Philips Sonicare ExpertResults 7000 User manual

ExpertResults
7000

1
2
11
4
3
5
6
7
8
9
10

empty page before TOC

English 6
简体中文 25
繁體中文 45

English
Introduction
Congratulations on your new Philips Sonicare
power toothbrush! Superior plaque removal, whiter
teeth and healthier gums are at your fingertips.
Using Sonicare’s combination of gentle sonic
technology and clinically developed and proven
features, you can be confident that you’re getting
the very best clean, every time. Further support
and product registration are available to you at:
http://www.philips.com/welcome.
Welcome to the Philips Sonicare family!
Intended use
ExpertResults series power toothbrushes are
intended to remove adherent plaque and food
debris from the teeth to reduce tooth decay and
improve and maintain oral health. ExpertResults
series power toothbrushes are intended for
consumer home use. Use by children should be
with adult supervision.
Important safety information
Read this important information carefully before
you use the appliance and save it for future
reference.
Note: The accessories and features of different
models vary. For example, some models come with
a sanitizer or are equipped with Bluetooth.
Danger
- Keep the charger and/or sanitizer away from
water. Do not place or store the appliance
where it can fall or be pulled into a tub or sink.
- Do not immerse the charger and/or sanitizer in
water or any other liquid.
6English

- After cleaning, make sure the charger and/or
sanitizer is completely dry before you connect it
to the wall socket.
Warning
- This appliance can be used by children and
persons with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge if they have been given supervision
or instruction concerning use of the appliance
in a safe way and understand the hazards
involved. Cleaning and user maintenance shall
not be made by children without supervision.
- Children shall not play with the appliance.
- Keep the sanitizer out of the reach of children
at all times.
- Stop using the sanitizer if the UV light bulb
remains on when the door is open. UV light can
be harmful to the human eye and skin.
- If the appliance is damaged in any way (brush
head, toothbrush handle, charger and/or
sanitizer), stop using it.
- The mains cord cannot be replaced. If the mains
cord is damaged, discard the charger and/or
sanitizer.
- Always replace the charger and/or sanitizer
with one of the original type in order to avoid a
hazard.
- This appliance contains no user-serviceable
parts. If the appliance is damaged, contact the
Consumer Care Center in your country (see
'Warranty and support').
- Keep the cord away from heated surfaces.
- Do not use the charger and/or sanitizer
outdoors or near heated surfaces.
7
English

Caution
- Do not clean the brush head, handle, charger,
charger cover or sanitizer in the dishwasher.
- If you have had oral or gum surgery in the
previous 2 months, consult your dentist before
you use this appliance.
- Consult your dentist if excessive bleeding
occurs after using this appliance or if bleeding
continues to occur after 1 week of use. Also
consult your dentist if you experience
discomfort or pain when you use this appliance.
- This Philips appliance complies with the safety
standards for electromagnetic devices. If you
have a pacemaker or other implanted device,
contact your doctor or the appliance
manufacturer of the implanted appliance prior
to use.
- If you have medical concerns, consult your
doctor before you use this appliance.
- This appliance has only been designed for
cleaning teeth, gums and tongue. Do not use it
for any other purpose. Stop using the appliance
and contact your doctor if you experience any
discomfort or pain.
- This appliance is a personal care device and is
not intended for use on multiple patients in a
dental practice or institution.
- Do not use other brush heads than the ones
recommended by Philips Sonicare.
- Stop using a brush head with crushed or bent
bristles. Replace the brush head every 3 months
or sooner if signs of wear appear.
- If your toothpaste contains peroxide, baking
soda or bicarbonate (common in whitening
toothpastes), thoroughly clean the brush head
with soap and water after each use. This
prevents possible cracking of the plastic.
8English

- Avoid direct contact with products that contain
essential oils or coconut oil. Contact may result
in bristle tufts dislodging.
- The UV light bulb of the sanitizer is hot during
and immediately after the sanitizing cycle. Do
not touch the UV light bulb when it is hot.
- Do not operate the sanitizer without the
protective screen in place to avoid contact with
a hot UV light bulb.
- If you have used the sanitizer for 3 UV clean
cycles in a row, switch it off for at least 30
minutes before you start another UV clean
cycle.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
Radio Equipment Directive
Hereby, Philips declares that electric toothbrushes
with radio frequency interface (Bluetooth) are in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
www.philips.com/support
The radio frequency interface in this product
operates at 13.56MHz.
The maximum RF power transmitted by the
appliance is 30.16dBm.
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Smart brush head(s)*
3 Handle
4 Power on/off button
9
English

5 Intensity light
6 Mode/intensity button
7 Modes
8 Brush head replacement reminder light
9 Battery indication
10 Charger
11 Travel case
*Note: The content of the box may vary based
on the model purchased.
Using your Philips Sonicare
Brushing instructions
1Push the brush head firmly onto the handle.
Note: It is normal to see a slight gap between
the brush head and the handle.
2Wet the bristles and apply toothpaste.
3Place the toothbrush bristles against the teeth
at a slight angle (45 degrees), pressing firmly to
make the bristles reach the gumline or slightly
beneath the gumline.
45°
Note: Keep the center of the brush in contact
with the teeth at all times.
4Press the power on/off button to turn on the
Philips Sonicare.
5Apply light pressure to maximize Philips
Sonicare’s effectiveness and let the Philips
Sonicare toothbrush do the brushing for you.
Gently move the brush head slowly across the
teeth in a small back and forth motion so the
longer bristles reach between your teeth.
Continue this motion throughout the brushing
cycle.
10 English

Note: To learn how to brush with specific
modes, see ‘Modes’.
Note: The bristles should slightly flare. Do not
scrub.
Note: A change in sound and vibration from the
handle alerts you when you apply too much
pressure while brushing.
Note: Your handle will briefly pause its vibration
when its time to brush the next section, see
'QuadPacer'.
6To clean the inside surfaces of the front teeth,
tilt the brush handle semi-upright and make
several vertical overlapping brushing strokes on
each tooth.
Your Philips Sonicare toothbrush is safe to use
on:
- Braces (brush heads wear out sooner when
used on braces)
- Dental restorations (fillings, crowns, veneers)
Brush heads
Your brush heads
To see what type of brush head you have, check
the brush head label at the bottom.
W
C 3
Brush head name DiamondClean Premium Plaque
Control
Brush head label W C3
11
English

Benefit Stain removal Plaque removal
To explore our full range of brush heads, go to
www.philips.com/toothbrush-heads for more
information.
BrushSync Technology (Oslo)
BrushSync technology enables your brush heads
to communicate with your handle using a
microchip. The symbol at the bottom of the brush
head indicates that it is equipped with the
BrushSync technology.This enables the following
features:
- Brush head mode pairing
- Brush head replacement reminder
Brushing modes
Your power toothbrush is equipped with 3
different modes: Clean, White, and Gum Care.
Based on the smart brush head you use, the mode
will be selected automatically. To manually change
the mode, press the mode/intensity button while
the toothbrush is off.
Clean White Gum Care
Benefit Plaque removal Plaque and
surface stains
removal
Plaque removal
and gum
massage
12 English

Clean White Gum Care
Re-
commended
brush head
Premium
Plaque Control
(C3)
Diamond Clean
(W)
Optimal Gum
Care (G2)
Re-
commended
intensity level
3 3 3
Total brushing
time
2 minutes 2 minutes and
30 seconds
3 minutes
How to brush Brush each
quadrant for 30
seconds
2
4
3
1
Brush each
quadrant for 30
seconds,
2
4
3
1
then brush the
front top and
bottom teeth
for an
additional 30
seconds.
1
2
Brush each
quadrant for 30
seconds,
2
4
3
1
then brush
along the
gumline for an
additional
minute.
Note: After you have completed the brushing cycle,
you can spend additional time brushing the
chewing surfaces of your teeth and areas where
13
English

staining occurs. You can also brush your tongue,
with the toothbrush turned on or off, as you prefer.
Note: All brush heads work with each mode.
Note: When the Philips Sonicare is used in clinical
studies, it must be used in the Clean mode (for
plaque and gum claims) or in White mode (for
whitening claims), at high intensity, with the
EasyStart feature turned off.
Intensity settings
Your power toothbrush comes with 3 different
intensity levels: low, medium and high. When
attached to the handle, the smart brush head will
automatically select the recommended intensity.
To manually change the intensity, turn on the
handle and press the mode/intensity button.
Features
- EasyStart
- Brush head replacement reminder
- Pressure sensor
- Brush head mode pairing
- QuadPacer
EasyStart
The EasyStart feature gently increases the power
of the handle over the first 14 brushings to help
you get used to the brushing power of the Philips
Sonicare.
The EasyStart feature works with all modes.
Note: The EasyStart feature comes deactivated
with your product. To activate EasyStart, see
'Activating or deactivating features'.
Brush head replacement reminder
The handle will track the wear of your brush head.
It measures:
14 English

- The pressure you apply when you brush
- The time you have brushed with the brush head
Once your brush head is no longer effective, the
brush head replacement reminder will blink amber.
This indicates that it is recommended to change
your brush head.
Note: The brush head replacement reminder
comes activated with your product. To deactivate
this feature, see 'Activating or deactivating
features'.
Pressure sensor
Your Philips Sonicare measures the pressure you
apply while brushing to protect your gums and
teeth from damage.
If you apply too much pressure, the handle will
change its vibration until you reduce the pressure.
Note: The pressure sensor comes activated with
your product. To deactivate this feature, see
'Activating or deactivating features'.
Brush head mode pairing
Brush heads with BrushSync technology are
equipped with an RFID chip. The chip
communicates to the handle and automatically
pairs it with the recommended mode and intensity.
Note: If you change modes/intensity, the handle
will remember the last used setting. If you wish to
brush with the recommended setting, you can find
the recommended modes/intensity in ‘Brushing
Modes’.
QuadPacer
The QuadPacer feature indicates via a brief
change in vibration when you are supposed to
move onto the next brushing section.
15
English

The toothbrush will automatically turn off at the
end of the brushing session.
Charging and battery status
Charging
1Plug the charger into an electrical outlet.
2Place the handle on the charger.
3The charging indicator will flash green until your
toothbrush is fully charged.
Battery status (handle on plugged-in
charger)
When placed on the charger, the battery light will
flash green based on the current battery level.
LED color Battery charging status
Flashing green Charging
Solid green Fully charged
Off Fully charged and in sleep mode
When placing the handle on the charger:
- The handle will emit 2 short beeps to confirm
the handle is placed properly and the handle
starts charging.
- The battery light will flash green to indicate it is
charging.
- The handle will show solid green when it is fully
charged. In order to preserve the charge, the
green light will switch off 30 seconds after the
charging process is complete.
Battery status (when handle is not placed on
charger)
When removing the handle from the charger, the
battery light at the bottom of the handle will
indicate the status of the battery.
16 English

LED color Number of beeps Status
Solid green n/a Full
Flashing green n/a Medium
Flashing amber 3 Low
Flashing amber 5 Battery empty
Note: Your toothbrush comes pre-charged for first
use. After first use, charge for at least 24 hours.
Note: It is OK to leave the handle on the plugged in
charger in between brushings. This will not impact
the battery life negatively.
Activating or deactivating features
You can activate or deactivate the following
features of your toothbrush:
- EasyStart
- Brush head replacement reminder
- Pressure sensor
1Place the handle on the charger.
2Press and hold the power button for:
Feature Press the power button for
EasyStart 3 seconds
Brush head replacement
reminder
Up to 5 seconds
Pressure sensor Up to 7 seconds
3Let go of the power button when you hear:
Feature You will hear
EasyStart 1 beep
17
English

Brush head replacement
reminder
1 beep then 2 beeps
Pressure sensor 1 beep, 2 beeps then 3 beeps
If you see the brush head replacement reminder
and the battery indicator lights flashing green and
hear low to high triple tones, then the feature had
been activated.
OR
If you see the brush head replacement reminder
and the battery indicator lights flashing amber and
hear high to low triple tones, then the feature had
been deactivated.
18 English

Cleaning
Caution: Unplug the charger before you clean it.
Caution: Do not use essential oils to clean the
brush heads as this can cause damage.
Caution: Do not use isopropyl rubbing alcohol,
vinegar or bleach to clean the handle as this may
cause discoloration.
Caution: Do not push on the rubber seal at the
top of the handle.
Locating the model number
Look on the bottom of the Philips Sonicare
toothbrush handle for the model number (HX751x).
19
English

Frequently asked questions
Question Answer
Is my Philips Sonicare toothbrush
water resistant?
Yes. However, do not fully
submerge the handle in liquid for
an extended period of time.
How often should I clean the
connection between the brush
head and the handle?
It is recommended to clean this
after each brushing, or at least
once a week.
Can I leave my Philips Sonicare
toothbrush on the charger
between brushings?
Yes, you can always keep your
Philips Sonicare toothbrush on a
plugged-in charger. This will not
affect the battery lifetime.
How often can I use my Philips
Sonicare toothbrush per charge?
Your Philips Sonicare toothbrush
should last 2-3 weeks with
standard brushings (2x/day) with
a full battery. You do not have to
charge your Philips Sonicare
toothbrush on a daily basis.
Recycling
- This symbol means that this product shall not
be disposed of with normal household waste
(2012/19/EU).
20 English
