If you have a TV set without a cable TV tuner, you can receive
cable WV transmissions via your video recorder.
@ If your dealer did not install the video recorder refer to -
‘installation’.
Whatever your situation; it is suggested that you read Section 3°
to familiarise yourself with your video recorder’ s Ope ation
@ If something happens which you do not expect, or don’t |
understand, refer to Section 9 - ‘Before you call the repairman’:

Explanation of buttons and controls’
1 Display
2 + **Up +
3 - **Down —
4 ©) * Timer |
5 Search (SUCHEN) |
6 Store (SPEICHERN)
7 * Clock/Programme selector
(UHR/PROG.)
8 * Channel/Programme selector |
-. (KANAL/PROG.)
9 =... Memory (MEMO)
10 — +* Reset (RUCKST.)
11... .. * Tracking.
12 Set clock (UHR STELLEN) -
13 @ * Record (AUFNAHME)
14... * Fast motion (ZEITRAFFER)
15.=«. * Slow motion (ZEITLUPE)
16 2 * OTR (STOPZEIT)
17, * Delayed OTR (STARTZEIT)..
18 HE. =* Pause/Still picture
(PAUSE/STANDBILD)
19 >> /@) * Wind/Picture search forward
(VORLAUF)
20 a : Stop
21 > * Play (WIEDERGABE)
22 <4/G * Rewind/Picture search reverse
= (RUCKLAUF) ©
23 A Eject (CASSETTE)
241() * On/Standby
Rear... cov
25 @) AV Euroconnector
26. +/- .. Sharpnesscontrol —
27. Service bus.
: Antenna out socket
28
29 IT Antenna in socket
30 -Channel output adjuster
Additional functions via remote control unit
only —
0- Q Digit buttons:
-/--._ One/two digit ently
+> Goto
q "Play reverse
* Buttons marked * can aS be operated using the infra- ted
remote control unit: oe
** To enter desired values directly (e.g. channel or programme
number, time, etc.) you can use the digit buttons (0-9):on the-:
remote control unit instead of the +/-— buttons.
Note:
See Section 3 for a short description of the buttons and controls.
es
Explanation of Display information
‘CASS’ :
No cassette loaded
‘STOP’: : Stopp all functions
‘WIED’ : Play
‘LGS’ — : Slow motion
‘SCHN’: : Fast motion
‘STND' : Still picture
‘BSL’: Picture search
‘AUFN’ .: Record
‘PSE’: Pause
‘VOR’: Wind
‘RUE’ : Rewind
‘GOTO’ : Goto tape counter position
‘TEST’ : Generating test picture ~ :
‘SPER’ : Protected cassette inserted
‘SSL’: Searching for.a station sie
‘SSP’: Storing a station”
‘UHR’ = : Time when setting the clock.
‘JAHR’ : Year when setting the clock
‘MON::: : Month when setting the clock
‘DAT’: Date when setting the clock
‘TAG’: Weekday when setting the clock
‘BL X*- : Programming block number: .
‘STRT’ : Start time when setting the timer
‘STOP’, : Stop time when setting the timer:
‘DAT’ _: Date when setting the timer
‘TGL’.- : Daily recording when setting the timer. -
‘WOCH’ : Weekly recording when setting the timer
‘PROG’ : Programme number when setting the timer+:
‘P--’ : Programme number during OTR setting
Eastern European reception oaaee East)
‘Your video recorder is equipped forthe. recepiion of. ae
transmissions on the PAL colour TV standard as well as East
European transmissions (see Technical Data):
For the:recorded programmes to be reproduced in colour, the. ,
colour. TV connected must be equipped to receive both ©
‘standards. :
Your video pabarder will switch automatically from PAL to Eastern
European reception and vice versa.
Note:
Video cassettes recorded on the French SECAM colour system .
can only be reproduced in black-and-white. This is a cechinica.
limitation arid:not a fault in your video recorder. ns

If your dealer did not install and set up the video recorder for you,
follow the instructions in this section.
Once the video recorder is installed, you can stil use the TV set
in the normal way.
Safety precautions
@ First check that your supply voltage is the same as that given
on the type plate at the rear.
@ To avoid risk of fire or electric shock, do not expose this video
recorder to rain or moisture.
@ Ensure that no objects or fluids pass through the ventilation
openings. If liquid is spilt into the video recorder, disconnect the
video recorder from.the mains and consult a qualified service
technician.
@ Dangerous voltage inside. Do not open the cabinet. There are
no serviceable parts inside. Repairs should be carried out by
avaliiod: service personnel only.
Precautions
The manufacturer cannot be held reliable for damages which are
incurred by not using the video recorder in compliance with the
guarantee conditions and/or safety instructions.
@ The video recorder must be positioned in such a way that
additional heating by an external source of heat (radiatior, etc.) is
avoided.
Ensure that there is at least 20 cm between the video recorder
and.the TV. set, and that air can circulate freely through the
ventilation openings of the video recorder. .
@ Avoid using your video recorder immediately after moving it
from a cold to a warm location, or soon after heating a cold place,
or under conditions of high humidity.
e@ Avoid using:the video recorder. on soft surfaces or near
appliances generating strong magnetic fields (e.g. motors,
transformers).
e@ Do not use the video recorder i in dusty digces or Where it may
be subject to vibration.
@ If you have to transport your-video recorder, do not leave a :
video cassette loaded and avoid violent aber
Connections
“ANN
Pore
@ Remove the antenna cable from the TV set and plug it into the
Antenne in If socket 29 at the back of the video recorder.
@ Take the antenna cable supplied and connect it from the
Antenne out socket ( 28 of the video recorder to the antenna ~
socket IF of the TV set.
Extra connection possibilities
Connecting your video recorder to the TV set or to a second
video recorder via the AV Euroconnector ;
@ if your TV set has an AV Euroconnector socket, you may find
that you can improve the picture quality during playback by
connecting this socket to AV Euroconnector @) 25 on the video
recorder.
@ See the Operating Instructions for your TV set for the exact
location of such a socket, and how to select the AV mode.
Consult your dealer for the correct Eurocable.
Connection to the mains
@ Connect the mains lead of the video recorder to the mains
supply.
After a few seconds, a time and day indication will appear on
Display 1.
Notes:
- If the Display shows any other indication, just press On/Standby
| © button 24.
- If a mains failure occurs while your video recorder is being used,
it will always continue the previous operation as soon as the
mains power is restored.
@3

Setting the clock/calendar
(A) Press Set clock (UHR STELLEN) button 12.
Display 1 shows ‘UHR’.
e@ Use the Up + and/or Down — buttons 2 and 3 to set the
correct time.
(Pressing either of these buttons once alters the time slowly;
keeping either button pressed changes the time quickly.)
The time is shown in 24-hour form; for example, nine minutes
past five in the afternoon is shown as ‘17:09’. .
Press the Set clock (UHR STELLEN) button again.
The Display shows ‘JAHR’.
e@ Use the Up + and/or Down — buttons to set the correct year.
© Press the Set clock (UHR STELLEN) button again.
me display shows ‘MON’.
e Use the Up + and/or Down —.buttons to set the correct
month ae 12).
() Press the Set clock (UHR STELLEN) button once more.
The display shows ‘DAT’.
@ Use the Up + and/or Down — buttons to set the correct date
(1-31). :
© Press the Set clock ae STELLEN) button once more.
The display:shows ‘TAG’. - :
@ Use the Up + and/or Down — buttons to set the correct
weekday (Su, Mo, Tu, etc.).
) Press the Set clock. (UHR STELLEN) button one more time to
complete the clock/calendar setting. . i
The clock/calendar is now set and will remain accurate even if the
video recorderis disconnected from the mains supply for up to 3
months.
4 @®
Tuning the TV set to the video recorder
Important!
If the TV set and the video recorder are connected via their
Euroconnectors only, select the AV input on your TV set (see the
Operating Instructions of the TV set) and proceed to ‘Searching
for and storing TV stations’.
(roy
| Tn Tl
i
e@ Your video recorder is equipped with a modulator. In order to
receive the video recorder signal, you have to tune the TV set to:
the video recorder as follows:
@) Switch on the TV set.
®) Check whether the recaniion of the TV ‘stations has been *:*:
changed in picture quality (disturbed or weakened snowy
picture). This might be the case when that paeuler) TV station is
broadcasting around channel 37 UHF. ste Gin) acim
In this case proceed as follows:
© Turn, with a small screwdriver, the 30-39.channel adjuster 30°
on.the rear of the video’recorder (to the left or the nah) Baul Ane
TV station is received-properly..
If Deeeoeay repeat this procedure.
(©) Press Play (WIEDERGABE) > button 21.
Attention: There should be NO cassette in thee cassette holder..
Display 1 shows ‘TEST’.
© Most modern TV sets have a number.of pre-selector buttons
(or pre-selector numbers) used to select'TV stations. One of
these pre-selectors should be reserved for the video recorder
signal; refer to.the TV Operating Instructions to determine which
pre-selector button or number to choose.. :
) Tune this pre-selector button or number until the TV set
shows a picture-which has this black and white pattern:
VCR
TESTBILD
Note:
if your TV set has auto search tuning, you now have to store this
channel on the chosen pre-selector number (see the TV
Operating Instructions).

Searching for and storing TV stations
@ Your video recorder is equipped with an FST (Frequency
Synthesized Tuning) system allowing direct channel selection
using the remote control unit.
@ You can store up to 48 TV stations in the video recorder’s
memory.
Situation:
@ The TV set.is switched on, and tuned to the video recorder
channel.
@
Press
Stop
li
button
20
to
set
the
video
recorder
in
the
stop
mode.
You can now store the TV stations using either Method 1 or 2
below:
Method 1 - ‘Electronic search’
(A) Press Search (SUCHEN) button 5.
The video recorder starts searching across the wavebands for a
TV channel. The display shows ‘SSL’ and an incrementing
channel number. Also a programme number between 1 and 48 is
shown.
The TV screen shows:
SENDER-SUCHLAUF
KA58
e once a TV station has been found, the Display shows ‘SSP’
and the channel number found. The programme number flashes.
The programme being broadcast is shown.
On the TV screen the OSD information ‘WAEHLE
PROGRAMMNUMMER UND DRUECKE ”SPEICHERN”’ (select
programme number and press Store button) is shown:
SENDER SPEICHERN
WAEHLE PROGRAMMNUMMER
UND DRUECKE “SPEICHERN”
Check which TV station has been found by comparing the
programme with the stations on your TV set.
@ You can do this by pressing the pre-selector buttons (or
selecting the pre-selector numbers) on the TV until you have
found the same programme.
© Assign a programme number to this TV station (any number
between 1 and 48 is possible).
Note: ,
Use the same numbers as on the Corresponding pre-selector
button (or number) on your TV.
@ You can do this by pressing the Up + and/or Down — buttons
2 and 3 as necessary until the Display and the TV screen show
the number you wish to assign to this TV station.
SENDER SPEICHERN
WAEHLE PROGRAMMNUMMER
UND DRUECKE “SPEICHERN”
®) Press Store (SPEICHERN) button 6 if you want to store this
TV station under the chosen programme number.
Notes:
- If the picture on the TV is poor, this channel is ; too weak to be
received properly. In this case press Search (SUCHEN) button 5
again.
- If no TV channel is found, the search can be stopped by
pressing Stop IM button 20. In this case check your antenna
connections.
@ If you want to store all the TV stations you require (maximum
48), select the pre-selector for the video recorder again and
repeat steps (a) to ©.
Method 2 - ‘Direct channel selection’
@) Press Channel/Programme (KANAL/PROG.) button 8 to .
select the channel mode.
The
Display
shows
‘C’
followed
by
a
channel
number
and
the
TV
screen
shows:
3033
4 KEINE CASSETTE
KA 10
11:36
®) Select the desired channel number using either the Up +
and/or Down — buttons 2 and 3 or the digit buttons (0-9) on the -
remote control unit.
For special channels see the table on the next page.
Note:
if
you
use
the
remote
control
unit
to
select
a
single
digit
channel
number,
for
example
2,
you
have
to
enter
‘02’
” pressing
the
digit
buttons
0
and
2.
:

© Press Store (SPEICHERN) button 6 to store this TV station... -
The Display shows ‘SSP’ and the programme number flashes. -
On the TV screen the OSD information ‘WAEHLE
PROGRAMMNUMMER UND DRUECKE ”SPEICHER”’ (select
programme number and press Store button) is shown:
SENDER SPEICHERN - KA16
PRO4
WAEHLE PROGRAMMNUMMER
UND DRUECKE “SPEICHERN”
©) Assign a programme number to this TV station (any number
between 1 and 48 is possible).
Note: ;
Use the same numbers as on nthe corresponding pre-selector
buttons (or numbers) on your TV.
@ You can do this by pressing the Up + Mandir Down: > buttons
2 and 3 as necessary until the Display and the TV screen show
the programme number you wish to assign to this TV station.
© Press the Store (SPEICHERN) button once more to store the
TV station under the chosen programme number.
@ Repeat steps @) to © to store all the TV stations you require
(maximum 48).
General notes:
- Pressing any cassette deck button eee the search and store
mode.
- Once you have stored all TV stations required, you can use the
Up +/Down ~ buttoris to select thesé stations.
When indication ‘E’ is shown on the Display, this indicates
external Euroconnector input.. ~
- If you store a TV station under a programme number that is... .
already used, the new station will be stored, and the old one will
be deleted.
This can be useful if you find better reception of a TV station
which has already been stored.
Special channels
With cable TV the following channel numbers have to be entered
for the special channels.
Special Select Special... ......Select
enamine. : channel
$1 80 “= $21 “400
$2 81 $22" 101
$3 82 $23 102
$4 83 $24 103 :
$5 84 $25 104
S6 85 $26 105
$7 86° $27 106
$8 ‘87 $28 “107
$9 88 $29 108°
$10 89 $30 109 .
$i 90 $31 4110
$12 91 $32 111
$13 92 $33 112
$14 93 $34 113
$15 94 $35 114
$16 95 S36 115
$17 96 $37 116
$18 97 $38 117
$19 98 $39 118
$20 99 $40 119
$41 120
6 @)
Playback of a cassette
Situation:
@ The TV set is switched on, and ’
@ The pre-selector for the video recorder channel is selected.
Loading a cassette
A) Hold the cassette with the title label facing you and the fs g
window side up, and push it gently into the cassette holder; the
video recorder is switched on automatically.
The Display shows ‘STOP’ and the cassette-loaded (eg)
indicator.
The TV screen shows:
® Press Play (WIEDERGABE) > button 21. The recorded
programme will be shown on your TV set.
The Display shows ‘WIED’ and the TV screen shows:
» WIEDERGABE

©
Press
Stop
ll
button
20
to
stop,
or
press
Eject
(CASSETTE)
4
button
23
to
eject
the
cassette.
:
@
lf
the
cassette
is
ejected
on
the
TV
screen
the
OSD
Pn
information
‘KEINE
CASSETTE’
(no
cassette
loaded)
is
shown:
4 KEINE CASSETTE
You
can
press
any
button
after
any
other
without
pressing
Stop
M@
button
20
in
between,
without
harming
the
cassette
or
the
video
recorder.
: ;
BS
oy"
10:06
1 Display
@
The
Display
comprises
several
indicators
which
show
the
current operation, for example ‘PSE’.
@
When
the
video
recorder
is
in
standby,
the
Display
shows.the
current
time
and
weekday.
(If
the
Display
shows
the
wrong
time,
set
the
clock
as
described
inSection2.)
.
General
note:
ine
During
playback
the
may
be
affected
by
disturbances.
This
can
be
soived
as
follows:
@
When
setting
the
clock
or
programming
the
timer,
the
Display
shows
the
information
you
are
changing.
The
previous
mode
will
be
displayed
again
when
the
new
instructions
have
been
completed.
@ Press Tracking button 11. :
The
video
recorder
will
then
find
the
optimal
playback
quality,
during
which
time
the
sound
is
temporarily
muted.
This
function
can
be
stopped
at
any
time
by
pressing
Play
(WIEDERGABE)
>
button
21.
:
.
a
@
When
the
video
recorder
is
on
you
can
select
the
time
display
@
When
the
end
of
the
tape
is
reached
in
any
playback
mode,
the
|
using
Clock/Programme
(UHR/PROG.)
button
7.
Ths
tape
is
automatically
rewound.
‘
‘
@
The
tape
counter
position
is
also
shown
when
the
video
recorder
is
on.
This
is
automatically
reset
to
zero
after
rewinding
a
cassette.
:
2 and 3 Up + and Down —
With
these
buttons
the
following
can
be
changed:
-
the
required
TV
channel/programme
numbers
-
clock/month/day
(in
set
clock
mode)
~
programming
data
(in
program
mode).
4 Timer ©
Press
this
button
to
preprogram
a
recording.
See
Section
5
for
more
information.
5 Search (SUCHEN)
Press
this
button
to
search
for
TV
stations.
See Section 2 for more information.
6 Store (SPEICHERN)
With
this
button
you
can
store
your
preferred
TV
stations
during
installation.
See
Section
2
for
more
information:
7
Clock/Programme
selector
(UHR/
PROG.)
When
this
button
is
pressed
you
can
switch
between
the
following
display
information:
ye
-
the
current
TV
channel/programme
number,
or
-
the
current
time
(in
hours
and
minutes).
8
Channel/Programme
selector
(KANAL/
PROG.)
Press
this
button
to
switch
betweén
channel
and/or
programme
_
numbers.
,
The
Display
shows
‘C’
(except
for
Hyperband)
and
a
channel
number
or
‘P’
and
a
programme
number.
The
TV
screen
shows
‘KA’
and
a
channel
number
or
‘PR’
anda
programme
number.
:
9 Memory (MEMO)
@ Press the Memory button.
The
Display
and
the
TV
screen
show
‘M’
and
the
tape
counter
position.
if
The
video
recorder
will
now
stop
when
the
tape
counter
reaches
‘0’
during
the
wind
and
rewind
modes.
@
Press
the
Memory
button
again
to
switch
off
the
memory
function.

Note:
To reset the tape counter to ‘0’ you have to press Reset
(RUCKST.) button 10 (e.g. during playback) at the desired tape
position.
10 Reset (RUCKST.) If a tape counter value is shown, pressing
this button resets it to ‘0’.
When setting the clock/calendar, pressing this button resets the
time to 20:00.
When programming a recording, pressing this button resets the
start and/or stop time to 20:00, the date to the present date or
switches the VPS control on or off.
This button is also used to.cancel a ‘recording block’ during
programming. First select the block to be cancelled, using the Up
+ and/or Down — buttons 2 and 3 or the digit buttons on the
remote control.
11 Tracking
Press this button if the piehare is affected by disturbances during
play functions.
This function can be.stopped at any time by pressing Play
(WIEDERGABE) > button 21.
(During this mode the sound is muted.)
12 Set clock (UHR STELLEN)
Press this button to set the clock/calendar.
See Section 2 for more information. °
13 Record (AUFNAHME) @
Press this button to start a recording.
The Display shows ‘AUFN’ and the TV screen shows:
@ AUFNAHME
PR 03
On the Display the channel/programme number flashes for a few
seconds to remind you to check that it is the correct TV station
for recording.
See Sections 4 and 5 for detailed information.
14 Fast motion (ZEITRAFFER)
When this button is pressed, the picture will be played back at 3
times the normal speed.
(During this mode the sound is muted. )
The Display shows ‘SCHN’ and the TV screen shows:
> ZEITRAFFER
8 @)
15.Slow motion (ZEITLUPE)
Press this button to play back the tape in slow motion.
The Display shows ‘LGS’ and the TV screen shows:
{> ZEITLUPE
16 OTR (STOPZEIT) 4
With this button you can make a Saé Touch Recording which
starts immediately and stops at a chosen time in 30 minute steps.
See Section 4 for more information.
17 Delayed OTR (STARTZEIT)
With this button you can make a One Touch Recording but sa
can
choose
the
start
time
(delay
time)
yourself.
:
See Section 4 for more information.
18 Pause/Still picture (PAUSE/STANDBILD) Hi. :
@ When this button is pressed during playback, a still picture is
shown. Each time you press this-button, the tape advances a few
frames at normal speed and a new still picture is shown (‘frame
advance’).
The Display shows ‘STND’ and the TV screen shows:
wm STANDBILD
@ If this button is pressed continuously, the tape is played back
in super slow motion.
The Display shows ‘LGS’ and the TV screen shows:
\> ZEITLUPE
Note:
If the still picture ‘bounces’, keep Tracking button 11 pressed
until this effect is eliminated.
@ When button Ellis pressed during a recording, the tape
movement stops temporarily.
The Display shows ‘PSE’ and the TV screen shows:
gm PAUSE
PR O3
If you later continue recording (within 8 minutes), you will get a
clean continuation or ‘automatic assembly’.

Note:
The video recorder automatically enters the stop mode after 8:
minutes in either pause or still mode to avoid tape wear.
Example:
- Press Pause/Still picture (PAUSE/STANDBILD) Bll button from
the play mode.
The Display shows ‘STND’ and a still picture from the tape is
shown on the TV screen together with the OSD information
“STANDBILD’ (still).
If a recording with a clean continuation is wanted from this point,
proceed as follows:
- Press Record (AUFNAHME) @ button 13.
The Display shows ‘PSE’ and the TV screen shows ‘PAUSE’.
- Select the required programme number (or indication ‘E’ for
Euroconnector input). On the TV the picture from a TV broadcast
(or another video recorder via Euroconnector) is shown.
(You can select ‘E’ by pressing + button 2 after programme
number ‘48’ appears or pressing — button 3 after programme
number ‘1’ appears or pressing button -@ on the remote
control.) : :
- Press Record (AUFNAHME) @ button 13 again to start the
recording.
19 Wind/Picture search forward (VORLAUF) >>/@)
@ Press this button from the stop mode to wind the cassette
forwards at high speed (without picture or sound from the tape).
The Display shows ‘VOR’ and the TV screen shows:
>» VORLAUF
PRO1
11:01
@ Press this button from the play or record mode to play the
cassette forwards at high speed or to quickly find a particular
scene. It is quite normal for some bars of ‘noise’ to be visible on
the picture.
(During this mode the sound is reduced.)
The Display shows ‘BSL’ and the TV screen shows:
>> BILDSUCHLAUF 2025
Note: tons ;
If you use the remote control unit you can make a direct choice,
independent from the present video recorder mode. :
20 Stop M
Press this button to stop the tape movement.
The Display shows ‘STOP’ and the TV screen shows:
21 Play (WIEDERGABE) >
When this button is pressed, the cassette is played back.
The Display shows ‘WIED’.and the TV screen shows:
> WIEDERGABE
(If no cassette is loaded, the Display shows ‘TEST’, and the
black-and-white test pattern is shown on the TV set.)
22 Rewind/Picture search reverse (RUCKLAUF) 44/2
@ Press this button from the stop mode to wind the cassette
backwards at high speed (without picture or sound from the
tape).
The Display shows ‘RUE’ and the TV screen shows:
<44RUECKLAUF
PR 02
41:17
@ Press this button from the play or record mode to play the
cassette backwards at high speed and to quickly find a particular
scene. It is quite normal for some bars of ‘noise’ to be visible on
the picture.
(During this mode the sound is reduced.)
The Display shows ‘BSL’ and the TV screen shows:
<KBILDSUCHLAUF
Note:
If you use the remote control unit you can make a direct choice,
independent from the present video recorder mode.
GB) 9

23 Eject (CASSETTE) &
Press this button to eject the cassette from the video recorder. ©
The Display shows ‘CASS’ and the TV screen shows: ~
2000
@& KEINE CASSETTE
PR 02
12:14
24 On/Standby | ()
Pressing this button switches the ¥ideo recoraee on or in the .
standby mode: When the video recorder is in-standby, the Display
still shows the current time and weekday.
@ The video recorder should remain connected to the mains at all
times to ensure that timed recordings can be made and to enable
normal TV reception.
26 Sharpness control + /— (on rear)
Adjust this control during playback for a ‘sharper’ or ‘softer’
picture according to your preference.
10 @®
Note:
If you want to display the OSD information select on the TV the
pre-selector reserved for the video recorder. ;
@) Press Up + and/or Down — buttons 2 and 3 to select the TV
station to record from.
@ If necessary, select indicatin ‘E’ to record the input from an
external source via the AV Euroconnector @ 25.
(You can select ‘E’ by pressing Up + button 2 after programme
number ‘48’ appears or pressing Down — button 3 when after
programme number ‘1’ appears or pressing button +) on the
remote control.) fe .
Load an unprotected cassette and wind or rewind as
necessary.
The Display and the TV screen show ‘STOP’ and on the Display
the cassette-loaded [@g@) indicator lights up.
© Press Record (AUFNAHME) @ button 13 when the TV
programme starts.
The Display shows ‘AUFN’ and the channel/programme number’
flashes for a few seconds.
The TV screen shows:
@ AUFNAHME
PR 03
Note: ;
The channel/programme number can be changed even after the
recording has started.
©) If you want to interrupt the recording temporarily, press
Pause/Still picture (PAUSE/STANDBILD) 8M button 18.
The Display shows ‘PSE’ and the TV screen shows:
gp PAUSE ~
PR 03
@ Press the Record (AUFNAHME) @ button again (within 8 -
minutes) if you want to resume recording. This ensures a clean
continuation (‘automatic assembly’).
e@ Press Stop & button 20 to stop the recording, or Eject
(CASSETTE) & button 23 to eject the cassette.

General notes:
-
If
the
cassette
loaded
is.
protected,
it
willbe
ejected
and
‘SPER’
flashes
on
the
DISpiey:
ane
TV
screen
schows
‘CASSETTE
-
GESPERRT’.
-
If
no
cassette
is
loaded,
‘CASS’
flashes
on
the
Display
and
‘KEINE
CASSETTE’
flashes
on
the
TV
screen.
-
The
cassette
is
automatically
ejected
when
the
end
of
the
tape
is
reached.
-
You
do
not
have
to
have
your
TV
switched
on.
However,
if
itis
on,
you
can
change
to
another
TV
station
on
your
TV
without
interfering
with
the
programme
being
recorded.
-
If
you
want
to
let
the
video
recorder
finish
the
recording
automatically,
see
‘One
Touch
Recording’
below.
One Touch Recording (OTR)
This
feature
is
useful
if
for
example
you
are
already
watching
a
TV
programme,
and
you
want
to
start
a
recording
immediately
for
a
pre-determined
time
and
then
let
the
video
recorder
switch
to
standby
automatically.
@
Make
sure
that
the
correct
channel/programme
number
has
been
selected.
:
@ Press OTR (STOPZEIT) EJ button 16 to start recording.
The
Display
shows
‘AUFN’,
‘OTR’
and
a
stop
time
(the
stop
time
indicated
is
the
current
time
plus
30
minutes).
On
the
TV
screen
the
OSD
information
‘WAEHLE
"STOPZEIT”’
(select
stop
time)
is
shown:
OTR OHNE WARTE ZEIT .
START
19:25
STOP
WAEHLE “STOPZEIT”
The channel/programme number flashes for a few seconds to
remind
you
to
check
that
this
is
the
correct
TV
station
for
recording.
(If necessary, change the channel/programme number.)
@ Each time you press the OTR (STOPZEIT) E] button, another
30 minutes will be added to the stop time.
If
you
go
too
far,
press
the
OTR
(STOPZEIT)
EZ
button
until
you
see
the
current
time
pius
30
minutes
again
(‘
Step
through’).
—
Note:
:
When
the
current
time
plus
30 minutes
is
reached
the
video
recorder
goes
into
the
pause
mode
for
about
8
seconds.
After
that
the
OTR
stop
time
should
be
entered
again.
When the stop time is reached, the video recorder switches to
standby automatically.
If
the
end
of
the
tape
is
reached,
the
cassette
is
automatically
ejected.
@
The
OTR
recording
is
cancelled
immediately
if
you
press
any
cassette
deck
button
(other
than
Record
(AUFNAHME)
@
button
13).

Delayed OTR
With this feature, the start time of an OTR recording can be
delayed. : ;
(A) Press Delayed OTR (STARTZEIT) ll button 17. |
The Display shows: ‘OTR’, the programme number to be
recorded and the time at which the recording is to start (to the
nearest half hour).
On the TV screen the OSD information ‘WAEHLE ’STARTZEIT”
UND ’STOPZEIT”’ (select start and stop time) is shown:
OTR MIT WARTEZEIT —
START.
19:26
STOP
WAEHLE "STARTZEIT”
UND ’STOPZEIT”
® Each time you press the Delayed OTR (STARTZEIT) lf button
again, the start time of the recording will be delayed by anomner
half hour (maximum 23,5 hours).
The TV screen shows:
OTR MIT WARTEZEIT 19:26
START STOP
WAEHLE "STARTZEIT”
UND “STOP ZEIT”
Example:
- If you press button ill at 18:48, the recording. will start at the first
complete half hour, which is 19:00.
- Press button ill again. The recording start time will be delayed
for another half hour.
If you go too far, wait a few seconds.and press Delayed OTR -
(STARTZEIT) i button 17 again. —
©r Press OTR (STOPZEIT) EJ button 16 to set the stop.time of
the recording. .
The TV screen shows:
OTR MIT WARTEZEIT 19:27
START STOP
WAEHLE “STARTZEIT”
UND *STOPZEIT”
@ |fno OTR value is chosen within 8 seconds after pressing the
Delayed OTR (STARTZEIT) al button, the delayed OTR mode will
be cancelled automatically.
The previous mode is shown again.
® Ifnecessary, adjust the programme number.
12 @®
Notes:
- If the maximum delay time for a delayed OTRis selected (23,5 .
hours) the recording will be made the following day, but the day
indicator on the Display remains unchanged.
- If you have loaded a protected cassette, ‘SPER’ flasheson the
Display and the TV screen shows ‘CASSETTE GESPERRT’.
- If no cassette has.been loaded, ‘CASS’ flashes on the Display
and ‘KEINE CASSETTE’ flashes on the TV screen.
- During the waiting time before the delayed OTR recording takes
place, the video recorder can be operated normally. However, the
recording will only start if the video recorder is in the standby
mode.
- If the video recorder.is used manually at the time a delayed OTR
recording is to be made, the ‘OTR’ indicator flashes on the
Display.
Press Record (AUFNAHME) @ button 13 to confirm that the
recording is to be made or press delayed OTR (STARTZEIT) fall
button 17 once to cancel the delayed OTR function.
- If the end of the tape is reached during recording, the cassette
is atomatically ejected.

You
can
program
the
video
recorder
to
switch
itself
on
and
record
a
TV
programme
at a
particular
time,
and
on
a
particular
date
up
to
30
days
in
advance,
or
every
week,
or
every
day.
Note:
Your
TV
set
need
not
be
switched
on,
but
if
you
want
to
use
the
OSD
system
you
have
to
switch
on
the
TV
set
and
select
the
pre-selector
reserved
for
the
video
recorder.
@
A'timed
recording
will
only
be
made
if,
at
the
time
it
is
due
to
take
place,
the
video
recorder
is
in
the
standby
mode
and
an
unprotected
cassette
is
loaded.
@
This
video
recorder
is
equipped
with
a
VPS
decoder,
which
means
timed
recordings
will
be
controlled
by
a
VPS
code
sent
out
by
the
transmitter.
;
‘
For
further
details
see
the
information
at
the
end
of
this
section.
Programming
a
timed
recording
©
eS
Details
of
the
TV
programmes
to
be
automatically
recorded
are
-
Stored
in
‘programming-blocks’.
;
There
are
4
blocks
available,
so
you
can
program
the
video
recorder
to
record
4
different
TV
programmes
at
different
times.
(A)
Press
Timer
©
button4.
_
.
Display
1
shows
the
first
free
block
(for
example
‘BL
1’).
On
the
TV
screen
the
OSD
information
‘WAEHLE
BLOCKNUMMER.
WEITER
MIT
“TIMER”-TASTE’
number
and
press
Timer
button)
is
shown:
(select block
WAEHLE BLOCKNUMMER
WEITER
MIT
"TIMER"-TASTE
Note:
If
no
block
is
free;
the
Display
shows
‘BL
1
=’
and
on the
TV
screen
the
information
for
all
blocks
will-be
displayed.
Select
the
block
you
want
to
program
using
the
+
and/or.
—
buttons
2
and
3
or
the
digit
buttons
(0-9)
on
the
remote
control.
©
Press
the
Timer
©
button
again
to
enter
the
block
to
be
programmed.
The
Display
shows
‘STRT’
and
a
start
time.
On
the
TV
screen
the
OSD
information
‘WAEHLE
STARTZEIT.
WEITER
MIT
“TIMER”-TASTE?
(select
start
time
and
press
Timer
button)
is
shown:
WAEHLE STARTZEIT
WEITER
MIT
“TIMER”-TASTE
@
Use
the
Up
+
and/or
Down
—
buttons
or
the
digit
buttons
on
the
remote
control
to
set
the
correct
start
time.
(Pressing
the
Up
+
or
Down
—
buttons
once,
changes
the
time
by
one-minute.
.
;
Keeping
the
Up
+
or
Down
—
buttons
pressed,
changes
the
time
rapidly.)
.
(As
a
short
cut,
press
Reset
(RUCKST.}
to
20:00.)
button.
10
to.set
the
time
©)
Press
the
Timer
©
button
again.
3
The
Display
shows
‘STOP’
and
the
previous
programmed
start
time
is
shown.
: ; ;
On
the
TV
screen
the
OSD
information
“WAEHLE
STOPZEIT.
WEITER
MIT
“TIMER”-TASTE’
(select
stop
time
and
press
Timer
button)
is
shown:
he
WAEHLE
STOPZEIT
WEITER
MIT
“TIMER™-TASTE
e
Use
the
Up.
+
or
Down
=
buttons
or
the
digit
buttons
on the
remote
control
to
set
the
stop
time.
. :
©
Press
the
Timer
©
button
again.
The
Display
shows
‘DAT’
and
a
date.
On
the
TV
screen
the
OSD
information
‘WAEHLE
DATUM.
WEITER
MIT
*TIMER”-TASTE’
(select
date
and
press
Timer
button)
is
shown:
a
; :
20:15 21:50
WAEHLE DATUM
WEITER
MIT
“TIMER”-TASTE
@
Use
the
Up
+
or
Down
—
buttons
or
the
digit
buttons
on
the.
remote
control
to
set
the
date
on
which
you
want
the
recording
to
start.
:
; : :
@) 13

Notes:
-
‘Tis
the
first
of
the
month,
‘2’
the
second
and
so
on
up
to‘31’.
- If today is the 16th of the month and you program the date a as
‘14’, recording will be made on the 14th of next month.
- Press Reset (RUCKST.) button 10 to set the date to today.
- For a TV programme starting at midnight, remember to give the
following date.
- If for a TV programme the given VPS start time is after midnight,
the date of the following day must be selected.
- Select indication ‘TGL’ on the Display and on the Vs screen for a
daily recording to be made at the same time every-day until the
block is You can select ‘TGL’ by pressing Up + button 2 once
after indication ‘31’ is shown.
(Selecting the block to be cleared can only be done using the Up"
+ or Down — buttons or the digit buttons on the remote
control.) ;
- Select on the Display indication ‘WOCH’ and the correct
weekday or TV screen for instance ‘SU’ for a weekly recording to
be made every the same day and at the same time until the block
is cleared.
You can select ‘WOCH’ and the correct weekday by pressing
Down =~ button 2 one or more times after indication ‘1’ is shown.
(Selecting the block to be cleared can only be done using the Up
+ or Down — buttons or the digit buttons on the remote
control.)
) Press the Timer © button again.
The Display shows ‘PROG’ and the last programmed TV station.
On the TV screen the OSD information ‘WAEHLE PROGRAM
UND VPS. WEITER MIT ”TIMER’-TASTE’ (select programme
number and press Timer button) is shown:
BL START STOP DATUM, PR
FEEL
20:15 = 21:50 09 Svesoic
WAEHLE PROGRAMM UND VPS
WEITER MIT “TIMER’-TASTE
@ In addition, on the Display and the TV screen the ‘VPS’
indicator light up to indicate that the VPS control has been
switched on for this block.
By pressing Reset (RUCKST.) button 10 you can switch off the
VPS control for this block (indication ‘VPS’ is no longer lit) or
switch it on again.
Notes:
- When the VPS control is switched on the video recorder will go
into recording standby 28 hours (maximum) before the
programmed start time. If the TV station does not transmit a VPS
code the VPS control will automatically be out of operation. The
recording will then be carried out in accordance with the
programmed start and stop times.
- If during programming the VPS control has been switched off,
the video recorder will switch on at the programmed time, start
recording and stop at the programmed stop time. Any VPS code
transmitted by the TV station cannot control the video recorder.
@ Use the Up + or Down — button or the digit buttons on the
remote control to select the correct TV station from which to
record.
14 G@
© Complete the programming by pressing the Timer © button
once more.
The Display returns to its previous indication and ‘TIMER’ is lit.
On the TV screen the OSD information ‘PROGRAMMIERUNG
FERTIG’ (programming completed) is shown:
BL START STOP DATUM PR
20:15 = 21:50 09 VPSOi
PROGRAMMIERUNG FERTIG
@)
Press
On/Standby
|
()
button
24
to
confirm
that
the
timed
-
recording
is
to
be
made.
Notes:
- The Display and the TV screen may also show a warning: -
‘CASS’
flashing
on
the
Display
and.
‘KEINE
CASSETTE’
flashing
on the TV screen indicate that no cassette is loaded.
‘SPER’
flashing
on
the
Display
and
‘CASSETTE
GESPERRT’
on
°
the TV screen indicate that a protected cassette is loaded.
-
Timed
recordings
will
be
made
in
sequence
of
their
start
times
(except
VPS).
-
If
the
end
ofthe
tape
is
reached
during
recording,
the
cassette
©
is
aurcmanicahy
ejected.
Important
@ You can still use the video recorder normally after
programming
a
timed
recording,
but
be
sure
to
switch
the
video
recorder to standby by pressing On/Standby button | © 24
before the programmed recording take place.
@ If the VPS control is switched on, it is possible that you will see
the TV programme again after pressing the On/Standby |
button. This happens when the TV set is switched on and the
pre-selector
reserved
for
the
video
recorder
is
selected.
The
VPS
control is then searching for the VPS signal.
(See Video Programm System at the end of this section.)
® If the video recorder is used manually when a timed recording
is due to take place, ‘TIMER’ flashes on the Display.
® Press On/Standby @ button 24 to start the timed
recording.
Note:
Once a timed recording has started, the video recorder is
protected against accidental manual operation.
If you want to stop a timed recording which is in progress, first
press Timer © button 4 and then Reset (RUCKST.) button 10.

Example of timer programming
* Current time
Checking or changing block details
You can check or change the details of a block as follows:
@) Press Timer © button 4.
On the TV screen the number of a block flashes and the OSD
information ‘WAEHLE BLOCKNUMMER. WEITER MIT
*TIMER”-TASTE (select block number and press Timer button) is
shown:
BL START STOP
09 =VPS01
03. VPSO3
12 02
14. VPSO4
WAEHLE BLOCKNUMMER
WEITER MIT “TIMER”-TASTE
Use the Up + or Down — buttons or the digit buttons on the
remote control to select the block to be checked or changed.
© Press the Timer @) button again.
The Display and the TV screen show the recording details of the
block.
©) You can change the start time using the Up + or Down —
buttons or digit buttons (0-9) on the remote control.
Important!
If you have changed the start time, you also have to change the
stop time.
© If you want to change the other details, press the Timer © .
button as many times as required until the item to be changed
appears.
Use the Up +/Down — buttons or the digit buttons on the
remote control to change the details.
) Press.the Timer © button as many times. as necessary to
complete the procedure.
The previous mode is shown. again.
Clearing a block
You can clear a block of a recording already in progress:
@ First press Timer © button 4 and then Reset (RUCKST.)
button 10.
You can also clear a block of a scoring which has not yet
started:
(A) Press the Timer © button.
Use the Up + and/or Down — buttons or the digit buttons on
the remote control to select the block to be cleared.
© Press the Reset (RUCKST.) button to clear the block. .
On the Display the previous mode is shown again and on the TV
screen the OSD information ‘BLOCK GELOESCHT’ Pee
cleared) is shown:
BL. START STOP DATUM PR
BLOCK GELOESCHT
@B 15

Video Programm System (VPS)
@ This video recorder is equipped with a VPS decoder, so that
you no longer have to worry if TV programmes stop earlier or go
on longer than expected which means that timed recordings start
and stop too late or too soon.
@ With the help of this VPS decoder recordings will be made at
the exact moment the TV programme starts and will be recorded
from the beginning till the end.
e@ At this moment a VPS code is transmitted by the ARD and ZDF
stations and some third stations of the ARD and SRG.
In the near future other TV stations will transmit a VPS code. They
will give you more information.
@ Each transmitted TV programmes has a different VPS code
which ‘controls’ the start and stop times of the programmed
recording block.
Example of a recording without VPS control
20:15 hours - Stop time of News bulletin (according to your TV
- guide, Teletext page or programme review of the
; TV station)
20:30 hours - The real stop time.
20:15 hours - Your video recorder does not recognizes the:
7 “- delay and starts the timed recording (for example
a feature film).
21:40 hours - Original stop time of the film.
21:55 hours - Real stop time of the film.
Result: The end of the film has not been recorded.
Other problems which may occur
- A transmission stops earlier than indicated, which means that
the feature film will be transmitted earlier. The programmed start
time is later.
Result: The beginning of the film will not be recorded.
- Due to a 10 minute disturbance in transmission the film ends 10
minutes later than planned. However, your video recorder
records also records the disturbance.
- Result: The end of the film will not be recorded.
WITH VPS THESE PROBLEMS WILL NO LONGER OCCUR
@ When programming a block (see beginning of this section) you
can switch the VPS control on or off using Reset (RUCKST.)
button 10.
If the VPS control is switched on the Display and the TV screen
show ‘VPS’.
When a VPS controlled recording has been made, the ‘VPS’
indication disappears.
Pay attention to the following:
1. Enter the exact VPS start time as indicated in your TV guide (or
Teletext page or programme review of the TV station).
if a different start time is entered, a recording cannot be made.
2. if a VPS start time is already known before the TV guide was
printed or before the Teletext pages were updated, the correct
VPS start time will be indicated. :
If the new start time is entered inadvertently, a recording cannot
be made.
3. If you have programmed 2 recording blocks, it is possible that
the programme of the first block stops too late, although the start
time second block has already been reached: —
The recording of the first biock will be made completely. After
that the video recorder switches over to the second block and
starts the recording.
4. If the start time of the first recording block is delayed until start
time of the second block, the video recorder switches over to
second block and starts the recording.
The first programmed recording will not be made or starts after
the second block has been completed.
The VPS control of the video recorder responds to the VPS signal
transmitted by the TV station.
If, despite careful programming, the recording is not carried out
the cause may be a different VPS signal transmitted by the TV
station.
5. If for a TV programme the given VPS start time is after
midnight, the date of the following day must be entered.
VPS recording standby mode
@ The video recorder must properly recognise programme
alterations.
In order to be able to record programmes which may possibly be
transmitted earlier, the VPS control starts to search for the VPS
code 28 hours (maximum). before the entered start time and
observes the up to 28 VPS code hours (maximum) after the
entered start time.
During this time the video recorder is in VPS recording standby
mode.
Example
Thursday 00:00 hours - ..The video recorder switches over to
VPS recording standby
Thursday 21:20 hours - The programmed VPS start time of a
recording
Friday 04:00 hours - The VPS contro! will be switched off
(unless the recording has been made in
the meantime).
@ In the time between 00:00 and 21:20 hours the video recorder |
can be operated manually, but be sure to press On/Standby re)
button 24 after use.
In order to be able to record earlier transmitted programmes,
manual use of the video recorder should be minimized in the last -
few minutes before a timed recording should take place.
@ \f a programme is cancelled (for example a football match) and
another programme is:transmitted in its place, the VPS start time
of the replacing programme will be 1 minute earlier than indicated
(20:14 instead of 20:15).
In this case you must enter the new VPS start time.
In what cases does the VPS control not work
- If the VPS code is not yet transmitted by: the TV station. In Ve
case the recording will be made in the normal way.
- If, due to a disturbance, the TV set shows a ‘ghost picture’. In
this case the VPS indicator flashes and the recording will be
made the normal way.
The aerial needs to be checked by a specialist.
- If the wrong date has been entered.

Recording via a camera
You can make your own video recordings using a video. camera.
Your dealer can advise you which camera models are suitable
and which adaptors are necessary.
@ Set up the camera as shown in the camera’s Operating
Instructions.
e Connect the camera, or its adaptor, to AV Euroconnector
25 and the Service bus 27.
@ Load an unprotected cassette.
@ Select indication ‘E’ using the + and/or — buttons 2 and 3.
(You can select “E’ by pressing Up + button 2 after programme
number ‘48’ appears or pressing Down — button 3 after:
programme number ‘1’ appears or pressing button -&) on the
remote control.)
@ Press the camera trigger or Record (AUFNAHME) @ button:
13.
@ To interrupt the recording, release the camera trigger, or press
Pause/Still picture (PAUSE/STANDBILD) Ml button 18 or Eject
(CASSETTE) & button 23.
1 IQ
2
3 8
4 @
5
6 0-9
7 -C/P
8 -/--
Q <>
10 +
Wo
12 &)
13 ®
14 &
15 4
16 Wi
17
1383 @
19 ®
20
21
22 44
23 b>
24 ff
2 &
26 &
27 >
Us
TO
On/Standby button
Delayed OTR (press this button as. many mes
as necessary to set the required delay):
OTR button (press this button and Active
button (5) simultaneously, but press button: El:
once for every 1/2 hour)
Record (press this button and Active button (5)
simultaneously)”
Active button
Digit buttons
Chanal/Programme selector
One/Two digit entry
Go to button
Up button
Down button:
Euroconnector input selector
Slow motion button
Fast motion button
Play reverse button
Pause/Still picture button
Clock or Channel/Programme selector
Switching on/off OSD
Timer button
Reset button
Tracking button
Rewind button
Wind button
Stop
Picture search reverse button
Picture search forward button
Play button
GB 17

@ You can control all the record and playback functions of your
video recorder using the remote control unit. The video recorder
acknowledges the signal from the remote control with the o))
symbol on the Display.
@ To prevent accidental recording via the remote control unit, it
is necessary to press two buttons simultaneously to start a
recording.
Press Active button (5) and either Record @ button (4) or OTR
E) button (3) simultaneously.
You will also find that you have additional features - not
accessible through the controls of the video recorder itself.
These functions are:
(6) Digit buttons 0-9 (CO
The digit buttons can be used to enter information directly (for
example the channel/programme number or recording times).
(8) One/two digit entry -/-:
For asingle digit entry. select the required number directly.
For a two digit entry first press the -/-- button and then the
required number.
To return to single digit entry you first have to press button -/--
again.
(9) Go to «>
@ Press button «+ onthe feniote control unit.
The Display shows ‘GOTO’ and ‘----’.
On the TV screen the OSD information ‘WAEHLE
ZAEHLWERKPOSITION UND GEWUENSCHTE FUNKTION’
(select tape position and choose function) is shown:
GOTO ----
WAEHLE ZAEHLWERKPOSITION
UND GEWUENSCHTE FUNKTION
@ Use the. digit buttons to select the tape counter position you
want to go to.
@ Select the function to be started from that point (for example.
Play, Stop or standby).
The video recorder will wind fonieide or rewind to the required
position and then start the chosen function. .
@ If you want to correct the counter go-to position, just press
button «>» again.
(15) Play reverse ¢
Press this button for reverse Praypaer at normal speed.
18 Ge)
Storing cassettes
Cassettes should be stored:
- vertically, and.
- at room temperature.
Cassettes should be kept away from:
- dust,
- extreme humidity,
- bright sunlight,
- loudspeakers,
- electric motors,
- transformers and
- magnets.
To prevent tape damage, avoid storing a half wound cassette.
First rewind the tape to the peg: then: store:.
Never: ;
- disassemble the cassette (this may cause 6 damage to the tape
and/or the video recorder mechanism). . ; = :
- touch the tape.
Recording and re-recording
What you should do:
- note the start and finish tape position readings shown on the
Display when you record a cassette;
- write down the readings on the index card.
Note:
When you record on a cassette, any previous recording on that
part of the tape is erased.
Protecting recorded cassettes
To prevent re-use and erasure of ‘precious’ cassettes containing
recordings which you wish to keep indefinitely, remove the erase
prevention tab on the rear edge of the cassette.
(Use a screwdriver or similar instrument to break off the tab from
the cassette.)
If you attempt to record again on this cassette, it will be
automatically ejected from the video recorder.
