Philips 800 Series T12 Fluorescent Lamps
featuring ALTO®Lamp Technology
High Performance, Long Life, Environmentally-Responsible Lamps
Ideal for all applications requiring
maximum continuous light output
such as offices, industry, healthcare,
schools and retail
◗Performance
–High CRI of 82
–Approximate inital lumens range
from 2650–3200
–Replace Philips SPEC Lamps with Philips
800 Series Lamps for higher CRI
◗Long Life
20,000 hours rated average life1
◗Available in 34W Econ-O-Watt®
and 40W
◗Ballast
–Operates on current ballasts
–Magnetic or electronic
–Replace standard T12 lamps for longer life
◗EnvironmentallyResponsible
–Lowmercury: TCLP2-compliant
–Energy efficient
–Long life
◗Sustainable Lighting Solution
Less mercury and fewer lamps in landfills,
combined with energy efficiency, reduces the
impact on the environment
◗Look for the Green End-Caps®
Our Green End-Caps mean you are using
ALTO®environmentally-responsible lamps
1) Average life under specified test conditions with lamps turned off and
restarted no more frequently than once every 3 operating hours. Lamp
life is appreciably longer if lamps are started less frequently.
2) The TCLP is the US EPA’s Toxicity Characteristic Leaching Procedure.
Photo © Z. Jedrus.

Approx. Rated Color Color
Nominal Product Ordering Product Ordering Length Initial Design Average Temp. Rendering
Watts Number Code Number Code Bulb (In.) Lumens1Lumens2Life (Hrs.)3(Kelvin) Index (CRI)
34 23775-0 F34/SPEC30/RS/EW/ALTO 14253-9 F34T12/830/EW/ALTO T12 48 2800 2660 20,000 3000 82
34 23777-6 F34/SPEC35/RS/EW/ALTO 14254-7 F34T12/835/EW/ALTO T12 48 2800 2660 20,000 3500 82
34 23779-2 F34/SPEC41/RS/EW/ALTO 14255-4 F34T12/841/EW/ALTO T12 48 2800 2660 20,000 4100 82
34 Now Available > 14256-2 F34T12/850/EW/ALTO T12 48 2650 2520 20,000 5000 82
40 27311-0 F40/SPEC30/ALTO 14261-2 F40T12/830/ALTO T12 48 3200 3040 20,000 3000 82
40 27291-4 F40/SPEC35/ALTO 14262-0 F40T12/835/ALTO T12 48 3200 3040 20,000 3500 82
40 27295-5 F40/SPEC41/ALTO 14263-8 F40T12/841/ALTO T12 48 3200 3040 20,000 4100 82
40 Now Available > 14264-6 F40T12/850/ALTO T12 48 3050 2900 20,000 5000 82
Electrical,Technical and Ordering Data (Subject to change without notice)
Philips 800 Series T12 Fluorescent Lamps Featuring ALTO®Lamp Technology
Philips Lighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, NJ 08875-6800
1-800-555-0050
ADivision of Philips Electronics North America Corporation
Printed in USA 6/05 P-1373-G
Philips Lighting
281 Hillmount Road
Markham, Ontario
Canada L6C 2S3
1-800-555-0050
ADivision of Philips Electronics Ltd.
www.philips.com
Old Product: SPEC New Product: Philips 800 Series Lamps
1) Approximate initial lumens.The lamp lumen output is based upon lamp performance after 100 hours of operating life, when the output is measured during operation on a reference ballast under standard laboratory conditions.
For expected lamp lumen output, commercial ballast manufacturerscan advise the appropriate ballast factor for each of their ballasts when they are informed of the designated lamp.The ballast factor is a multiplier applied to the
designated lamp lumen output.
2) Design lumens are the approximate lamp lumen output at 40% of the lamp’s rated average life.This output is based upon measurements obtained during lamp operation on a reference ballast under standard laboratory conditions.
3) Average life under specified test conditions with lamps turned off and restarted no more frequently than once every 3 operating hours. Lamp life is appreciably longer if lamps are started less frequently.
E
N
V
I
R
O
N
M
E
N
T
B
E
T
T
E
R
F
O
R
T
H
E
†
†This fluorescent lamp is better for the environment because of its reduced mercury content.All fluorescent lamps
contain mercury for effective operation, however, Philips lamps with ALTO®Lamp Technology average 70% less
mercury than the 2001 industry average for fluorescent lamps up to sixty inches which are not TCLP-compliant.
