Philips ELANCE GC3035 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Steam Iron Elance
GC3035
03/07
PRODUCT INFORMATION
Features
- Colour pearl blue
- Careeza soleplate
- Tank capacity (300 ml)
- Steam rate (35 g/min)
- Shot of steam (85 g/min)
- Vertical steam
- Permanent Anti-Calc
- Automatic shut off
- Soft touch hand grip
- Drip stop
- Anti slip
- Integrated cord winder
- Cord length : 2 m.
Safety Information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements and
legal regulations as officially laid down at this moment.
TECHNICAL INFORMATION
Voltage : 120 V, 220 - 240 V
Frequency : 50 - 60 Hz
Power consumption : 1300 W, 1900 W
Water advice
Suitable for tap water use. However if the tap water in
your area is very hard, we advise you to mix it with a equal
portion of distilled water or to use distilled water only.
Cleaning of the Iron
Use only the Calc clean button for cleaning of the Iron.
Never use vinegar, starch or chemically descaled water.
Soleplate
Careeza is a multi layer chemical substance that gives an
excellent gliding over various fabrics and better care for the
garments.
Vertical Steam
When the iron is kept in a vertical position, the shot of steam
(S.O.S) button can be used to iron hanging fabrics such as
curtains.
Auto shut-off
A relay in the electronic module interrupts the power to the
heating element when the iron has been motionless.
- for 30 secs in the horizontal position.
- for 8 minutes in the vertical position.
The Auto- shut-off is activated when the red ”Auto-off” pilot
light starts blinking. It is automatically switched ‘ON’ again
when the iron is moved.
Drip stop
Water is only released to through the tank valve into the
steam chamber if the soleplate temperature is high enough
to evaporate all water. If the temperature is too low, the tank
valve is closed by means of a bi-metal disc.
Anti Slip heel rest
The rubberised part that is provided on the backplate prevent
the iron from slipping off a smooth surface (like a table top)
when left in a vertical position.
= changed

GC3035
DIAL 1
BACKPLATE 2
CORD SET 3
SWIVEL 4
Remove Screw A (1x)
Remove BACKPLATE 2
Remove Screw B (2x) cord clamping
DISASSEMBLY ADVICE
INLAY 5
AUTO SHUT OFF UNIT 6
FILLING DOOR 7
STEAM SLIDER 8
LAMP COVER 9
SOS KNOB 10
SPRAY KNOB 11
TANK SEAL 12
remove Screw A (1x)
remove BACKPLATE 2
remove Screw B (2x) cord clamping
remove INLAY 5
DOSING UNIT 13
remove Screw A (1x)
remove BACKPLATE 2
remove Screw B (2x) cord clamping
remove INLAY 5
remove Screw C (2x)
remove Screw D (2x)
remove DOSING UNIT 13
HANDLE 14
RATTLE SPRING 15
PUMP 16
remove Screw A (1x)
remove BACKPLATE 2
remove Screw B (2x) cord clamping
remove INLAY 5
remove Screw C (2x)
remove Screw D (2x)
remove DOSING UNIT 13
remove Screw E (2x)
remove HANDLE 14
TANK 17
VALVE BELLOW 18
THERMOSTAT BUSH 19
remove Screw A (1x)
remove BACKPLATE 2
remove Screw B (2x) cord clamping
remove INLAY 5
remove Screw C (2x)
remove Screw D (2x)
remove DOSING UNIT 13
remove Screw E (2x)
remove HANDLE 14
remove Screw F (2x)
remove TANK 17
SHIELD 20
remove Screw A (1x)
remove BACKPLATE 2
remove Screw B (2x) cord clamping
remove INLAY 5
remove Screw C (2x)
remove Screw D (2x)
remove DOSING UNIT 13
remove Screw E (2x)
remove HANDLE 14
remove Screw F (2x)
remove TANK 17
remove Screw G (1x)
remove SHIELD 20
COVER 21
SOS SEAL 22
DOSING SEAL 23
SOLEPLATE ASSY 24
remove Screw A (1x)
remove BACKPLATE 2
remove Screw B (2x) cord clamping
remove INLAY 5
remove Screw C (2x)
remove Screw D (2x)
remove DOSING UNIT 13
remove Screw E (2x)
remove HANDLE 14
remove Screw F (2x)
remove TANK 17
remove Screw G (1x)
remove SHIELD 20
remove Screw H (2x)
remove COVER 21 2-4

GC3035
PARTS LIST
REPAIR INSTRUCTIONS
- Due to high voltage of the iron, ONLY the specified cordsets must be used.
- For standardisation reasons :
Type plate : No information about the typenumber and voltage have been stamped onto the typeplate.
When replacing the typeplate, engrave at least typenumber onto the typeplate with a sharp object.
- Thermostat, fitted to the soleplate 24 has already been adjusted by the supplier and secured by glue. To avoid mal-function of the
iron, NEVER re-adjust the thermostat.
NOTE :
The thermostat can only be ordered together with the soleplate assembly 24.
OPTIONAL (accessories)
- No specific issues
THERMOSTAT
HEATING
UNIT
FUSE
BLACK
BROWN
ELECTRONIC
MODULE
INPUT
BLUE
RED
L
N
E
3-4
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
4239 022 53260
4239 022 53090
4239 000 07970
4322 000 08380
4239 026 10120
4239 021 10500
4239 021 01960
4239 021 01970
4239 021 10070
4239 026 10170
4239 026 08280
4239 026 10050
4239 026 10100
4239 015 54400
4239 021 11730
4239 026 10440
4239 026 08840
4239 020 90560
4239 022 53281
4239 020 85140
4239 015 98410B
4239 010 07850
4239 026 10420
4239 015 51450
4239 015 55430
4239 022 53150
4239 022 53160
Dial
Backplate
Cordset (Europe)
Cordset (UK)
Swivel
Inlay
Auto Shut Off unit (ASO)
Auto Shut Off unit (ASO - LV)
Filling door assy
Steam slider
Lamp cover
SOS knob
Spray knob
Tank seal
Dosing unit
Handle
Rattle spring
Pump
Tank Assy (Drip stop)
Valve bellow
Thermostat bush
Heat shield
Cover (Drip Stop)
SOS seal
Dosing seal
Soleplate assy 230 V / 1800 W
Soleplate MTD assy 120 V / 1300 W
Note:
When replacing either Dosing seal (23) or Heat shield (20), both parts have to be replaced together.
= changed

GC3035
EXPLODED VIEW
4-4
Screws : d x 1
A, B 3.5 x 16 mm
C2.5 x 14 mm
D3.5 x 15 mm
E3.5 x 17 mm
(with washer 1mm)
F4.0 x 12 mm
(with washer 1mm)
G4.0 x 10 mm
