Philips Alto CDM-i25w User manual

CDM-i25w/PAR38/A TO
Transform your business
with a simple twist!
The Philips MasterColor®Integrated 25W is an
all-in-one lamp and ballast in a PAR38 reflector.
MasterColor®technology
• Energy savings—Up to 3x less energy consumption than
standard PAR38 halogen lamps with comparable light output
• 15,000 hours rated average life1— asts up to 3x
longer than standard halogen PAR38
• Very good color rendering of 87, crisp white light (3000K)
Integrated electronic ballast
• Easy upgrade and instant retrofit from halogen PAR38
Familiar PAR38 shape and size
• Simple ‘twist in’ for one step easy installation
• Easy maintenance
• 10º, 25º, and 40º beam spread
(1, See back of page for footnote)
Philips MasterColor®
Integrated 25W PAR38
Ceramic Metal Halide
amps featuring A TO®
amp Technology
Ideal for general, ambient
or accent lighting
†This lamp is better for the environment
because of its reduced mercury content.
All Philips ALTO®lamps give you end-of-life
options which can simplify and reduce your
lamp disposal costs depending on your
state and local regulations.

CDM-i25w/PAR38/A TO
Philips MasterColor®Integrated 25W PAR38 Ceramic Metal Halide amps
featuring A TO®amp Technology
Ordering Data
Product Pkg.
Number Ordering Code Qty. Beam MBCP2
14477-4 CDM-i25W/830/PAR38/10/A TO 6 Spot (10˚) 26,000
14478-2 CDM-i25W/830/PAR38/25/A TO 6 Flood (25˚) 5600
14479-0 CDM-i25W/830/PAR38/40/A TO 6 Wide Flood (40˚) 2100
Warnings, Cautions and Operating Instructions
WARNING: These lamps can cause serious skin burn
and eye inflammation from short wave ultraviolet radiation
if outer envelope of the lamp is broken or punctured. Do
not use where people will remain for more than a few
minutes unless adequate shielding or other safety precautions
are used.Certain lamps that will automatically extinguish
when the outer envelope is broken or punctured are
commercially available.” This lamp complies with FDA
radiation performance standard 21 CFR subchapter J.
(USA:21CFR 1040.30 Canada:SOR/DORS/80-381)
If the outer bulb is broken or punctured, turn off at
once and replace the lamp to avoid possible injury
from hazardous short wave ultraviolet radiation. Do
not scratch the outer bulb or subject it to pressure
as this could cause the outer bulb to crack or shatter.
Apartial vacuum in the outer bulb may cause glass
to fly if the envelope is struck.
WARNING: The arc-tube of metal halide lamps are designed
to operate under high pressure and at temperatures up to
1000°C and can unexpectedly rupture due to internal or
external factors such as a ballast failure or misapplication.
If the arc-tube ruptures for any reason, the outer bulb may
break and pieces of extremely hot glass might be discharged
into the surrounding environment. If such a rupture were to
happen, THERE I A RI K OF PER ONAL INJURY,
PROPERTY DAMAGE, BURN AND FIRE.
This lamp contains an arc tube with a filling gas
containing less than 41 nCi of Kr-85 and is distributed
by Philips Lighting Company, a division of Philips
Electronics North America Corporation, omerset,
New Jersey, 08875.
CAUTION:TO REDUCE THE RISK OF PERSONA INJURY,
PROPERTY DAMAGE, BURNS AND FIRE RESU TING
FROM AN ARC-TUBE RUPTURE THE FO OWING
AMP OPERATING INSTRUCTIONS MUST BE FO OWED.
LAMP OPERATING IN TRUCTION :
1. At high lighting levels or when illuminating light-sensitive
materials the use of an extra UV filter is recommended.
2. Before lamp installation/replacement, shut power off and
allow lamp and fixture to cool to avoid electrical shock and
potential burn hazards.
3.Time should be allowed for lamps to stabilize in color
when turned on for the first time.This may require several
hours of operation, with more than one start. amp color
is also subject to change under conditions of excess
vibration or shock, and color appearance may vary
between individual lamps.
4. amps may require up to 10 minutes to re-light if there
is a power interruption.
5. Do not operate with an additional ballast, since a ballast
is integrated in the lamp itself.
6. Do not use in totally enclosed recessed fixtures.
7. Take care in handling and disposing of lamps. If an
arc tube is broken, avoid skin contact with any of the
contents or fragments.
8. amp should not be used with dimmers.
9. Protect lamp, lamp socket and wiring against moisture,
corrosive atmosphere and excessive heat. amp should
be used in dry locations only.
These lamps may be used in open fixtures.
Hg: LAMP CONTAIN MERCURY Manage
in Accord with Disposal Laws ee:
www.lamprecycle.org or 1-800-555-0050
1) Rated average life is the life obtained, on the average, from large representative groups of lamps in laboratory tests
under controlled conditions at 10 or more operating hours per start. It is based on survival of at least 50% of the
lamps and allows for individual lamps or groups of lamps to vary considerably from the average.
2) Maximum Beam Candlepower.
3) CA TION: New construction should allow for the current used by these lamps. Because of a power factor
of 0.57 in the ballast of the lamp, the lamp uses .36 amps.
4) Measured at 100 hrs. life.Approximate lumen values listed are for vertical operation of the lamp.
5) Approximate lumen output at 40% of lamp rated average life.
This product utilizes ALTO®Lamp Technology. ALTO products pass the S EPA's Toxicity Characteristic Leaching
Procedure (TCLP) and can be classified as non-hazardous waste. Check with state and local regulations.
Above specifications subject to change without notice.
© 2008 Philips ighting Company. All rights reserved.
Printed in USA 12/08
P-5747-F
www. philips.com
Philips ighting Company
200 Franklin Square Drive
P.O. Box 6800
Somerset, NJ 08875-6800
1-800-555-0050
A Division of Philips Electronics North America Corporation
Philips ighting
281 Hillmount Road
Markham, Ontario
Canada 6C 2S3
1-800-555-0050
A Division of Philips Electronics td.
Electrical and Technical Data
Wattage ––––––––––––––––––––––––––––––––25W
Input Voltage ––––––––––––––––––––––––120V±10%
Max.THD –––––––––––––––––––––––––––––––142%
Frequency–––––––––––––––––––––––––––––––60Hz
Input Current3––––––––––––––––––––––––––––0.36
Warm-up to 80% Full Brightness –––––––––2 minutes
RestrikeTime for Hot amps–––––––––– 5-7 minutes
Minimum Operating Temp.–––––––––––– -20˚C (-4˚F)
Physical Characteristics
Bulb Size–––––––––––––––––––––––––––––––PAR38
Bulb Finish ––––––––––––––––––––––––––––––Clear
Base –––––––––––––––––––––––––––––––––Medium
Max. Overall ength (MO ) –––––––––5.33'' (135mm)
ight Center ength ( C ) ––––––––––––––––––N/A
Arc ength –––––––––––––––––––––––––––––––N/A
Arc Tube Material ––––––––––Polycrystalline Alumina
Max. Ring Temp. ––––––––––––––––––––65ºC (149ºF)
Max. Cap Temp. ––––––––––––––––––––65ºC (149ºF)
Max. Neck Temp. –––––––––––––––––––80˚C (176˚F)
Max.Arc Tube to Base Eccentricity ––––––––––––––3º
Operating Characteristics
Approx. Initial umens4–––––––––––––––––––––1275
Approx. Mean umens4,5 –––––––––––––––––––––880
Rated Average ife, Hours.1––––––––––––––––15,000
Correlated Color Temp. (CCT)2––––––––––––3000K
CIE Chromaticity Approx.2–––––––––––x-.440, y-.393
Color Rendering Index (CRI)––––––––––––––––––87
Efficacy (lpw)–––––––––––––––––––––––––––––––51
Beam Angle (at 50% of MBCP)––––––––––10˚/25˚/40˚
Operating Position
Universal-Open or Enclosed PAR Style uminaires
(Do not use in totally enclosed recessed luminaires.)
Spectral Power Distribution
Power (W per nm)
200 300 400 500 600 700 800
Wavelength (Nanometers)
0.08
0.07
0.06
0.05
0.04
0.03
0.02
0.01
0
