Important: Do not attach or detach the spout when the juicing unit is mounted on
the motor unit. Always take o the juicing unit from the motor unit before
assembling or disassembling.
6 Place the berry tray on the feeding tube (Fig. 7).
Placing the juicing unit onto the motor unit
1 Place the assembled juicing unit onto the motor unit, with the pulp outlet
tting into the opening on the motor unit (Fig. 8).
2 Align the projections on the juicing unit with the recesses in the motor unit.
Slide the juicing unit onto the motor unit until it locks into place. (Fig. 9)
3 Press the juicing unit onto the motor unit (1) and then close the locking clamp
(2). (Fig. 10)
Note: If the locking clamp cannot be closed, check if the juicing unit is positioned
properly with the projections on the juicing unit into the recesses of the motor
unit.
4 Slide the pulp container into the motor unit (Fig. 11).
Using the appliance
The appliance only functions if the juicing unit and the pulp outlet are
assembled correctly and the locking clamp is locked properly.
1 Wash the fruit and/or vegetables. If necessary, cut them into pieces that t into
the feeding tube.
Note: Remove stones and thick peels of the fruits you would not eat, for example
from oranges, pomegranates etc.
2 Place a jug or a glass under the spout (Fig. 12).
3 Press the on/o button to switch on the appliance (Fig. 13).
4 Put the pieces of fruit or vegetables in the feeding tube and gently press them
down towards the juicing screw with the pusher (Fig. 14).
Never insert your ngers or an object into the feeding tube or juicing unit.
5 When the juice ow has stopped, switch o the appliance and wait until the
juicing screw has stopped rotating.
6 Press the pre-clean button to remove the last drops of juice from the juicing
unit (Fig. 15).
7 To prevent juice from dripping onto the table, press the drip stop (Fig. 16).
Tips
-Use fresh fruit and vegetables, as they contain more juice. Pineapples, beetroots,
celery stalks, apples, cucumbers, carrots, spinach, melons, tomatoes,
pomegranates and grapes are particularly suitable for processing in the juicer.
-You do not have to remove thin peels or skins. Only remove peels which you
would not eat, e.g. those of oranges, pineapples, kiwis, melons and uncooked
beetroots.
-If you want to juice fruits with stones, such as peaches, plums or cherries,
remove the stones before juicing.
