Philips VisaPure Advanced SC53 Series User manual

VisaPure
Advanced
Advanced
SC53XX
19076.pdf 1 07-06-16 16:55

1
2
4
8
9
3
5
6
7
12
11
10
14
15
16
17
13
1

English 6
简体中文 21
繁體中文 32
한국의 43

English
Introduction
Congratulations on your purchase and welcome to Philips! To fully
benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
With VisaPure Advanced you will enjoy a range of benefits to reveal a
radiant, revitalized and refreshed skin. Thanks to Intelligent Head
Recognition, the appliance recognizes which head you put on and
automatically activates a customized DualMotion program, with
dedicated levels of rotation, duration and vibration. This means you
get great skincare results! VisaPure Advanced comes with a diverse
set of heads that can be easily integrated into your skincare routine.
You can use all heads with your current skincare products like
cleansers, creams, oils and serums. This user manual contains usage
instructions for the device and information about the recommended
cleansing process. In the box you find separate leaflets with usage
information and instructions for the other attachments.
Why cleansing?
Cleansing is an essential part of the daily skincare routine. VisaPure
Advanced cleanses your skin better compared to cleansing by hand*.
It cleanses your skin thoroughly and removes dead skin cells and
make-up. Through research we found out that your skincare products
will be absorbed better after you have used VisaPure Advanced.
Therefore your skin feels clean and soft after you used VisaPure
Advanced.
* Internal study performed in the Netherlands in 2015 with 15 women.
General description (Fig. 1)
1 Handle
2 Charging light and battery low indication
3 Intensity setting indication
-Intensity setting 1
-Intensity setting 2
4 On/off button
5 Connection pin
6 Charging pins
6English

7 Anti-roll ridge
8 Brush head
9 Socket for small plug
10 Protection cap
11 Charging stand
12 Small plug
13 Adapter
14 Travel pouch (specific Visapure types only)
15 Storage palette (specific Visapure types nly)
16 Fresh Eyes head (specific Visapure types only)
17 Revitalising Massage head (specific Visapure types only)
Important
Read this user manual carefully before you use the appliance and
save it for future reference.
Danger
-Keep the adapter dry.
Warning
-For the purpose of recharging the battery,
only use the detachable supply unit
provided with this appliance. Adapter
reference number SSW-2082 or SSW-2600.
-Do not use the appliance, an attachment or
the adapter if it is damaged or broken to
avoid injuries.
-If the adapter is damaged, always have it
replaced with one of the original type in
order to avoid a hazard.
7
English

-The adapter contains a transformer. Do not
cut off the adapter to replace it with another
plug, as this causes a hazardous situation.
-Fully charge the appliance at least every 3
months to sustain battery lifetime.
-This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
-Children should be supervised to ensure
that they do not play with the appliance.
-Do not insert metal-containing material into
the socket for the small plug to avoid short
circuiting.
Caution
-Only use VisaPure attachments from Philips
as described in this user manual.
-For hygienic reasons, we advise you to not
share the appliance and the heads with
other people.
8English

-Do not clean the appliance with water that
is hotter than shower temperature (max.
40°C/104°F).
-Do not put the appliance or any part in the
dishwasher.
-Charge, use and store the appliance at a
temperature between 10°C/50°F and
40°C/104°F.
-Do not use the appliance on chapped skin,
open wounds, healing wounds, skin
recovering from surgery or if you suffer from
a skin disease or skin irritation, such as
severe acne, sunburn, skin infection, skin
cancer, inflammation, eczema, psoriasis,
nylon allergy etc.
-Do not use the appliance if you are taking
steroid-based medication.
-If you wear piercings on your face, remove
the piercings before you use the appliance
or make sure that you do not use the
appliance on or near the piercing.
9
English

-Please make sure that no loose hair gets
trapped in the attachment during use by
wearing a headband, tying your hair or
holding it back with your hands.
-If you wear jewelry or glasses, take them off
before you use the appliance, or make sure
that you do not use the appliance on or
near jewelry or glasses.
-Do not use the appliance with self-made
cleansers, creams, oils or cosmetic products
containing harsh chemicals or rough
particles.
-Select intensity setting 1 the first few times
you use the appliance or when you use a
new type of attachment. If you do not
experience any skin reactions, you can start
using the appliance at intensity setting 2.
Your skin might need to get used to the new
treatment just like it normally does with a
new skincare product.
10 English

-If your device has intelligent attachments
with NFC tag, please follow the usage
instructions described in their separate
leaflets.
General
-Please note that the condition of the skin
varies throughout the year. Facial skin can
get dryer during the winter season. In that
case you may reduce the treatment time or
frequency, depending on the needs of your
skin.
-Regular cleaning of the appliance ensures
optimal results and a longer life of the
appliance.
-The appliance complies with the
internationally approved IEC safety
regulations and can be safely used in the
shower and cleaned under the tap.
-The appliance is equipped with an
automatic voltage selector and is suitable
for mains voltages ranging from 100 to 240
volts.
11
English

Electromagnetic fields (EMF)
This Philips device complies with all applicable standards and
regulations regarding exposure to electromagnetic fields.
Features
Intelligent Head Recognition
VisaPure Advanced has Intelligent Head Recognition. Each
attachment that comes with VisaPure has specific levels of rotation
and vibration. When you attach a different intelligent attachment and
switch on the appliance, it recognizes the intelligent attachment. You
hear a beep and the intensity setting indications flash alternately. The
device then activates a customized program for the attachment in use
(Fig. 3).
Intensity settings
You can choose between 2 different intensity settings depending on
your personal preference.
- Intensity setting 1 for a gentle treatment (Fig. 4).
- Intensity setting 2 for an intensive treatment.
The first time you use the appliance, we advise you to select intensity
setting 1. If you do not experience any skin reactions, you can start
using the appliance at intensity setting 2.
Note: your skin might need to get used to the new treatment just
like it normally does with a new skincare product.
The intelligent attachments with NFC tag may require other treatment
settings. Consult the separate leaflets of the different attachments for
the advised treatment settings or visit www.philips.com
Skin zone timer
The skin zone timer indicates when you need to move the appliance
to another skin zone. For more information about skin zones, see
chapter 'Using the brush head'.
12 English

Using the brush head
You can either use VisaPure Advanced in front of the sink or in the
shower. We advise you to use the brush head in combination with
your favorite cleanser. You can cleanse your face with VisaPure
Advanced twice a day. Other types of attachments may require other
treatment frequencies. Consult the separate leaflets of the different
types of attachments for the advised treatment frequencies or visit
www.philips.com/.
Facial cleansing with VisaPure Advanced
Skin zones
The face can be divided into two zones: the U-zone (cheeks, chin and
the area between nose and upper lip) and the T-zone (forehead and
nose). Always treat the zones one by one, in the following order (Fig.
5):
1Right cheek, chin and area between nose and upper lip
2Left cheek, chin and area between nose and upper lip
3Forehead and nose
Cleansing program
The cleansing program consists of 3 treatment periods of 15 to 20
seconds. The exact duration depends on the type of brush head you
have, so please consult the separate leaflets from your attachment
for the advised treatment periods. The treatment periods for VisaPure
Advanced intelligent brush heads are customized and vary from
person to person.
• For optimal performance, start on the right cheek and switch to the
left cheek after 15 - 20 seconds. Use the last 15- 20 seconds to treat
the forehead and nose (Fig. 6).
Tip: You can also use the VisaPure Advanced cleansing brush heads
for cleansing the neck and décolleté.
Note: VisaPure Essential does not have Intelligent Head
Recognition and therefore does not recognize the customized
settings of intelligent attachments.
13
English

Note: do not use the brush head on the sensitive skin area around the
eyes.
Tip: if you want to change the rotation direction of your attachment
after you turned on the appliance, you can hold the button until the
rotation direction changes.
Cleansing procedure
1Push the brush head onto the connection pin until it locks into
position with a click. (Fig. 7)
2Moisten the brush head with water. Do not use the appliance with
a dry brush head, as this can irritate the skin.
3Moisten your face with water and apply a cleanser to your face.
4Place the brush head on your right cheek.
5Press the on/off button once to switch on the appliance. The
appliance starts to operate at intensity setting 1. If you want to use
intensity setting 2, press the on/off button twice. Press three times
to switch off the appliance or wait until it switches off
automatically (Fig. 8).
6Gently move the brush head across your skin from the nose
towards the ear (Fig. 9).
Tip: Do not push the brush head too hard onto the skin to make sure
the treatment remains comfortable.
7The face can be divided in different zones. The intelligent skin
zone timer lets you know through a short pause when it is time to
move to the next skin zone (Fig. 10).
8After 15-20 seconds, the appliance pauses briefly to let you know
that you have to move the appliance. Gently move the brush head
from left to right (Fig. 11). The appliance stops automatically after it
has completed the program for the entire face.
Note: We advise you to not overdo the cleansing and to not
cleanse any zone longer than 20 seconds.
9After the treatment, rinse and dry your face.Your face is now ready
for the next step of your daily skincare routine.
10 Clean the brush head with water and mild soap and allow it to dry
properly.
14 English

Cleaning
Never use scouring pads, abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean the appliance.
Cleaning the appliance and the brush head
Make sure the appliance is switched off before you start cleaning it.
Rinse the appliance and the brush head thoroughly with water and
mild soap after each use, to ensure optimum performance.
1Rinse the appliance and the brush head under the tap with warm
water and mild soap (Fig. 12) (max. 40ºC/104ºF).
2Remove the brush head from the appliance (Fig. 13).
3Clean the bottom of the brush head and the connection pin of the
appliance under the tap at least once a week (Fig. 14).
4Dry the brush head and the appliance with a towel.
5Place the attachment on the storage palette (if you have one) and
leave it to dry. You can also leave the attachment on the handle
placed on the charging stand without the protection cap and leave
it to dry.
Cleaning the adapter and the charging stand
Danger: Always keep the adapter dry. Never rinse it
under the tap or immerse it in water.
1Make sure the adapter is unplugged when you clean it. Only wipe
it with a dry cloth.
2Always detach the charging stand from the adapter before you
clean it (Fig. 15).
3You can clean the charging stand with a moist cloth. Dry the
charging stand before you reconnect it to the adapter (Fig. 16).
Charging
Charging the appliance
Charging the appliance takes approximately 6 hours. A fully charged
appliance can be used for at least 2 weeks without charging.
1Make sure the appliance is switched off.
15
English

2Insert the small plug into the socket of the charging stand (1). Put
the adapter in the wall socket (Fig. 17) (2).
3Remove the protection cap (Fig. 18).
4Place the appliance upright into the charging stand, make sure
that it is placed properly (Fig. 19).
5The charging light flashes white to indicate that the appliance is
charging. When the battery is fully charged, the charging light
lights up white continuously for 30 minutes (Fig. 20).
Battery-low indication
When the battery is almost empty, the charging light flashes amber
for 15 seconds. The battery still contains enough energy for a
complete treatment (Fig. 21).
Storage
- Store the appliance in the charging stand (Fig. 22).
- To store the appliance horizontally, place it on its anti-roll ridge
(Fig. 23).
- You can store the brush heads in the storage palette (Fig. 24)
(specific types only).
-If you are taking the appliance with you when you travel, put
the protection cap on the dry brush head to protect the brush
head filaments (Fig. 25).
Note: Never put the protection cap on a wet brush head.
-Put the appliance in the travel pouch (Fig. 26) (specific types
only).
Brush head replacement
Damaged brush heads or worn filaments could lead to skin irritation.
To ensure a hygienic skincare routine, we advise to replace the brush
heads every 3 months, or earlier if the filaments are deformed or
damaged. Replacement brush heads are available from our website
www.shop.philips.com or from the shop where you purchased your
Philips VisaPure Advanced. If you have any difficulties obtaining
replacement brush heads, please contact the Philips Consumer Care
16 English

Center in your country. You find its contact details in the worldwide
guarantee leaflet. You can also visit www.philips.com/support.
Other attachments
If you like to know more about other types of heads that are available
for specific skincare needs, please visit www.philips.com/beauty for
information.
Recycling
- This symbol means that this product shall not be disposed of with
normal household waste (2012/19/EU) (Fig. 27).
- This symbol means that this product contains a built-in
rechargeable battery which shall not be disposed of with normal
household waste (Fig. 28) (2006/66/EC). We strongly advise you
to take your product to an official collection point or a Philips
service centre to have a professional remove the rechargeable
battery.
- Follow your country’s rules for the separate collection of electrical
and electronic products and rechargeable batteries. Correct
disposal helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Warning: Only remove the rechargeable battery when you discard the
appliance. Make sure the battery is completely empty when you
remove it.
1Remove the appliance from the charging stand, switch on the
appliance and let it operate until it switches off after one minute.
Repeat this action until the rechargeable battery is empty.
2Insert a small flathead screwdriver between the silver-colored ring
and the anti-roll ridge and pry loose the top part of the appliance.
Carefully pull the top part with the battery holder out of the
housing (Fig. 29).
3Remove the rechargeable battery from the battery holder.
Warning: Do not attempt to replace the rechargeable
battery.
17
English

Warning: Do not reconnect the appliance to the mains after
you have removed the rechargeable battery.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the international warranty leaflet.
Troubleshooting
This chapter summarizes the most common problems you could
encounter with the appliance. If you are unable to solve the problem
with the information below, visit www.philips.com/support for a list
of frequently asked questions or contact the Consumer Care Center in
your country.
Problem Solution
I do not know if
the appliance is
suitable for use
on my skin.
Do not use the appliance on dry, chapped skin,
open wounds, healing wounds, skin recovering
from surgery or if you suffer from a skin disease
or skin irritation, such as severe acne, sunburn,
skin infection, skin cancer, inflammation,
eczema, psoriasis etc. Do not use the appliance
if you are taking steroid-based medication.
The appliance
does not charge.
Consult the chapter ‘Charging the appliance’ for
the correct placement into the charging stand.
Make sure the socket to which you connect the
appliance is live. Check whether contact pins on
the appliance are in proper contact with the
contact points in the stand. If you use a socket
in a bathroom cabinet, you may need to switch
on the light to activate the socket. If the charging
light on the appliance still does not light up or if
the appliance still does not charge, take it to
your Philips dealer or the nearest Philips service
center.
18 English

The appliance
does not work
anymore.
Make sure that you have pressed the on/off
button properly. Charge the appliance according
to the instructions in this user manual. Verify
whether there is a power failure and if the wall
socket is live. Check if the charging light on the
appliance lights up to make sure the appliance
is charging. If it does not light up or if the
appliance still does not work, take it to your
Philips dealer or the nearest Philips service
center.
I don’t know
which heads I can
use with VisaPure
Advanced.
All standard or intelligent cleansing brush heads,
the Revitalising Massage head and the Fresh
Eyes head can be used with VisaPure
Advanced. To find out more about the range of
VisaPure attachments consult our website
www.shop.philips.com or the shop where you
purchased your Philips VisaPure Advanced. If
you have any difficulties obtaining information
on replacement brush heads, please contact the
Philips Consumer Care Center in your country.
You find its contact details in the worldwide
guarantee leaflet. You can also visit
www.philips.com/support.
The brush head
feels too harsh on
my skin.
If you experience the brush head as too harsh,
we advise you to start using one of the brush
heads specially developed for sensitive or extra
sensitive skin. The Sensitive and Extra Sensitive
brush heads have softer bristles. We
recommend the Sensitive brush head for
sensitive skin and the Extra Sensitive brush head
for extra sensitive and dry skin. For the best
treatment for your sensitive skin, we advise you
to use the Intelligent Sensitive brush head.
Thanks to the NFC tag in the brush head, the
brush is programmed with lower levels of
rotation, vibration and duration that are tailored
to your delicate skin. Enjoy the benefits of a
customized brush head that is adapted to your
needs, with the intensity levels that are right for
your skin.
19
English

I don’t know with
which cleansing
products I can
use the brush
head.
We advise you to cleanse your skin with your
favorite cleanser. You can use cleansing gel,
foam, oil, milk or lotions. Please do not use
scrub cream or gel with particles.
Is the smart brush
head compatible
with all VisaPure
models?
The Intelligent brush is compatible with all
VisaPure models. However, we recommend to
use it with VisaPure Advanced, as thanks to the
Intelligent head recognition function in VisaPure
Advanced, the Intelligent brush will start a
customized cleansing program adjusted to your
skin needs. The Intelligent brush head can also
be used on VisaPure Essential, but the program
is similar to the program for standard brushes
and takes the regular 1 minute.
There are no extra benefits if the Intelligent
brush head will be used on VisaPure Essential.
What is the
difference
between a Smart
brush and a
standard brush?
The intelligent brush head has a NFC tag
incorporated in it, which makes it possible to
have customized programs for specific skin type
for you to achieve the best results for your skin
type. Thanks to the Intelligent head recognition
function in VisaPure Advanced, the Intelligent
brush head gets recognized by the appliance
and specific program with dedicated rotation,
vibration and program duration settings will
start. The standard brush head does not have a
NFC tag incorporated, and will always run on
the standard 1 minute program.
The Intelligent brush head is compatible with all
VisaPure models, but for optimal use we
recommend you to use it with VisaPure
Advanced to achieve the most benefits. The
standard brush head is compatible with both
VPA and VPE.
20 English
