Philips eW®Profile
Powercore®
Ideally suited for work
surfaces, display cases and
under cabinet locations
ESSE TIALWHITE™SERIES
(1, 2 See back page for footnotes.)
Sleek design is simple to install,
power and maintain
Philips eW®Profile Powercore low profile linear white LED fixture provides
efficient under cabinet lighting, task lighting and display case lighting.
High efficacy LED linear fixture
• Offers long life with minimum lumen maintenance
at 50,000 hours1
• Saves energy, low power consumption
• Available in 2700K and 4000K color temperatures
• Fully dimmable
• Enables runs up to 50 linear fixture feet
• Prevents fading of fabric, no UV/IR damage
Low profile 7⁄8" fixture with multiple mounting options
• Blends with the environment, unobtrusive fixture
• Avoids additional installation costs, no transformer to hide
Powercore Technology—direct line voltage connection
• Installs easily, connects directly to power at junction box2
P-5978-A eW P ofile Powe co e Bulletin.qxd:Layout 1 1/6/09 1:23 PM Page 1

Printed on chlorine free paper from Sappi Fine Paper mills, who are accredited with EMAS environmental certification.
Sappi claims that the pulp used in the manufacture of Magno Dull paper is derived from environmentally certified forests.
© 2008 Philips Lighting Company. All rights reserved.
eW and EssentialWhite are trademarks of Philips
Electronics .A. in the U.S. and other countries.
Printed in USA 12/08
P-5978-A
www. philips.com
Philips Lighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, J 08875-6800
1-800-555-0050
A Division of Philips Electronics orth America Corporation
Philips Lighting
281 Hillmount Road
Markham, Ontario
Canada L6C 2S3
1-800-555-0050
A Division of Philips Electronics Ltd.
Philips eW®Profile Powercore
Ordering, Electrical and Technical Data (Subject to change without notice)
Minimum Min.
Product SAP Alternate Color Nominal Initial Watts @ Lumen
Number Description SAP Description Temp. Length Lumens3Steady State Maint.1
22157-2 eW PROFILE, 11", 2700K, 120VAC eW PROFILE, 11", 2700K, 120VAC 2700K 11" 150 6.5 50,000 hrs
22161-4 eW PROFILE, 21", 2700K, 120VAC eW PROFILE, 21", 2700K, 120VAC 2700K 21" 275 10.0 50,000 hrs
22162-2 eW PROFILE, 41", 2700K, 120VAC eW PROFILE, 41", 2700K, 120VAC 2700K 41" 524 20.0 50,000 hrs
22163-0 eW PROFILE, 11", 4000K, 120VAC eW PROFILE, 11", 4000K, 120VAC 4000K 11" 180 6.5 50,000 hrs
22166-3 eW PROFILE, 21", 4000K, 120VAC eW PROFILE, 21", 4000K, 120VAC 4000K 21" 325 10.0 50,000 hrs
22168-9 eW PROFILE, 41", 4000K, 120VAC eW PROFILE, 41", 4000K, 120VAC 4000K 41" 648 20.0 50,000 hrs
1) Minimum Lumen Maintenance is the minimum number of hours after which the LED light output depreciates to 70% of its initial output. This value, L70, is tested @ 25°C ambient temperature. (IES LM-80)
2) 120 and 277 (all 50/60Hz) @ 15W steady state.
3) The SSL Fixture, Initial Lumens is determined as prescribed in IESNA LM-79, Approved Method for the Electrical and Photometric Measurements of Solid-State Lighting Products, which specifies lumen measurements
of the fixture be reported after the measurements have stabilized at 25°C.
Ordering and Shipping Data (Subject to change without notice)
SKUs SKUs Case Case Case
Product SAP Alternate SKUs Per Per LxDxH Gr.Wt Volume
Number Description SAP Description MOQ Case Pallet (in.) (lb.) (cu. ft.)
BASE UNITS
22157-2 eW PROFILE, 11", 2700K, 120VAC eW PROFILE, 11", 2700K, 120VAC 1 SKU 25 675 13.2 x 12.7 x 15.9 13.1 1.55
22161-4 eW PROFILE, 21", 2700K, 120VAC eW PROFILE, 21", 2700K, 120VAC 1 SKU 25 300 22.8 x 13.4 x 16.2 27.2 2.87
22162-2 eW PROFILE, 41", 2700K, 120VAC eW PROFILE, 41", 2700K, 120VAC Case 6 120 42.4 x 8.9 x 8.0 12.8 1.75
22163-0 eW PROFILE, 11", 4000K, 120VAC eW PROFILE, 11", 4000K, 120VAC 1 SKU 25 675 13.2 x 12.7 x 15.9 13.1 1.55
22166-3 eW PROFILE, 21", 4000K, 120VAC eW PROFILE, 21", 4000K, 120VAC 1 SKU 25 300 22.8 x 13.4 x 16.2 27.2 2.87
22168-9 eW PROFILE, 41", 4000K, 120VAC eW PROFILE, 41", 4000K, 120VAC Case 6 120 42.4 x 8.9 x 8.0 12.8 1.75
ACCESSO IES
22177-0 eW PROFILE, LDR, 10',WHT, US PLG eW PROFILE, LDR, 10',WHT, US PLG Case 12 528 13.4 x 10.8 x 11.2 14.6 0.94
22180-4 eW PROFILE, 6" JMPR, UL,WHT eW PROFILE, 6" JMPR, UL,WHT 8 SKUs 64 2816 13.4 x 10.8 x 11.2 5.7 0.94
22181-2 eW PROFILE, 12" JMPR, UL,WHT eW PROFILE, 12" JMPR, UL,WHT 8 SKUs 64 2816 13.4 x 10.8 x 11.2 6.8 0.94
22182-0 eW PROFILE, 18" JMPR, UL,WHT eW PROFILE, 18" JMPR, UL,WHT 8 SKUs 32 1408 13.4 x 10.8 x 11.2 5.7 0.94
22184-6 eW PROFILE, 5' JMPR, UL,WHT eW PROFILE, 5' JMPR, UL,WHT 8 SKUs 24 1056 13.4 x 10.8 x 11.2 8.4 0.94
22186-1 eW PROFILE, 12" Y-JMPR, UL,WHT eW PROFILE, 12" Y-JMPR, UL,WHT 8 SKUs 24 1056 13.4 x 10.8 x 11.2 6.4 0.94
22195-2 eW PROFILE,WIRI G COMPARTME T eW PROFILE,WIRI G COMPARTME T 8 SKUs 80 4400 13.4 x 9.5 x 4.3 33.1 0.32
22200-0 eW PROFILE, 11" MOU TI G TRACK eW PROFILE, 11" MOU TI G TRACK Case 1 150 10.6 x 9.5 x 4.3 7.5 0.25
22196-0 eW PROFILE, 21" MOU TI G TRACK eW PROFILE, 21" MOU TI G TRACK Case 1 100 19.8 x 9.5 x 4.3 12.1 0.47
22198-6 eW PROFILE, 41" MOU TI G TRACK eW PROFILE, 41" MOU TI G TRACK Case 1 45 43.3 x 7.5 x 4.9 20.3 0.92
22489-9 eW PROFILETRMTRS MULTIPACK 10PC eW PROFILE TRMTRS MULTIPACK 10PC 10 SKUs 40 1760 13.4 x 10.8 x 11.2 12.6 0.94
eW Profile Installation
Meets IESNA Standards for Luminance
Category D applications at 40 fc, 2700K
• Ideal for nursing stations, hotel bathrooms, merchandising
displays, general kitchen lighting, and checkout counters
Meets IESNA Standards for Luminance
Category E applications at 50 fc, 4000K
• Ideal for critical kitchen prep areas, high-activity casino
areas, food service displays, and detailed industrial
processing stations
