Philips Multimedia Base 6G3B11 User manual

· Multimedia Base (6G3B11)
Powerful 36 W PMPO stereo sound output
Bass Boost for extra enhancement
Headphone connector for personal listening
Microphone connector for recording and videoconferencing
· USB Hub (PCUH411)
Connect up to 127 USB devices simultaneously
1 upstream port and 4 downstream ports
Self-powered or bus-powered operation
Fulfills USB-IF specification Rev. 1.1
Stands alone or clips on monitor base
Multimedia Base
/USB Hub
Multimedia Base
/USB Hub
Philips Monitors
Multimedia Base
USB Hub
Multimedia Base
USB Hub attached to
multimedia base
USB Hub attached to
standard base

Regulatory Approvals (Version Dependent)
• CE • CSA • FCC
• C-Tick • UL • T-mark
Environment
• Operation Temperature 0°C to 70°C
• Humidity 0%-80% RH Non-Condensing
Physical Specifications
• Weight .4 lbs./150g
• Dim.With Cover (WxHxD)(inch) 5.3" x 1.0" x 2.8"
• Dim.With Cover (WxHxD)(mm) 136 mm x 25 mm x 72 mm
• Dim.Without Cover (WxHxD)(inch) 5.3" x 1.0" x 2.1"
• Dim.Without Cover (WxHxD)(mm) 136 mm x 25 mm x 55 mm
• UPC Code 0 37849 89681 5
• Carton Dimensions (WxHxD)(inch) 10.0" x 7.2" x 2.7"
• Carton Dimensions (WxHxD)(mm) 255 mm x 183 mm x 68 mm
• Carton Weight 1.5 lbs./0.7 kg
Windows®95/98/NT is a trademark of Microsoft Corp.
All trademarks acknowledged.
INTERNET ADDRESS: http://www.philipsusa.com
FAX INFORMATION SYSTEM: [phone]
TECHNICAL SUPPORT: [phone] (USA)
[phone] (outside USA)
Specifications subject to change without notice.
Printed in the U.S.A., ©2000 Philips Consumer Electronics Co.A Division of Philips Electronics North America Corp. Literature Order Number: 6G3B11 (Multimedia Base); PCUH411 (USB Hub) KID Design 200243 - 9/00
Multimedia Base
/USB Hub
Multimedia Base
/USB Hub
Physical Specifications
• Dim. (Excl. Swivel)(WxHxD)(inch) 9.4" x 2.1" x 8.2"
• Dim. (Excl. Swivel)(WxHxD)(mm) 239 mm x 54 mm x 208 mm
• Additional Height for Monitor 1.1"/28 mm
(MultimediaBase-Normal Base)
• Weight 2.0 lbs./0.9 kg
• Additional Weight for Monitor 1.1 lbs./0.5 kg
(MultimediaBase-Normal Base)
• Power Consumption 5 Watts
• UPC Code 0 37849 89587 0 (6G3B11)
• Carton Dimensions (WxHxD)(inch) 12.8" x 9.8" x 4.5"
• Carton Dimensions (WxHxD)(mm) 239 mm x 54 mm x 208 mm
• Carton Weight 3.1 lbs./1.4 kg
Connections and Cables
• Headphone Connection 3.5 mm jack
• Microphone Input 3.5 mm jack
• Microphone Output 3.5 mm jack
• Audio Cable 1.8M, 3.5 mm jack to 3.5 mm jack
Product Number 6G3B11 (Multimedia Base)
Technical Specifications
Amplifier
• RMS Power 2x1.5W
• PMPO Power 36 Watts
• Input Signal Level 340 mV RMS
• Bass Boost
Speakers
• Unit Diameter 2"
• Impedance 4Ω
• Frequency Response 140Hz-20kHz
• Dual Passive Bass Pipes
Option
USB Hub PCUH411 Clip-On Option
Adapter
• Input 108~132 VAC, 60Hz, 0.1A (10W)
• Output: 9 VDC, 600mA
Regulatory Approvals
• UL • CSA
• CE • TCO ’99
Product Number PCUH411 (USB Hub)
Technical Specifications
Device Support
• All USB Products
• Up to 127 Devices Simultaneously
Standards
• USB-IF Specification Rev. 1.1
Bandwidth
• 1.5 Mbps for Unshielded Cable
• 12 Mbps for Shielded Cable
Ports
• 4 Downstream Ports
• 1 Upstream Port
Over-Current Protection
• On Each Downstream Port
Power Source
• Self-Powered via Power Supply
• Bus-Powered from PC
• Maximum per Port Current 500 mA
(when using power supply)
Power Consumption
• Operating Current 65 mA
Power Supply
• Input 100~240V, 1.0A max.
50~60Hz, 28~40VA
• Output +5V, 2.6A
LED Indicators
• Green/On = Link/Active Port
• Green/Off = Over-Current or Alert
Compatibility
For Multimedia Base and USB Hub compatibility with monitors, refer to
chart below. (The USB Hub can be used stand alone or attached to the
6G3B11 Multimedia Base.)
Base
Hub
105Exx 105Sxx 105Bxx 107Sxx 107Bxx 107Pxx 107Txx 109Sxx 109Bxx 109Pxx 201Bxx 201Pxx
