Philips XXL User manual

EN User manual 2
DE Bedienungsanleitung 24
FR Mode d'emploi 48
NL Gebruiksaanwijzing 72
HD986X

2
ENGLISH
TABLE OF CONTENTS
Important 3
Introduction 5
General description 5
Before rst use 7
Preparing for use 7
Placing the removable mesh bottom and fat reducer 7
Food table for manual time/temperature settings 8
Using the appliance 10
Airfrying 10
Food table for Smart Chef programs 14
Cooking with Smart Chef programs 15
Making home-made fries 16
Choosing the keep warm mode 16
Save your favorite setting 17
Cleaning 19
Cleaning table 21
Storage 21
Recycling 21
Guarantee and support 21
Troubleshooting 22

3
ENGLISH
Important
Read this important information carefully before you use the appliance
and save it for future reference.
Danger
- Never immerse the appliance in water nor rinse it under the tap.
- Do not let any water or other liquid enter the appliance to prevent
electric shock.
- Always put the ingredients to be fried in the basket, to prevent them
from coming into contact with the heating elements.
- Do not cover the air inlet and the air outlet openings while the
appliance is operating.
- Do not ll the pan with oil as this may cause a re hazard.
- Do not use the appliance, if the plug, the mains cord or the appliance
itself is damaged.
- Never touch the inside of the appliance while it is operating.
- Never put any amount of food that exceeds the maximum level
indicated in the basket.
- Always make sure heater is free and no food stuck in heater.
Warning
- If the supply cord is damaged, it must be replaced by Philips, its service
agent or similarly qualied persons in order to avoid a hazard.
- Only connect the appliance to an earthed wall socket. Always make
sure that the plug is inserted into the wall socket properly.
- This appliance is not intended to be operated by means of an external
timer or a separate remote-control system.
- The accessible surfaces may become hot during use.
- This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
- Keep the appliance and its cord out of the reach of children less than
8 years.
- Do not place the appliance against a wall or against other appliances.
Leave at least 10 cm free space at the back, on both sides and above
the appliance. Do not place anything on top of the appliance.
- During hot air frying, hot steam is released through the air outlet
openings. Keep your hands and face at a safe distance from the steam
and from the air outlet openings. Also, be careful of hot steam and air
when you remove the pan from the appliance.
- Never use light ingredients or packing paper in the appliance.
- Accessible surfaces may become hot during use.

4
ENGLISH
- Storage of potatoes: The temperature shall be appropriate to the
potato variety stored and it shall be above 6°C to minimize the risk of
acrylamide exposure in the prepared foodstu.
- Do not place the appliance on or near a hot gas stove or all kinds of
electric stove and electric cooking plates, or in a heated oven.
- Never ll the pan with oil.
- This appliance is designed to be used at ambient temperatures
between 5°C and 40°C.
- Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.
- Keep the mains cord away from hot surfaces.
- Do not place the appliance on or near combustible materials such as a
tablecloth or curtain.
- Do not use the appliance for any other purpose than described in this
manual and use only original Philips-accessories.
- Do not let the appliance operate unattended.
- The pan, basket and fat reducer becomes hot during and after use of
the appliance, always handle carefully.
- Thoroughly clean the parts that come into contact with food before
you use the appliance for the rst time. Refer to the instructions in the
manual.
Caution
- This appliance is intended for normal household use only. It is not
intended for use in environments such as sta kitchens of shops,
oces, farms or other work environments. Nor is it intended to be used
by clients in hotels, motels, bed and breakfasts and other residential
environments.
- Always disconnect the appliance from the supply if it is left unattended
and before you assemble, disassemble, store or cleaning.
- Place the appliance on a horizontal, even and stable surface.
- If the appliance is used improperly or for professional or semi-
professional purposes or if it is not used according to the instructions
in the user manual, the guarantee becomes invalid and Philips refuses
any liability for damage caused.
- Always return the appliance to a service center authorised by Philips
for examination or repair. Do not attempt to repair the appliance
yourself, otherwise the guarantee becomes invalid.
- Always unplug the appliance after use.
- Let the appliance cool down for approximately 30 minutes before you
handle or clean it.
- Make sure the ingredients prepared in this appliance come out
golden yellow instead of dark or brown. Remove burnt remnants. Do
not fry fresh potatoes at a temperature above 180°C (to minimise the
production of acrylamide).
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable standards and
regulations regarding electromagnetic elds.

5
ENGLISH
Automatic shut-o
This appliance is equipped with an automatic shut-o function. When
the time of the timer has elapsed, the device will shut o automatically. If
you do not press a button within 30 minutes, the appliance switches o
automatically. To switch o the appliance manually, press the
power On/o button.
Introduction
Congratulations on your purchase and welcome to Philips!
To fully benet from the support that Philips oers, register your product at
www.philips.com/welcome.
With Philips Airfryer, you can now enjoy perfectly cooked fried food—crispy
on the outside tender on the inside—Fry, grill, roast and bake to prepare a
variety of tasty dishes in a healthy, fast and easy way.
For more inspiration, recipes and information about the Airfryer, visit
www.philips.com/kitchen or download the free NutriU App* for IOS®or
Android™.
*The NutriU app may not be available in your country.
In this case please download the Airfryer App.
General description
1 Drawer
2 Basket with removable mesh bottom
3 Removable mesh bottom
4 Fat reducer
5 Pan
6 Cord storage compartment
7 Air outlets
8 MAX indication
9 Power cord
10 Air inlet
11 Control panel
A Temperature indication
B Temperature button
C Favorites button
D Keep warm button
E Keep warm indication
F QuickControl dial
G Power On/O button
H Return button
I Timer button
J Time indication
K Smart Chef programs: Frozen fries/home-made fries/ whole sh/
chicken drumsticks/whole chicken
L Shake indication

6
ENGLISH
1
B
A JKL
C
D
E
H
I
G
F
2
3
4
5 6
7
9
8
10
11

7
ENGLISH
Before rst use
1 Remove all packing material.
2 Remove any stickers or labels (if available) from the appliance.
3 Thoroughly clean the appliance before rst use, as indicated in the
cleaning chapter.
Preparing for use
Placing the removable mesh bottom and fat reducer
1 Open the drawer by pulling the handle.
2 Remove the basket by lifting the handle.
3 Place the fat reducer into the pan.
4 Insert the removable mesh bottom into the slot on the right bottom
side of the basket. Push the mesh bottom down until it locks into
position (“click” on both sides).
1
2

8
ENGLISH
5 Put the basket in the pan.
6 Slide the drawer back into theAirfryer by the handle.
Note
•Never use the pan without the fat reducer or the basket in it.
Food table for manualtime/temperature settings
The table below helps you select the basic settings for the types of food
you want to prepare.
Note
•Keep in mind that these settings are suggestions. As ingredients dier in origin,
size, shape as well as brand, we cannot guarantee the best setting for your
ingredients.
•When preparing larger amount of food (e.g. fries, prawns, drumsticks, frozen
snacks), shake, turn, or stir the ingredients in the basket 2 to 3 times in order to
achieve a consistent result.
Ingredients Min.– max.
amount
Time
(min) Temperature Note
Home-made fries
(12 x 12 mm/0.5 x 0.5 in)
200–1400 g
7–49 oz
18–35 180°C/350°F •Soak 30 minutes in cold water
or 3 minutes in luke warm water
(40°C/104°F), dry then add 1
tbsp of oil per 500 g/18 oz.
•Shake, turn, or stir halfway
Homemade potato wedges 200–1400 g
7–49 oz
20–42 180°C/350°F •Soak 30 minutes in water, dry
then add 1/4 to 1 tbsp of oil.
•Shake, turn, or stir halfway
Frozen snacks
(chicken nuggets)
80–1300 g/
3–46 oz
(6–50 pieces)
7–18 180°C/350°F •Ready when golden yellow and
crispy outside.
•Shake, turn, or stir halfway
Frozen snacks
(small spring rolls around
20 g/0.7 oz)
100–600 g/
4–21 oz
(5–30 pieces)
14–16 180°C/350°F •Ready when golden yellow and
crispy outside.
•Shake, turn, or stir halfway

9
ENGLISH
Ingredients Min.– max.
amount
Time
(min) Temperature Note
Chicken breast
Around 160 g/6 oz
1–5 pieces 18–22 180°C/350°F
Chicken ngers bread
crumbed
3–12 pieces
(1 layer)
10–15 180°C/350°F •Add oil to the breadcrumbs.
Ready when golden yellow.
Chicken wings
Around 100 g/3.5 oz
2–8 pieces
(1 layer)
14–18 180°C/350°F •Shake, turn, or stir halfway
Meat chops without bone
Around 150 g/6 oz
1–5 chops 10–13 200°C/400°F
Hamburger
Around 150 g/6 oz (diameter
10 cm/4 in)
1–4 patties 10–15 200°C/400°F
Thick sausages
Around 100 g/3.5 oz
(diameter 4 cm/1.6 in)
1–6 pieces
(1 layer)
12–15 200°C/400°F
Thin sausages
Around 70 g/2.5 oz (diameter
2 cm/0.8 in)
1–7 pieces 9–12 200°C/400°F
Pork roast 500–1000 g/
18–35 oz
40–60 180°C/350°F •Let it rest for 5 minutes before
cutting.
Fish lets
Around 120 g/4.2 oz
1–3
(1 layer)
9–20 160°C/325°F •In order to avoid sticking, place
the skin side to the bottom and
add some oil.
Shellsh
Around 25–30 g/0.9–1 oz
200–1500 g/
7–53 oz
10–25 200°C/400°F •Shake, turn, or stir halfway
Cake 500 g/18 oz 28 180°C/350°F •Use a cake pan.
Muns
Around 50 g/1.8 oz
1–9 12–14 180°C/350°F •Use heat-proof silicone mun
cups.
Quiche (diameter
21 cm/8.3 in)
1 15 180°C/350°F •Use a baking tray or oven dish.
Pre-baked toast / bread rolls 1–6 6–7 180°C/350°F
Fresh bread 700 g/25 oz 38 160°C/325°F •The shape should be as at as
possible to avoid that the bread
touches the heating element
when rising.
Fresh rolls
Around 80 g/2.8 oz
1–6 pieces 18–20 160°C/325°F
Chestnuts 200–2000 g/
7–70 oz
15–30 200°C/400°F •Shake, turn, or stir halfway
Mixed vegetable (roughly
chopped)
300–800 g/
11–28 oz
10–20 200°C/400°F •Set the cooking time according
to your own taste.
•Shake, turn, or stir halfway

10
ENGLISH
Using the appliance
Airfrying
Caution
•This is an Airfryer that works on hot air. Do not ll the pan with oil, frying fat
or any other liquid.
•Do not touch hot surfaces. Use handles or knobs. Handle the hot pan and fat
reducer with oven-safe gloves.
•This appliance is for household use only.
•This appliance may produce some smoke whenyou use it for the rst time.
This is normal.
•Preheating of the appliance is not necessary.
1 Place the appliance on a stable, horizontal, level and heat-resistant
surface. Make sure the drawer can be opened completely.
Note
•Do not put anything on top or on the sides of the appliance. This could disrupt
the airow and aect the frying result.
2 Pull the power cord out of the cord storage compartment at the back
of the appliance.
3 Put the plug in the wall outlet.
4 Open the drawer by pulling the handle.

11
ENGLISH
5 Put the ingredients in the basket.
Note
•The Airfryer can prepare a large range of ingredients. Consult the ‘Food table’
for the right quantities and approximate cooking times.
•Do not exceed the amount indicated in the ‘Food table’ section or overll the
basket beyond the ‘MAX’ indication as this could aect the quality of the end
result.
•If you want to prepare dierent ingredients at the same time, make sure you
check the suggested cooking time required for the dierent ingredients before
you start to cook them simultaneously.
6 Slide the drawer back into theAirfryer by the handle.
Caution
•Never use the pan without the fat reducer or basket in it. If you heat up the
appliance without basket, use oven gloves to open the drawer. The edges
and inside of the drawer become very hot.
•Do not touch the pan, fat reducer or basket during and for some time after
use, as they get very hot.
7 Press the power On/O button to switch on the appliance.
Note
•To start with the Smart Chef programs, refer to chapter “Cooking with Smart
Chef programs”.
8 Press the temperature button .
»The temperature indication blinks on the screen.
Note
•If you press the timer button rst, the appliance will start cooking right
after the cooking time has been conrmed.
9 Turn the QuickControl dial to choose your desired cooking
temperature.
2

12
ENGLISH
10 Push the QuickControl dial to conrm the selected temperature.
»After the temperature is conrmed, the time indication starts
blinking on the screen.
11 Turn the QuickControl dial to choose your desired cooking time.
Note
•If you press the favorite button you will save this cooking temperature and
time as your favorite cooking settings. Any previously saved settings will be
overwritten. For more details, refer to chapter "Save your favorite setting".
•Refer to the food table for manual time/temperature settings for dierent
types of food.
12 Push the QuickControl dial to conrm the selected time.
13 The appliance starts cooking after the cooking time has been
conrmed.
Tip
•To pause the cooking process, push the QuickControl dial. To resume the
cooking process, push the QuickControl dial again.
•To change the cooking temperature or time during cooking, repeat steps 8–10.
•To cancel any ongoing process and go back to the main menu, press the return
button .
Note
•If you do not set the required cooking time within 30 minutes, the appliance
automatically shuts o for safety reasons.
•If “- -” is selected as the time indication, the appliance goes into preheating
mode.
•Some ingredients require shaking or turning halfway through the cooking time
(see ‘Food table’). To shake the ingredients, press the QuickControl dial to
pause cooking, open the drawer and lift the basket out of the pan and shake it
over the sink. Then slide the pan with the basket back into the appliance, and
press the QuickControl dial to resume cooking.
•If you set the timer to half the cooking time, when you hear the timer bell
it is time to shake or turn the ingredients. Be sure to reset the timer to the
remaining cooking time.
14 When you hear the timer bell, the cooking time has elapsed.
2

13
ENGLISH
15 Open the drawer by pulling the handle and check if the ingredients
are ready.
Note
•If the ingredients are not ready yet, simply slide the drawer back into the
Airfryer by the handle and add a few extra minutes to the set time.
16 To remove small ingredients (e.g. fries), lift the basket out of the pan
by the handle.
Caution
•After the cooking process, the pan, the fat reducer, the basket, interior
housing and the ingredients are hot. Depending on the type of ingredients in
the Airfryer, steam may escape from the pan.
17 Empty the basket contents into a bowl or onto a plate. Always remove
the basket from the pan to empty contents as hot oil may be in bottom
of the pan.
Note
•To remove large or fragile ingredients, use a pair of tongs to lift out ingredients.
•Excess oil or rendered fat from the ingredients is collected on the bottom of
the pan below the fat reducer.
•Depending on the type of ingredients cooking, you may want to carefully
pour o any excess oil or rendered fat from the pan after each batch or before
shaking or replacing the basket in the pan. Place the basket on a heat-resistant
surface. Wearing oven-safe gloves, lift the pan o tracks and place on heat-
resistant surface. Carefully remove the fat reducer from the pan using rubber
tipped tongs. Pour o excess oil or rendered fat. Return the fat reducer to the
pan, the pan to the drawer and the basket to the pan.
When a batch of ingredients is ready, the Airfryer is instantly ready for
preparing another batch.
Note
•Repeat steps 4 to 17 if you want to prepare another batch.

14
ENGLISH
Food table for Smart Chef programs
Note
•This appliance is for indoor use only. Start the automatic cooking programs
with the appliance at room temperature—do not pre-heat.
•Always distribute the food evenly in the basket.
•Turn/shake the food if indicated by the appliance. Keep the drawer open as
short as possible.
•Do not use any accessories. Make sure that the fat reducer is properly placed in
the appliance.
•As food diers in origin, size and brand, make sure it is suciently cooked
before serving.
Smart Chef programs for Directions
Frozen fries
Thin (7x7mm)
Medium (10x10mm)
Frozen potato
based snacks
200–1400g
•Use frozen fries directly from freezer. Do
not thaw before cooking.
•The program is developed for thin (7x7mm)
and medium (10x10mm) frozen fries.
•If you purchased fries specially made for
Airfryer, please follow instructions on the
package.
Home-made
fries
Home made cut
(10x10mm) 500–1400g
•Use oury, raw potatoes. Do not pre-cook
potatoes.
•Do not use potatoes stored below 6°C.
•Follow the fresh fries recipe for best
results.
Fish
A whole sh
Big at sh
Fish llet
1-4 pcs (300-1600g)
1 pcs (up to 800g)
2-5 pcs (150-200g/pcs),
up to 700g
•Do not cook frozen sh
•The program is developed for whole sh
around 300–400 g.
•If smoke occurs, please use manual mode
with lower temperatures.
Drumsticks
Drumsticks
Chicken breast
2-16 pcs (200-2000g)
1-5 pcs (up to 150g /pcs)
•The program is developed for fresh (non-
frozen) drumsticks. If you want to cook
whole chicken legs, add manually 5-10
minutes cooking time after the Smart Chef
program has stopped.
A whole
chicken
A whole chicken
Half chicken
1000-1800g
>1000g
•Only cook raw chicken in the Airfryer.
Do not cook frozen chicken.
•The program is developed for a whole
chicken.

15
ENGLISH
Cooking with Smart Chef programs
Season your ingredients as desired. Put the food inside the basket and
slide the basket inside the appliance.
Note
•Do not use honey, syrups or any other sugary ingredients to season your food,
since the browning will get very dark.
1 Press the On/O button to switch on the appliance.
2 To change the Smart Chef program, turn the QuickControl dial until
the desired icon is blinking.
3 To conrm the Smart Chef program, press the QuickControl dial.
»The appliance automatically calculates the ideal cooking
temperature and time. The screen displays the rst estimated
cooking temperature and time after a few minutes. During this
time the appliance has already started cooking. As long as the
screen displays the blinking bars and the temperature/time
alternately, the appliance is still calculating the cooking time, and
the appliance will automatically adjust the time during cooking.
Note
•To prepare a whole chicken, weigh the chicken before placing it in the basket.
Choose the weight by turning the QuickControl dial and pressing it to conrm.
•Do not pull out the drawer as long as the appliance is calculating the cooking
time, which is indicated by blinking bars on the display. Otherwise the Smart
Chef program will stop, and the appliance will reset to the main menu. Proceed
cooking with the manual mode because restarting the Smart Chef program
with partially cooked food will lead to a wrong estimation of the cooking time.
•As soon as the calculation phase is nished you will see the temperature and
time displayed continuously (without blinking bars), and you may open the
drawer to check the status of the food.
2

16
ENGLISH
4 When you hear the bell and see the shake indication blinking, open
the drawer and turn the ingredients or shake the basket with the
ingredients. Then slide the basket back into the appliance.
5 When you hear the bell and the timer has elapsed to 0, the food is
ready.
Note
•If your food is underdone or the food does not reach your prefered browning
level, proceed cooking for several more minutes by pressing the timer button
(see steps 11–12 in chapter “Using the appliance”).
Making home-made fries
To make great home-made fries in the Airfryer:
1 Peel the potatoes and cut into sticks (10 x 10 mm/0.4 x 0.4 in thick).
2 Soak the potato sticks in a bowl of lukewarm water (~40°C/100°F) for
3 minutes.
3 Empty the bowl and dry the potato sticks with a dish towel or paper
towel.
4 Pour 1–3 tablespoons of cooking oil in the bowl, put the sticks in the
bowl and mix until the sticks are coated with oil.
5 Remove the sticks from the bowl with your ngers or a slotted kitchen
utensil so excess oil remains in the bowl.
Note
•Do not tilt the bowl to pour all the sticks in the basket at once to prevent
excess oil from going into the pan.
6 Put the sticks in the basket.
7 Start the Smart Chef program for home-made fries . When shaking
of the fries is needed, you will hear the timer bell and see the blinking
shaking icon on the display.
Note
•Consult the chapter “Food table for Smart Chef programs” for the right
quantities.
Choosing the keep warm mode
1 Press the keep warm button (you can activate the keep warm
mode at any time).
»The keep warm indication lights up with pulsing eect.

17
ENGLISH
»The keep warm timer is set to 30 minutes. To change the keep
warm time (1–30 min), press the timer button , turn the
QuickControl dial and then push it to conrm. You cannot adjust
the keep warm temperature.
2 To pause the keep warm mode, push the QuickControl dial. To resume
the keep warm mode, push the QuickControl dial again.
3 To exit the keep warm mode, press the return button or the On/O
button .
Tip
•If food like French fries loses too much crispness during the keep warm mode,
either shorten the keep warm time by switching o the appliance earlier or
crisp them up for 2–3 minutes at the temperature of 180°C.
Note
•If you activate the keep warm mode during cooking (the keep warm indication
lights up), the appliance will keep your food warm for 30 minutes after the
cooking time has elapsed.
•During the keep warm mode, the fan and heater inside of the appliance turn
on from time to time.
•The keep warm mode is designed to keep your dish warm immediately after it
is cooked in the Airfryer. It is not meant for reheating.
Save your favorite setting
1 Press the On/O button to switch on the appliance.
2 Press the temperature button .
1
2
3

18
ENGLISH
3 Turn the QuickControl dial to select the temperature.
4 Press the QuickControl dial to conrm the chosen temperature.
5 Turn the QuickControl dial to select the time.
6 Press the favorite button to save your setting. You will hear a beep
after the setting is saved.
7 Press the QuickControl dial to start the cooking process.
2
2

19
ENGLISH
Cooking with a favorite setting
1 Press the On/O button to switch on the appliance.
2 Press the favorite button .
3 Press the QuickControl dial to start the cooking process.
Note
•You can overwrite your favorite setting by applying the same procedure as
mentioned above.
•Pressing the favorite button in the manual mode will overwrite your favorite
setting. To apply your favorite setting, press the return button to exit the
manual mode rst.
•To exit the favorite mode, press the return button .
•During cooking with the favorite mode, you will be able to change the
temperature or time by pressing the temperature or timer button. The change
will not overwrite the stored favorite setting.
Cleaning
Warning
•Let the basket, pan, fat reducer and the inside of the appliance cool down
completely before you start cleaning.
•Remove the fat reducer from the pan using rubber tipped tongs. Do not
remove usingyour ngers as hot fat or oilcollects under the fat reducer.
•The pan, basket, fat reducer and inside of the appliance have a non-stick
coating. Do not use metalkitchen utensils or abrasive cleaning materials as
this maydamage the non-stick coating.
Clean the appliance after every use. Remove oil and fat from the bottom of
the pan after every use.
1 Press the power On/O button to switch o the appliance, remove
the plug from the wall outlet and let the appliance cool down.

20
ENGLISH
Tip
•Remove the pan and basket to let the Airfryer cool down more quickly.
2 Remove the fat reducer from the pan using rubber tipped tongs.
Dispose of rendered fat or oil from the bottom of the pan.
3 Clean the pan, basket and fat reducer in a dishwasher. You can also
clean them with hot water, dishwashing liquid and a non-abrasive
sponge (see ‘cleaning table’).
Tip
•If food residues stuck to the pan, fat reducer or basket, you can soak them in
hot water and dishwashing liquid for 10–15 minutes. Soaking loosens the food
residues and makes it easier to remove. Make sure you use a dishwashing
liquid that can dissolve oil and grease. If there are grease stains on the pan, fat
reducer or basket and you have not been able to remove them with hot water
and dishwashing liquid, use a liquid degreaser.
•If necessary, food residues stuck to the heating element can be removed with
a soft to medium bristle brush. Do not use a steel wire brush or a hard bristle
brush, as this might damage the coating on the heating element.
4 Wipe the outside of the appliance with a moist cloth.
Note
•Make sure no moisture remains on the control panel. Dry the control panel with
a cloth after you have cleaned it.
5 Clean the heating element with a cleaning brush to remove any food
residues.
6 Clean the inside of the appliance with hot water and a non-abrasive
sponge.
