Philips PD7015 User manual

www.philips.com/welcome
PD7015
User manual
Always there to help you
Register your product and get support at
Question?
Contact
Philips
Question?
Contact
Philips

1EN
Contents
1 Important 3
Safety and notice 3
Safety 3
Compliance 5
Care of the environment 5
Copyright 7
Warranty 7
2 Your portable DVD player 8
Introduction 8
What's in the box 8
Overview 9
3 Get started 14
Charge power 14
Install remote control battery 15
Switch on/off 16
Volume reminder 17
Select on-screen display (OSD) language 17
4 Play discs 19
Play options 19
Parental control 22
Screen saver 23

2EN
Connect additional equipment 24
DVD Settings 24
5 Watch digital TV and listen to the radio 26
Connect TV antenna 26
First-time setup 27
Turn in to TV/ radio stations 28
Setup 32
6 Play from USB 36
Play options 37
7 Product information 38
8 Troubleshooting 40

3EN
1 Important
Safety and notice
Read and understand all instructions before you use this product. If damage is
caused by failure to follow the instructions, the warranty does not apply.
Safety

Use only power supplies listed in the user manual.
The product shall not be exposed to dripping or splashing.

lighted candles).
Batteries (battery pack or batteries installed) shall not be exposed to excessive

Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
Where the plug of the Direct Plug-in Adapter is used as the disconnect device, the
disconnect device shall remain readily operable.
Risk of swallowing batteries!
 The product or remote control may contain a button cell battery, which is
possible to be swallowed. Keep the battery out of reach of children at all

internal burns can occur within two hours of ingestion.
 If you suspect that a battery has been swallowed or placed inside any part of
the body, seek immediate medical attention.
 When you change the batteries, always keep all new and used batteries out
of reach of children. Ensure that the battery compartment is completely
secure after you replace the battery.

4EN
 If the battery compartment cannot be completely secured, discontinue use
of the product. Keep out of reach of children and contact the manufacturer.

other unsafe operation.
Warning
 Never remove the casing of this product.
 Never lubricate any part of this product.
 Never place this product on other electrical equipment.
 
 Never look into the laser beam inside this product.
 Ensure that you always have easy access to the power cord, plug or adaptor to disconnect the
product from the power.
 Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
Hearing safety
A pleine puissance, l’écoute prolongée du baladeur peut endommager l’oreille
de l’utilisateur.
Warning
 To prevent possible hearing damage, do not listen at high volume levels for long periods.

5EN
The maximum output voltage of the player is not greater than 150 mV.
Compliance
This product complies with the radio interference requirements of the European
Community.
This apparatus includes this label:
Note
 The type plate is located on the bottom of the product.
Care of the environment
Environmental information
All unnecessary packaging has been omitted.We have tried to make the packaging
easy to separate into three materials: cardboard (box), polystyrene foam (buffer)
and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused if
disassembled by a specialized company. Please observe the local regulations
regarding the disposal of packaging materials, and old equipment.

6EN
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it means that
the product is covered by the European Directive 2002/96/EC.
Please inform yourself about the local separate collection system for electrical and
electronic products.
Please act according to your local rules and do not dispose of your old products
with your normal household waste. Correct disposal of your old product helps to
prevent potential negative consequences for the environment and human health.
Your product contains batteries covered by the European Directive 2006/66/EC,
which cannot be disposed with normal household waste.Please inform yourself
about the local rules on separate collection of batteries because correct disposal
helps to prevent negative consequences for the environmental and human health.
Always bring your product to a professional to remove the built-in battery.

7EN
Copyright
This item incorporates copy protection technology that is protected by U.S.
patents and other intellectual property rights of Rovi Corporation. Reverse
engineering and disassembly are prohibited.



supplies accordingly.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
Warranty
 
damage to the product and will void your warranty.
 Use the product and accessories only as intended by the manufacturer.The
caution sign printed on the back of the product indicates risk of electric
shock.
 Never remove the cover of the product. Always contact Philips Customer
Support for service or repairs.
 
assembly procedures not recommended or authorized in this manual shall
void the warranty.

8EN
2 Your portable DVD player

the support that Philips offers, register your product at www.philips.com/welcome.
Introduction
On this portable DVD player, you can do the following:
 You can play the following discs (including CD-R, CD-RW, DVD±R and
DVD±RW):

 Receive digitalTV/ radio programs from the the Digital Video Broadcasting

 Play media that you store on the USB mass storage device.
What's in the box
Check and identify the contents of your package:
 Portable DVD player
 Remote control
 AC power adaptor, DC120150110 (Philips)
 Car adaptor
 AV cable
 Antenna
 Short user manual
 Safety and warranty sheet

9EN
Overview
Main unit
a 
 Slide to switch the player on/off.
b DC IN 12V
 Power supply socket
c PHONE
 
d AV OUT
 
e USB
 USB port
f
a
b
c
d
e
j
h
i
g
k

10 EN
f Antenna jack
g CHR/IR
 Charging indicator/Remote control sensor
h SETUP/
 DVD/USB: Press once to stop play.
 DVD: Press twice to access the setup menu.
 DVB-T: Press once to access the setup menu.
SOURCE
 Switches between DVD, DVB-T and USB.
VOL+/-
 Increases or decreases volume.
i
 Opens the disc compartment.
j (CH+), (CH-), / , /
 Navigate menus.
(CH+), (CH-)
 DVB-T: Switch to the next or previous channel.
/ , /
 DVD/USB: Search backward or forward at different speeds.
OK/
 
 DVD/USB: Starts, pauses or resumes play.
k Display panel

11EN
Remote control
a
 Switches the player on from standby or back to standby.
b 
 Switches on/off the screen.
c (CH+), (CH-), ,
 Navigate menus.
(CH+), (CH-)
 DVB-T: Switch to the next or previous channel.
,
 DVD/USB: Search backward or forward at different speeds.
OK/
 
 DVD/USB: Starts, pauses, or resumes play.
d /
 DVD/USB: Skips to the previous or next title, chapter, or track.
av
w
x
u
t
s
r
q
p
o
n
m
l
k
j
f
g
h
i
b
c
e
d

12 EN
e /
 Increases or decreases volume.
 Mutes or restores volume.
f 0-9
 Numeric keypad
g
 DVD: (For VCD, PBC on) Returns to the PBC menu.
 DVB-T:
Edit menu.
 USB: Returns to the previous folder.
h
 DVD/USB: Zooms in or out a picture/video image.
 DVB-T
i ANGLE
 DVD: Selects a different viewing angle of a DVD.
j PROG
 DVD: Programs tracks.
k REPEAT
 DVD/USB: Repeats a chapter/track/title.
l GO TO
 DVD/USB: Skips to a chapter/track/title or a play time.
m TELETEXT
 DVB-T: Switches teletext on or off.
n AUDIO
 DVD
mode.
 DVB-T: Selects an audio language of current service.
 USB: For movie, selects an audio mode.
o SUBTITLE
 DVD: Selects DVD subtitle language.
 DVB-T: Selects subtitle language of current service.
 USB: Accesses the subtitle menu.

13EN
p EPG
 DVB-T:Toggles the Electronic Program Guide (EPG) on or off. Enabled
on digital channels only.
q 
 DVD/USB
play.
 DVB-T: Displays program information, if available.
r "
 DVB-T: Displays the list of channels that are marked as favorite.
s LIST
 DVB-T: Displays the list of channels.
t RADIO (TV)
 DVB-T: Switches between radio and TV.
u EXIT/
 DVD/USB: Stops play.
 DVB-T: Goes to the previous menu.
v SOURCE
 Switches between DVD, DVB-T and USB.
w DVD MENU
 For DVD, accesses or exits disc menu.
 ForVCD, turns on or off PBC (Playback Control) mode.
x SETUP
 DVD/DVB-T: Selects or exits the setup menu.

14 EN
3 Get started
Caution
 Use the controls only as stated in this user manual.
 Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number of your
player.The model number and serial number are on the bottom of your player.
Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Charge power
Charge through the AC adaptor
Caution
 Risk of product damage. Ensure that the power supply voltage corresponds to the voltage printed
on the bottom of the player.
You can only charge the player when it is powered off or in standby mode.
1 Make sure that you have connect the player to power.
2 On the main unit, slide the  switch to the  position.

15EN
 Alternatively, press on the remote control to switch to standby mode.
» The CHR indicator turns on (red).
» When the battery is fully charged, the CHR indicator turns off.
Tip
 To maximize battery life, recharge the battery immediately once the battery is fully discharged. If
you do not use the player for a long time, fully recharge the battery once every two months.
Charge through the car adaptor
Connect the supplied car adaptor to the player and car cigarette lighter.
Install remote control battery
Caution
 
 Risk of decreased battery life! Never mix different brands or types of batteries.
 Risk of product damage! When the remote control is not used for long periods, remove the
batteries.
 Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.
To install the remote control battery:
1 Open the battery compartment.
2 Insert one CR2025 battery with correct polarity (+/-) as indicated.

16 EN
3 Close the battery compartment.
Switch on/off
1 To switch on, slide  to the ON position on the portable DVD
player.
» The CHR indicator turns on (green).
2 To switch off, slide  to the  position on the portable DVD
player.
 Alternatively, press on the remote control to switch to standby mode.
» The CHR indicator turns on (red).The battery charging starts.
» When the battery is fully charged, the CHR indicator turns off.
Auto standby
In DVB-T mode or USB mode, if there is no button press or media play for three
hours, the player switches to standby mode to save power.
1
2
3

17EN
1 In DVB-T mode, press SETUP on the remote control.
2 Select [Time] > [Auto Standby].
3 Press / to select [On].
Volume reminder
The portable DVD player can have you reminded when:
 
 you have listened at a high volume level for 20 hours.
With the feature of volume reminder, the Philips Portable DVD player complies
with the European Union regulations (EN 60950-1) in protecting your hearing
safety.
When you increase the volume,
1 Press .
» When the volume level reaches the high level, a pop-up screen is
displayed.
2 To continue to increase the volume, select OK and press OK/ to

» You can continue to increase the volume.
 CANCEL and press OK/ 
» The play resumes at the previous volume level.
When you have listened at a high volume level for 20 hours, a pop-up is
displayed.
 To keep listening at a high volume level, select OK and press OK/ to

 To exit high volume, select CANCEL and press OK/ 
» The volume level drops below the high level (85 dBA) .
Select on-screen display (OSD) language
You can select a different language for the onscreen menus.

18 EN
Select OSD in DVD mode
1 On the remote control, press SETUP.
» The setup menu is displayed.
2 Go to [Language] > [Language], then press OK/ .
3 Press / to select a language.
4 Press OK/ 
5 Press SETUP to exit.
Select OSD in DVB-T mode
1 On the remote control, press SETUP.
» The setup menu is displayed.
2 Go to [Option] > [OSD Language].
3 Press / to select a language.
4 Press SETUP to exit.
